Zachry MS-652 User manual

2-way marine
6.5" & 6.9" system
Model: MS-652 & MS-692
User Manual
Zachry-audio.com

I STALLATIO I STRUCTIO S
1. Cut speaker mounting hole using template provided.
2. Attach the "+" speaker wire from the stereo (or amplifier) to the "+" terminal of the speaker (the
"+" sign is imprinted on the speaker terminal strip).
3. Attach the " " speaker wire from the stereo(or amplifier) to the " " terminal of the speaker.
4. Remove front grill from speaker.
5. Fit the speaker into the speaker mounting hole (cutout in point #1 above).
6. Attach the speaker to boat using the stainless steel screws provided.
7. Apply the black butyl adhesive to the inside edge of the speaker as shown, to attach the grill to
the speaker. This adhesive will stick, but will not harden so if necessary the grills may be removed
in the future.
8. Replace the speaker grills, pressing them into the butyl adhesive.

SPECIFICATIO S
Thiele Small Parameters: unit MS-652 MS-692
Nominal Impedance Znom ohms 4 4
DC Resistance DCR ohms 3.4 3.7
Resonant Frequency Fs Hz 80 55
Mechanical Q Qms 2.99 3.23
Electrical Q Qes 0.76 0.91
Total Q Qts 0.61 0.71
Xmax (linear) in 0.0512 0.0984
Xmax (mechanical) in 0.0768 0.1476
Sensitivity 1 watt / 1 meter dB 88 89
Effective Piston Area Sd m2 0.0122 0.0220
Acoustic Compliance Vas cf 0.3173 0.9355
Moving Mass Mms grams 9.12 21.10
Suspension Compliance Cms m/N 425 385
Motor Strength BL TM 4.55 5.48
Magnet and Voice Coil Parameters:
Voice Coil Diameter d in 1 1.2
Voice Coil Length hvc in 0.299 0.433
Voice Coil Layers n 2 2
Voice Coil Type Kapton Kapton
Continuous Power watts 50 60
Maximum Power watts 100 120
Weights and Dimensions:
Magnet OD in 3.15 3.94
Magnet Thickness in 0.59 0.59
Magnet Weight oz 10 14
Frame OD in 6.42 9.37 x 6.61
Mounting Hole in 5.53 8.82 x 6.06
Mounting Depth in 2.5 3.27
Speaker Weight lbs 1.96 /pc 3.15 /pc
Driver Displacement in 92.63 141.70
Crossover Specifications:
High pass / Slope Hz / dB 4K / 12 3.5K / 12
Low pass / Slope Hz / dB Pass Pass
