Zanussi ZDI 6053 QA User manual

DISHWASHER
ZDI 6053 QA
Instruction book
GB

2
Safety instructions 2
Description of the appliance 4
The control panel 4
Prior to using for the first time 5
Setting the water softener 5
Filling with salt 5
Rinse aid 6
In daily use 7
Loading cutlery and dishes 7
The lower basket 7
The cutlery basket 8
The u er basket 8
Adjusting the height of the u er basket 8
Use of detergent 9
Washing programmes 10
Starting a washing programme 11
Maintenance and cleaning 12
Cleaning the filters 12
Prolonged eriods of non-o eration 12
Frost recautions 12
Moving the machine 12
What to do, when... 13
Service and s are arts 14
Protection against flooding 14
Installation instructions 15
Fitting under a counter 15
Levelling 15
Water su ly connections 15
Water inlet hose 15
Water outlet hose connection 16
Electrical connection 16
Hints for test centres 17
Contents
Dimensions Width 59.6 cm
Height 81.8 - 87.8 cm
Max de th 57.5 cm
Max de th with o en door 111.4 cm
lectrical connection: Information on the electrical connection is given on the rating late on the
Voltage inner edge of the dishwasher’s door on the right.
Overall ower
Fuse
Water su ly ressure Minimum 50 kPa (0.5 bar)
Maximum 800 kPa (8 bar)
Ca acity 12 lace settings
Technical specifications
This appliance complies with the following . .C. Directives:
- 73/23 or 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 or 3.5.89 ( lectromagnetic Compatibility Directive) and subsequent modifications.

3
It is most important that this instruction book should be
retained with the appliance for future reference. Should
the appliance be sold or transferred to another owner, or
should you move house and leave the appliance, always
ensure that the book is left with the appliance in order that
the new owner can get to know the functioning of the
appliance and the relevant safety information.
This information has been provided in the interest of your
safety. You MUST read it carefully before installing or
using the appliance.
Installation
●Check your dishwasher for any trans ort damage. Never
connect a damaged machine. If your dishwasher is
damaged, you should contact your su lier.
●For safety reasons it is dangerous to alter the s ecifications
or attem t to modify this roduct in any way.
●Any electrical and lumbing work required to install this
a liance should be carried out by a qualified and
com etent erson.
●Care must be taken to ensure that the a liance does not
stand on the electrical su ly cable.
●The sides of the dishwasher must never be drilled to
revent damage to hydraulic com onents.
Child safety
●This a liance is designed to be o erated by adults.
●Children should not be allowed to tam er with the controls
or lay with the roduct.
●Packaging arts may be dangerous for children, who could
even be suffocated! You should therefore kee all
ackaging well away from children.
●The water in your dishwasher is not for drinking. Detergent
residues may still be resent in your machine. Kee
children well away from your dishwasher when the door is
o en.
●Kee all detergents in a safe lace out of children's reach.
Your dishwasher in day-to-day use
●Items that are contaminated by etrol, aint, steel or iron
debris, corrosive, acidic or alkaline chemicals must not be
washed in this dishwasher.
●Under no circumstances should you o en the door whilst
the a liance is in o eration, es ecially during the washing
hase, hot water may esca e. However, if the door is
o ened, a safety device ensures that the machine sto s.
●Only use roducts (detergent, salt and rinse aid) s ecifically
designed for use in dishwashers.
●Long bladed knives stored in an u right osition are a
otential hazard.
●Long and/or shar items of cutlery such as carving knives
must be ositioned horizontally in the u er basket.
●When finishing loading or unloading close the door, as an
o en door can be a hazard.
●Do not sit or stand on the o en door.
●Isolate the a liance from the ower su ly and turn off the
water su ly after use.
●This roduct should be serviced by an authorised service
engineer, and only genuine s are arts should be used.
●Under no circumstances should you attem t to re air the
machine yourself. Re airs carried out by inex erienced
ersons may cause injury or serious malfunctioning.
Contact your local consumer services de artment. Always
insist on genuine s are arts.
Disposal
Dis ose of the dishwasher ackaging material correctly.
All ackaging materials can be recycled.
Plastic arts are marked with standard international
abbreviations:
>PE< for olyethylene, e.g. sheet wra ing material.
>PS< for olystyrene, e.g. adding material (always CFC-
free).
>POM< for olyoxymethylene, e.g. lastic cli s.
Cardboard ackaging is manufactured from recycled a er
and should be de osited in the waste a er collection for
recycling.
As and when you cease to use your dishwasher and withdraw
it from service, your should render it unserviceable before
having it dis osed of.
Warning! Children at lay could lock themselves in your
dishwasher or otherwise endanger their lives. Therefore cut off
the ower su ly cable and make the door closing device
unusable to revent children from being tra ed inside.
For the dis osing of the a liance lease take it to a recycling
centre or to your dealer who will, for a small contribution to the
costs, dis ose it for you.
conomical and
ecological dishwashing
●Ensure that the water softener is correctly adjusted.
●Do not re-wash under running water.
●Select the wash rogramme to suit the nature and degree of
the soiling on the dishes.
●Do not use more detergent, s ecial salt and rinse aid than is
recommended in these o erating instructions and by the
manufacturer of the res ective roduct.
Safety instructions

The control panel
4
1. Water hardness adjustment
2. Levelling s acers
3. U er basket sto
4. Salt container
5. Lower s ray arm
6. Detergent dis enser
7. Control anel
8. Rating late
9. Rinse aid dis enser
10. Large filter
11. Central filter
12. U er s ray arm
13. U er basket
Description of the appliance
2
3
4
5
6
8
9
10
11
12
IN85
13
1
7
1. On/Off indicator light
2. On/Off push button
3. Main wash temperature push
buttons
4. "Salt refill" indicator light
5. Programme marker
6. Programme selector dial
7. Programme guide

5
Before using your dishwasher for the first time:
1. Ensure that the electrical and water connections com ly
with the installation instructions.
2. Remove all ackaging from inside the a liance.
3. Set the water softener.
4. Pour 1 litre of water inside the salt container and then fill
with salt.
5. Fill the rinse aid dis enser.
6. Run a "Rinse and Hold" rogramme.
Setting the water softener
The dishwasher is equi ed with a water softener designed to
remove minerals and salts from the water su ly, which would
have a detrimental or adverse effect on the o eration of the
a liance.
The higher the content of these salts, the harder your water is.
Water hardness is measured in equivalent scales, German
degrees, French degrees and PPM ( arts er Million).
The softener should be adjusted according to the hardness of
the water in your area. Your local Water Authority can advise
you on the hardness of the water in your area.
The dishwasher is factory set at level 2.
If the current level is not suitable for your area the softener
should be adjusted.
If your water is below level 1 it is already soft and therefore
there is no need to use salt.
In this case set the water softener at level 1 without using salt.
If the water softener has been adjusted on level 1 without the
use of salt, the "salt refill" indicator light on the control anel
will always remain illuminated when the machine is switched
on.
To adjust the water softener
With a screwdriver turn the selector on the u er front corner
of the machine until the level required corres onds with the
marker.
Filling with salt
Special salt can be added in one of two ways:
●If you are using dishwasher detergent that already contains
salt, the detergent including the salt is laced in the
detergent com artment.
- In this case the water softener must be set to 1, to
ensure that the s ecial salt is taken from the detergent
container only.
●If you are using dishwasher detergent and salt se arately,
the s ecial salt is to be ut into the salt container.
- In this case the water softener must be set between 1
and 5 (de ending on the water hardness in your area) to
ensure that the s ecial salt is taken from the detergent
container only.
Only use salt specifically designed for use in
dishwashers.
All other types of salt not specifically designed for use in
a dishwasher, especially table salt, will damage the water
softener.
Only fill with salt just before starting one of the washing
programmes (not the Rinse and Hold programme).
This will prevent any grains of salt or salty water, which
may have been spilt, remaining on the bottom of the
machine for any period of time, which may cause
corrosion.
To fill:
1. O en the door, remove the lower basket and unscrew the
ca of the salt container.
2. Pour 1 litre of water inside the container (this is necessary
only before filling with salt for the first time).
3. Using the funnel rovided,
our in the salt until the
container is full.
4. Re lace the ca making
sure that there is no trace
of salt on the screw thread
or on the gasket.
5. Screw on the ca tightly.
The salt container will require to ing u eriodically.
You are reminded of this by the "salt refill" indicator light on the
control anel which will illuminate when the salt has finished.
The "salt refill" indicator light on the control panel can
remain illuminated for 2-6 hours after the salt has been
replenished, assuming the dishwasher remains switched
on. If you are using salts that take longer to dissolve then
this can take longer. The function of the machine is not
affected.
Do not worry if water over flows from the unit when filling with
salt, this is quite normal.
Prior to using for the first time
Setting
level Use of
salt
French
degrees
(°TH)
PPM
( arts er
million)
German
degrees
(°dH)
-
1
2
3
4
5
0 - 4
5 - 11
12 - 22
23 - 34
35 - 45
46 - 50
NO
YES
YES
YES
YES
YES
0 - 8
9 - 20
21 - 40
41 - 60
61 - 80
81 - 90
0 - 80
81 - 200
201 - 400
401 - 600
601 - 800
801 - 900
Water hardness
2
AA05
1
3
5
4
2
SALE
SALT
SALZ
SEL
SR14

6
Rinse aid
Rinse aid is automatically added during the last rinse, ensuring
thorough rinsing, and s ot and streak free drying. The
dis enser, which is ositioned inside the door, holds about 110
ml of rinse aid, which is sufficient for 16 - 40 dishwashing
rogrammes, de ending u on the dosage setting.
Rinse aid can be added in one of two ways:
●If you are using dishwasher detergent that already contains
rinse aid, the detergent including the rinse aid is laced in
the detergent com artment.
- In this case the rinse aid com artment must be em ty.
If in the rinse aid dis enser there is still rinse aid you
must wait until it has finished before using detergent that
contains rinse aid.
●If you are using dishwasher detergent and rinse aid
se arately, the rinse aid is to be ut into the rinse aid
dis enser.
- In this case the rinse aid dosage must be set in osition
from 1 to 6 (see "Adjusting the dose") and the rinse aid
indicator light activated.
Filling with rinse aid
1. O en the container by turning the lid (A) anticlockwise.
2. Add the rinse aid until the container is com letely full. The
indicator (B) will be com letely dark.
3. To u with rinse aid when the indicator (B) becomes clear.
nsure that the lid is closed after every refill.
Clean u any rinse aid s ilt during filling with an absorbent
cloth to avoid excess foaming during the next wash.
Use only branded rinse aid for dishwashers. Never fill the rinse
aid dis enser with any other substances (e.g. dishwasher
cleaning agent, liquid detergent). This would damage the
a liance.
Adjusting the dose
According to the finish and drying results obtained, adjust the
dose of rinse aid by means of the 6 osition selector (C)
( osition 1 minimum dosage, osition 6 maximum dosage).
Increase the dose if there are dro s of water or lime s ots on
the dishes after washing.
Reduce it if there are sticky
whitish streaks on the dishes.
BR01 BR03
BR02

7
●Check if it’s necessary to refill with s ecial salt or rinse aid
●Load cutlery and dishes into the dishwasher.
●Fill with dishwasher detergent .
●Select a wash rogramme suitable for the cutlery and
dishes.
●Start the wash rogramme.
Loading cutlery and dishes
Sponges, household cloths and any object that can
absorb water may not be washed in the dishwasher.
●Before loading the dishes, you should:
- Remove large left-overs.
- Soften remnants of burnt food in ans
●When loading the dishes and cutlery, lease note:
- Dishes and cutlery must not im ede the rotation of the
s ray arms .
- Load hollow items such as cu s, glasses, ans, etc. with
the o ening downwards so that water cannot collect in the
container or a dee base.
- Dishes and items of cutlery must not lie inside one
another, or cover each other.
- To avoid damage to glasses, they must not touch.
- Lay small objects in the cutlery basket.
In daily use
For washing in the dishwasher the following cutlery/dishes
are of limited suitability:
- Only wash stoneware in the dishwasher if it is s ecifically
marked as being dishwasher-safe by the manufacturer.
- Glazed atterns may fade if machine washed frequently
- Silver and aluminium arts have a tendency to discolour
during washing. Left-overs, e.g. egg white, egg yolk and
mustard often cause discolouring and staining on silver.
Therefore always clean left-overs from silver immediately, if
it is not to be washed straight after use.
- Some ty es of glass can become dull after a large number
of washes
are not suitable:
Cutlery with wooden, horn, china or
mother-of- earl handles
- Plastic items that are not heat resistant
- Older cutlery with glued arts that is not
tem erature resistant
- Bonded cutlery items or dishes
- Pewter or co er items
- Lead crystal glass
- Steel items subject to rusting
- Wooden latters
- Items made from synthetic fibres
O en the door and slide out the baskets to load the dishes.
The lower basket
The lower basket is designed to take sauce ans, lids, lates,
salad bowls, cutlery etc.
Serving dishes and large lids
should be arranged around
the edge of the basket,
ensuring that the u er s ray
arm can turn freely.
The rows of rongs on the lower basket can be easily lowered
to allow you to load ots, ans and bowls.
To lower the prongs:
- Slightly ull them u ward
and let them dro down
(see icture).
- To bring them back to the
standing osition, just ull
them u again.
UI48
UI21
UI85
UI18

8
The cutlery basket
Long bladed knives stored in an upright position are a
potential hazard.
Long and/or sharp items of cutlery such as carving knives
must be positioned horizontally in the upper basket.
Take care when loading or unloading sharp items such as
knives.
Cutlery should be laced in the removable cutlery basket with
the handles facing downwards. If the handles rotrude from
the bottom of the basket, obstructing the lower s ray arm, load
the cutlery with the handles facing u wards.
Mix s oons with other cutlery to revent them from sticking
together.
For best results we
recommend you to use the
cutlery grids rovided (if the
size and dimensions of the
cutlery allow it).
The cutlery basket is in two
arts which can be
se arated to give greater
loading flexibility. To se arate
the two arts, slide them
horizontally in o osite
directions and ull them
a art. To reassemble,
reverse the rocedure.
The upper basket
The u er basket is designed for lates (dessert lates,
saucers, dinner lates of u to 25 cm in diameter), salad
bowls, cu s and glasses.
Arrange items on and
underneath the cu racks so
that water can reach all
surfaces.
Glasses with long stems can
be laced u side down in the
cu racks.
Light items ( lastic bowls
etc.) must be loaded in the
u er basket and arranged
so they do not move.
In case that plates are loaded in the upper
basket:
load them starting from the
rear positions of the
basket; tilting them slightly
forwards and avoiding the
front positions near the
door.
Before closing the door, ensure that the spray arms can
rotate freely.
Adjusting the height of the upper basket
If washing very large lates you can load them in the lower
basket after moving the u er basket to the higher osition.
To move to the higher position proceed as
follows:
1. Move the front runner sto s (A) of the u er basket
outwards and slide the basket out.
2. Refit the basket in the higher osition and re lace the sto s
(A) in their original osition.
After loading your machine always close the door, as an
open door can be a hazard.
US46
US71
RC01
With u er basket raised 20 cm 31 cm
With u er basket lowered 25 cm 27 cm
Maximum height of the dishes in
upper basket lower basket
UI62
UI63

9
Use of detergent
Only use detergents specifically designed for use in
dishwashers.
Using no more then the correct amount of detergent
contributes to reducing pollution.
Fill with detergent
Prior to the start of a wash rogramme. The detergent is
released during the washing hase.
Please observe the manufacturer’s dosing and storage
recommendations as stated on the detergent ackaging.
1. O en the dis enser by ulling the catch (D).
2. Fill the detergent dis enser with detergent.
The marking indicates the dosing levels:
Min = a roximately 15 g of detergent
Max = a roximately 30 g of detergent
3. Close the lid and ress until it locks in lace.
For all rogrammes with rewash, an additional detergent
dose (5 g) must be laced over the lid of the dis enser.
This detergent will take effect during the rewash hase
Use of "3 in 1" combi detergent tablets
General advice
These roducts are tablets with combined detergent/rinse-aid
and salt functions.
1. Before using these roducts you should first check that the
water hardness in your su ly is com atible with the use of
these roducts as er the detergent manufacturers (on the
roduct ackaging).
2. These roducts should be strictly used according to the
detergent manufacturers instructions.
Do not place the tablets in the tub or in the cutlery
basket as this will result in poorer wash results. The
tablets should be placed in the detergent dispenser.
3. If you encounter roblems when using 3 in 1 roducts for
the first time then lease contact the detergent
manufacturers care line (the tele hone number is given on
the roduct ackaging).
Special advice
If you decide to turn back to the use of the standard detergent
system we advise that you:
●Refill both the salt container and rinse aid dis enser.
●Switch the water hardness setting to the highest ossible
osition and run a normal washing rogramme without a
load.
●Readjust the water hardness setting again according to the
hardness of the water in your area.
Concentrated detergent
Based on their chemical com osition, dishwasher detergents
can be s lit into two basic ty es:
- conventional, alkaline detergents with caustic com onents.
- low alkaline concentrated detergents with natural enzymes.
The use of 50°C washing rogrammes in conjunction with
concentrated detergents reduces ollution and is good for your
dishes; these wash rogrammes are s ecially matched to the
dirt-dissolving ro erties of the enzymes in the concentrated
detergent. For this reason 50°C wash rogrammes in which
concentrated detergents are used can achieve the same
results that can otherwise only be achieved using 65°C
rogrammes.
Detergent tablets
Detergent tablets of different brands dissolve at different
s eeds. For this reason some detergent tablets cannot
develo their full cleaning ower during short rogrammes.
Therefore lease use normal rogrammes with rewash when
using detergent tablets.
DE17 DE02

10
Washing programmes
(1) Testing rogramme for EN 50242 (see "Hints for Test Centres). This rogramme, develo ed for the use of detergents with enzymes, allows to
achieve, with reduced consumption of energy the same cleaning results that would otherwise be obtained only with the 65°C rogrammes
and conventional detergents.
(2) This is a s ecial rogramme for quick washing a full load of lightly soiled dishes, glasses and crockery (exce t ots) so that you may re-use
them rom tly.
(3) The consum tion values are intended as a guide and de ends on the ressure and the tem erature of the water and also by the variations of
the ower su ly.
Programme Type of load and
degree of soil
Any.
Partial load (to be
com leted later in the
day).
Heavy soil.
Crockery, cutlery, ots
and ans
Normal soil.
Crockery and cutlery
Normal soil.
Crockery and cutlery
Light soil.
Crockery and cutlery
Cycle
description (3) Consumption values
Rinse and Hold
Intensive
70°C
Normal 65°C
(1) Bio 50°C
(2) Quick wash
50°C
1 cold rinse (to avoid
food scra s from
sticking together).
Hot rewash
Main wash u to 70°C
2 cold rinses
1 hot rinse
Drying
Warm rewash
Main wash u to 65°C
2 cold rinses
1 hot rinse
Drying
Cold rewash
Main wash u to 50°C
1 cold rinse
1 hot rinse
Drying
Main wash u to 55°C
1 cold rinse
1 hot rinse
Programme
duration
(in minutes)
nergy
consumption
(in kWh)
Water
consumption
(in litres)
105 - 115 1,9 25
91 - 101 1,4 20
91 - 101 1,24 19
31 - 41 1,2 17
60,1 10
Required
main wash
temperature
push button
Starting
position of the
programme
selector
A
A
50°
50°
A
B
C

11
1. Check that the baskets have been
loaded correctly and that the spray
arms can rotate freely
2. Turn on the water tap
3. Close the dishwasher door
4. Setting and starting the programme
Turn the rogramme selector dial clockwise until the
rogramme marker on the knob corres onds with the
rogramme you wish to select (see "Washing
rogrammes" chart).
Select the main wash tem erature if the selected
rogramme requires it.
De ress the On/Off ush button, the On/Off indicator
light will come on and the machine will start.
5. Interrupting a washing programme
Interrupt a washing programme in progress ONLY if
it’s absolutely necessary
Attention! Hot steam may esca e when the door is
o ened. There is risk of scalding. O en the door
carefully.
●O en the dishwasher door; the rogramme will sto .
Close the door; the rogramme will start from the
oint in which it was interru ted.
●Pressing the On/Off ush button (in this case the
On/Off indicator light turns off). Press the On/Off ush
button again; the rogramme will start from the oint
in which it was interru ted.
6. nd of the washing programme
The dishwasher will automatically sto at the end of the
rogramme.
The On/Off indicator light remains illuminated until the
On/Off ush button is de ressed.
Switch off the dishwasher by ressing the On/Off ush
button.
Hot steam may esca e from the a liance when o ening
the door immediately after the end of the rogramme,
therefore, open the door carefully.
Unloading the dishwasher
Hot dishes are sensitive to knocks. The dishes should
therefore be allowed to cool down before removing from
the a liance.
Leave the dishes in the dishwasher for a rox. 15
minutes, with the door ajar, after the end of rogramme
so that they dry better and will be cooler.
Em ty the lower basket first and then the u er one; this
will avoid water dri ing from the u er basket onto the
dishes in the lower one.
When the washing programme has finished, it is
recommended that the dishwasher is unplugged and the
water tap turned off.
Starting a washing programme

12
Clean the external surfaces of the machine and control anel
with a dam soft cloth. If necessary use only neutral
detergents.
Never use abrasive roducts, scouring ads or solvent
(acetone, trichloroethylene etc....).
Ensure that the seals around the door, the detergent and rinse
aid dis ensers are cleaned regularly with a dam cloth.
We recommend every 3 months to run a 65°C wash
rogramme without dishes using detergent.
Cleaning the central filter
(After each wash)
Scra s of food may accumulate in the drain filter (A) and
should be removed by rinsing the filter under running water.
To remove the drain filter
- sim ly ull it out by the handle
Once cleaned, refit the filter by ushing it back to its original
osition until it engages.
Cleaning the large filter
(Every week)
If necessary clean the large filter (B) on both sides under
running water, using a brush.
To remove the large filter
1. Remove the s ray arm by ulling it u wards.
2. Turn the column (C) anticlockwise by 90° and then slide out
the filter.
3. Once cleaned refit it following the above instructions in
reverse order.
4. Ensure that the filter is in its original osition, the handle of
the drain filter should be ointing towards the front of the
a liance.
The dishwasher must not be used without filters. Incorrect
repositioning and fitting of the filters will produce poor
washing results. Cleaning the filters is vital to ensure
correct operation of the machine.
To ensure a correct
working of the dishwasher,
N V R try to remove the
upper spray arm.
If residues of soil have
clogged the holes in the
u er s ray arm, remove
them with a tooth ick.
Prolonged periods of non-operation
If you are not using the machine for any eriod of time you are
advised to:
1. Un lug the a liance and then turn off the water.
2. Fill the rinse aid dis enser.
3. Leave the door ajar to revent the formation of any
un leasant smells.
4. Leave the inside of the machine clean.
Frost precautions
Avoid lacing the machine in a location where the tem erature
is below 0°C. If this is unavoidable, em ty the machine, close
the a liance door, disconnect the water inlet i e and em ty
it.
Moving the machine
If you have to move the machine (moving house etc....):
1. Un lug it.
2. Turn the water ta off.
3. Remove the water inlet and discharge hoses.
4. Pull the machine out together with the hoses.
Avoid over tilting the machine during trans ortation.
Maintenance and cleaning
A
MA04
MA19
C
90°
B
MA05
MA20
MA21
MA18
MA33

13
What to do, when...
Certain roblems are due to the lack of sim le maintenance or oversights, which can be solved with the hel of the instructions
given here, without calling out an engineer.
Once the checks have been carried out, close the door and ress the On/Off ush button, the rogramme will continue from the
oint in which it was interru ted. If the dishwasher does not start or continue the rogramme contact the consumer services
de artment.
The machine does not fill with
water.
The dishwasher will not drain.
Fault Possible cause Solutions
The water ta is blocked or furred with
limescale.
The water ta is turned off.
The filter (where resent) in the threaded hose
fitting at the water inlet valve is blocked.
The water inlet hose has not been correctly laid
or it is bent or squashed.
Clean the water ta .
Turn the water ta on.
Clean the filter in the threaded hose
fitting.
Check the water inlet hose connection.
The si hon is blocked. Clean out the si hon.
The water drain hose has not been correctly laid
or it is bent or squashed. Check the water drain hose connection.
Protection against flooding is active. Close the water ta and contact the
consumer services de artment.
...there are problems when operating the dishwasher
The dishwasher will not start or sto s during o eration, o en the door and ress the On/Off ush button to switch the dishwasher off
and carry out the following suggested corrective actions.
The rogramme does not start
There is a whistling noise during
washing
The dishwasher door has not been ro erly
closed.
The main lug is not lugged in.
The fuse has blown in the household fuse box.
Close the door.
Insert the mains lug.
Re lace the fuse.
Use a different brand of detergent.The whistling is not a cause for concern.

14
If after all these checks, the roblem ersists, contact your
local consumer services de artment, quoting the model
(Mod.), roduct number (PNC) and serial number (S.N.).
This information can be found on the rating late located on
the right hand side of the dishwasher door (see icture).
So that you always have these numbers at hand, we
recommend you to make a
note of them here:
Mod. : . . . . . . . . . . . . . . . . . .
PNC : . . . . . . . . . . . . . . . . . .
S.N. :. . . . . . . . . . . . . . . . . . .
Service and spare parts
This roduct should be serviced by an authorised service
engineer, and only genuine s are arts should be used.
Under no circumstances should you attem t to re air the
machine yourself.
Re airs carried out by inex erienced ersons may cause injury
or serious malfunctioning. Contact your local consumer
services de artment.
Always insist on genuine s are arts.
Protection against flooding
The machine is fitted with a device in the bottom of the
machine to rotect against flooding.
This device will o erate if there are any water leaks in the
machine, however it will only o erate if the machine is on.
In case of intervention, turn off the water ta and call the
consumer services de artment.
RA08
...the wash results are not satisfactory
The dishes are not clean
●The wrong washing rogramme has been selected.
●The dishes were arranged in such a way as to sto water reaching all arts of the surface. The baskets must not be overloaded.
●The s ray arms do not rotate freely due to wrong arrangement of the load.
●The filters in the base of the washing com artment are dirty or incorrectly ositioned.
●Too little or no detergent has been used.
●Where there are limescales de osits on the dishes; the salt container is em ty or the wrong level of the water softener has been
selected.
●The drain hose connection is not correct.
●The salt container ca is not ro erly closed.
The dishes are wet and dull
●Rinse aid was not used.
●The rinse aid dis enser is em ty.
There are streaks, milky spots or a bluish coating on glasses and dishes
●Decrease rinse aid dosing.
Water drops have dried onto glasses and dishes
●Increase rinse aid dosing.
●The detergent may be the cause. Contact the detergent manufacturer’s consumer care line.

15
Any electrical and/or plumbing work required to install
this appliance should be carried out by a qualified
electrician and/or plumber or competent person.
Remove all ackaging before ositioning the machine.
If ossible, osition the machine next to a water ta and a
drain.
Building-in
This dishwasher is designed to be fitted under a kitchen
counter or worksurface.
Attention!
Carefully follow the instructions on the enclosed tem late for
building in the dishwasher and fitting the furniture anel.
No further o enings for the venting of the dishwasher are
required, but only to let the water fill and drain hose and ower
su ly cable ass through.
The dishwasher incor orates adjustable feet to allow the
adjustment of the height.
During all o erations that involve accessibility to internal
com onents the dishwasher has to be un lugged.
When inserting the machine, ensure that the water inlet hose,
the drain hose and the su ly cable are not kinked or
squashed.
Levelling
Good levelling is essential for correct closure and sealing of
the door.
When the a liance is correctly levelled, the door will not catch
on either side of the cabinet.
If the door does not close correctly, loosen or tighten the
adjustable feet until the machine is erfectly level.
Fixing to the adjacent units
The dishwasher must be secured against tilting.
Therefore make sure that the counter it is fixed under, is
suitably secured to a fixed structure (adjacent kitchen units
cabinets, wall).
Water supply connections
This dishwasher may be fed with either hot (max. 50°) or cold
water. Nevertheless we advise you a cold water su ly.
A hot water su ly is not always efficient with very soiled
crockery as it shortens the washing rogrammes a lot.
For making the connection itself, the cou ling nut fitted to the
machine’s su ly hose is designed to screw onto either a 3/4"
inch gas thread s out or to a ur ose made quick-cou ling ta
such as the Press-block.
The water ressure must be within the limits given in the
technical s ecifications. Your local Water Authority will advise
you on the average mains ressure in your area.
The water inlet hose must not be kinked, crushed, or entangled
when it is being connected u .
The dishwasher features fill and drain hoses which can be
turned either to the left or the right to suit the installation. The
locknut must be correctly fitted to avoid water leaks.
If the machine is connected to new i es or i es which have
not been used for a long time, you should run the water for a
few minutes before connecting the inlet hose.
Do not use, for connection, old hoses which have been
used in another appliance.
Water inlet hose
The water su ly hose is fitted with a safety device, which
revents water from entering the machine should the inner
hose s lit, due to wear. It o erates even with the machine off
The roblem is signalled by a red indicator which a ears in
the window (B - ➀ ➁).
If this ha ens, close the water ta and have the hose
re laced.
The retaining ring (A- ➀ ➁) must be ro erly fitted so as to
avoid water leaks.
Note!
Only for water supply hoses with Lock-fast safety device
to prevent inadvertent loosening.
To detach the hose ress yellow lever (C - ➁) and turn the
retaining ring anticlockwise ➁.
Installation instructions
B
A
B
AC
CA13
12

16
Water outlet hose connection
The end of the drain hose can be connected in the following
ways:
1. To the sink outlet s igot, securing it if necessary with a cli .
2. To a stand i e rovided with vent-hole, minimum internal
diameter 4 cm.
The waste connection must be at a height of between 30 cm
(minimum) and 100 cm (maximum) from the bottom of the
dishwasher.
The drain hose can face either to the right or left of the
dishwasher
Ensure the hose is not bent or squashed as this could revent
or slow down the discharge of water.
The sink lug must not be in lace when the machine is
draining as this could cause the water to si hon back into the
machine.
If you use a drain hose extension it must be no longer than 2
metres and its internal diameter must be no smaller than the
diameter of the hose rovided.
Likewise the internal diameter of the cou lings used for
connections to the waste outlet must be no smaller than the
diameter of the hose rovided.
Attention!
Our a liances are su lied with a security device to rotect
against the return of dirty water back into the machine.
If the s igot of your sink has a "no return valve" incor orated
this can revent the correct draining of your dishwasher.
We advise you therefore to remove it.
lectrical connection
Information concerning the electrical connection is given on the
rating late on the edge of the dishwasher’s door on the right.
Before lugging the a liance into the wall socket, make sure
that:
1. The mains voltage and current rating at the site of
installation match the nominal voltage and current rating
given on the rating late.
2. The meter, fuses, mains ower su ly and wall socket can
all take the maximum load required. Make sure that the
socket and lug are com atible without having to use any
ty e of ada tor. If necessary, have the domestic wiring
system socket re laced.
To isolate the dishwasher from mains, remove the mains lug.
Important!
The plug must still be accessible after the appliance has
been installed.
In case that the electrical cable has to be replaced, please
contact your local consumer services department.
Safety standards require the appliance to be earthed.
The manufacture accepts no liability for failure to observe
the above safety precautions.
CS18

17
Testing in accordance with N 60704 must be carried out with a liance fully loaded and using the test rogramme (see "Washing
rogrammes" chart).
Test in accordance with N 50242 must be carried out when the salt dis enser and rinse aid container have been filled with salt and
rinse aid res ectively and using the test rogramme (see "Washing rogrammes" chart).
Hints for test centres
Load: 12 standard lace settings
Rinse aid setting: osition 5 (Ty e III)
Detergent dosage : 5 g + 25 g (Ty e B)
Arrangement lower basket
Arrangement u er basket
Arrangement cutlery basket

Subject to change without notice
152972 34/0
From the Electrolux Group. The world’s No.1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen,
cleaning and outdoor use. More than 55 million Electrolux Group products (such as
refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year
to a value of approx. 14 billion USD in more than 150 countries around the world.
0 09/02
