Zastone WT-1004 User manual

WT-1004
Walkie-Talkie
User Manual

1. LCD display
2. Charger
3. PTT key
4. Up key
5. Down key
6. Power on/off
key
7. Scan key
8. Menu Key
9. Call Tone
key
10. Microphone
11. Speaker
12. Antenna
WT-1004 Instruction Manual
1
2
4
3
86
7
9
5
12
10
11

LCD DISPLAY ICONS
MAIN FEATURES
●Frequency: 462MHz ●3 VOX level
●Power output ＜0.5W ●10 Call tones
●22 Channels ●5 level speak volume
●38 CTCSS code ●Scan
●83 DSC code ●Key lock function
●10 km optimal range ●Auto Power Off
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1. VOX
2. Dual Watch
3. RX
4. TX
5. Main Channel Number
6. Speaker Volume
7. Key Lock
8. APO (Auto Power Off)
9. Battery Level
10. DCS
11. Code for CTCSS/ DCS
12. CTCSS
13. Scan
14. Call tone

PRECAUTIONS
●Read this manual before use the radio.
●Avoid the direct exposure to solar rays and/or in front of heat.
●Do not use adaptor and/or batteries diverged from that specified on instructions
manual.
●Do not operate the radio in hazardous environments, explosion or fire may result.
●Do not operate the radio in high humidity, dusty, or explosive environment.
●Clean by using a cloth slightly dampened. Do not use alcohol, solvents or abrasives etc.
●Do not attempt to modify the radio. The radio is designed to comply with FCC and CCC.
●The LCD display is made of glass and maybe damaged if dropped or impacted.
INSTALLING BATTERIES
●Slide down the battery compartment cover
as shown in Figure 1,
●Install the batteries by following the orientation
as shown in Figure 2,
●Replace the battery compartment cover.
Fig 1 Fig 2

WARNING
●Follow the polar directions and insert 3 X AAA Ni-MH rechargeable batteries.
●Incorrect positioning can damage both the batteries and unit.
●Don’t try to recharge non-rechargeable batteries.
●Make sure the battery compartment cover is securely locked in place when you are
charging the batteries.
●Dispose of used batteries safely and in a way that will not harm the environment, never
try to burn them or put them anywhere, they could get burnt or punctured.
●Don’t leave dead batteries in your unit. They might leak if you do.
CHARGING BATTERIES
When the “Battery level icon is low, you need to charge the batteries with the enclosed
AC/DC adaptor, or replace the batteries.
WARNING
●To avoid damage to the radio use only original accessories.
●The radio will be slightly warm during charging.
●SK6S is rechargable , but SK6 is non-rechargeable.

GENERAL OPERATIONS
1. TRANSMITTING RANGE
●The talk range depends on the environmental and terrain. It will be reach (up to about
10 KM) in wide open spaces, without obstructions such as hills or buildings. Don’t try
to use two PMR units which are less than 1.5m apart. If you do, ou may have
experience interference.
2. POWER ON/OFF
●To power on the radio, press Power On/Off key for 2 seconds until a beep is
heard and the LCD display turn on.
●To power off the radio, press Power On/off key for 2 seconds until LCD display
turns off .
3. MAKING COMMUNICATIONS
The radio has 22 main frequencies and 38 CTCSS codes or 83 DCS codes effectively
giving you 2662 channels. You can communicate with any other user who is using the
same combinations, providing they are within range.
4. SPEAK TO OTHER RADIO
●Press & hold the PTT key, LCD TX icon indicating the radio is transmitting.
●Hold the radio in a vertical position with the microphone 3-5 cm from your mouth and the
speak.

●When you finish speaking, release the PTT key and a beep tone will be heard.
5. LISEN TO OTHER RADIO
●The radio will automatically sound received signal from the other radio with the same
channel and LCD show the icon .
●When you press the PTT key, you can’t listen to other radios. Make sure you do not
press the PTT key, you can’t listen to other radios. Make sure you do not press PTT
key for listening.
●Adjust volume control if necessary.
6. ADJUSTING SPEAKER VOLUME( 5 LEVELS)
●Press the Up key ▲to increase the volume.
●Press the Down key ▼to decrease the volume.
7. TALK TIME-OUT FUNCTION
●Time-out function can avoid transmitting by chance and prolong the battery life.
●The radio will stop transmitting and sound a warning tone when PTT is held over 3
minutes. You then need to release PTT and press again for further transmission.
●In VOX mode, the unit will stop transmitting and sound a warning tone after
continuous talk for 3 minutes. You can re-activate VOX after the time-out.( Please
refer to VOX function for detailed VOX operation.)

9. SELECT CHANNEL
To select the main channel
●Press the Menu key once, Main channel number displayed will flash.
●Press ▲or ▼key to select your desired main channel number.
●Press the PTT key to confirm and quit or press to continue next function setting.
●You have 10 seconds to decide before auto-reverting back to the main screen.
10. CTCSS/ DCS CODE FUNCTION
This function can help you select your group (38 CTCSS code / or 83 DCS code）of
User on the same channel. Only the users with the same CTCSS/DCS code can listen
and talk to each other. Please note that selecting a CTCSS/DCS code does not.assure
total privacy, In radio communication, any PMR 446 radio can listen to all
communications on the same channel when using the default standard setting with
CTCSS/ DCS=0 (OFF).
10.1 CTCSS CODE
●Press the Menu key twice, CTCSS code display will flash.
MENU FLOW CHART
Press Menu key once to enter main channel selection, press again for
next function selection etc.
Main screen Main Channel CTCSS DCS VOX Call tone
Auto Power Off Beep Tone Roger Beep Main screen

11. VOX (Hands-Free Function）
The unit has a built-in Voice Activated Circuit (VOX) function. You can enjoy
talking and listening without pressing PTT key. To have better performance, you
can use this function with the external earphone (optional accessories).
●Press the Menu key 4 times, LCD display VOX icon and VOX sensitivity
digit will flash.
●Press ▲or ▼key to select sensitivity level from “ OF, 1, 2, 3” for “ OFF,
low, Medium and High respectively.
●After turning on the VOX function, LCD will display VOX icon. Press PTT to
confirm and quit.
●Press ▲or ▼key to select your desired CTCSS code from 1 to 38, 0 is OFF.
●Press the PTT key to confirm and quit.
10.2 DCS Code
Each channel also has 83 digital codes to let you set up group of users for more secured
private communication.
●Press the MENU key 3 times, DCS code display will flash.
●Press ▲or ▼key to select your desired DCS code from 1 to 83, 0 is OFF.
●Press the PTT key to confirm and quit.

14. AUTO POWER OFF (APO)
●Press Menu key 6 times, LCD display APO icon.
●Press ▲or ▼key to select auto power off time from 0 to 6 hours.
●Press PTT key to confirm and quit or press Menu to return to Main screen.
●After turning on the function, LCD will display APO icon and automatically turn off at
designated time.
12. SENDING CALL TONE
You can use 1of 10 different “Call Tones” to get attention of other user on the same
channel.
●Press the music key and the tone will sound, LCD will display the transmit icon
and icon and your call tone will be sent.
13. SELECTING CALL TONE
●Press the Menu key 5 times, LCD display icon and call tone number
will flash.
●Press ▲or ▼key to select your desired call tone.
●Press the PTT key to confirm and quit or press Menu to continue next function
setting.

15. KEY TONE ON/OFF
The unit has the function to turn the beep tone on or off.
●Press Menu key 7 times, LCD display “t o”.
●Press ▲or ▼key to turn on (LCD display ON icon) or turn off (LCD display OF icon).
●Press PTT to confirm and quit or press Menu to continue next function setting.
16. ROGER BEEP
The roger beep function enables a short tone signal which is transmitted after releasing
the PTT button.

●Press Menu key 8 times, LCD display “r o”.
●Press ▲or ▼key to turn on (LCD display ON icon) or turn off (LCD display OF icon)
●Press PTT to confirm and quit or press MENU to continue next function setting.
17. SCANNING CHANNELS
●Press the key once and LCD will display and radio will start scanning.
●LCD display shows the scanning channel one by one.
●It will stop at those channels with signal for a while,and LCD will diasplay icon,
●Press ▲or ▼key to continue scanning.
●Or if you want to use this channel, press PTT to confirm and your radio will change to
this channel.
●If there is no signal, it will continue to scan. Press the PTT key and it will stay on the
current selected channel and quit the scanning function. Or press menu to quit
and enter next function setting.

SPECIFICATIONS
Operation Frequency Range : 462.5625 ~ 462. 7520 MHz
Modulation : FM
RF Output Power : ＜500mW
Channels : 22
CTCSS sub-code : 38
DCS sub-code : 83
Power Supply : AAA battery X 3
18. MONITOR
Press and hold key to break the squelch noise and open (un-squelch) the
frequency for monitor function. Release the key to stop.
19. KEY LOCK
Press and hold key for 3 seconds, LCD display icon.
All keys are locked expect PTT and key.
To unlock, press and hold key for 3 seconds again.

Channel Frequency Table
Channel Frequency（MHz) Channel Frequency（MHz)
1462.5625 12 467.6625
2462.5875 13 467.6875
3462.6125 14 467.7125
4462.6375 15 462.5500
5462.6625 16 462.5750
6462.6875 17 462.6000
7462.7125 18 462.6250
8467.5625 19 462.6500
9467.5875 20 462.6750
10 467.6125 21 462.7000
11 467.6375 22 462.7250

CAUTION
Risk of explosion if battery is replaced by an incorrect, dispose of used
batteries
according to the instructions
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.

•This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•—Reorient or relocate the receiving antenna.
•—Increase the separation between the equipment and receiver.
•—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•—Consult the dealer or an experienced radio/TV technician for help.

This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy. The exposure standard for wireless
device employs a unit of measurement known as the Specific Absorption Rate,
or SAR The SAR limit set by the FCC is 1.6W/Kg. For in-front-of the face
operation, this device has been tested and meets the FCC RF exposure
guidelines for use and be positioned a minimum of 25 mm from the face.
Disposal of Old Electrical & Electrnic Equipment
Disposal of Old Electrical & Electrnic Equipment
( Applicable in the European Union and other European
cuntries with separate collection systems) This symbol on
the product or on its shall Be handed over to the applicable
collection point for the recycling of electrical and electrinic
equipment . By ensuring this product is disposed of
correctly , you will help prevent potential negative
consequences for the enviroment and human health, which
could otherwise be caused by inappropriate waste handling of this product. The
recycling of mateials will help to conserve natural resources.

For more detailed information about recycling of this product, please contact your local city
office or your household waste disposal service.
SEM-PKSK601OT Ver. o1
