zBoost Pro Plus YXC-15K Installation guide
zBoost®Pro Plus YXC-15K Installation Overview
zBOOST INSTALLATION
The zBoost Pro Plus YXC-15K indoor coverage kit provides a complete solution for improving cellular voice and data
signal within buildings up to 15,000 square feet. The kit provides the key components and design elements to allow
professional installation over a wide variety of building conditions with proven technology from zBoost. zBoost indoor
coverage kits use a network of active amplifiers and antennas configured to provide optimum signal strength for multiple
cellular providers while protecting the integrity of the carrier network using patented technology.
OVERVIEW:
1. Connect the system according to the diagram. The required RG-6 or RG-11 coax is not provided and will vary in length
according to your particular installation.
The maximum length of RG-6 coax is indicated on the drawings. For
installations requiring longer than 100 feet of coax, an upgrade to RG-11 coax is strongly recommended.
2. Using the provided J-Pole, Mount the Signal Antennas (YX021 and YX023) on the roof such that the faces point toward
the nearest cell tower used by your network provider. After attaching 18” coax jumpers to the Signal Antennas, connect
them to the corresponding port on the YX015 combiner (i.e. YX021-CEL connects to CEL port).
Note: Signal Antennas should be mounted at least 3 feet away from any metal.
Antenna Aiming: To achieve maximum performance, take special care pointing the Signal Antennas in the direction of
the best signal for your wireless service provider. You may wish to use a YX699 RF signal meter available at
www.zBoost.com.
3. The YX044-F30 should be placed at the coax entrance to the building and grounded to a suitable connection.
4. The YX841D Network Unit should be located indoors, as close to the Signal Antennas as possible and away from the
YX842 Coverage amplifiers. WARNING: Do not use the YX841D as a Coverage Unit (Part YX842D). If the YX842D and
YX841D are mixed, your zBoost system will not work.
5. Several values of attenuators are included in the kit. The value used will depend upon signal strength and cable lengths.
Ensure that the attenuator connects from the CEL port of one YX015 to the CEL port of the other YX015. Connect the
attenuator on the PCS ports in the same way. A tool to calculate the final value needed can be found in the Commercial
Solutions Division section of our zBoost website when logged in with your dealer account.
6. Locate both YX842D amplifiers and associated ]= broadcast antennas within the desired indoor coverage area. (Note:
110 VAC is required for each YX842D amplifier). Both amplifiers and associated broadcast
antenna will cover
approximately 7500 sq ft depending on outdoor signal strength. The Network Units can be easily mounted on a wall
using the included mounting hardware. Connect the Indoor Broadcast Antenna to the 15’ RG-6 coax cable. Then
connect the cable to the Base Unit using the TNC-F adaptor. The Broadcast Antenna should be mounted on a wall
facing the direction where increased coverage is desired . Keep the Broadcast Antenna 4 - 5 feet from the floor and at
least 3 feet away from other cords, metal objects or other wireless devices. Note that signal is broadcasted in a
beamwidth of 70° horizontally and 60° vertically from the front of the Broadcast Antenna.
or call 1-800-871-1612 for assistance.
CHECK YOUR SYSTEM FOR PROPER OPERATION
YXC-15K Works with 800 MHz and 1900 MHz Devices
To verify proper operation of your zBoost system:
1. Apply power to each of the YX842D amplifiers. Once power is applied to all amplifiers, check that the LED light
on each YX842D is a solid green. If the light on any amplifier is solid or flashing red, additional attenuation or
increased separation between the external and internal antennas may be required. Contact technical support
for assistance at 1-800-871-1612.
2. Using your cell phone or a YX699 signal meter, check various areas of your desired indoor coverage area for
improved signal strength.
The following contents are included in your zBoost system:
OUTPUT
CEL PCS
OUTPUT
CEL PCS
OUT
IN
OUT
2-WAY SPLITTER
❺
⓫
(2) YX031-15W
RG-6 Coax, 15’,
F(m) to F(m)
⓬
(4) CCBL-0006
RG-6 Coax, 18”,
F(m) to F(m)
(3) YX043-TNC-F
⓭
(5) CCBL-0017
Coax, 3”, F(m) to F(m)
❿
YX021-CEL Outdoor
Signal Antenna
❽
YX023-PCS Outdoor
Signal Antenna
❾
(2) YX027-F
Base Unit Antenna
YX041-F2P
Splitter
❻
(3) YX015
Combiner (diplexer)
DC PASS
CANT-0017
OUTPUT
SIGNAL ANTENNA COMBINER
CEL PCS
❼
❺
YX014
J Pole
Antenna Mount
YX044-F30
Surge Arrestor
❸
Attenuator Kit
(16 pieces)
❹
(2) YX842D Coverage
Unit and Power Supply
❶
(1) YX841D Network
Unit and Power Supply
❷
⓮
OUT
IN
OUT
2-WAY SPLITTER
⓫
❷
❷
❻❼
⓬
❿
❼
❶
⓭
❹
❸
❾
❽
❼
⓬
⓮
❺
⓫
❿
❺❺
⓫⓫
❻
YX027-F
❷❷
❶
❸
❹
❿
⓬
❼
❼
❼
❽
❾*ALL RG-6 cable is
supplied by the customer
YX023-PCS
DC PASS
CANT
-0017
OUTPUT
SIGNAL ANTENNA COMBINER
CEL PCS
DC PASS
CANT-0017
OUTPUT
SIGNAL ANTENNA COMBINER
CEL PCS
DC PASS
CANT-0017
OUTPUT
SIGNAL ANTENNA COMBINER
CEL PCS
RG-6 (3 - 6 )
YX841D
110 VAC required for all amplifiers. Keep
this amplifier at least 4 feet away from
other system amplifiers
YX043-TNC-F Adapter
YX041-F2P-splier
RG-6 (10 - 150 )
RG-6 (10 - 150 )
RG-6 (1- 50 )
YX842D
YX031-15W
CCBL-0006
CCBL-0017
YX021-CEL
RG-6 (10 - 100 ). For longer than 100 feet, use RG-11
CCBL-0006 (18”)
YX015 Combiner
YX044-F30. Ground at building penetraon
YX015 Combiner
YX015 Combiner
CCBL-0006 (18”)⓬⓬
⓭
(Aenuaon will vary depending on outdoor
signal strength and cable lengths. See step 5
in the Overview for more informaon.)
110 VAC required
for all amplifiers
YXC-15K Rev D
OUT
IN
OUT
2-WAY SPLITTER
❿CCBL-0017
YX043-TNC-F Adapter
⓭
⓭
⓭
⓭
Indicates insufficient distance between the Signal Antennas and Base Unit Antenna. The amplifier is operating at significantly
The amplifier is disabled
For questions or assistance, contact zBoost customer service at 1-800-871-1612 or email [email protected]
CUSTOMER SERVICE
FCC Information
FCC ID: SO4YX545-PCS-CEL
Warning: Changes or modifications to this device not expressly approved by zBoost could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located
or operating in conjunction with any other antenna or transmitter. In accordance with FCC requirements of human exposure to radio frequency
fields, the radiating element (antenna) shall be installed such that a minimum separation distance of 20cm (8in) is maintained from all persons.
Industry Canada Regulations
Canada IC: 5544A-YX545PCSCEL
This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.
RF Exposure:
The manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present,
the rating would have to be reduced by 3.5 dB, especially where the output is re-radiated and can cause interference to adjacent band users.
This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device.
Please note: This unit has been approved for use in Canada under RSS 131, however, consent for the use of this device to improve cellular or
PCS coverage, must be obtained through your cellular or PCS provider, prior to placing the unit in operation. Please refer to the Industry Canada
document CPC 2-1-05, Section 6.1 available or viewable at: http://www.ic.gc.ca/epic/site/smt-gst.nsf/en/sf08942e.html
Cet appareillage numérique de la classe [B] répond à toutes les exigences de l’interférence canadienne causant des règlements d’équipement.
L’opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l’interférence nocive, et (2) ce dispositif doit accepter
n’importe quelle interférence reçue, y compris l’interférence qui peut causer l’opération peu désirée.
Le fabricant nominale de la puissance de sortie de ce matériel est simple transporteur. Pour les situations lorsque plusieurs signaux porteurs
sont présents, l’évaluation devrait être réduite de 3.5 dB, en particulier lorsque le signal de sortie est ré-émise et peut provoquer des
interférences adjacentes à la bande utilisateurs. Ce pouvoir est de la réduction par le biais de la sortie d’alimentation ou la réduction de gain
et non par un atténuateur à la sortie du dispositif.
LIMITED 1 YEAR WARRANTY | REGISTER AT WWW.ZBOOST.COM
zBoost warrants every zBoost product to be free from defects in material and workmanship under normal use for the warranty period of 1 year.
Who Is Covered?
You must have proof of purchase to receive warranty service. A sales receipt or other documentation showing the product purchased and the purchase
date is considered proof of purchase. This limited warranty extends only to the original consumer purchaser or any person receiving the product as a
gift from the original consumer purchaser and to no other purchaser or transferee. This warranty does NOT extend to commercial users.
What is Covered?
Warranty coverage begins the day you purchase the product. For one year from the original date, the zBoost Cell Phone Signal Booster will be repaired
or replaced with a new, repaired, refurbished or comparable product (whichever is deemed necessary by zBoost) if it becomes defective or inoperative.
The exchange will be made without charge to you for parts and labor. You will be responsible for the cost of shipping to the location designated by
zBoost. If zBoost cannot reasonably repair or replace the unit then zBoost may, at its sole discretion, refund the price you paid for the product. All
products, including replacement products, are covered only for the original warranty period. When the warranty on the original product expires, the
warranty on the replacement product also expires.
What is Excluded?
Your warranty does NOT cover:
• Labor charges for set up of the unit.
• Product replacement because of misuse, accident, lightning damage, unauthorized repair or other cause not within the control of zBoost.
• Incidental or consequential damages resulting from the product. Some states do not allow the exclusion of incidental or consequential
damages, so the above exclusion may not apply to you.
• Any modifications or other changes to the product, including but not limited to software or hardware modifications in any way other
than as expressly authorized by zBoost will void this limited warranty.
• Product that has been modified or adapted to enable it to operate in any country other than the country for which it was designed,
manufactured, approved and/or authorized, or repair of products damaged by these modifications.
Make sure you keep…
Please keep your sales receipt or other document showing proof of purchase. Attach it to this Setup Overview and keep both nearby. Also, keep the
original box and packing material in case you need to return your product.
Before requesting repair service…
Please review the BASE UNIT LED INDICATORS section listed in this overview - This may save you a call.
To get warranty service…
Warranty service will be provided by zBoost. If you believe you need service for your unit, contact zBoost at 1-800-871-1612 or [email protected].
A representative will go through a diagnostic checklist with you. If it is determined that the product needs to be returned for service or exchanged, you
will receive a return merchandise authorization (RMA) number. The representative will give you complete shipping details. Do not return products to
zBoost without a Return Authorization Number (RMA).
To get out of warranty service…
To obtain out of warranty service, contact zBoost at 1-800-871-1612 or [email protected] for information on the possibility of any costs for repair
or replacement of out-of-warranty products.
Reminder: Record the model and serial number found on the product below:
Model #:
Serial #:
Purchase Date:
WARRANTY INFORMATION
PCS Frequency CEL Frequency
Frequency 1850 - 1990 MHz 824 - 894 MHz
Band Supported ALL: A,D,B,E,F & C ALL: A,B, A’ & B’
Antenna Signal 13 dBi Panel; F-type female 8 dBi Panel; F-type female
Antenna- Base Unit 9 dBi Panel, TNC Male 6 dBi Panel, TNC Male
Cable Loss 3000 MHz RG-6, approx. 1 dB/10 ft 3000 MHz RG-6, approx. 0.6 dB/10 ft
Both PCS and CEL Frequencies
Network Format CDMA, GSM, TDMA, AMPS, GPRS, EDGE, EVDO, HSPA, 3G
Base Unit RF Connectors F-type female and TNC female
Wall Supply Unit 100-240 VAC 50 Hz-60Hz
Power Consumption 3W standby; 7W max signal - 2.0A Max
UL, FCC Parts 15 & 24 (PCS), FCC Parts 15 & 22 (CEL), Industry Canada
Base Unit Size and Weight 5” x 7” x 1.375” - 12 oz.
Base Unit and Power Supply Indoor Use Only, 5° to 40° C (40° to 105° F)
Coverage (open areas) 4-5 signal bars at the roof antenna; 110’ radius at 100° width; 3-4 signal bars inside; up to 15,000 sq. ft.
YXC-15K Product Specifications
System Certifications
At Initial Power Up Only
Solid GREEN Normal condition at power up.
Slowly Alternating RED and
GREEN
zBoost is working, but at reduced performance and coverage due to “non-ideal” setup.
Solution: Increase the distance between Signal Antennas and Base Unit Antenna to achieve maximum performance and
coverage.
Fast Flashing RED
reduced coverage.
Solution: Increase distance between Base Unit Antenna and Signal Antennas.
Solid RED System is receiving signal from either the mobile device or the base station transceiver that is too strong for proper operation.
Solutions: Move away from receiving antenna with your cell phone. Move antenna away from other devices.
Fast Alternating RED and
GREEN followed by no light Solution: Unplug and start over.
After Initial Power Up
Solid GREEN Normal condition.
Solid RED System is receiving signal from either the mobile device or the base station transceiver that is too strong for proper operation.
Solution: Please unplug your system. Re-orient your Signal Antenna and/or Base Unit Antenna to reduce the excessive signal
source. Plug your system back in. If still solid red, call customer support 1-800-871-1612.
Base Unit LED Conditions
Other zBoost Amplifier manuals
