Zennio Securel v3 Guide

© Zennio Avance y Tecnología S.L. Edition 2 Further information www.zennio.com Page 1/2
Securel v3
Access Controller - Encrypted Relay
ZIOSECV3 TECHNICAL DOCUMENTATION
FEATURES
•Actuator for one (1x) electric strike through a monostable relay
•Encrypted communication with the access control device during the
opening of the door, either via serial communication or through a
secure KNX object (depending on the access control device)
•Supports KNX Data Security
•Manual output operation with push button and LED status indicator
•Auxiliary power supply required
•Total data saving on power failure
•Integrated KNX BCU (TP1-256)
•Dimensions 67 x 90 x 36 mm (2 DIN units)
•DIN rail mounting (IEC 60715 TH35), with fixing clamp
•Conformity with CE, UKCA, RCM directives (marks on the right side)
1. Pairing button
2. Pairing LED
3. Auxiliary power
supply
4. Electric strike
output
5. Encrypted communication
6. Output status
LED
7. Output control button
8. Programming/Test button
9. Programming/Test LED
10. KNX connector
11. Fixing clamp
Figure 1: Securel v3
PROGRAMMING/TESTBUTTON: short button press to set programming mode. If this button is held while connecting the device to the auxiliary power
supply, it enters the safe mode. If this button is held for more than 3 seconds, the device enters the test mode.
PROGRAMMING/TEST LED: programming mode indicator (red). When the device enters the safe mode, it blinks (red) every half second. The manual
mode is indicated by the green color. During the start-up (after reset or power failure) and if the device is not in safe mode, it emits a red flash.
PAIRING BUTTON: holding this button for more than three seconds will activate the pairing mode and delete the previous one in case the device was
paired before.
PAIRING LED: the LED will flash in blue colour while the device is unpaired. Once paired, the LED remains off.
GENERAL SPECIFICATIONS
CONCEPT
DESCRIPTION
Type of device
Electric operation control device
KNX supply
Voltage (typical)
29 VDC SELV
Voltage range
21-31 VDC
Maximum
consumption
Voltage
mA
mW
29 VDC (typical)
2.8
81.2
24 VDC¹
10
240
Connection type
Typical TP1 bus connector for 0.8 mm Ø rigid cable
External power supply
24 VDC. Maximum consumption: 13 mA
Operation temperature
0 .. +55 °C
Storage temperature
-20 .. +55 °C
Operation humidity
5 .. 95%
Storage humidity
5 .. 95%
Complementary characteristics
Class B
Protection class
III
Operation type
Continuous operation
Device action type
Type 1
Electrical stress period
Long
Degree of protection
IP20, clean environment
Installation
Independentdeviceto be mounted inside electricalpanels with DIN rail (IEC
60715)
Minimum clearances
Not required
Response on external power supply failure
Data saving according to parameterization
Response on external power supply restart
Data recovery according to parameterization
Operation indicator
The programming LED indicates programming mode (red) and test mode
(green). The output LED indicates its status (green). The pairing LED will
flash in blue while the device is unpaired.
Weight
79 g
PCB CTI index
175 V
Housing material
PC FR V0 halogen free
¹ Maximum consumption in the worst-case scenario (KNX Fan-In model).
5
4
10
8
9
3
11
1
2
6
7

© Zennio Avance y Tecnología S.L. Edition 2 Further information www.zennio.com Page 2/2
SAFETYINSTRUCTIONS ANDADDITIONALNOTES
•Installation should only be performed by qualified professionals according to the laws and regulations applicable in each country.
•Do not connect the mains voltage nor any other external voltage to any point of the KNX bus; it would represent a risk for the entire
KNX system. The facility must have enough insulation between the mains (or auxiliary) voltage and the KNX bus or the wires of other
accessories, in case of being installed.
•Once the device is installed (in the panel or box), it must not be accessible from outside.
•Keep the device away from water (condensation over the device included) and do not cover it with clothes, paper or any other material
while in use.
•The WEEE logo means that this device contains electronic parts and it must be properly disposed of by following the instructions at
https://www.zennio.com/en/legal/weee-regulation.
•This device contains software subject to specific licences. For details, please refer to http://zennio.com/licenses.
EXTERNAL POWER SUPPLY SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Voltage
24 VDC
Current
13 mA
Connection method
Screw terminal block (0.4 Nm max.)
Cable cross-section
0.5-2.5 mm² (IEC) / 26-12 AWG (UL)
OUTPUTS SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Number of outputs
1
Output type / Disconnection type
Potential-free output through monostable relay / Micro-disconnection
Maximum load per output
1 electric strike
Rated current per output
DC 1.5 A @ 24 VDC (36 W)
Short-circuit protection
NO
Overload protection
NO
Over-voltage protection
NO
Connection method
Screw terminal block (0.4 Nm max.)
Cable cross-section
0.5-2.5 mm² (IEC) / 26-12 AWG (UL)
Maximum response time
10 ms
Mechanical lifetime (min. cycles)
20000000
Electrical lifetime (min. cycles)
100000 @ 3 A / 50000 @ 5 A
⚠Important notes:
•To program this device through the KNX bus, the
auxiliary power supply must remain connected
(24 VDC).
•This device is designed for standard electric strikes
(normally-open circuit, i.e., the lock remains closed in the
absence of current). When using fail-safe electric strikes
(normally-closed circuit, i.e., the lock opens in the
absence of current), a 24 VDC normally-closed relay
between the fail-safe electric strike and the device must
be installed.
•Please, use this device only to control one electric strike.
Parallel or serial connection of two or more electric
strikes is not allowed.
•The cable length between the power supply, Securel v3
and the electric strike should be 30 meters maximum.
SYSTEM CONNECTION DIAGRAM(ACCESS CONTROLLER, SECURELV3, POWER SUPPLY ANDELECTRICSTRIKE)
Attaching Securel v3 to DIN rail:
Removing Securel v3 from DIN rail:
SECURE ZONE
Access controller
24 VDC Power Supply
24 VDC Electric Strike
Securel v3
