Zenoah EXZ2610DL User manual

GB-1
EXZ2610DL (HE-EX)
(HE-EX)
EXZ2610DL
OWNER’S MANUAL
CONVERTIBLE
EDGER ATTACHMENT
115 37 52-10 (004)

GB-2
EXZ2610DL (HE-EX)
SAFETY FIRST
Instructions contained in warnings within this manual marked
with a symbol concern critical points which must be taken
into consideration to prevent possible serious bodily injury, and
for this reason you are requested to read all such instructions
carefully and follow them without fail.
WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions, which must be followed in or-
der to prevent accidents, which could lead to serious bodily in-
jury or death.
IMPORTANT
This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.
NOTE
This mark indicates hints or directions useful in the use of the
product.
EXZ2610DL-PUO
HE-EX
15
16
17
23
4
5
6
8
9
10
11
12
13
14
1
7
18 19
1. Parts location
11. Loop handle
12. Suspension point
13. Stop switch
14. Throttle cable
15. Throttle trigger
16. Throttle set button
17. Shaft tube
18. Knob bolt
19. Spark arrester
10. Stater knob
11. Fuel tank
12. Primer
13. Choke lever
14. Air cleaner cover
15. Wheel
16. Blade guard
17. Blade
18. Bracket
19. J-handle
Contents
1. Parts location .................................................. 2
2. Specifications ................................................. 3
3. Warning labels on the machine ...................... 4
4. Symbols on the machine ................................ 4
5. For safe operation ........................................... 5
6. Set up ............................................................. 8
7. Fuel and chain oil ........................................... 9
8. Operation ...................................................... 10
9. Maintenance ................................................. 13
10. Storage ......................................................... 14
11. Disposal ........................................................ 14
12. Troubleshooting guide .................................. 15

GB-3
EXZ2610DL (HE-EX)
2. Specification
Engine
Type ............................................................................ Air-cooled 2-stroke gasoline
Model ............................................................................................ Zenoah GZ25N
Displacement ........................................................................................... 25.4 cm3
Max. output .................................................. 1.2 Hp (0.9 kW) at 7500/min-1 (rpm)
Idle speed .......................................................................... 3000 ±200/min-1 (rpm)
Fuel ............................................................................ Mixture (Gasoline 50 : Oil 1)
(when using ZENOAH genuine oil)
Carburetor ........................................................................ Walbro Diaphragm type
Spark plug .......................................................................................... NGK CMR7H
Fuel tank capacity ............................................................................................... 0.65 L
HE-EX
Overall size (L  W  H) ........................................................ 1860  560  445 mm
Dry weight w/o acc. ........................................................................................... 7.5 kg
Transmission ........ Centrifugal clutch, rigid drive shaft, Bevel gears (Angle: 90 deg.)
Reduction ratio ........................................................................................ 2.538 (33.13)
Blade length .................................................................................................... 200 mm
Specifications are subject to change without notice.

GB-4
EXZ2610DL (HE-EX)
3. Warning labels on the machine
Never modify your machine.
We won’t warrant the machine, if you use the
remodeled brushcutter or if you don’t observe
the proper usage written in the manual.
If warning label peels off or becomes soiled and
impossible to read, you should contact the
dealer from which you purchased the product
to order new labels and affix them in the required
location(s).
15m (50ft)
(1) (2) (3) (4) (5) (6) (7)
(1) Read owner’s manual before operating this machine.
(2) Wear head, eye and ear protection.
(3) Wear foot protection.
(4) Wear gloves.
(5) Beware of thrown objects.
(6) Warning / Attention
(7) Keep all children, bystanders and helpers 15 meters away from the machine.
The port to refuel the “MIX GASOLINE”
Position: FUEL TANK CAP
The direction to close the choke
Position: AIR CLEANER COVER
The direction to open the choke
Position: AIR CLEANER COVER
4. Symbols on the machine
For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications,
please be careful not to make a mistake.

GB-5
EXZ2610DL (HE-EX)
1. Read this manual carefully until
you completely understand and
follow all safety and operating
instructions.
2. Keep this manual handy so that
you may refer to it later when-
ever any questions arise. Also
note, if you have any questions
which cannot be answered
herein, contact the dealer from
whom you purchased the prod-
uct.
3. Always be sure to include this
manual when selling, lending, or
otherwise transferring the own-
ership of this product.
4. Never allow children or anyone
unable to fully understand the
directions given in the manual
to use the machine.
WORKING CONDITION
1. When using the product, you
should wear proper clothing and
protective equipment.
(1) Helmet
(2) Ear protectors
(3) Protection goggles or face
protector
(4) Thick work gloves
(5) Non-slip-sole work boots
2. And you should carry with you.
(1) Attached tools
(2) Properly reserved fuel
(3) Spare blade
(4) Things to notify your working
area (rope, warning signs)
(5) Whistle (for collaboration or
emergency)
(6) Hatchet or saw (for removal of
obstacles)
3. Do not wear loose clothing, jew-
elry, short trousers, sandals, or go
barefoot. Do not wear anything
which might be caught by a mov-
ing part of the unit. Secure hair
so it is above shoulder length.
WORKING CIRCUMSTANCE
1. Never start the engine inside a
closed room or building. Exhaust
gases contain dangerous carbon
monoxide.
2. Never use the product,
a. when the ground is slippery
or when you can’t maintain a
steady posture.
5. For safe operation
b. At night, at times of heavy fog,
or at any other times when
your field of vision might be
limited and it would be diffi-
cult to gain a clear view of the
working area.
c. During rain storms, during
lightning storms, at times of
strong or gale-force winds, or
at any other times when
weather conditions might
make it unsafe to use the
product.
WORKING PLAN
1. You should never use the prod-
uct when under the influence of
alcohol, when suffering from ex-
haustion or lack of sleep, when
suffering from drowsiness as a re-
sult of having taken cold medicine
or at any other time when a pos-
sibility exists that your judgment
might be impaired or that you
might not be able to operate the
product properly and in a safe
manner.
2. When planning your work sched-
ule, allow plenty of time to rest.
Limit the amount of time over
which the product is to be used
continuously to somewhere
around 30 ~ 40 minutes per ses-
sion, and take 10 ~ 20 minutes of
rest between work sessions. Also
try to keep the total amount of
work performed in a single day
under 2 hours or less.
WARNING
1. If you don’t observe the working
time, or working manner (See
“USING THE PRODUCT”), Re-
petitive Stress Injury (RSI) could
occur.
If you feel discomfort, redness and
swelling of your fingers or any
other part of your body, see a doc-
tor before getting worse.
2. To avoid noise complaints, in gen-
eral, operate product between
8 a.m. and 5 p.m. on weekdays
and 9 a.m. to 5 p.m. on weekends.
NOTE
Check and follow the local regula-
tions as to sound level and hours of
operations for the product.

GB-6
EXZ2610DL (HE-EX)
5. For safe operation
BEFORE STARTING
THE ENGINE
1. The area within a perimeter of
15 m of the person using the
product should be considered a
hazardous area into which no one
should enter. If necessary, yellow
warning rope, warning signs
should be placed around the pe-
rimeter of the area. When work is
to be performed simultaneously
by two or more persons, care
should also be taken to constantly
look around or otherwise check
for the presence and locations of
other people working so as to
maintain a distance between
each person sufficient to ensure
safety.
2. Check the condition of working
area to avoid any accident by hit-
ting hidden obstacles such as
stumps, stones, cans, or broken
glass.
IMPORTANT
Remove any obstacle before begin-
ning work.
3. Inspect the entire unit for loose
fasteners and fuel leakage. Make
sure that the cutting attachment
is properly installed and securely
fastened.
4. Be sure the cutting attachment
guard is firmly attached in place.
5. Always use the harness. Adjust
the harness for comfort before
starting the engine. The harness
should be adjusted so the left
hand can comfortably hold the
handlebar grip approximately
waist high.
STARTING THE ENGINE
1. Keep bystanders and animals at
least 15 m away from the operat-
ing point. If you are approached,
immediately stop the engine.
2. The product is equipped with a
centrifugal clutch mechanism, so
the cutting attachment begins to
rotate as soon as the engine is
started by putting the throttle trig-
ger into the start position. When
starting the engine, place the
product onto the ground in a flat
clear area and hold it firmly in
place so as to ensure that neither
the cutting part nor the throttle
trigger come into contact with any
obstacle when the engine starts.
WARNING
Never place the throttle trigger
into the high-speed position when
starting the engine.
3. After starting the engine, check
to make sure that the cutting at-
tachment stops rotating when the
throttle is moved fully back to its
original position. If it continues to
rotate even after the throttle trig-
ger has been moved fully back,
turn off the engine and take the
unit to your authorized ZENOAH
servicing dealer for repair.
USING THE PRODUCT
IMPORTANT
Cut only materials recommended by
the manufacturer. And use only for
tasks explained in the manual.
1. Grip the handles firmly with both
hands using your whole hand.
Place your feet slightly apart
(slightly further apart than the
width of your shoulders) so that
your weight is distributed evenly
across both legs, and always be
sure to maintain a steady, even
posture while working.
2. Keep cutting attachment below
waist level.
3. Maintain the speed of the engine
at the level required to perform
cutting work, and never raise the
speed of the engine above the
level necessary.
4. If the unit starts to shake or vi-
brate, turn off the engine and
check the whole unit. Do not use
it until the trouble has been prop-
erly corrected.
5. Keep all parts of your body away
from rotating cutting attachment
and hot surfaces.
6. Never touch the muffler, spark
plug, or other metallic parts of the
engine while the engine is in op-
eration or immediately after shut-
ting down the engine. Doing so
could result in serious burns or
electrical shock.

GB-7
EXZ2610DL (HE-EX)
5. For safe operation
• IF SOMEONE COMES
1. Guard against hazardous situa-
tions at all times. Warn adults to
keep pets and children away from
the area. Be careful if you are ap-
proached. Injury may result from
flying debris.
2. If someone calls out or otherwise
interrupts you while working, al-
ways be sure to turn off the en-
gine before turning around.
MAINTENANCE
1. In order to maintain your product
in proper working order, perform
the maintenance and checking
operations described in the
manual at regular intervals.
2. Always be sure to turn off the en-
gine and disconnect the spark
plug wire before performing any
maintenance or checking proce-
dures.
WARNING
The metallic parts reach high tem-
peratures immediately after stop-
ping the engine.
3. When replacing the cutting at-
tachment or any other part, or
when replacing the oil or any lu-
bricant, always be sure to use
only ZENOAH products or
products which have been cer-
tified by ZENOAH for use with
the ZENOAH product.
4. In the event that any part must be
replaced or any maintenance or
repair work not described in this
manual must be performed,
please contact a representative
from the store nearest ZENOAH
authorized servicing dealer for
assistance.
5. Do not use any accessory or at-
tachment other than those bear-
ing the ZENOAH mark and rec-
ommended for the unit.
6. Under no circumstances should
you ever take apart the product
or alter it in any way. Doing so
might result in the product be-
coming damaged during opera-
tion or the product becoming un-
able to operate properly.
HANDLING FUEL
1. The engine of the ZENOAH prod-
uct is designed to run on a mixed
fuel, which contains highly flam-
mable gasoline. Never store cans
of fuel or refill the tank of the unit
in any place where there is a
boiler, stove, wood fire, electrical
sparks, welding sparks, or any
other source of heat or fire which
might ignite the fuel.
2. Never smoke while operating the
unit or refilling its fuel tank.
3. When refilling the tank, always
turn off the engine and allow it to
cool down. Take a careful look
around to make sure that there are
no sparks or open flames any-
where nearby before refueling.
4. Wipe spilled fuel completely us-
ing a dry rag if any fuel spillage
occurs during refueling.
5. After refueling, screw the fuel cap
back tightly onto the fuel tank and
then carry the unit to a spot 3 m
or more away from where it was
refueled before turning on the en-
gine.
TRANSPORTATION
1. When hand-carrying the product,
cover over the cutting part if nec-
essary, lift up the product and
carry it paying attention to the
blade.
2. Never transport the product over
rough roads over long distances
by vehicle without removing all
fuel from the fuel tank. If doing so,
fuel might leak from the tank dur-
ing transport.

GB-8
EXZ2610DL (HE-EX)
Insert the cable
to the end of
adjuster Full on stopper
Idling adjust screw
M3 screw
Adjuster
MOUNTING ENGINE
1. Push the shaft tube toward the clutch housing and
rotate it by hand to check that the drive shaft is en-
gaged with the gears.
2. Insert the shaft tube into the clutch housing until it
bottoms, and align the positioning holes on the clutch
housing and the shaft tube and install the screw. When
difficult to engage, twist the engine slightly.
3. Fasten the clamp securely with two screws.
IMPORTANT
Tighten the screws gradually by turns.
CONNECTING THROTTLE WIRE
1. Remove the air cleaner cover.
2. Connect the end of the throttle wire to the joint on the
top of the carburetor.
1. Connect throttle wire with carburetor. Insert the cable
to the end of adjuster fix the throttle cable by tighten-
ing M3 screw. (Tightening torque: 0.4 ~ 0.8 N.m.)
2. Make sure the ‘STOPPER-PLATE’ of carburetor moves
to contact with ‘IDLING ADJUST SCREW’ and the
‘SWING-ARM’ of carburetor moves to contact with
‘FULL ON STOPPER’ by gripping throttle lever.
CONNECTING SWITCH WIRES
•Connect the switch wires between the engine and the
main unit. Pair the wires of the same color.
6. Set up
JOINT ATTACHMENT
• Insert the attachment to the main shaft.
•Tighten the knob bolt securely.
Knob bolt
INSTALLING HANDLE
NOTE
INSTALLING BLADE
1. Place the blade between the cutter holders (A) and
(B) while locking the gear shaft by putting the bar,
one of the tools provided, through the key holes on
the holder (A) and the angle transmission. Use the
socket and the screwdriver as shown in the picture
below to tighten the blade mounting bolt.
(1) Blade mounting bolt (Left-handed)
(2) Cutter holder (B)
(3) Blade
(4) Bar
(5) Cutter holder (A)
INSTALLING WHEEL
1. Split the bracket and install the wheel assembly to
the shaft tube and clamp at a position best for your
job.
Bracket
•Install the J-shaped handle to the shaft tube and clamp
at a position best for your job.

GB-9
EXZ2610DL (HE-EX)
7. Fuel
■ FUEL
WARNING
•Gasoline is very flammable. Avoid smoking or
bringing any flame or sparks near fuel. Make sure
to stop the engine and allow it cool before refuel-
ing the unit. Select outdoor bare ground for fueling
and move at least 3 m (10 ft) away from the fueling
point before starting the engine.
•The Zenoah engines are lubricated by oil specially
formulated for air-cooled 2-cycle gasoline engine use.
If Zenoah oil is not available, use an anti-oxidant added
quality oil expressly labeled for air-cooled 2-cycle en-
gine use (JASO FC GRADE OIL or ISO EGC GRADE).
•Do not use BIA or TCW (2-stroke water-cooling type)
mixed oil.
■RECOMMENDED MIXING RATIO
GASOLINE 50 : OIL 1
(when using ZENOAH genuine oil)
•Exhaust emission are controlled by the funda-
mental engine parameters and components (eq.,
carburation, ignition timing and port timing) with-
out addition of any major hardware or the introduc-
tion of an inert material during combustion.
•These engines are certified to operate on unleaded
gasoline.
•Make sure to use gasoline with a minimum octane
number of 89RON (USA/Canada: 87AL).
•If you use a gasoline of a lower octane value than pre-
scribed, there is a danger that the engine tempera-
ture may rise and an engine problem such as piston
seizing may consequently occur.
•Unleaded gasoline is recommended to reduce the
contamination of the air for the sake of your health and
the environment.
•Poor quality gasolines or oils may damage sealing
rings, fuel lines or fuel tank of the engine.
■ HOW TO MIX FUEL
WARNING
•Pay attention to agitation.
1. Measure out the quantities of gasoline and oil to be
mixed.
2. Put some of the gasoline into a clean, approved fuel
container.
3. Pour in all of the oil and agitate well.
4. Pour in the rest of gasoline and agitate again for at
least one minute. As some oils may be difficult to
agitate depending on oil ingredients, sufficient agi-
tation is necessary for the engine to last long. Be
careful that, if the agitation is insufficient, there is an
increased danger of early piston seizing due to ab-
normally lean mixture.
5.
Put a clear indication on the outside of the container
to avoid mixing up with gasoline or other containers.
6. Indicate the contents on outside of container for easy
identification.
■ FUELING THE UNIT
1. Untwist and remove the fuel cap. Rest the cap on a
dustless place.
2. Put fuel into the fuel tank to 80% of the full capacity.
3. Fasten the fuel cap securely and wipe up any fuel
spillage around the unit.
WARNING
1. Select flat and bare ground for fueling.
2. Move at least 10 feet (3 meters) away from the fu-
eling point before starting the engine.
3. Stop the engine before refueling the unit. At that
time, be sure to sufficiently agitate the mixed gaso-
line in the container.
■ FOR YOUR ENGINE LIFE, AVOID:
1. FUEL WITH NO OIL (RAW GASOLINE) – It will cause
severe damage to the internal engine parts very quickly.
2. GASOHOL – It can cause deterioration of rubber and/
or plastic parts and disruption of engine lubrication.
3. OIL FOR 4-CYCLE ENGINE USE – It can cause spark
plug fouling, exhaust port blocking, or piston ring stick-
ing.
4. Mixed fuels which have been left unused for a pe-
riod of one month or more may clog the carburetor
and result in the engine failing to operate properly.
5. In the case of storing the product for a long period of
time, clean the fuel tank after rendering it empty. Next,
activate the engine and empty the carburetor of the
composite fuel.
6. In the case of scrapping the used mixed oil container,
scrap it only at an authorized repository site.
NOTE
As for details of quality assurance, read the description
in the section Limited Warranty carefully. Moreover, nor-
mal wear and change in product with no functional influ-
ence are not covered by the warranty. Also, be careful
that, if the usage in the instruction manual is not observed
as to the mixed gasoline, etc. described therein, it may
not be covered by the warranty.

GB-10
EXZ2610DL (HE-EX)
8. Operation
WARNING
The cutting head will start rotating upon the engine
starts.
1. Feed fuel into the fuel tank and tighten the cap se-
curely.
(1)
2. Rest the unit on a flat, firm place. Keep the cutting
head off the ground and clear of surrounding objects,
as it will start rotating upon starting of the engine.
3. Push the primer several times until overflown fuel flows
out in the clear tube.
STARTING ENGINE
The ZENOAH stick edger is designed for edging lawn in
gardens, parks, roadsides and so on.
Before starting the engine, take the operating position
and adjust the handle position and the wheel height as
necessary.
ADJUSTING HANDLE POSITION
•Loosen the handle bracket screws and re-position the
handle to your best operating position. Re-tighten the
screws.
ADJUSTING WHEEL HEIGHT
•Loosen the clamp lever and change the wheel height
to obtain desired cutting depth.
(1) Deep cut (2) Shallow cut
WARNING
Never adjust wheel height with the engine running.
1
2
3
(1)
(1) Stop switch
5. Set the stop switch to the “ - ” position. Set the throttle
trigger to the start position (1 →2 →3).
Place the unit on a flat, firm place.
Keep the cutting head clear of everything around it.
6. While holding the unit firmly, pull out the starter rope
quickly until engine fires.
WARNING
The product is equipped with a centrifugal clutch
mechanism, so the cutting attachment begins to ro-
tate as soon as the engine is started by putting the
throttle into the start position. When starting the en-
gine, place the product onto the ground in a flat clear
area and hold it firmly in place so as to ensure that
neither the cutting part nor the throttle come into
contact with any obstacle when the engine starts.
4. Move the choke lever to the closed position.
(1)
(2)
(3)
(1) Choke lever (2) Close (3) Open

GB-11
EXZ2610DL (HE-EX)
8. Operation
7. Move the choke lever downward to open the choke.
And restart engine.
(1)
(2)
(3)
(1) Choke lever (2) Close (3) Open
8. Allow the engine to warm up for a several minutes
before starting operation.
NOTE
1. When restarting the engine immediately after stop-
ping it, leave the choke open.
2. Overchoking can make the engine hard to start due
to excess fuel. When the engine failed to start after
several attempts, open the choke and repeat pulling
the rope, or remove the spark plug and dry it.
STOPPING ENGINE
1. Release the throttle lever and run the engine for half
a minute.
2. Shift the stop switch to the STOP position.
IMPORTANT
•Except for an emergency, avoid stopping the engine
while pulling the throttle lever.
IMPORTANT
•When it doesn’t stop at the stop switch, move the choke
level to the closed position.
(1) Choke lever
IMPORTANT
•Avoid pulling the rope to its end or returning it by re-
leasing the knob. Such actions can cause starter fail-
ures.
ADJUSTING THROTTLE CABLE
•The normal play is 1 or 2 mm when measured at the
carburetor side end. Readjust with the cable adjuster
as required.
(1)
(1) Cable adjuster
ADJUSTING IDLING SPEED
(1)
(1) Idle adjusting screw
1. When the engine tends to stop frequently at idling
mode, turn the adjusting screw clockwise.
2. When the cutting head keeps rotating after releasing
the trigger, turn the adjusting screw counter-clockwise.
NOTE
•Warm up the engine before adjusting the idling speed.
1 ~ 2 mm

GB-12
EXZ2610DL (HE-EX)
8. Operation
WARNING
•Always wear eye protection such as safety
goggles. Never lean over the rotating cutting head.
Rocks or other debris could be thrown into eyes
and face and cause serious personal injury.
•Keep the blade guard and the mad guard attached
in place at all times when the unit is operated.
•Before starting a job, check the area and remove
all obstacles and objects that could be thrown by
the blade.
•Do not adjust the wheel height or try to remove
anything entangled to the blade with the engine
running.
1. Before starting the engine, adjust the wheel height
for desired cutting depth (see page 10).
2. Before starting a job, plan your direction of travel so
that you can always hold the edger on you right side
and can walk on a hard surface as much as possible.
3. When starting to edge, run the engine at full throttle,
and slowly have the blade cut into the edge groove.
NOTE
•Do not use the HE-EX to make a new groove into the
ground. Such usage will not be covered by ZENOAH
Warranty.
BLADE
ROTATION

GB-13
EXZ2610DL (HE-EX)
WARNING
•Make sure that the engine has stopped and is cool
before performing any service to the machine. Con-
tact with moving cutting head or hot muffler may
result in a personal injury.
AIR FILTER
•The air filter, if clogged, will reduce the engine perfor-
mance. Check and clean the filter element in warm,
soapy water as required. Dry completely before in-
stalling. If the element is broken or shrunk, replace
with a new one.
(1)
(1) Air filter
FUEL FILTER
•When the engine runs short of fuel supply, check the
fuel cap and the fuel filter for blockage.
(1)
(1) Fuel filter
9. Maintenance
Every Every Every
25 50 100
System/components Procedure Before
hours hours hours Note
use
after after after
fuel leaks, fuel spillage wipe out ✔
fuel tank, air filter, fuel filter inspect/clean ✔✔ replace, if necessary
see adjusting replace carburetor
idle speed adjuster idling speed (p. 11) ✔if necessary
clean and readjust GAP: 0.026 in (0.65 mm)
spark plug plug gap ✔replace, if necessary
intake air cooling vent clean ✔
throttle trigger, stop switch check operation ✔
replace if
cutting attachment something’s wrong ✔
transmission grease ✔
screws/nuts/bolts tighten/replace ✔✔not adjusting screws
cutting attachment guard make sure to attach ✔
ENGINE
SHAFT
SPARK PLUG
•Starting failure and misfiring are often caused by a
fouled spark plug. Clean the spark plug and check
that the plug gap is in the correct range. For a re-
placement plug, use the correct type specified by
ZENOAH.
•REPLACEMENT PLUG IS A NGK CMR7H.
IMPORTANT
•Note that using any spark plug other than those des-
ignated may result in the engine failing to operate prop-
erly or in the engine becoming overheated and dam-
aged.
•To install the spark plug, first turn the plug until it is
finger tight, then tighten it a quarter turn more with a
socket wrench.
0.026 in (0.65mm)
TIGHTENING TORQUE: 9.8 ~ 11.8 N.m.
(1 ~ 1.2 kg.m.)

GB-14
EXZ2610DL (HE-EX)
9. Maintenance
MUFFLER
WARNING
•Inspect periodically, the muffler for loose fasten-
ers, any damage or corrosion. If any sign of ex-
haust leakage is found, stop using the machine
and have it repaired immediately in the repair spe-
cialty store.
•Note that failing to do so may result in the engine
catching on fire.
TRANSMISSION
•The reduction gears are lubricated by multipurpose,
lithium-based grease in the transmission. At every 20
hours of use, supply the transmission with new grease.
•Remove the cutter holders before installing new
grease to arrange for old grease to exit.
NOTE
•When removing and installing the cutter holder (a),
use care not to allow any dirt and dust entering in to
the transmission.
SPARK ARRESTER
•The muffler is equipped with a spark arrester to pre-
vent red hot carbon from flying out of the exhaust out-
let. Periodically inspect and clean as necessary with
a wire brush in the repair specialty store.
(1)
(1) Spark arrester
INTAKE AIR COOLING VENT
WARNING
•Check the intake air cooling vent and the area
around the cylinder cooling fins after every 25
hours of use for blockage, and remove any waste
which has attached itself to the machine.
10. Storage
11. Disposal
•When you dispose of the machine, do not disas-
semble the machine.
•When you dispose of the machine, fuel, oil, be sure
to follow your local regulations.
Aged fuel is one of major causes of engine starting fail-
ure. Before storing the unit, empty the fuel tank and run
the engine until it uses all the fuel left in the fuel line and
the carburetor. Store the unit indoor taking necessary
measures for rust prevention.
IMPORTANT
•If waste gets stuck and causes blockage around the
intake air cooling vent, it may cause the engine to over-
heat, and that in turn may cause mechanical failure
on the part of the brushcutter.
(1)
(1) Intake air cooling vent (back)
■PERIODICAL SERVICE POINTS
1. CYLINDER FINS
Periodically check and clean the cylinder fins in the re-
pair specialty store.

GB-15
EXZ2610DL (HE-EX)
12. Troubleshooting guide
Case 1. Starting failure
CHECK PROBABLE CAUSES ACTION
fuel tank →incorrect fuel →drain it and use correct fuel
fuel filter →fuel filter is clogged →clean
carburetor adjustment screw →out of normal range →adjust to normal range
sparking (no spark) →spark plug is fouled/wet →clean/dry
→plug gap is incorrect →correct (GAP: 0.65 mm)
spark plug →disconnected →retighten
Case 2. Engine starts but does not keep running/hard re-starting
CHECK PROBABLE CAUSES ACTION
fuel tank →incorrect fuel or staled fuel →drain it and use correct fuel
carburetor adjustment screw →out of normal range →adjust to normal range
muffler, cylinder (exhaust port) →carbon is built-up →consult with the repair specialty store
air cleaner →clogged with dust →air blow or wash
cylinder fin, fan cover →clogged with dust →consult with the repair specialty store
When your unit seems to need further service, please consult with our ZENOAH service shop in your area.
Limited warranty
Should any failure occur on the product under normal oper-
ating conditions within the applicable warranty period, the
failed part will be replaced or repaired free of charge by a
ZENOAH authorized dealer.
WARRANTY PERIOD: 1 year (6 months if used profession-
ally, and 30 days if used for rental purpose) from the date of
initial purchase.
THE PURCHASER SHALL BEAR COSTS OF TRANS-
PORTING THE UNIT TO AND FROM THE ZENOAH
DEALER.
THE PURCHASER SHALL NOT BE CHARGED FOR DIAG-
NOSTIC LABOR WHICH LEADS TO THE DETERMINATION
THAT A WARRANTED PART IS DEFECTIVE, IF THE DIAG-
NOSTIC WORK IS PERFORMED AT THE ZENOAH DEALER.
THE PURCHASER OR OWNER IS RESPONSIBLE FOR THE
PERFORMANCE OF THE REQUIRED MAINTENANCE AS
DEFINED BY THE MANUFACTURER IN THE OWNER/OP-
ERATOR MANUAL.
ANY WARRANTED PART WHICH IS NOT SCHEDULED FOR
REPLACEMENT AS REQUIRED MAINTENANCE, OR
WHICH IS SCHEDULED ONLY FOR REGULAR INSPECTION
TO THE EFFECT OF REPAIR OR “REPLACE AS NECES-
SARY” SHALL BE WARRANTED FOR THE WARRANTY PE-
RIOD. ANY WARRANTED PART WHICH IS SCHEDULED
FOR REPLACEMENT AS REQUIRED MAINTENANCE
SHALL BE WARRANTED FOR THE PERIOD OF TIME UP
TO THE FIRST SCHEDULED REPLACEMENT POINT FOR
THE PART.
ANY REPLACEMENT PART THAT IS EQUIVALENT IN PER-
FORMANCE AND DULABILITY MAY BE USED IN NON-
WARRANTY MAINTENANCE OR REPAIRS, AND SHALL
NOT REDUCE THE WARRANTY OBLIGATION OF THE
COMPANY.
THE COMPANY IS LIABLE FOR DAMAGES TO OTHER
ENGINE COMPONENTS CAUSED BY THE FAILURE OF A
WARRANTED PART STILL UNDER WARRANTY.
THE WARRANTY DOES NOT APPLY TO THOSE UNITS
WHICH HAVE BEEN DAMAGED BY NEGLIGENCE OF IN-
STRUCTION LISTED IN THE OWNER/OPERATOR MANUAL
FOR PROPER USE AND MAINTENANCE OF THE UNITS
ACCIDENT MISHANDLING, ALTERATION, ABUSE, IM-
PROPER LUBRICATION, USE OF ANY PARTS OR ACCES-
SORIES OTHER THAN THOSE SPECIFIED BY THE COM-
PANY, OR OTHER CAUSES BEYOND THE COMPANY’S
CONTROL.
THIS WARRANTY DOES NOT COVER THOSE PARTS RE-
PLACED BY NORMAL WEAR OR HARMLESS CHANGES
IN THEIR APPEARANCE.
THERE ARE NO OTHER EXPRESS WARRANTIES.
IMPLIED WARRANTIES INCLUDING THOSE OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE ARE LIMITED TO TWO (2) YEARS OF HOME USE
[ONE (1) YEAR FOR ANY OTHER USE] FROM THE ORIGI-
NAL DELIVERY DATE.
LIABILITIES FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGE UNDER ANY AND ALL WARRANTIES ARE
EXCLUDED.
IF YOU NEED TO OBTAIN MORE INFORMATION, PLEASE
CALL YOUR NEAREST SERVICE CENTER,
OR CHECK PLEASE ZENOAH WEB SITE
http://www.zenoah.net

PRINTED IN JAPAN
