Ryobi RED1220 User manual

ORIGINAL INSTRUCTIONS
Electric Edger
RED1220

Important!
It is essential that you read the instructions in this manual before assembling,
operating and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have
been given top priority in the design of your
electric edger.
INTENDED USE
The electric edger is intended to be used only
by adults who have read and understood
the instructions and warnings in this manual
and can be considered responsible for their
actions. The product is only intended for use
outdoors in a well-ventilated area.
The product is intended for edging along
sidewalks, walkways, driveway, ower beds,
curbs, and other similar areas.
The product is not allowed to be used for
cutting or chopping hedges, shrubs, bushes,
owers, and compost.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING
When using the product, the safety rules
must be followed. For your own safety
and that of bystanders, please read these
instructions before operating the product.
Please keep the instruction safe for later
use.
WARNING
The product is not intended to be used by
children or persons with reduced physical,
mental, or sensory capabilities. Children
should be adequately supervised to ensure
they do not play with the product.
TRAINING
■Read the instructions carefully. Be familiar
with all controls and the proper use of the
product.
■Never allow children or people unfamiliar
with these instructions to use the product.
Local regulations may restrict the age of
the operator.
■Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their property.
■Keep bystanders, children, and pets 15 m
away from the area of operation. Stop the
product if anyone enters the area.
■Never use the product when you are tired,
ill, or under the influence of alcohol, drugs
or medicine.
ELECTRICAL SAFETY
■Power plugs must match the outlet. Never
modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and
matching outlets will reduce risk of electric
shock.
■Prevent unintentional starting. Always
check that the switch is in off position
before plugging in the product to the power
supply. Do not carry a plugged in product
with your finger on the switch.
■Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
■Do not operate the product when there is a
risk of lightning.
■Do not expose the product to rain or wet
conditions. Water entering an appliance
will increase the risk of electric shock.
■Electrical power should be supplied via
a residual current device (RCD) with a
tripping current of not more than 30 mA.
■Before every use, examine the power cord
for damage. If there are signs of damage,
it must be replaced. Always uncoil the
power cord during use; coiled cables can
overheat.
■If you need to use an extension cable,
ensure it is suitable for outdoor use and
has a current capacity sufficient to supply
your product. Always uncoil it during use
because coiled cables can overheat.
Damaged extension cables should not be
repaired; they should be replaced with an
equivalent type.
■Do not use the product if the electric cables

2
are damaged or worn.
■If the power cord or extension cable
becomes damaged during use, disconnect
from the power supply immediately. Do not
touch the electric cables until the power
supply has been disconnected.
■Make sure the power cord is positioned so
that it cannot be damaged by the cutting
means and will not be stepped on, tripped
over, or otherwise subjected to damage or
stress.
■Never pull the power cord to disconnect
from the power supply.
■Never pick up or carry the product by the
electric cable.
■Keep the power cord away from heat, oil,
and sharp edges.
■Make sure voltage is correct for your
product. A nameplate on the product
indicates the product’s voltage. Never
connect the product to an AC voltage that
differs from this voltage.
■Make sure the switch is in off position
before disconnecting from power supply.
PREPARATION
■Wear full eye and hearing protection while
using the product. If working in an area
where there is a risk of falling objects, head
protection must be worn.
■Hearing protection may restrict the
operator’s ability to hear warning sounds.
Pay particular attention to potential hazards
around and inside the working area.
■Wear heavy, long trousers, boots, and
gloves. Do not wear loose fitting clothing,
short trousers, jewellery of any kind, or use
with bare feet.
■Secure long hair so it is above shoulder
level to prevent entanglement in moving
parts.
■Before use and after any impact, check that
there are no damaged parts. A defective
switch or any part that is damaged or worn
should be properly repaired or replaced by
an authorised service centre.
■Before using, always visually inspect that
the blade, blade bolts, and cutter assembly
are not worn or damaged. Replace worn
or damaged blade and bolts in sets to
preserve balance.
■Make sure the cutting attachment is
properly installed and securely fastened.
■Never operate the product unless all
guards, deflectors, and handles are
properly and securely attached.
■Consider the environment in which you are
working. Keep the working area free from
wires, sticks, stones, and debris, which if
struck by the cutter, can become thrown
objects.
EDGER SAFETY WARNINGS
■Never allow children or people unfamiliar
with the instructions to use the product.
■Use the product in daylight or good artificial
light.
■Avoid using on wet grass.
■Keep firm footing and balance. Do not
overreach. Overreaching can result in loss
of balance. Always be sure of your footing
on slopes. Walk, never run.
■Use extreme caution when reversing or
pulling the edger toward you.
■Beware, the cutting elements continue to
rotate after the engine/motor is switched
off. Maintain proper control until the blade
has completely stopped rotating.
■Make sure the blade has stopped before
crossing surfaces other than grass and
when transporting the edger to and from
the area to be edged.
■Start the product carefully according to
instructions and with feet well away from
the blade. Never stand or have any part of
your body in line with the path of the edger
blade.
■Do not adjust the powerhead governor
settings or over-speed the engine/motor.
■The guard on this edger is designed to
throw debris forward and away from the
operator while in use. Remember that the
blade below the guard is not guarded when
the product is tilted or lifted away from

3
the ground. This is particularly important
during starting the product. Never start the
product if anyone is in front of the blade.
■Do not operate the product when there is a
risk of lightning.
■Do not expose the product to rain or wet
conditions. Water entering an appliance
will increase the risk of electric shock.
■Keep bystanders, children, and pets 15 m
away from the area of operation. Stop the
product if anyone enters the area.
■Never operate the product with damaged
guards or without guards in place.
■Beware of objects thrown by the cutting
means. Clear debris like small stones,
gravel and other foreign objects from the
work area before starting operation. Wires
or string may become entangled with the
cutting means.
■To reduce the risk of injury associated with
moving parts, always stop the product,
and disconnect from the power supply (if
applicable). Make sure all moving parts
have come to a complete stop:
●before servicing
●before leaving the product unattended
●before clearing a blockage
●before checking, cleaning, and working
on the product
●before working on the blade
●before checking for any damage if the
product starts to vibrate abnormally
●whenever performing maintenance
●whenever the product starts to vibrate
abnormally
■Always ensure that ventilation openings
are kept clear of debris.
■Make sure the cutting head attachment is
properly installed and securely fastened.
■Make sure all guards, deflectors, and
handles are properly and securely
attached.
■Do not modify the product in any way, this
may increase the risk of injury to yourself
or others.
■Use only the manufacturer’s replacement
cutting line. Do not use any other cutting
attachment.
WARNING
Inspection after dropping or other impacts:
Thoroughly inspect the product and identify
any problems or damage to it. Any part that
is damaged should be properly repaired or
replaced by authorized service centre.
TRANSPORTATION AND STORAGE
■Stop the product and allow it to cool down
before storing or transporting. Always
disconnect from the power supply and wind
the cable to prevent damage.
■Clean all foreign materials from the product.
Store it in a cool, dry and well-ventilated
place that is inaccessible to children.
Keep away from corrosive agents, such as
garden chemicals and de-icing salts. Do
not store outdoors.
■For transportation in vehicles, secure the
product against movement or falling to
prevent injury to persons or damage to the
product.
MAINTENANCE
WARNING
Use only original manufacturer’s
replacement parts, accessories, and
attachments. Failure to do so can
cause possible injury, contribute to poor
performance, and may void your warranty.
WARNING
Servicing requires extreme care and
knowledge and should be performed only
by a qualied service technician. Have the
product serviced by an authorised service
centre only. When servicing, use only
original replacement parts.
■Turn off the product and disconnect
from the mains before conducting any
maintenance or cleaning work.
■You may make adjustments and repairs
described in this manual. For other repairs,

4
contact the authorised service agent.
■After each use, clean the product with a
soft, dry cloth. Any part that is damaged
should be properly repaired or replaced by
an authorised service centre.
■Check all nuts, bolts, and screws at
frequent intervals for proper tightness
to ensure the product is in safe working
condition. Any part that is damaged should
be properly repaired or replaced by an
authorised service centre.
■Bring the product to an authorised service
centre to replace damaged or unreadable
labels.
■Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to
damage from various types of commercial
solvents and may be damaged by their use.
Use clean cloth to remove dirt, dust, oil,
grease, etc.
WARNING
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils,
etc., come in contact with plastic parts.
Chemicals can damage, weaken or destroy
plastic which may result in serious personal
injury.
Only the parts shown on the parts list are
intended to be repaired or replaced by the
customer. All other parts should be replaced
at an authorised service centre.
RESIDUAL RISKS
Even when the product is used as prescribed,
it is still impossible to completely eliminate
certain residual risk factors. The following
hazards may arise during use, and the
operator should pay special attention to avoid
the following:
■injury caused by vibration
–Hold the product by designated handles
and restrict working time and exposure.
■injury caused by exposure to noise
–Wear hearing protection and limit
exposure.
■injury caused by flying debris.
–Wear eye protection at all times.
RISK REDUCTION
It has been reported that vibrations from
handheld tools may contribute to a condition
called Raynaud’s Syndrome. Symptoms may
include tingling, numbness and blanching of
the ngers, usually apparent upon exposure
to cold. Hereditary factors, exposure to cold
and dampness, diet, smoking and work
practices are all thought to contribute to the
development of these symptoms. There are
measures that can be taken by the operator
to possibly reduce the effects of vibration:
■Keep your body warm in cold weather.
When operating the product, wear gloves
to keep the hands and wrists warm. It is
reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to
increase blood circulation.
■Take frequent work breaks. Limit the
amount of exposure per day.
If you experience any of the symptoms of this
condition, immediately discontinue use and
see your physician.
WARNING
Injuries may be caused, or aggravated, by
prolonged use of a tool. When using any
tool for prolonged periods, ensure you take
regular breaks.
WHAT’S IN THE BOX
■Powerhead x 1
■Edger attachment x1
■Combination wrench x 1
■Front handle x 1
■Operator’s manual
■Harness x 1
■Clamp x 1
Locking Pin x1

5
SYMBOLS ON THE PRODUCT
Read and understand all
instructions before operating
the product, follow all warnings
and safety instructions.
Wear eye and hearing
protection.
Do not expose to rain or damp
conditions.
Immediately remove the
plug from the mains before
maintenance or if cable is
damaged, cut, or entangled.
Direction of edger blade
rotation
Keep feet away from the
rotating blade.
Beware of thrown or ying
objects. Keep all bystanders,
especially children and pets,
at least 15 m away from the
operating area.
Waste electrical products
should not be disposed of
with household waste. Please
recycle where facilities exist.
Check with your local authority
or retailer for recycling advice.
91
102
Guaranteed sound power
level and guaranteed sound
pressure level.
Class II tool, double insulation
Regulatory Compliance
Mark (RCM). Product
meets applicable regulatory
requirements.
SYMBOLS IN THIS MANUAL
Connect to power outlet.
Disconnect from power outlet.
Parts or accessories sold
separately
Note
The following signal words and meanings
are intended to explain the levels of risk
associated with this product.
DANGER
Indicates an imminently hazardous
situation, which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation,
which, if not avoided, could result in death
or serious injury.
CAUTION
Indicates a potentially hazardous situation,
which, if not avoided, may result in minor or
moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in
property damage.

6
WHAT’S IN THE BOX
x 1 x 1x 1
x 1 x 1

7
Know your product
KNOW YOUR PRODUCT
54321
76
13
12
8
9
10
11
1. Harness
2. Hanger
3. Throttle trigger
4. Lock-out trigger
5. Rear handle
6. Cord retainer
7. Power cord
8. Upper shaft
9. Adjustment knob
10. Guide wheel
11. Edger blade
12. Indication line
13. Blade guard

8
GETTING STARTED
1
5
1
2
6
Always wear safety goggles or safety glasses with side shields
when operating the product. Wear non-slip, heavy-duty protective
gloves. Wear non-skid, protective footwear that will protect your
feet and improve your footing on slippery surfaces.
Form a loop and secure the cable in the cable retainer.
NOTE: Prevent the unintentional starting. Always check that the
switch is in off position before plugging in the product to the power
supply.
Before using the product, make sure the cable is positioned
correctly to avoid damage. Hang the cable onto the cable retainer.
3
1
2
2
Install the lower shaft to the upper shaft..

9
GETTING STARTED
1
2
3
4
7
1
2
8
Install the harness.
Press the lock-out button (1) and then squeeze the throttle trigger
(2).
Connect the plug to a power outlet.
1
23
4
3
Install the front handle on the upper shaft. Tighten the adjustment
knob securely.

10
OVERVIEW
Blade depth adjustment Storing the product
Operating the Edger Replacing the blade
Cleaning the product
p.11
p.14 p.15
p.13
p.16

11
OPERATION
1
2
1
2
OPERATING THE EDGER
WARNING: Always operate with two
hands and exercise extreme caution
when using the product. The blade will
reduce in speed if the edger is operated
too quickly.
1. Connect the plug to a power outlet.
2. Press the lock-out trigger (1) and then
squeeze the throttle trigger (2).

12
OPERATION
3
3. Operate the edger at a steady pace. The
blade begins to freeze when you edge
too fast. Do not force the blade into the
ground. Avoid edging in wet soil or areas
with damp grass and shrubbery.
WARNING: The cutting elements will
continue to rotate for 2-3 seconds after
the product is turned off.

13
MAINTENANCE
1
2
3
2
1
3
1
2
3
REPLACING THE BLADE
1. Disconnect the plug from the power
outlet.
WARNING: Replace the blade when
the blade wears down to the indication
line.
2. Insert the locking pin into the inner
ange washer. Using the combination
wrench, remove the blade nut, outer
ange washer and blade.
3. Install the new blade on the inner ange
washer and then reinstall the outer
ange washer, and blade nut. Secure
using the combination wrench. Make
approximately 3.5 turns after nger
tight to tighten the blade screw. The
recommended torque for the blade is ≥
25 Nm. Remove the locking pin.
WARNING: Make sure the blade
is correctly installed and securely
fastened before each use.

14
MAINTENANCE
1
2
3
BLADE DEPTH ADJUSTMENT
1. Disconnect the plug from the power
outlet.
2. Loosen the adjusting knob.
3. Move the wheel arm up to increase the
depth or down to decrease the depth.
4. After adjustment is complete, tighten
the adjusting knob securely.
NOTE: The blade can be adjusted
from 12 mm to 57 mm. Initially, make
a shallow cut to test the cutting depth.
If the cutting depth needs adjusting, this
should be done progressively until the
desired depth is reached.
4

15
MAINTENANCE
1
2
CLEANING THE PRODUCT
1. Disconnect the plug from the power outlet.
2. Clean all foreign materials from the
product.
WARNING: Keep the product away from
corrosive agents, such as garden chemicals
and de-icing salts.

16
STORAGE
20180103v1
1
3
2
1
2
STORING THE PRODUCT
NOTE: Make sure to clean the product
before storing.
1. Disconnect the plug from the power outlet.
2. Remove the lower shaft from the upper
shaft.
3. Store the product.
3

PRODUCT SPECIFICATIONS
Electric edger
Model RED1220
Rated power 1200 W
Rated voltage 230-240 ~ 50 Hz
Blade length size 204 mm
No-load speed 4000 min
-1
Edging depth Adjustable from 12
mm to 57 mm
Weight 5.54 kg
Recommend torque for blade ≥ 25 Nm
Vibration Level (in accordance with AS/NZS 60335.2.91 Annex
BB)
Front handle 0.4 m/s²
Rear handle 1.3 m/s²
Uncertainty of measurement 1.5 m/s²
Noise emission level ( in accordance with AS/NZS 60335.2.91
Annex CC)
A-weighted sound pressure level at the
operator’s position
88.3 dB(A)
Uncertainty of measurement 2.5 dB
A-weighted sound power level 99.1 dB(A)
Uncertainty of measurement 2.5 dB
REPLACEMENT PART
Blade 638006013
