Zetronix NANO-4K User manual

NANO-4K
USER MANUAL

In the Box
Diagram
App Setup
Remote Live Video Feed
Advanced Settings
Troubleshooting
Help
Page 1
Page 2
Page 3
Page 7
Page 11
Page 14
Page 15
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
CONTENTS
Warranty Page 16
__________________________________________

IN THE BOX
A NANO 4K camera unit
B Li-ion battery
C USB cable
D 8x shirt buttons
E This manual
PAGE | 1

DIAGRAM
PAGE | 2

1. Download the app - HDWiFiCamPro
Search and download HDWiFiCamPro on the App
Store or Google Play. .... can also scan the QR code
below via QR scanning app.
2. Setup the NANO
Insert a micro SD card in the card slot 8 if you're
planing on recording media directly on the NANO.
Push the card in all the way until you feel it click.
Turn on the camera: move the switch 7 to the ON
position, wait 30 seconds, then the indicator light
4 should turn solid blue.
HDWiFiCam Pro
SETTING UP THE APP
Plug in the battery connector (10) to the NANO's
connector 3
PAGE | 3

Connect your phone to this camera's WiFi access
from your phone's WiFi settings, search and connect
to the WiFi signal starting with "DGK".
Some Android phones will notice that your camera's wifi
cannot access the internet. Please ignore this notice
and continue to connect to the camera's wifi.
3. Setup the WIFI
PAGE | 4

Open the HDWiFiCam Pro app, click on Add
New Camera, Add online camera, click Search,
then select the first camera to add it. Hit Sure to
save, the camera will list back on the main menu.
4. Connect to camera
PAGE | 5

5.Setup remote access
Click on the Setting icon, select Wi-Fi, then select
your router’s WiFi name, enter your WiFi password,
Click Join, and then wait about a minute for it to
connect.
Locate your router’s WiFi
name and input the password,
then click "Join". Please note:
If your router has 2 wifi
signals, please don't choose
5G. Because it only supports
2.4 GHz wifi.
PAGE | 6

Click on the video to view the live feed.
Click here to switch Mode 1 and Mode 2.
Mode 1
REMOTE LIVE FEED
Mode 2
PAGE | 7

1. Vertical Flip: click to flip the camera’s view vertically
2. Horizontal Flip: click to flip the camera’s view horizontally
3. Indicator Light: click to turn LED lights on/off
4. Night Vision: turn on /off Night Vision (on supported models only)
5. Time Display Switch: turn on/off the time display on the clock
6. Resolution: you can change the viewing resolution as your needs
7. Video: click to record videos into your phone.
8. Snapshot: click to take a picture into your phone.
9. Hold to Talk: (N/A)
10. Audio: (N/A)
11. More Picture Setting: Contrast, Brightness, Playback, etc
PAGE | 8

Night Vision Mode (on supported models only)
Captures sharp images even with limited or no light.
Night Vision Off Night Vision On
Snapshots
Tap to take photos Photos will be shown here.
PAGE | 9

Video Recording
Tap to record video. videos will be shown here.
You can access the recorded media for playback either from the
live view, or from the main menu.
PAGE | 10

ADVANCED SETTINGS
To manage each device’s settings, click the settings
icon in the bottom right corner. Here, you can modify,
delete or share the device and also manage each
camera’s individual settings. In Device Settings you can
configure the device password, alarm notifications,
motion detection settings, SD card recording settings
and much more.
PAGE | 11

User
To protect your privacy, it is highly
recommended that you change the
camera's password. The default
password is 6666.
Time
Adjust your time zone and preferred time display
format. Or simply click "Sync phone time".
Alarm
These settings allow you to manage your push
notifications and activity alerts from your camera.
The alarms will be shown here.
PAGE | 12

Record
Manage your micro SD card recording settings, record
mode, and set a length of time you want the camera to
record.
Record time: The minimum time in minutes it will
record after motion activation.
Video stream: Video resolution to be recorded onto
the Micro SD card, 720P or 1080P.
Video mode: 3 recording modes, Throughout the
video allows for continuous recording. Alarm video
enables motion detection. Timing video sets a time
for videos to record onto a Micro SD card.
PAGE | 13

Most issues can be resolved by resetting the camera
device; press and hold the reset button 6 for 15
seconds while the NANO power switch 7 is set to on.
Also formatting the memory card can clear up any
memory curruption. Please use a computer to do that.
Q&A
Why can't I find or connect the camera's WiFi?
If your camera has already been connected to a router, it will no
longer be available in your WiFi list. Do not worry, this is normal.
Reset is required (See "Resetting the Camera"). Reset the
camera and wait approximately 2 minutes. Then repeat Setup
Instructions.
Why does the camera show "device not on line"?
When you connect it to the router, it may display "device not on
line" during rebooting. Please wait 1~2mins, until it displays Online
Please check to make sure the connected router is plugged
in and powered on. Check the router wireless WiFi to make sure it
is set to 2.4G, it should not be on 5G.
A RESET and reconnection of the camera may be necessary if
the steps above do not work. See "Resetting the Camera" if a
reset is required.
TROUBLESHOOTING
PAGE | 14

SD card cannot save files.
Before you insert the SD card, turn off the camera, and
you can also try formatting the SD card.
Ensure that the memory card isnt full. Please move some files
into your computer.
The passwords was forgotten
Reset the camera device by pressing and holding the reset
switch 7 for 15 seconds. The password will then default back
to 6666



Still Have Questions?
Do not return your camera
For additional assistance contact
Zetronix Tech Support
By Phone...............................877-644-7592
By [e-mail]
Li
Live Chat at Zetronix.com
9AM-5PM EST
Monday to Friday
PAGE | 15

1 Year Limited Warranty
Zetronix Corporation (“Zetronix”) warrants this product against defects in material or workmanship as follows:
PRODUCT: Zetronix will repair this product with new or refurbished parts, free of charge, for a period of one (1) year
from the date of original purchase in the event of a defect in materials or workmanship. REPAIRS: Zetronix will
repair or replace defective parts used in the repair or replacement of this product with new or refurbished parts,
free of charge, for a period equal to the remainder of the original limited warranty period on the original product, or
f
for 60 days after the date of the repair or replacement, whichever is longer. This warranty is extended only to the
original purchaser. Proof of purchase in the form of a bill of sale or receipted invoice, which is evidence that the unit
is within the warranty period, must be presented to obtain warranty service. To obtain warranty service,
y
you must take this product, or deliver the product freight prepaid, in either its original packaging or packaging af-
fording an equal degree of protection, to Zetronix Corporation. See below for additional information. This warranty
only covers failures due to defects in materials and workmanship, which occur during normal use.. The warranty
does not cover damages, which occurred in shipment, cosmetic damage, damage that is attributable to acts of God,
failures which are caused by products not supplied by the warrantor, or failures which result from accident, misuse,
abuse, neglect, mishandling, faulty installation, misapplication, improper installation, operation or maintenance,
alteration, modication, introduction of sand, humidity or liquids, line power surge, improper voltage supply,
lightning damage, or subjecting the product to operating/environmental conditions in excess of the maximum
values or below the minimum values set forth in the applicable specications, or products serviced by anyone other
than Zetronix. This warranty is invalid if the factory-applied serial number has been altered or removed from the
product. This warranty does not cover products sold AS IS or WITH ALL FAULTS. This warranty excludes consumable
parts such as batteries and power supplies.
Z
Zetronix Corporation (“Zetronix”) warrants this product against defects in material or workmanship as follows:
PRODUCT: Zetronix will repair this product with new or refurbished parts, free of charge, for a period of one (1) year
from the date of original purchase in the event of a defect in materials or workmanship. REPAIRS: Zetronix will
repair or replace defective parts used in the repair or replacement of this product with new or refurbished parts,
free of charge, for a period equal to the remainder of the original limited warranty period on the original product, or
f
for 60 days after the date of the repair or replacement, whichever is longer. This warranty is extended only to the
original purchaser. Proof of purchase in the form of a bill of sale or receipted invoice, which is evidence that the unit
is within the warranty period, must be presented to obtain warranty service. To obtain warranty service, you must
take this product, or deliver the product freight prepaid, in either its original packaging or packaging affording an
equal degree of protection, to Zetronix Corporation. See below for additional information. This warranty only
covers failures due to defects in materials and workmanship, which occur during normal use.. The warranty does not
co
cover damages, which occurred in shipment, cosmetic damage, damage that is attributable to acts of God, failures
which are caused by products not supplied by the warrantor, or failures which result from accident, misuse, abuse,
neglect, mishandling, faulty installation, misapplication, improper installation, operation or maintenance,
alteration, modication, introduction of sand, humidity or liquids, line power surge, improper voltage supply, light-
ning damage, or subjecting the product to operating/environmental conditions in excess of the maximum values or
below the minimum values set forth in the applicable specications, or products serviced by anyone other than
Zetronix. This warranty is invalid if the factory-applied serial number has been altered or removed from the
product. This warranty does not cover products sold AS IS or WITH ALL FAULTS. This warranty excludes consumable
parts such as batteries and power supplies.
PAGE | 16
