ZTV Electron ZT-812 User manual

MODEL：
ZT-812 PAGE:
1 OF 4
PRODUCT
INSTRUCTION DESCRIPTION
Wireless Camera
ZT-815T
WIRELESS CAMERA USER’S MANUAL
REVISIONS DESCRIPTION DATE DESIGN
SHENZHEN ZHONGWANG ELECTRON CO., LTD APPROVAL
PAGES
TOTAL FILE
NUMBER ISSUE DATE CHECK
4 DESIGN

- 2 -
FILE NUMBER：MODEL：ZT-815T PAGES: 2 OF 4
Operation instruction
1. Connecting the receiver antenna. (Figure 1)
2. Connecting the 9V direct current stabilizer (Figure 2), pilot lamp lighting (Figure 3).
3. Connecting the audio and video (figure 4) output with the input to the monitor, the television
should be set on A/V model.
4. Connecting the audio and video output with the input of the transmitter.
5. Plug power jack of DC power supply(8V，300mA)into the power socket of the CMOS
camera(figure 6).(Battery of the same voltage is acceptable.)
6. Turning the micro-adjustment knob (figure 5)on the receiver till receiving the picture of the
wireless camera.
7. Fine tune to the desire position till the image of CMOS camera is received.
8. Adjust the lens of the CMOS camera (figure 7) to best position.
Notice
1. The machine is supplied with many different types, please provide with electric power according
the value on the label.
2. Obstructs by the building and so in will cause attenuation.
3. Normally that the machine will slightly warm up during operation.
4. Should any other malfunctions occur, please contact local distributor.
5. Under normal operational conditions, one year’s warranty is granted .if there are quality problems
within 3 months, this company will unconditionally replace with a new camera.
Waning
This product is for the sole purpose of security and applicable for monitoring in residential
houses, shop sand companies the users shall observe local rules, regulations and laws, and
shall be solely liable in this regard, this company shall not be liable for any illegalities therein.
Note: Any change of the product will void the FCC authorization.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.

- 3 -
SHENZHEN ZHONGWANG ELECTRON CO.,LTD TEL：[phone]
FAX：[phone]
http://www.ztv.cc
FILE NUMBER：MODEL：ZT-815T PAGES: 3 OF 4
Technical data
ITEM TYPE
Transmission
Frequency 2.414~2.468GHz 4cH
Electric power: DC 8V
Video input: 1.0VP-P(MAX)
Power consumption current 180mA
Audio input: 2VP-P(Max.)
Effective range(no obstacles) 30m
CMOS
IMAGE SENSOR 1/3-inch CMOS Image Sensor
CMOS TOTAL PIXELS 628*582
SYNC SYSTEM INTEMAL
MINIMUM ILLUMINATION 1 Lμx F1.2 5600°K/ 0 Lμx(IR ON)
RESOLUTION 330TV Line
Mode: AWB(Zero color rolling)
WHITE BALANCE Range:3200~10000°K
GAIN CONTROL AGC
S/N RATIO 48dB(Min)/60dB(TYP)(AGC OFF)
ELECTRONIC SHUTTER 1/60~1/15,000sec
CAMMA CORRECTION 0.45
OPERATION TEMPERATURE -20℃~60℃
OPERATION HUMIDITY 85%RH
SHENZHEN ZHONGWANG ELECTRON
CO.,LTD
TEL：[phone]
FAX：[phone]
http://www.ztv.cc

- 4 -
FILE NUMBER：MODEL：ZT-815T PAGES: 4 OF 4
.
SHENZHEN ZHONGWANG ELECTRON CO.,LTD TEL：[phone]
FAX：[phone]
http://www.ztv.cc
TV
DC
①
②
③
④
2.4G Receiver
⑤
①: Antenna
②: Power Jack
③: Flash LED
④: Video and Audio Jack
⑤: Channel Switch
⑥: Camera Power Line
⑦: Lens of camera
⑥
⑦
A
udio
Video
