ZTV ZT-906T User manual

MODEL
ZT-906T
PAGE:
1OF4
PRODUCT
INSTRUCTION DESCRIPTION
Wireless Camera
ZT-906T
WIRELESS CAMERAUSER SMANUAL
REVISIONS DESCRIPTION DATE DESIGN
SHENZHENZHONGWANG ELECTRONCO., LTD
APPROVAL
PAGES
TOTAL
FILE
NUMBER ISSUEDATE CHECK
4 DESIGN

-2-
FILENUMBER MODEL ZT-906T PAGES:2OF4
Operationinstruction
1.Connectingthe receiverantenna. (Figure1)
2.Connectingthe12Vadapter(Figure2),open upthe switch(Figure5),LEDindicatorlightsup
(ch1),Press the Key-press(Figure8),LEDindicator（ch1、ch2、ch3、ch4）lightsupinproperorder。
3.Connectingtheaudioand video (figure4)outputwiththe inputtothe monitor,the television
shouldbeset on A/Vmodel.
4.Connectingthe audioand video output withthe input ofthe transmitter.
5.Plugpowerjack ofDC powersupply(12V ，500mA)intothepowersocketofthe CCD
camera(figure6).(Batteryofthe samevoltageisacceptable.)
6.Turningthe micro-adjustmentknob(figure5)on the receivertill receivingthe pictureofthe
wireless camera.
7.Fine tune tothe desireposition till the imageofCMOScameraisreceived.
8.Adjust the lensofthe CMOScamera(figure7)tobest position.
Notice
1.The machine issupplied withmanydifferenttypes,pleaseprovide withelectricpoweraccording
the value on the label.
2.Obstructsbythe buildingand soinwill causeattenuation.
3.Normallythat the machine will slightlywarmupduringoperation.
4.Shouldanyothermalfunctionsoccur, pleasecontact localdistributor.
5.Undernormaloperationalconditions,oneyear swarrantyisgranted.iftherearequalityproblems
within3months, thiscompanywill unconditionallyreplacewithanewcamera.
Waning
Thisproductisforthe solepurposeofsecurityandapplicableformonitoringinresidentialhouses,shop
sand companiesthe usersshall observelocalrules,regulationsandlaws,and shall besolely
liableinthisregard, thiscompanyshall not beliableforanyillegalitiestherein.
SHENZHENZHONGWANG ELECTRONCO.,LTD TEL [phone]
FAX [phone]
http://www.ztv.cc
FCC Information
Thisdevicecomplieswithpart15oftheFCCRules,Operationissubjecttothefollowingtwoconditions:(1)Thi
sdevice
maynotcauseharmfulinterference,and (2)Thisdevice mustacceptanyinterference
received,includinginterference that
maycauseundesiredoperation.
CAUTION: Changesormodificationsnot expresslyapprovedbySummerinfant mayvoidtheusers
authoritytooperatethis
equipment.
NOTE:Thisequipmenthasbeentestedand foundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15of
theFCC Rules.
Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulint
erference inaresidentialinstallation.This
equipmentgenerates,usesand canradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe
instructions,maycauseharmfulinterferencetoradiocommunications,However,thereisnoguaranteethatinterference
will
notoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterference toradioortelevisionreception,which
canbedeterminedbyturningtheequipmentoffand on,theuserisencouragedtotrytocorre
cttheinterferencebyoneor
moreofthefollowingmeasures:
l Reorient orrelocatethereceivingantenna
l Increasetheseparationbetweentheequipment and thereceiver
l Consult thedealeroranexperiencedradio/ TVtechnicianforhelp.

-3-
FILENUMBER MODEL ZT-906T PAGES:3OF4
Technicaldata
ITEM TYPE
Transmission
Frequency 2.414~2.468GHz4cH
Electricpower:DC 12V
Output power 0±3dBm
Video input: 1.0VP-P(MAX)
Powerconsumption current180mA
Audioinput: 2VP-P(Max.)
Effectiverange (no obstacles) 30m
CCD
IMAGESENSOR 1/4(SharpCCD)
CCD PixelPitch 7.2(H) ×4.7(V)
SYNC SYSTEM INTENAL
Minimumillumination <2(IROFF)/0(IRON)
HorizontalResolution 420TVLine
Mode:AWB(Zerocolorrolling)
WHITEBALANCE
Range:3200~10000°K
GAINCONTROL AGC
S/NRATIO 40dB
ELECTRONICSHUTTER 1/50-1/100000 sec
GAMMACORRECTION 0.45
OPERATIONTEMPERATURE -20℃~50℃
OPERATIONHUMIDITY 15%~85%RH
SHENZHENZHONGWANG ELECTRON
CO.,LTD
TEL [phone]
FAX [phone]
http://www.ztv.cc

-4-
FILENUMBER MODEL ZT-906T PAGES:4OF4
.
SHENZHENZHONGWANG ELECTRONCO.,LTD TEL [phone]
FAX [phone]
http://www.ztv.cc
TV
DC
12V
①
②
③
④
2.4G Receiver
⑤
①:Antenna
②:PowerJack
③:FlashLED(ch1、ch2、ch3、ch4)
④:Videoand AudioJack
⑤:Switch
⑥:CameraPowerLine
⑦:Lensofcamera
⑧Key-press
Audio
Video
⑥
⑦
⑧
Ch4
Ch3
Ch2
Ch1
