ZZY ZY-88 User manual

User Manual
Model: ZY-88
Thank you for choosing Shenzhen ZZY technological production bluetooth
music cup, your use is our pleasure , thank you for your support !
I. Features
[ Bluetooth audio ] Bluetooth3.0, maximum receiving distance of 10 meters .
[ Bluetooth phone ] voice clarity, no echo .
[ Audio Output ] fidelity, subwoofer output , output volume larger.
[ Control ] human touch sensing
[ Power and memory ] automatically remembers the last volume.
[ Active connection ] to open the Bluetooth speakers, active connection last
connected device.
[ Built-in battery ] Built-in rechargeable lithium battery, environmental
protection , energy saving, practical.
[ Long working ] once fully charged, more than 6 hours of continuous playback .
[ Long standby ] once fully charged, it can even stand more than 60 days .
Second, the product key functional definition ( to prevail in kind )
1. [ON / OFF]: Power switch ; long press on the front panel ON / OFF button for
speaker startup and shutdown state switching . And with a corresponding tone
and status indicators.
2. [O / PLAY]: Play / Pause / Answer / Hang up the phone mode conversion .
Short press : Bluetooth mode to play / pause , press to answer the phone
call , call , short press to hang up.
Long press the “play” button to switch this mode.(bluetooth mode –TF
card mode)
3 [ - ] : adjust the volume of small / previous one . Short press : the upper one ;
Long press: to adjust the volume decreases.
4 [ + ] : volume adjustment Large / next one . Short press : for the next one ;
Long press: to adjust the volume increases.

[ON/OFF]
Power switch;long press on the front panel ON/OFF button
For speaker startup and shutdown state switching.And with a
corresponding tone and status indicators
Adjust the volume
Of small/previous
One.Short press;
The upper one;
Long press:to
Adjust the volume
decreases
Volume adjustment
Large/next one.
Short press;for
The next one;
Long press;to
Adjust the volume
increases
[O/PLAY]
Play/Pause/Answer/Hang up the phone mode conversion
Short press;Bluetooth mode to play/pause,press to answer the phone
call,call,short press to hang up.
Long press the “play” button to switch this mode.(bluetooth mode –TF
card mode)
5. [MIC]: Call microphone ; call is a call on the microphone can enhance the
effect . ( This can not write )
6. Disconnect automatically into the matching condition, restoring boot state
after 60 seconds, matching state needs to be turned off again by 10 seconds
long into the matching state (red and blue flashing)
Third, Indicator Description
Red light: is charging , fully charged, lights off automatically .
Blue light: Indicates Bluetooth normal operating mode ; low -power
shutdown indicator .
Fourth, the Bluetooth connection method ( Optional models , to prevail in
kind ) :
1 , Long press the “power” button for 4sec turn on the Unit. The unit will
enter into pairing mode,and take the initiative to connect the last matching
equipment.
2, open mobile devices ( cell phones, computers , etc. ) of the
Bluetooth function, search for Bluetooth devices "N9000".
3 , manual clicks, the device automatically paired , connection, the
connection is successful will issue a "grunt " sound .
( Under normal circumstances do not enter a password, special models
prompted to enter a password , enter "0000 " can be )

4 , have been successfully paired devices , open the opportunity to
automatically connect to the next .
5 , if we already have a Bluetooth device connected to the same speaker ,
need to switch to another Bluetooth device to connect with speakers , this time
need ( you add how operations )
Note : Enter Bluetooth mode within 10 seconds , the Bluetooth device will
automatically find and pair connection 10 seconds after going through the
manual connection.
6，When the unit into the bluetooth pairing mode,the status indicator lamp will
blue-red flash; if the unit doesn’t connect any matching equipment more than
10Min,the unit will be turn off by itself.
7, bluetooth connection state, two consecutive within 1 second time touch the
play button, the system will automatically breathe out last conversation. Call in
the process, short press the play key can hang up the phone. Short call state,
press the play key can I plug in the phone.
Bluetooth music playing, short press play button to play pause; Long press the
play button switch mode; Long press the volume button for volume; Short
press the volume up and down the first music.
8. T card playing:
Short press play button to play pause; Long press the play button switch mode;
Long press the volume button for volume; Short press the volume up and down
the first music. If the music on TV, and more than 10 minutes, then the system
automatically power off.
9. Calibration touch buttons:
The touch key for capacitance sensor, the key active (not to enter a dormant
state), more than 8 seconds long press button, the system will be touch
calibration. After calibration, key lights, move the fingers, to touch operation.
V. Charge Method
Plug the power cord into the unit's [USB] jack and the other end of the USB
into the computer's USB port, or connect the charger interface standard 5V
500mA , the charge of " Red Light" , full of " red light" off. The machine built
overcharge protection circuit can be connected to a computer or charge for a
long time , about three hours to fully charge the battery ; battery life every time
the volume due to the use of time varies .
Six , low battery
When the battery low occurs , the system will automatically shut down , then
please charge ; if the machine is not used for a long time , at least once a
month charge , you can protect the battery to extend battery life.
Seven , non- Bluetooth audio cup head soaked , try to use a wet cloth to clean
wrung Bluetooth speaker parts ; water if not careful , please promptly after the
power off and dry it .

Eight, glass with water level calibration MAX words, please don't over, such as
over a cup of inverse head will squeeze the water out, easy to soup
Nine , technical specifications
Supported models ; Android 4.3, IPHONE5
Output Power: 3W Working Voltage : 3.7V
Frequency Response : 100Hz-18KHz
SNR : ≥80dBA
Distortion: <1%
Audio input: Bluetooth, Computer
Support MP3: bit rate , 32Kbps-320Kbps
Speaker Unit : 52mm, double magnetism, 16 core , 4Ω
Input Power : Built-in polymer rechargeable battery or external DC5V
600mAh 3.7V
Adjusting: buttons adjust input sensitivity : 450 ± 50mV
Weight:380g/420g
Size:80*80*215mm
Ten , Troubleshooting
1, Q: boot automatically shut down ?
A: battery , please charge , recommended charging two hours before use.
2, Q: Play flash blue lights have been shut down or restart automatically after ?
A: battery , please charge , recommended charging two hours before use.
3, Q: can not be charged ?
A: Please check the power and charging cable, and make sure the access
charge 5V input voltage is normal .
4, Q: when charging red light does not light or red light is dark ?
A: normal phenomenon . If the battery is fully charged or fast full, the red
charging indicator may not light or dark.
5, Q: No sound speakers ?
A: OK in the Bluetooth mode and the device audio and speaker audio
connection is working , and check the two paired device volume .
6, Q: Bluetooth will not automatically connect ?
A: 1, only the success of paired devices into an effective working range
Bluetooth speaker will connect automatically.
2 , Please check with another Bluetooth speaker now has the device is kept
connected.
3 , check whether your own Bluetooth is turned on and working properly.
7, Q: Bluetooth no sound ?
A: 1, make sure that Bluetooth is connected successfully .
2 , make sure that the two paired Bluetooth devices or the volume is turned to
minimum .
8, Q: button no function ?
A: 1, check the Bluetooth speaker power has power.

2 , check whether the Bluetooth speakers in the boot state.
9, Q; Bluetooth stereo cup head after the water how to do ?
A: 1, if switched on, immediately shut down , do not energized , the available
hair dryer before use.
2, if in the off state , please do not energized , the available hair dryer
before use.
10, Q: TF play when not smooth?
A: please format the memory card, again to copy songs, song format is MP3,
name had better use English name, don't with punctuation marks.
Eleven , packaging accessories
Bluetooth cup head 1 , the data line 1 , Manual 1 , 1 certificate .
Twelve , precautions
In order to properly use the player the user to ensure that players with good
performance , please carefully read and follow :
Do not severely impact the the bottle or cup head
Do not touch benzene, thinner or other chemicals .
Do not go near a strong magnetic field , electric field .
Please avoid direct sunlight or heating appliances .
Do not disassemble , repair, or modification .
Do not listen to the maximum volume , so as to avoid adverse effects on
hearing .
packaging waste , batteries, used electronic products, please classification
properly handled.
Do not place the Bluetooth audio cup head soaked .
To make it easy for you to experience products, we are equipped with
detailed instructions for use , which you can get information about the product
introduction , usage and other aspects of knowledge , when you use the
machine read the instructions carefully before , if typographical errors or
translation hope customers understand mistakes .

FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the followingmeasures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
End users must follow the specific operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction
