247Security mDVR 500 Series User manual

Copyright © 2009, 247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
USERS MANUAL
mDVR512 / mDVR514

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
TABLE of CONTENTS
1. GENERAL INFORMATION AND SPECIFICATIONS
1.1. INTRODUCTION
1.2. SPECIFICATIONS
1.3. DIMENSION
1.4. CONNECTORS & LED LOCATIONS
1.4.1. FRONT PANEL
1.4.2. BACK PANEL
2. PREPARATION FOR USE
2.1. FRONT CONNECTORS
2.1.1. 10/100 BASE-T LAN CONNECTOR
2.1.2. VIDEO OUT CONNECTOR
2.1.3. AUDIO OUT CONNECTOR
2.1.4. USB 2.0 CONNECTOR
2.2. BACK CONNECTORS
2.2.1. POWER INPUT CONNECTOR
2.2.2. SERIAL PORT RS485, 5V CONNECTOR
2.2.3. EVENT MARKER CONNECTOR
2.2.4. RELAY OUTPUTS CONNECTOR
2.2.5. GENERAL PURPOSE INPUT / OUTPUT CONNECTOR
2.2.6. CAMERA 1,2,3 AND 4 CONNECTORS
2.2.7. WIFI CONNECTOR
2.2.8. RF MODEM CONNECTOR
2.2.9. GPS CONNECTOR
2.2.10. GENERAL PURPOSE INPUT / OUTPUT CONNECTOR
2.2.11. G-FORCE CONNECTOR
2.2.12. CELL MODEM CONNECTOR
2.2.13. 10/100 BASE-T W/ POE CONNECTOR
2.2.14. USB 2.0 CONNECTOR
2.3. CABLE REQUIREMENTS
2.3.1. POWER CABLE
2.3.2. EVENT MARKER CABLE
2.3.3. SENSOR / ALARM CABLE
2.3.4. CAMERA CABLE
2.3.5. GPS MODULE CABLE
2.3.6. NETWORK CROSS-OVER CABLE
2.3.7. MINI USB CABLE
2.4. CAMERA LENSES, WHAT VIEW, WHAT LENS
3. OPERATION
3.1. STATUS INDICATORS
3.1.1. IGNITION LED
3.1.2. POWER LED
3.1.3. HDD SAFE REMOVAL LED
3.1.4. HDD HIGH TEMPERATURE LED
3.1.5. HDD ACTIVITY LED
1

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
3.1.6. HDD POWER LED
3.1.7. ERROR LED
3.1.8. VIDEO LOST LED
3.1.9. USB ACTIVITY LED
3.2. HDD ON/OFF LOCK
3.3. MEDIA STORAGE REMOVAL
3.4. WIRELESS VIDEO RETRIEVAL
3.5. REMOTE POWER CONTROL
3.6. EVENT MARKING AND RETRIEVAL
4. CONNECTING TO DVR
4.1. IP CONFIGURATION
4.2. CONNECT CROSS-OVER CABLE
4.3. SETTING UP YOUR PC
4.3.1. USING WINDOWS XP
4.3.2. USING WINDOWS VISTA
5. DVR SETUP
5.1. STARTING DVRVIEWER
5.2. DVRVIEWER LOGIN
5.3. CONNECTING TO DVR
5.4. SETUP LOGIN
5.5. SYSTEM CONFIGURATION MENU
5.5.1. DVR SERVER NAME
5.5.2. ADMIN PASSWORD
5.5.3. DVR TIME ZONE
5.5.4. SHUTDOWN DELAY (S)
5.5.5. STANDBY TIME (S)
5.5.6. MAXIMUM FILE SIZE (MB) & MAXIMUM FILE TIME (S)
5.5.7. MINIMUM AVAILABLE DISK SPACE (MB)
5.5.8. EVENT MARKER
5.5.9. PRE-LOCK TIME (S) & POST-LOCK TIME (S)
5.5.10. STOP RECORDING WHEN PLAY BACK
5.5.11. STOP RECORDING WHEN LIVE VIEW
5.5.12. ENABLE FILE ENCRYPTION
5.5.13. FILE ENCRYPTION PASSWORD
5.5.14. GPS PORT
5.5.15. GPS BAUDRATE
5.6. CAMERA CONFIGURATION MENUS
5.6.1. ENABLE CAMERA
5.6.2. CAMERA NAME
5.6.3. RECORDING MODE
5.6.3.1. CONTINUE
5.6.3.2. TRIGGER BY SENSOR
5.6.3.3. TRIGGER BY MOTION
5.6.3.4. TRIGGER BY SENSOR/MOTION
5.6.3.5. NO RECORDING
5.6.4. RESOLUTION
5.6.5. FRAME RATE
5.6.6. BIT RATE MODE
2

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
5.6.7. BIT RATE
5.6.8. PICTURE QUALITY
5.6.9. BRIGHTNESS, CONTRAST, HUE, AND SATURATION
5.6.10. TRIGGERS
5.6.11. PRE-RECORDING & POST-RECORDING TIME
5.6.12. SHOW GPS SPEED ON OSD & SPEED DISPLAY
5.6.13. SHOW GPS COORDINATE ON OSD
5.6.14. RECORDING, VIDEO LOST & MOTION ALARM
5.6.15. MOTION SENSITIVITY
5.7. SENSOR CONFIGURATION MENU
5.7.1. SENSOR NUMBER
5.7.2. SENSOR 1 TO 6
5.8. NETWORK MENU
5.9. STATUS MENU
5.10. TOOLS MENU
5.10.1. DOWNLOAD CONFIGURATION
5.10.2. UPLOAD CONFIGURATION
5.10.3. UPDATE FIRMWARE & MCU FIRMWARE
6. DVRVIEWER
6.1. INTRODUCTION
6.2. SOFTWARE CLIENT FEATURES
6.3. SYSTEM REQUIREMENTS
6.4. INSTALLATION
6.5. STARTING DVRVIEWER
6.6. LIVE VIEW
6.6.1. SELECTING SCREEN LAYOUT
6.6.2. CAMERA SELECTION
6.6.3. CAMERA MENU
6.6.4. SNAPSHOT
6.6.5. SETUP
6.6.6. DISCONNECT
6.7. PLAY ARCHIVE
6.7.1. SEARCH VIDEO BY CALENDAR AND TIMELINE BAR
6.7.2. SEARCH VIDEO BY EVENT
6.7.3. PLAY BACK CONTROL
6.7.4. EXPORT VIDEO
6.8. PLAY FILE
6.9. SNAPSHOT
6.10. USERS
6.10.1. USER MANAGEMENT
6.10.2. ADD/DELETE USER
6.10.3. CHANGE USER PASSWORD
6.11. ERASE STORAGE MEDIA
7. SUPPORT INFORMATION
3

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
1. GENERAL INFORMATION AND SPECIFICATIONS
1.1. INTRODUCTION
DVR stands for Digital Video Recorder with one common goal, allowing end-users to record / retrieve real time
video files with a few mouse clicks. Within the last decade, video encrypt/decrypt algorithms achieved noticeable
improvement along with the availability of large capacity digital storage devices that draw attention to designing
DVR systems. With this in mind, 247Security Inc. has designed and built the mDVR510x Series equipment to
make this transition smooth for the in-vehicle applications, specifically the transportation industry.
The mDVR510x employs high performance video compression H.264 standard to optimize video/audio data
stream so that it can be sent over a network or stored directly on a local disk. The compression algorithm mainly
runs on a DSP Engine, therefore freeing up valuable resources within the system to do other jobs. The mDVR510x
has features such as dynamic bit rate, controllable frame rate (max 30fps/channel), image quality control, real-
time previewing on all channels, alarm triggers, sensor configuration, easy retrieval and transfer of video files over
WIFI/LAN, GPS tracking and much more. In addition, mDVR510x allows end-users to independently manipulate
these parameters for each camera if desired.
1.2. SPECIFICATIONS
ELECTRICAL
Video Recording Resolution
•Each channel can be set independently using D1 (704x480), DCIF (528x320), 2CIF (704x240), CIF (352X240)
and QCIF (176x120) configurations.
Video Compression
•H.264 compression, highest quality video images and lowest bandwidth usage on the market today. Five
different levels of video quality configurations.
Video Recording Frame Rate
•Channels can be independently set to record from 1fps to 30fps
•All channels can record simultaneously at 30fps with D1 (704x480) resolution
Video recording channels
•2, 4 or 8 channels, 30fps/channel
Audio Recording Channels
•2, 4 or 8 audio channels; Camera has built-in noise-reduction microphone
•One audio recording channel synchronized to each video recording channel
Camera connection
•Video, Audio, Power and Encryption all in one cable, with locking mechanism
Internal video storage
•Hot Swap Removable drive
•Up to 750 GB
•Rugged
•USB. 2.0
•Integrated heater
4

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
Wireless Network
•WLAN 802.11g/n
•RF900 Modem
GPS
•GPS module can be connected to DVR using one cable, up to 40’ in length
•GPS data can be logged for over 15 years
Ethernet
•Two 10/100 Base-T Ethernet ports
•IEEE 802.3u 100BASE-T Fast Ethernet compatible
Sensors
•Up to 12 sensors can be connected
Alarms
•Up to 4 alarms can be connected
Indicators
•Ignition LED (amber)
•Power LED (green)
•HDD activity LED (green)
•USB LED (green)
•Error LED (red)
•Video Lost LED (red)
PHYSICAL/POWER
Housing
Ionized Aluminum for rugged applications
Form factor
Depth: 194 mm (7.625 inches)
Width: 176 mm (6.875 inches)
Height: 58 mm (2.313 inches)
(Not including shock and vibration isolator)
Weight
Typically approximately 1.3 kg (2.8 lb)
(Not including shock and vibration isolator)
Power supply
Vehicle power supply switcher
ESD protected
Battery
Lithium Coin Cell CR2032 (20.0 x 3.2 mm)
3 V / 235 mAh
5

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
Input Power Range
+8 VDC ~ +24 VDC normal operating voltage
+6 VDC ~ +28 VDC abnormal operating voltage up to 10 seconds
Over and under voltage protection
Ignition Signal / Power Down Timer
Software configurable delay power off signal from 1-120 minutes
50mA current draw in sleep mode after power down
Power consumption
Typical 12W (5°C ~ 55°C)
DVR draws less than 24ma when off
ENVIRONMENT
Temperature range
-30°C to +55°C (-22°F to +131°F) operating temperature
Relative humidity
10% to 90% non-condensing
6

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
1.3. DIMENSIONS
The dimensions used in the following 2 diagrams are in inches.
7

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
1.4. CONNECTORS & LED LOCATIONS
1.4.1.FRONT PANEL
HDD
High Temp
LED
HDD
Activity
LED
HDD
Power
LED
Removable
Hot-Swap
Hard Drive
Ignition
LED
Power
LED
HDD Safe
Removal LED
HDD On / Off
Ke
y
lock
10/100
Base-T
Video
Out
Audio
Out
Error LED Video
Lost LED
USB 2.0
USB
Activity
LED
1.4.2.BACK PANEL
General
Purpose
I/O
Power
+8 ~ +24V
DC IN
RS485 &
+5V DC
O
UT
Event
Marker
Video, Audio Input
12VDC Out
p
ut
Relay
USB 2.0Wi-Fi RF
Modem
GPS General
Purpose
I/O
G-Force Cell
Modem
10/100 Base-T with
Power-Over-Ethernet
8

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2. PREPARATION FOR USE
2.1. FRONT CONNECTORS
2.1.1. 10/100BASE-T LAN CONNECTOR
The RJ45 port allows access to the DVR from your laptop / computer using the included cross over cable. This port
is labeled as LAN and has a default static IP address of 192.168.1.100.
Pin Number Signal Description Pin out
1 TX+ Transmit Data +
2 TX- Transmit Data -
3 RX+ Receive Data +
4 RX- Receive Data -
5 NC Not connected
6 COM Common
7 COM Common
8 COM Common
9 COM Common
2.1.2. VIDEO OUT CONNECTOR
Connector type: RCA Jack
Pin Number Signal Description Pin out
Inside Video Video Signal
Outside GND Ground
2.1.3. AUDIO OUT CONNECTOR
Connector type: RCA Jack
Pin Number Signal Description Pin out
Inside Audio Audio Signal
Outside GND Ground
9

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.1.4. USB 2.0 CONNECTOR
Connector type: 4-pin friction-lock header
2.2. BACK CONNECTORS
Pin Number Signal Description Pin out
1 VCC Cable Power +5 V
2 -Data Balanced Data Line -
3 +Data Balanced Data Line +
4 GND Cable Ground
2.2.1. POWER INPUT CONNECTOR
The mDVR510x has a built-in Intelligent power switcher that can operate from +8V ~ +24V DC-IN. The
ON/OFF signal connects to the vehicle’s ignition signal. The mDVR510x uses this signal to trigger the power shut-
off delay and the timing circuitry. The mMVR5100 will remain ON until the shut-off delay time has been reached.
The system will then go through its normal shutdown procedures before completely powering down. The GND
(Common DC ground) signal should be connected to the vehicle common ground.
Pin Number Signal Description Pin out
1 ON/OFF
On/Off Switch
On when 6V ~ VIN
Off when 0V ~ 0.5V
2 GND Ground
3 VIN Input voltage (+8V~+24VDC)
4 GND Ground
2.2.2. SERIAL PORT RS485, 5V CONNECTOR
This connector provides 5V DC output and RS485 communication in case a PTZ camera needs to be installed.
Pin Number Signal Description Pin out
1 RS485 T(+)
2 RS485 R(+)
3 +5V
4 RESERVED
5 RS485 T(-)
6 RS485 R(-)
7 GND
8 +5V Standby
10

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.2.3. EVENT MARKER CONNECTOR
This connector is used to plug in the included event marker cable.
Pin Number Signal Description Pin out
1 DI_0
2 GND
3 +12V OUT
4 Output DO_0
5 Output DO_1
6 Output DO_2
2.2.4. RELAY OUTPUTS CONNECTOR
Pin Number Signal Description Pin out
1 Relay_A1
2 Relay_B1
3 Relay_A2
4 Relay_B2
2.2.5. GENERAL PURPOSE INPUT / OUTPUT CONNECTOR
This connector provides 4 digital inputs and 1 digital output. The digital inputs are labeled as DI_1, DI_2, DI_3,
DI_4. The digital output is labeled as DO_3. End-users can assign any sensors to one of these digital input signals.
Up to 4 sensors can be wired to the mDVR510x. Alternatively, one alarm (LED, Siren, etc.) is available on the
digital output.
Pin Number Signal Description Pin out
1 Input DI_1
2 Input DI_2
3 Input DI_3
4 Input DI_4
5 Motion Sensor
6 Output DO_3
7 GND
8 GND
9 +10V Standby
10 +10V Standby
11

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.2.6. CAMERA 1,2,3, AND 4 CONNECTORS
The mDVR510x supports a maximum of 4 cameras. These Micro-fit connectors are used to connect the four
camera inputs to the mDVR510x system (video and audio). Also included in each camera connection is DV12V Out
to power the camera. You can refer to the cover of the DVR for the PIN assignments of each connector. If any of
these cameras are not connected properly (for instance loose cables, unplugged etc…) than the mDVR510x
intelligently notifies the end-users with “NO VIDEO” on the preview screen. Camera inputs are labeled CAMERA 1,
CAMERA 2, CAMERA 3, and CAMERA 4.
Pin Number Signal Description Pin out
1 MIC-IN Microphone In
2 GND Ground
3 Video+ Video In (+)
4 Video- Video In (-)
5 +12VDC +12VDC OUT
6 GND Ground
2.2.7. WIFI CONNECTOR
Connector type: RP-SMA Jack
Pin Number Signal Description Pin out
1 RF RF Signal
2 GND RF Ground
2.2.8. RF MODEM CONNECTOR
Connector type: RP-SMA Jack
Pin Number Signal Description Pin out
1 RF RF Signal
2 GND RF Ground
12

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.2.9. GPS CONNECTOR
Connector type: D-SUB 9-Pin Male
Pin Number Signal Description Pin out
1 DCD Carrier detect
2 RXD Receive data
3 TXD Transmit data
4 DTR Data terminal ready
5 GND Ground
6 DSR Data set ready
7 RTS Request to send
8 CTS Clear to send
9 5V
5V (±5%)
2.2.10. GENERAL PURPOSE INPUT / OUTPUT CONNECTOR
This connector provides 6 additional digital inputs as well as video and out signals. The digital inputs are labeled
as DI_7, DI_8, DI_9, DI_10, DI_11 and DI_12. End-users can assign any sensors to one of these digital input
signals. If the front Video Out and Audio Out RCA jacks cannot be used than pins 1 and 2 can be used instead.
Pin Number Signal Description Pin out
1 Video Out
2 Audio Out
3 Input DI_7
4 Input DI_8
5 Input DI_9
6 Input DI_10
7 Input DI_11
8 Input DI_12
9 +5VDC OUT
10 GND
2.2.11. G-FORCE CONNECTOR
Pin Number Signal Description Pin out
1 UART_RD- Receive Data (-)
2 UART_RD+ Receive Data (+)
3 UART_TD+ Transmit Data (+)
4 UART_TD- Transmit Data (-)
5 GND Ground
6 +5VDC +5VDC OUT
13

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.2.12. CELL MODEM
Pin Number Signal Description Pin out
1 DCD Carrier detect
2 RXD Receive data
3 TXD Transmit data
4 DTR Data terminal ready
5 GND Ground
6 DSR Data set ready
7 RTS Request to send
8 CTS Clear to send
9 RI Ring
10 +5VDC
+5VDC OUT (±5%)
2.2.13. 10/100BASE-T LAN CONNECTOR
This network RJ45 port allows access to the DVR from your laptop / computer using the included cross over cable.
This port is labeled as LAN 1 and has a static IP address of 192.168.1.101.
Pin Number Signal Description Pin out
1 TX+ Transmit Data +
2 TX- Transmit Data -
3 RX+ Receive Data +
4 RX- Receive Data -
5 NC Not connected
6 COM Common
7 COM Common
8 COM Common
9 COM Common
2.2.14. USB 2.0 CONNECTOR
Connector type: 4-pin friction-lock header
Pin Number Signal Description Pin out
1 VCC Cable Power +5 V
2 -Data Balanced Data Line -
3 +Data Balanced Data Line +
4 GND Cable Ground
14

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.3. CABLE REQUIREMENTS
2.3.1.POWER CABLE
A 15 ft three wire power cable is included for connection between the DVR and your vehicle power and ignition
signals. It is highly recommended that in-line fast blow fuses (7.5 - 10 amps) be installed on the two power input
connections for safety pre-cautions.
Wire Color Signal Description Picture
Red VIN Input voltage (8~24VDC)
Black GND Ground
White ON/OFF
Ignition switched power
(only hot when ignition is
in RUN/ACC
2.3.2.EVENT MARKER CABLE
A 15 ft cable is already connected to the Event Marker and pre-wired to a 2X3 Molex connector; the Molex
connector will then connect to the event marker port on the back of the DVR. The event marker uses 3 digital
outputs for Video Lost, Recording & Power LED’s and 1 digital input for the push button. The push button is used
for pre/post trigger recording which when pressed, marks the video files at that specific moment. Pre-event and
Post-event time locking can be configured in the DVR setup.
Connector Signal Description Picture
Connects to Event Marker
connector on DVR
6-Pin
Molex
15

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.3.3.SENSOR / ALARM CABLE
A 15 ft sensor / alarm cable is provided to connect the 4 digital inputs, 1 digital output and motion sensor signals
to the GP I/O port of the DVR.
Wire Color Signal Description Picture
Brown Input DI_1
Connects to Digital Input 1
of GP I/O connector (Pin
1)
White/
Green Input DI_2
Connects to Digital Input 2
of GP I/O connector (Pin
2)
Green Input DI_3
Connects to Digital Input 3
of GP I/O connector (Pin
3)
White/
Orange Input DI_4
Connects to Digital Input 4
of GP I/O connector (Pin
4)
Orange Motion
Sensor
Connects to Motion Sensor
of GP I/O connector (Pin
5)
White/
Brown Output DO_3
Connects to Digital Output
3 of GP I/O connector (Pin
6)
Blue GND
Connects to GND of GP I/O
connector (Pin 7)
Connects to GND of GP I/O
connector (Pin 8)
White/ GND
Blue
2.3.4.CAMERA CABLE
STP (shielded twisted pair) cable is the standard and will use 2X3 Molex plugs for connections making the
installation simple and straight forward. The cable connectors are keyed so they cannot be connected incorrectly.
Connect one end of the cable to one of the available camera inputs on the DVR and the other end into the camera.
Connector Signal Description Picture
6-Pin
Molex Connects to DVR
6-Pin Connects to camera
Molex
16

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.3.5.GPS MODULE CABLE
A GPS module attached to a 25 ft cable connects to the back of the DVR using a DB9 connector
Connector Signal Description Picture
DB-9
Connects to GPS
connector on DVR
2.3.6.NETWORK CROSS-OVER CABLE
This cable connects a computer / laptop to the 10/100BASE-T LAN connector using the network standard RJ45
connector so that user can setup the DVR parameters as well as preview the video and audio from the video
channels.
Connector Signal Description Picture
RJ45
Connects to 10/100BASE-
T LAN connector
2.3.7.MINI USB CABLE
This cable connects the mDVR removable storage media to your computer or laptop for video / audio playback.
This is a standard USB 2.0 Type A to 5 Pin mini-B Cable which should be no longer than 12 to 16 inches. See
section 6 for instructions on how to use the DVRViewer application to connect to the storage media and play back
your recorded video and audio.
Connector Signal Description Picture
USB 2.0 Type
A Connects to your
computer
Connects to the mDVR
storage media
USB 2.0
5 Pin mini-B
17

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
2.4. CAMERA LENSES, WHAT VIEW, WHAT LENS
The chart below can be used as a guide when ordering and installing cameras in your vehicle.
Lens Angle of View Best focus distance Viewable distance
2.9mm 120° 4 ft 10 ft
3.6mm 92° 5 ft 12 ft
6.0mm 54° 8 ft 20 ft
8.0mm 39° 10 ft 28 ft
12mm 26° 13 ft 35 ft
16mm 19° 20 ft 56 ft
Viewable distance means maximum range of the optimum standard
18

247Security Inc. | 4400 North Point Parkway, Suite # 158, Alpharetta, GA 30022, USA | 1-866-693-7492 | www.247securityinc.com
3. OPERATION
3.1. STATUS INDICATORS
3.1.1. IGNITION LED
This LED is to notify the operator that the vehicle’s ignition has been turned on which will then turn on the DVR.
This LED will be blinking when ignition is turned on and until DVR powers on. This LED will also blink when ignition
is turned off and until DVR powers off.
3.1.2. POWER LED
This LED is to notify operator that system power is on.
3.1.3.HDD SAFE REMOVAL LED
This LED when blinking is to notify operator to NOT remove HDD until blinking stops. When this LED is blinking,
system is properly closing all data files on the HDD, once all data files are closed HDD power is switched off,
blinking stops
3.1.4.HDD HIGH TEMPERATURE LED
This LED is to notify the operator that the HDD temperature is over the maximum HDD operating temperature.
3.1.5.HDD ACTIVITY LED
This LED is to notify operator that there is hard drive activity.
3.1.6.HDD POWER LED
This LED is to notify operator that the HDD is powered on and that it’s ready to record data.
3.1.7.ERROR LED
This LED is to notify operator that the system has encountered a problem and cannot continue normal operation.
Please call tech support for troubleshooting procedures.
3.1.8.VIDEO LOST INDICATOR LED
This LED is to notify operator when any of the enabled cameras loses video signal meaning the cable is cut or is
not connected.
3.1.9.USB ACTIVITY LED
This LED is to notify the operator that there is USB activity, which means that data files are being downloaded from
the HDD to the USB thumb drive or that a firmware upgrade is in progress. Do not remove USB thumb drive until
LED stops blinking.
19
