Vicon V662-D-1 Operating instructions

www.vicon-security.com
Installation and Operation Guide
XX259-00-01
V662-D-1 High-Resolution
Analog WDR Camera
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788
Tel: [phone] Fax: [phone] Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Document Number: 8009-8259-00-01 Issued: 513
Copyright © 2013 Vicon Industries Inc. All rights reserved.

LIMITATION OF LIABILITY
- ii -
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL
RESPECTS; HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS
OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE
SUCH CHANGES

WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT
ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS
OR OTHER OPENINGS ON THE EQUIPMEMT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
- iii -

FCC COMPIANCE STATEMENT
CE COMPLIANCE STATEMENT
- iv -
FCC INFORMATION: This equipment has been tested and found
to comply with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
CAUTION: Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-
003 du Canada.
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required
to take adequate measures.

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from th
e apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been moisture, does not operate normally, or has
been dropped.
15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE
BY QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE
RISK OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING
OTHER THAN THAT CONTAINED IN THE OPERATING INSTRUC-
TIONS UNLESS YOU QRE QUALIFIED TO DO SO.
- v -
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/
Listed Class 2 power source only.

- vi -
PRECAUTIONS
Before installation, carefully read the manual to ensure correct operation and setup,
heeding all warnings and instructions.
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
Ensure manual is kept in good condition for future use.
Do not install the device near any heat sources such as radiators, heat registers, stoves,
or other equipment (including amplifiers) that produce heat.
Only use attachments/accessories specified by the manufacturer.
Should any liquid get into the housing, immediately disconnect the device from the
power supply and have it checked by authorized personnel before reusing.
Do not install the device in a place of high humidity or where exposed to gas or oil.
Installation and servicing by authorized personnel only, adhering to local safety
regulations.
Unless you are an authorized technician, never try to dismantle the device. To avoid
electric shock, never remove the screws or covers.
If a camera, do not expose the device to radioactivity. It will cause serious damage to
the CCD.
Use Certified/Listed Class 2 power source only.
Cleaning
Clean the device with a slightly damp soft cloth. Use a mild household detergent. Never
use strong solvents such as thinner or benzene as they might damage the finish of the
unit.

TABLE OF CONTENTS
CONTENTS OF PACKAGE ------------------------------------------------------------------------- 1
INTRODUCTION --------------------------------------------------------------------------------------- 2
CAMERA OVERVIEW -------------------------------------------------------------------------------- 3
CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 4
CONTROL AND CONNECTIONS / DAY&NIGHT I/O TERMINALS----------------------- 14
LENS ----------------------------------------------------------------------------------------------------- 15
SPECIFICATIONS ------------------------------------------------------------------------------------- 16
CONTENTS OF PACKAGE
Installation of the camera must be performed by qualified service personnel in
accordance with all local and national electrical and mechanical codes.
Carefully remove the color camera and its accessories from the carton and verify that
they were not damaged in shipment.
The contents of the package include:
1. Color CCD camera
2. Mini-DIN connector (for video-or DC-type auto-iris lens)
3. CS adapter ring for C mounting "C" lenses
4. This manual
- 1 -

INTRODUCTION
The V662-D-1 camera provides high-quality images using Sony 1/3” CCD and digital
signal processing LSIs.
Features:
1/3" Super-HAD CCD
Super High-Resolution (700 TVL)
Wide Dynamic Range (~x512)
Day & Night (Auto, Manual, External, Filter Delay, Change Level Adjust)
0.1 Lux (Color), 0.01 Lux (BW), 0.0001 Lux (Sens-Up B/W) @ F/1.2, 50IRE
Auto Electronic Shutter [1/60 (50) ~ 1/100,000] and Manual Electronic Shutter
Modes [1/60 (50) ~ 1/10,000]
Sens-Up (~x256)
2D-NR, 3D-NR
UDF Function(Ultra Deep Field)
Multi Camera Configuration Set (4-Sets/Night Profile, External Day/Night
Profile)
PVA/PVA+ (Personal Video Analytics)
Many Configurable Parameters
Various Detection Methods (Motion, Loitering Object, Abandon, Scene
Change, Unfocus, Windy Area)
Various Zone Event Detection Methods and Event Area Combinations
8 Objects Trace, 4 Objects Display
Concurrent Processing with All Detections and All Objects
Two Counting Blocks
Event String Sending (Editable String)
Digital Tracking (Using D-PTZ)
Various Detection Areas (max. 10 areas; Line, Rectangle, 4-Point
polygonal)
Backlight Compensation (EHLC, Auto, Spot)
i-Freeze Function (reduces recording space)
Privacy Mask or Mosaic (max. 10 areas; 4-point polygonal/transparency)
Digital Image Stabilization
Digital PTZ
Digital Effect (H/V reverse, 180 degree rotate, inverse, freeze)
White Pixel Removal
Focus Aid Function
Color Rolling Suppression
System Lock (4-character password)
C/CS, Back-Focus Camera for Easy Adjustment
Auto and Manual White Balance Modes
Supports Line-Lock External Synchronization
RS-485 Remote Camera Control
Multi-Language
Compatible with Video, DC-Type Lenses with OSD Select
Quick Connect for Video or DC Lens with 4-Pin Connector
User Certified/Listed Class 2 Power Source only
Operates in 12 VDC or 24 VAC
- 2 -

CAMERA OVERVIEW
FRONT VIEW
SIDE VIEW
TOP VIEW


Left Button
Up Button
Enter Button
Right Button
Down Button
Day/Night External I/O
Motion ALARM OUT
RS-485/UTP (optional)
Power Indicator
Video Output Connector (BNC)
UTP or BNC Transformation Switch
(optional)
AC/DC Compatible Input Terminal
AC Power Cord
REAR VIEW (Free Voltage)







REAR VIEW










- 3 -

<Navigating the Menu System>
1) Menu: Represents the present menu subject on top of screen.
When using Multi-Camset, CAM ID and “camset” name included.
Common Headers:
: Currently active menu item is displayed. Move with Up/Down keys.
: There is sub-menu. Press Enter key to go to sub-menu.
: Indicates the selected menu item.
Item: Displays the current control item being adjusted.
Item: Disabled menu item or can’t adjust.
2) Bottom Line Control Bar
Exit: Exit menu mode. Pop-up menu displays when configuration changes.
- Overwrite: Save the changed data to save area.
- Restore: Cancel the changes. Read from save area.
- Cancel: Return to menu.
Load: Load saved data.
- Default: Load default configuration from default area.
- Backup: Load saved configuration from backup area.
- Cancel: Return to menu.
Save: Save current configuration.
- Save: Save current configuration to save area.
- Backup: Copy configurations to backup area.
- Cancel: Return to menu.
Back: Return to previous menu.
NOTE:
* There are 4 types of configuration areas:
Editing Area (No Save), Default (Read Only). Save Area (Use on Start), Backup
* Do not Power off while doing a Save, Load, Backup or Overwrite.
CAMERA ADJUSTMENT
<White Balance>
1) ATW/Wide Mode: No limits in the range of color temperature.
2) ATW/Indoor Mode: Suitable for low color temperature.
- CRS (Color Rolling Suppression) Mode supported.
NOTE:
* When the CRS is selected, it will be processed in the following order:
Checking Condition: Checking current environment within the range.
Checking Variation: Measure color rolling range during 30 seconds.
User can stop this action.
No Need CRS: Variation is low. There is no need to use CRS function.
Force CRS: Even if color variation is low, use CRS function.
- ATW Range: Adjust AWB Range.
- Convergence Shift: Adjust AWB target.
R Variation: Represent blue variation.
B Variation: Represent red variation.
3) ATW/Outdoor Mode: Suitable for high color temperature (natural light).
- 4 -
4) Fix/Indoor Mode: Fixed color temperature (3200 ºK) mode, for indoor environment.

-R: Adjust red color.
-B: Adjust blue color.
- Push/Set: Tracking WB of current screen and represent R, B values.
- Default: Restore R, B default values.
5) Fix/FL Mode: Fixed color temperature mode (fluorescent lamp environment).
6) Fix/Outdoor Mode: Fixed color temperature (6300 ºK) mode, for outdoor
environment.
<Auto Exposure>
NOTE:
* MIN_SHT (Minimum shutter speed): NTSC: 1/60sec/PAL: 1/50sec
* MAX_SHT (Maximum shutter speed): 1/100000 sec
* FLC_SHT (Flickerless shutter speed): NTSC: 1/100sec/PAL: 1/120sec
1) AE Mode
- Full Auto: DC Lens or Video Lens – Fix shutter speed to MIN_SHT.
Manual Lens - Operating as shutter mode.
- Fast SHT (Fast shutter mode): Adjust range - 1/250~1/10000
-SHT Fix (Shutter Fix Mode): Shutter speed is fixed at a given value.
NOTE:
* If lighting is not enough, noise may be increased.
* If lighting is enough using AGC maximum, automatically decreases shutter speed.
2) UDF (Ultra Deep Field)
Depending on lighting conditions and motion state, automatically adjusts AE and DNR.
Normally in low light environment, Sens-up feature may miss the movement of objects
and high AGC value increases the noise. UDF function effectively improves
this phenomenon.
NOTE:
* No Motion: Noise removal mode.
* Motion has occurred: Fast screen update mode.
3) Low Light: If using UDF function, this function must be disabled.
-AGC: Boost the signal and adjust the brightness (Off/Low/Mid/High).
-Sens-Up: By adding up multiple fields, adjust the proper brightness in low light
conditions (2X~ 256X)
-Apert: In low light conditions, reduce noise by lowering the sharpness value.
- Color: In low light conditions, reduce noise by lowering the color value.
4) WDR (Wide Dynamic Range)/WDR-Lite
WDR function cannot be used with the BLC and is recommended in Full Auto Modes.
-Visibility: Increase sharpness of the high brightness region.
-Comb Bal (Combination Balance): Adjust the balance of high and low luminance
areas.
- Brightness: Adjust brightness level of WDR.
5) BLC: Backlight Compensation/BLC function cannot be used with WDR function.
- EHLC (Excessive High Light Compensation): Fill high brightness areas with gray
color; clip the area with more brightness than the threshold value.
Clip Th (Clipping Threshold): Adjust clipping level.
Clip Mask (Clip Mask Brightness): Select gray color of clipping area.
- Auto: Weight on the dark area of AE, splitting among the 9 areas.
- 5 -
- Spot: Weight on the specified area of AE.

6) Brightness: Adjust AE reference level.
<Mask>
Up to 10 Privacy Zones can be configured. Because they share area ID with PVA
Zones, they cannot use the same ID.
1) Zone:Select mask number.
NOTE:
*If you see "PVA" in the “Func” menu, PVA function is currently being used in the area.
2) Func: Select mask on/off.
3) Color: Select mask color (15 colors available).
4) Transparency: Change the mask transparency.
5) Mosaic: Make mosaic current area.
6) Frame: Border display current area.
7) Shape: Select the shape of mask (4-point polygon or rectangle).
- Rect (Rectangle)
Adjust rectangle size with 4-arrow keys; press [ENTER] key to finish editing area.
- Poly (4-Point Polygon/each point can move)
Select one of “a, b, c, d”; the active point is displayed. Move the point with
4-arrow keys; press [ENTER] key to finish editing area.
NOTE:
* More than 180º of interior angle is not permitted.
- Posi: Adjust area position with 4-arrow keys.
<PVA/PVA+ (Personal Video Analytics)>
PVA is the name of the video analytics.
If you exit menu, doing Initialize started while 4~5 seconds the background.
During initialization the background, it is good to be none of moving objects.
When Day / Night mode is changed or Camera Setting is changed, the background of
the re-initialization performed.
Global Functions: These functions are performed in the entire area.
- Output Select: Specify the outputs for each function to be enabled; press [ENTER]
key to select output of each detection zone.
Alarm: Trigger alarm to output port.
Communication: Event string sends on RS-485.
Screen: Display on screen.
Back: Return to previous menu.
- Detections
Motion: General motion detection.
Loitering: Detect loitering objects on entire screen within a set period of time.
NOTE:
* Do not use this as a signal to start video recording.
*The loitering detection can be inaccurate.
Abandon/Absent: Detect the difference compared to stored background.
NOTE:
- 6 -
* Do not use this as a signal to start video recording.

*The abandon/absent detection can be inaccurate.
Scene Change: Detect a change in the screen.
NOTE:
* This is good for detecting scene changes, including vertical lines or high contrast objects of
the background.
* Do not use this as a signal to start video recording.
*The scene change detection can be inaccurate.
Windy Area Detection: Detect continuous movement caused by wind, etc.
If this same movement occurs in same area, alarm is ignored in this area.
If no motion is detected for a period of time, windy area turns off.
NOTE:
* Do not use this as a signal to start video recording.
* Not supported in Simple mode.
*The windy area detection can be inaccurate.
1) Zone Based Functions
Max. of 10 zones can be configured.
NOTE:
* Because they share area ID with Privacy Mask, it cannot use same ID.
- Zone: Select zone ID.
- Func (Function): Zone Function On/Off (blinking enabled area).
- Shape: Select area shape.
Color: Select area’s frame color.
Rect (Rectangle): Adjust rectangle with 4-arrow keys; press [ENTER] key to finish
editing area.
Poly (Polygon)
It you select one of “a, b, c, d”, the active point is displayed.
Move the point with 4-arrow keys; press [ENTER] key to finish editing point.
NOTE:
* More than 180º of interior angle is not permitted.
Line: Select Start/End Point. If you select one of start/end, the active point is
displayed. Move the point with 4-arrow keys; press [ENTER] key to finish editing
point.
Posi: Adjust area position with 4-arrow keys.
- MD Event
NOTE:
*The MD event detection can be inaccurate.
Zone: Configurations for various zone events.
Following area, possible events are different.
Output Select: Press [ENTER] key on icon for event popup box to appear.
Alarm: Trigger alarm to output port.
Communication: Event string sends on RS-485.
Screen: Display on screen.
Back: Return to previous menu.
- 7 -
,: Send event to counting machine (OFF: No Effect/INC: Increment

counting value/DEC: Decrement counting value).
NOTE:
*The counting value can be inaccurate.
Screen: Printed event at bottom side by side scrolling.
- 8 -
Icon Subject Range
Motion Rect, Poly,
Line
Motion occurred.
Motion Inside Rect, Poly Motion occurred in the area.
Move Into Rect, Poly Object on outside moves into the area.
Appear Inside Rect, Poly Object which appeared inside.
*) Not supported in Simple mode.
Move Out Rect, Poly Object moves out.
*) Don’t use as a signal for starting video
recording.
Appeared &
Move Out
Rect, Poly Object which appeared inside, and moves out
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
Disappear
Inside
Rect, Poly Object disappeared inside.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
Moved In &
Disappear
Rect, Poly Objects from outside, move into inside, and
disappears inside.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
Loitering Rect, Poly Detect moving object within the zone during a
time.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
Abandon/
Absent
Rect, Poly Detect different region to stored background.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
In & Out
Direction
Rect Detect object moving. From top to enter of
area, detecting direction of moving out.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
In & Out
Direction
Rect Detect object moving. From right to enter of
area, detecting direction of moving out.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
In & Out
Direction
Rect Detect object moving. From left to enter of
area, detecting direction of moving out.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
In & Out Rect Detect object moving. From bottom to enter of

Direction area, detecting direction of moving out.
*) Don’t use as a signal for starting video
recording.
*) Not supported in Simple mode.
Move
Clockwise Line Event will occur the object moves in a
clockwise direction that start around.
*) Don’t use as a signal for starting video
recording.
Move Conter-
Clockwise Line Event will occur the object moves in a counter-
clockwise direction that start around.
*) Don’t use as a signal for starting video
recording.
Path Event: Detect route between two zones (max. detection of 10 paths.)
NOTE:
* Disabled zone cannot be configured.
* Not supported in Simple mode.
*The path event detection can be inaccurate.
Output Direction Setup: Same as zone output configuration.
Clear All: All path combinations clear.
2) Env. Setup (Environment setup): Configurations for each PVA function.
- Md Sens (MD Sensitivity): Adjust motion sensitivity (HW sensitivity).
- Loiter Time (min): Time to judge if loitering object.
- Abandon/Absent Setup
Sens (Sensitivity): Adjust sensitivity of abandon/absent detection.
Det Time (min): Time to judge if absent/abandon area.
Rst Time (sec): Time to maintain event. After this time, background will update.
- Scn Chg Setup (Scene Change Setup)
Sens (Sensitivity): Adjust sensitivity of scene change detection.
Chg Ratio: Adjust judgment ratio of change from the stored background.
Det Time (sec): Time to judge scene changes.
Rst Time (sec): Time to maintain event. After this, background will update.
Unfocus: Detection on/off of unfocused state/defocused state.
- Windy Setup (Windy Area Detection Setup):Not applied in Simple PVA mode.
Sens (Sensitivity): Adjust sensitivity of windy object detection.
Det Time (sec): Time to judge if windy object.
Rst Time (sec): Time to release if windy object stays with no motion
3) Display Setup: Configuration for information on screen.
NOTE:
* Priority: Abandon/Absent > Loiter > Moving Object > Windy
* Same priority: large object size order
Alarm: Represent alarm icon on right-up side by of screen.
Counter: Represent counting on left-bottom (Det Only: When an event occurs).
Zone Area: Represent active zone.
Moving Object: Represent moving object with white rectangle.
Loitering: Represent loitering object with green rectangle.
Abandon/Absent: Represent abandon/absent area with wine colored rectangle.
Windy Area: Represent moving object with violet rectangle.
4) dTracking Setup: Configurations for digital Pan/Tilt/Zoom.
- 9 -
NOTE:

* Priority: Tracking priority: Zone > Loitering > Abandon/Absent > Obj.
* Maximum 4 objects can be represented.
* Same priority: Continuing detect. And Obj. > Size
- All Object: Tracking all detected objects.
- Loitering: Tracking detected loitering object.
- Abandon/Absent: Tracking detected absent/abandon area.
- Zone: When zone event occurs, tracking the area.
<Picture/DNR (Picture/Digital Noise Reduction)>
Menu for adjustment of video quality and DNR.
1) Sharpness:Adjust sharpness of outlines (0~15).
2) Enhancement:Select high resolution mode (Low/Mid/High).
3) 2D-NR: Adjust 2D-NR strength.
4) 3D-NR: Adjust 3D-NR strength. Remove noise by adding up several frames.
5) DNR Demo: Represent DNR effect. Left side is no DNR screen, right side shows
DNR screen.
6) Color Enh (Color Enhance): Adjust color strength.
<Effect>
1) Freeze: When [ENTER] key is pressed, still image is output on the screen.
2) d-Effect: Off/Rotation/Mirror/V Flip
3) Nega (Negative Picture): Inverse color effect.
4) DIS (Digital Image Stabilization): Compensation for image vibration.
Use of this function causes d-PTZ screen magnification to change.
5) dPTZ Preset: Configuration for d-PTZ preset. This will be applied when menu is
exited.
- Zoom: Adjust magnification.
- Pan&Tilt: Adjust Pan/Tilt position.
- Up/Down: Adjust tilt position.
- Left/Right: Adjust pan position.
6) i-Freeze: Select time of refresh rate for output video. This function is useful to reduce
the recording data storage. When motion is detected during i-Freeze, image is refreshed
to live mode. This is used not only to reduce the recording data but also not to miss
object movement.
- No Motion(s): Adjust Interval while no motion.
- Motion (0.1s): Adjust Interval while motion exists.
<System Setup>
1) General
- Cam Info: Display camera basic information.
NOTE:
* Cam ID/Baud rate/Protocol/Lens Type/CCD Type/Video System/Firmware Version
- System Lock: System locking by 4-character PID (Lock/Unlock).
- Change PID: Change PID used in the system lock.
NOTE:
* Enter PID: Input previous password. Default PID is “0000”.
* Enter New PID: Input new password.
* Retype New PID: Confirm new password.
- 10 -
- Title: Change camera title (max. of 8 characters).

- Display: Configurations for display camera ID & title.
Cam ID: Select camera ID display on/off.
Title: Select title display on/off.
Display Pos: Change position the string location.
- Language: Change menu OSD language.
2) Setup Tools
- System Config
Multi-Camset: Select On (user can use 4 configuration sets)/Off
Video Analytics: Select PVA mode. (Simple PVA/PVA+)
Communication: Configuration for RS-485.
Cam ID: Select the camera ID (001 - 255).
Baud Rate: Select serial communication speed (2400/4800/9600/19200).
Protocol: RS-485 protocol (Auto, FASTRAX/PELCO-D/PELCO-P).
Event Out: Off, Text-Out, FxLink
Event Strings: Select & edit sending strings for PVA/PVA+ Events.
NOTE:
* Text Out: Send event string through RS-485 line.
This function can work with IDIS DVRs Text-in feature.
* FxLink: Send event to PC application.
- WPC (White Pixel Compensation): Compensation for defective pixel on CCD.
NOTE:
* While operating in WPC, Iris will close automatically if using DC/IRIS lens; for manual lens,
block the lens hole.
Static/Auto: Automatic detecting of defective pixel and compensation.
Proceeding: Doing detection for white pixel.
NOTE:
* If brightness is too high, stop the process and print message “Bright Too High”.
* This function can compensate a max. of 63 points.
* If detected points are more than 63 points, repeats this detection by changes of conditions.
* If more than 63 points while changing conditions, stop the process and print “Too Many WH
Pixels”.
* User can stop the proceeding during operation.
Done: Complete white pixel detection.
View Detected WP: print detected pixel on screen.
Retry: Restart WPC process.
Accept: Store WPC result and return to previous menu.
Dynamic
Automated white pixel compensation for non-compensated pixels using static
method; no limits of compensation pixel number.
Select level (Low/Mid/High). Higher value setting compensates for more pixels.
NOTE:
* If the scene contains high frequency components, this can cause a loss.
Static/Manual: Manual white pixel compensation by appointment method.
Move Finder window using 4-arrow keys.
Marker: Expand finder window using digital zoom.
Move compensation pixel using 4-arrow keys.
Register: Adding compensation pixel.
- 11 -

NOTE:
* If registered points are more than 63 points, print “Memory Full” and stop action.
Marker: Use this if user sees other points.
Finder: Use this to move finder screen.
UnDo: Cancel the registered point.
Done: Return to previous menu.
Unregist: Deleting registered pixel.
NOTE:
* No more existing registered pixel; print “Memory empty” and stop action.
Marker: Select to continue unregistered action.
UnDo: Cancel the unregistered point.
Done: Return to previous menu.
Default: Recover to factory adjustment state.
- Focus Aid
To prevent the spread of light, AE mode changed to Shutter Fix Mode.
Min SHT (sec): Adjust minimum shutter speed.
Zoom: Zoom to focus window.
Adj:Adjust.
Start: Start measurement of maximum focus value.
Stop: Stop the measurement and initialize maximum focus value.
NOTE:
* FAD Max: Hold maximum focus value.
* FAD Val: Print present focus value.
* Usage:
Step 1: Point target to focus window.
Good target: higher contrast, more complex patterns.
Step 2: Minimize the spread of light by adjusting shutter speed.
Step 3: Turn the lens focus ring to end, start “Adj”.
Step 4: Turn the lens focus ring slowly to opposite side; record max focus value.
Step 5: If current fad value is lower than max fad value, stop turning focus ring.
Step 6: Adjust focus ring to be closer to the max fad value.
3) Lens : Select lens (DC lens/Video lens/Manual lens)
- Iris Speed: Adjust Iris speed (only for DC/Video Lens).
NOTE:
* If iris speed is too high, AE hunting can occur.
* If iris speed is too low, IRIS adjustment can operate too slowly.
4) LLC (Line Lock Control)
Active only when AC power is used. Select Int (Internal)/Ext (External) mode.
If mode is set to Ext, Sync Phase can be adjusted.
5) Day/Night
- Detection: Configure D/N change method (Internal/Fix-Day/Fix-Night/EXT-IN).
Internal: Operating DN changes with internal detection algorithm.
Fix-Day: Day mode fixed.
Fix-Night: Night mode fixed.
External: Work with EXT-IN mode. If port input voltage is high,
DN mode is Night; if port voltage is low, DN mode is Day.
- Burst: Select burst signal on/off in night mode.
- 12 -
- Delay (sec): Select delay time for D/N mode to change.

- D/N Threshold: Configure the threshold level for D/N mode to change
(Low/Mid/High/User).
NOTE:
* User Mode: Difference between D>N Level and N>D Level must be more than 2
and D>N must be less than N>D.
D>N: Adjust level of changing point of Day -> Night.
N>D: Adjust level of changing point of Night -> Day.
- OPD: Optical detector value. Represent present physical brightness.
- Use Alt Camset (N), Alt Camset: Select camera configuration set to apply in night
mode.
NOTE:
* Not supported in single Camset mode.
6) EXT-I/O
- D/N OUT (Day&Night Output): Select output method, No Func/D/N Out/AUX0.
AUX0: User defined output 0.
Set AUX0: Output voltage through to D/N OUT port [Open Collector (5V/10mA)].
- ALARM OUT: Select output method, No Func/Alarm Out/AUX1.
AUX1: User defined output 1.
Set AUX1: Output voltage through to D/N OUT port [Open Collector (5V/10mA)].
- D/N IN: Select input method, No Func/Alt Camset.
Alt. Camset: When inputting signal, change camera configuration.
Select Camset number.
7) Counter: Configurations for output of counting machine.
- , : Represent counting value/adjust offset value.
- Alarm On Zero: When counter value reaches zero, camera will be alarmed.
Preset Cnt1, Cnt2: When counter reaches zero, counter value will be reset to this
value.
Reset: Initialize counter (Default Zero or Alarm on zero enabled: Offset Value).
TextOut to Comm: Event string sends through RS-485 lines.
NOTE:
* Event Out must be activated.
- 13 -
