3rd Eye AWTC60WP User manual

WARNING
Failure to follow all instructions and safety precautions in this
manual, in the vehicle and body manufacturers' manuals and
on the safety decals attached to the vehicle, body and this
product could result in serious injury or death to operators,
service technicians or bystanders and/or damage to property.
DO NOT operate the vehicle or install this product before you
READ and UNDERSTAND the vehicle Operation Manual, this
manual and other applicable manufacturers' manuals, and all
safety decals. This product must be installed by certified
technicians/installers familiar with the vehicles on which they
will be making the installation.
AWTC60WP HD
Camera
USER MANUAL
ISSUED OCTOBER 2018
© 2018 3rd Eye 3E-AWTC60WP-UM-1018

TABLE OF CONTENTS
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Table of Contents
Camera
........................................................................................................................................................................................3AWTC60WP
...................................................................................................................................................................................4
PrecautionsPrecautionsPrecautions
...................................................................................................................................................................................5
Camera Cable Pin FunctionCamera Cable Pin FunctionCamera Cable Pin Function
...................................................................................................................................................................................6
DIN Pin Waterproof AssuranceDIN Pin Waterproof AssuranceDIN Pin Waterproof Assurance
...................................................................................................................................................................................7
How to Connect the CableHow to Connect the CableHow to Connect the Cable
...................................................................................................................................................................................8
Features and SpecificationFeatures and SpecificationFeatures and Specification
...................................................................................................................................................................................10
InstallationInstallationInstallation
...................................................................................................................................................................................13
DimensionsDimensionsDimensions
...................................................................................................................................................................... 14
Index

1
USER MANUAL
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
SAFETY PRECAUTIONS
Federal Communications Commission (FCC) Statement
This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio / TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void
your authority to operate the equipment.
NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference and,
2. This device must accept any interference received, including interference that may cause undesired operation

2
USER MANUAL
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
PRODUCT DOCUMENTATION UPDATES
Thank you for purchasing our product. Please read this User Manual before using the product. All product documentation is
subject to change without notice. Please go to www.3rdeyecam.com to get the most current documentation for your 3rd Eye
products.

3
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
AWTC60WP HD CAMERA
COLOR CAMERA
USER MANUAL
ISSUED OCTOBER 2018
3E-AWTC60WP-UM-1018

4
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Precautions
PRECAUTIONS
Before attempting to hook up and operate, please read this manual.
1. To reduce the risk of electronic shock, do not remove cover or back. No user serviceable parts inside. Refer servicing to
qualified service personnel.
2. Never point the camera toward the sun. It should not expose the lens directly to sun or strong light as this may damage
the pick-up device.
3. Handle this camera with care. Avoid severe shock or impact to the camera as it contains sensitive parts which can be
damaged by improper handling.
4. The allowance temperature range for operation of this camera is between -20 to 65° (-4 to 146°F) and the allowable
humidity is 85% maximum. If the camera is to be placed in an extremely dusty location, a special housing may be
necessary to protect the camera and lens.

5
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Camera Cable Pin Function
CAMERA CABLE PIN FUNCTION
1
Video
2
GND (OPTION)
3
N/A
4
Power
5
GND
6
GND
7
Shield GND

6
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
DIN Pin Waterproof Assurance
DIN PIN WATERPROOF ASSURANCE
NOTE: Wrap the whole cable connection from one end to another end with the Weather-Sealer Strip (NOT SUPPLIED) to
ensure adequate insulation against water.

7
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
How to Connect the Cable
HOW TO CONNECT THE CABLE
Follow the instructions below when connecting the cable and camera.
STEP 1:
Line up the position marks on the male connector and female connector as shown in image below.
STEP 2:
Rotate the ring on the male connector by hand as shown in image below.
STEP 3:
Then screw in securely to the threads on the female connector.

8
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Features and Specification
FEATURES AND SPECIFICATIONS
A. Key Features
· 1/3" color CMOS sensor
· Electronic auto iris control
· AWB(Auto White Balance)
· Back light compensation (BLC on)
· IP 69K
· 10G shock/vibration
· G-Force Rating : 30
· Isolated ground
· Automatic heater
· Double window glasses & replaceable outer glass
B. Optical
· Lens : F=2.9 H:96° V:72° Diagonal 120°

9
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Features and Specification
FEATURES AND SPECIFICATIONS (CONTINUED)
C. Specification Electrical
· Signal Format : NTSC
· Image Device : 1/3" color CMOS sensor
· Picture Element : 720 x 480 NTSC
· Synchronization : Internal SYNC.
· Resolution : 420 TV lines
· S/N Ratio : More than 45d B
· Video Out : 75 Ohm 1Vp-p composite Signal
· IRIS: Electronic Auto IRIS System
· Operating Voltage Range : 9V-15V
D. General
· Operating Temperature : -40°C - 65°C (with Heat)
E. Accessories
· Supplied Accessories : Mounting Bracket & Screw Kits, Sun Shield

10
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Installation
INSTALLATION
When mounting the camera, proceed as follows:
STEP 1:
Hold the camera on the chosen location and mark at least two different points for the drill
holes.
STEP 2:
When fastening with self-tapping screws, drill 0 5.5 mm holes at the points you have just
marked.
STEP 3:
Screw the camera bracket on with the 6 x 20 mm self-tapping screws.
STEP 4:
When attaching with threaded screws, drill 6.5 mm holes at the points you have just
marked.

11
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Installation
INSTALLATION
When mounting the camera, proceed as follows:
STEP 5:
Screw the camera bracket on with the M6 x 20 mm threaded screws.
STEP 6:
Creating a through-hole for the camera connection cable, drill a hole of 16mm near the
camera.
STEP 7:
Mount the camera by pushing the camera into the camera bracket.
STEP 8:
Attach the camera loosely with the 4 screws M3 x 10 mm in the slots.

12
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Installation
INSTALLATION
When mounting the camera, proceed as follows:
STEP 9:
Tighten the 4 screws in the slots of the camera bracket.
NOTE: This camera is set to mirror for default. If need to change, please adjust it from your monitor.

13
USER MANUAL
AWTC60WP
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Dimensions
DIMENSIONS

INDEX
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Index
14
C
camera cable pin function 5
D
dimensions 13
DIN pin waterproof assurance 6
F
features and specifications 8
H
how to connect the cable 7
I
installation 10
P
precautions 4
