4xem 4X-IP7151 User manual

Progressive Scan Day/Night
PoE IP Network Camera
Need more information? Visit www.4XEM.com or call 1-866-999-4XEM
sku 4X-IP7151
Progressive Scan Sony CCD Image Sensor•
2.9~8.2mm Variable focus Auto-iris CS Mount Lens•
Removable IR cut lter for Day & Night functionality•
Real-time MPEG-4 and MJPEG Compression (Dual Codec)•
Supports Simultaneous Dual Streams•
Up to 30fps in VGA Resolution – 640x480•
3GPP Mobile Surveillance Support•
Built-in 802.3af Compliant Power over Ethernet (PoE)•
Multi-window Motion Detection•
Two-Way Audio Support•
Digital I/O for External Sensor and Alarm•
Includes 32 camera Monitoring & Recording Software•
Includes Mounting Bracket•
Features:
The 4X-IP7151 has been designed with a progressive scan CCD image sensor to deliver
superior-quality, crystal-clear video for professional surveillance applications such as
monitoring banks, airports, parking lots, and trac control. This camera can
capture clear, sharp, high-resolution images of moving objects that
traditional interlaced-scan cameras are not able to achieve. The
4X-IP7151 includes a removable IR-cut lter to deliver high-
quality images in infrared illuminated conditions as well as a
2.9-8.2mm variable focus auto iris lens to achieve the precise
angle of view indoors or outdoors when used with an enclosure
like the IPCAMENCLOHF.
Simultaneous dual streaming of MPEG-4 and MJPEG
provides dierent resolutions to dierent devices. Users can
therefore view and record on a PC at 30 fps inVGA resolution
as well as remotely view through a 3GPP device such as a
PDA or cell phone at another resolution at the same time.
The support for 3GPP mobile surveillance allows you to view
live video from your Internet capable PDA or cellular equipped
with a 3GPP player. Video surveillance on the go! Built-in 802.3af
compliant PoE makes the 4X-IP7151 a powerful, cost-eective IP surveillance
system solution for various indoor applications.
This high performance camera delivers superb image quality and is perfect for any indoor or outdoor
surveillance application. Two-way audio capabilities allow real time audio and video recording as well as
real time two-way communication.
All 4XEM cameras have built-in customizable motion detection that can be programmed to send detected
movement snapshots to specied FTP sites or email addresses.Thirty-two camera monitoring and recording
software is included with the exibility of recording on pre-determined daily schedules or based on your
programmed motion detection, or both!
Supports
3GPP
FREE
32 Camera
Monitoring & Recording
Software
Built-in
PoE
UPnP ™
Universal Plug & Play
DAY
NIGHT

Progressive Scan PoE
IP Camera
Need more information? Visit www.4XEM.com or call 1-866-999-4XEM
sku 4X-IP7151
Camera Specications
Image Sensor 1/4”Progressive Scan Sony
CCD, VGA resolution
LensType CS mount,
f=2.9mm~8.2mm vari-
focal, auto-iris, IR Corrected,
Embedded removable IR-cut
lter
Electronic Shutter Speed 1/30~1/15000 sec.
Auto-Iris Support Built-in auto iris
Auto Electronic Shutter Supported
Auto Gain Control Supported
AutoWhite Balancing Supported
Dimensions 205.5 mm [8.1 in] Diameter
82.1 mm [3.2 in]Width
51.2 mm [2.0 in] Height
Weight Net 568g IPCAMW90
System
CPU Trimedia PNX1300
RAM 64MB RAM
ROM 8MB Flash ROM
Embedded OS: Linux 2.4
System Requirements
Operating System MicrosoftWindows 2000/XP/
Vista
Browser Internet Explorer 5.x or above
Cellphone 3GPP player
Real Player 10.5 or above
QuickTime 6.5 or above
Packet Video Player 3.0 or above
Video Specications
Frames/Second Up to 30fps at 640 x 480
Streaming Simultaneous dual streaming
MPEG-4 streaming over UDP,
TCP, or HTTP
MPEG-4 multicast streaming
MJPEG streaming over HTTP
Supports 3GPP mobile surveillance
Features Adjustable image size, quality and bit
rate
Time stamp and text overlay
Flip & Mirror
Congurable brightness, contrast,
saturation, and hue
Automatic or manual day/night mode
Backlight compensation (BLC)
Supports privacy masks
Up to 3 motion detection windows
Event notication using HTTP, SMTP, or
FTP
Local recording of MP4 les
Upload snapshots (FTP or email)
Camera live viewing for up to 10
clients
Networking
Protocol IPv4,TCP/IP, HTTP, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS,
DDNS, and PPPoE
10/100 Mbps Ethernet, RJ-45
Miscellaneous
Audio Compression:
GSM-AMR speech encoding,
Bit Rate: 4.75kbps to12.2kbps
MPEG-4 AAC audio encoding,
Bit Rate: 16kbps tp 128kbps
Supports 2 way audio by SIP
protocol
Supports audio mute
Microphone Built-in
General I/O 1 sensor input
1 relay output
LED Indicators System power and status
indicator
System activity and network
link indicator
Power
Output 12V DC, 1.5A
EMI & Safety
Certication CE, FCC, C-Tick, LVD, MIC
Operating Environment
OperatingTemp. 0~40˚C (32~104˚F)
Operating Humidity 20% - 80% RH
Security Multi-level user access with
password protection
IP address ltering
Bundled Software
IPNV32 Security & Remote Monitoring Software:
Remote conguration and control of up to 32 devices
Fast/slow forward, replay, and pause
Scheduled backup
Event-triggered, scheduled, and manual recording
Instant search with preview windows
Hard disk quota warning
AVI format export
