4xem 4X-IP8330 User manual

Supreme Night Visibility
Bullet Network Camera
4X-IP8330
Need more information?
Visit www.4XEM.com or call
1-866-999-4XEM
Includes 32 camera professional monitoring & recording software•
Supreme Night Visibility•
Vivid and Faithful Color Performance•
60 fps for Smoother, Razor-Sharp Video of High-Speed Objects•
Removable IR-cut Filter for Day & Night Function•
Built-in IR Illuminators, eective up to 15 Meters•
Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)•
Simultaneous Multiple Streams•
Activity Adaptive Streaming for Dynamic Frame Rate Control•
Weather-proof IP66 rated Housing•
Tamper Detection for Unauthorized Changes•
Built-in 802.3af Compliant PoE•
Built-in MicroSD/SDHC Card Slot for On-board Storage•
Supports ONVIF Standard to Simplify Integration and Enhance•
Interoperability
Features:
The 4X-IP8330 is the best bullet-style network camera
oering supreme night visibility for diverse outdoor
applications. Featuring up to an unbelievable 60fps at
VGA resolution and exceptional low light sensitivity
down to 0.1 lux, the 4X-IP8330 captures impressively
smooth and crystal-clear video, even at nighttime.
In order to adapt to constantly changing outdoor
lighting conditions, the 4X-IP8330 also features a
removable IR-cut lter as well as IR illuminators for
superior image quality around the clock. With the
Advanced Color Reproduction technology, users
need to look no further for an all-in-one outdoor
camera capable of capturing high quality, vivid video
for both day and night.
For protection against harsh outdoor environments,
the camera comes in an IP66-rated housing and
weather-proof casing to withstand rain and dust.The
4X-IP8330 also supports the industry-standard H.264 compression technology, drastically reducing le sizes and conserving valuable
network bandwidth. With H.264, MPEG-4, and MJPEG compatibility all included, multiple streams can be simultaneously transmitted in
any of these formats at dierent resolutions, frame rates, and image qualities for versatile applications.The streams can also be individually
congured to meet dierent needs or bandwidth constraints, thereby further optimizing bandwidth and storage.
Incorporating a number of advanced features standard forVIVOTEK cameras, including tamper detection, 802.3af compliant PoE, MicroSD/
SDHC card slot, andVIVOTEK’s 32-channel recording software, the 4X-IP8330 is the ideal solution for outdoor surveillance with the highest
value.
www.4XEM.com
FREE 32 Camera
Monitoring & RecordingSoftware
Day/Night
Built-in SD/SDHC
Card Slot for On-board Storage
1 YEAR Warranty
1
YEAR
SD
card
Slot

Camera Specications
Image Sensor 1/4”CMOS inVGA Resolution
Lens f = 4 mm
F 1.6
Board lens
IR corrected
Removable IR-cut lter for day
& night function
Angle ofView 46.6° (horizontal)
35.4° (vertical)
57.7° (diagonal)
Electronic Shutter Speed 1/5 ~ 1/15,000 sec.
Min. Illumination Supreme NightVisibility:
below 0.1 Lux @ 10 IRE, F1.6,
1/5 s exposure time
0 Lux @ F1.6 ( IR LED on )
IR Illuminators IR LED*12
Built-in IR illuminators,
Eective up to 15 meter
Dimensions Ø: 60mm x 170 mm
Weight Net: 702g
System
CPU TI DM365 SoC
Flash 128MB
RAM 256MB
Embedded OS Linux 2.6
System Requirements
OS: MicrosoftWindows 2000/XP/Vista
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
QuickTime: 6.5 or above
On-Board Storage
SD/SDHC card slot
Stores snapshots and video clips
Networking
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/
RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE,
CoS, QoS, SNMP and 802.1X
Video Specications
Compression H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams•
H.264 streaming over UDP, TCP, HTTP or HTTPS•
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS•
MPEG-4 multicast streaming•
MJPEG streaming over HTTP or HTTPS•
Supports activity adaptive streaming for dynamic frame•
rate control
Supports 3GPP mobile surveillance•
Frame rates:
H.264: Up to 60 fps at 640x480•
MPEG-4: Up to 60 fps at 640x480•
MJPEG: Up to 60 fps at 640x480•
Image Settings
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Congurable brightness, contrast, saturation, sharpness,
white balance and exposure
AGC AWB AES
Automatic, manual or scheduled day/night mode
Supports privacy masks
Alarm & Event Management
Triple-window video motion detection
Event notication using HTTP, SMTP, or FTP
Local recording of MP4 les
Tamper Detection
Miscellaneous
Security:
Multi-level user access with password protection
IP address ltering
HTTPS encrypted data transmission
802.1X port-based authentication for network
protection
Users
10 clients on-line monitoring at the same time
Housing
Weather-proof IP66-rated housing
Power
12V DC
24V AC
Power consumption: Max. 4W
802.3af compliant Power-over-Ethernet
EMI & Safety
Certication CE, C-Tick, FCC, LVD, VCCI
Operating Environment
OperatingTemp. -20 ~ 50 °C (-4 ~ 122 °F )
Operating Humidity 90% RH
Need more information? Visit www.4XEM.com or call 1-866-999-4XEM
Bundled Software
IPNV32 Security & Remote Monitoring Software:
Remote conguration and control of up to 32 devices
Fast/slow forward, replay, and pause
Scheduled backup
Event-triggered, scheduled, and manual recording
Instant search with preview windows
Hard disk quota warning
AVI format export
Supreme Night Visibility
Bullet Network Camera
4X-IP8330
