A2B Accorroni HUB RADIATOR MINI 6.0 Manual

TECHNICAL INFORMATION
HUB RADIATOR MINI 6.0 - 8.0 - 11.0 - 16.0
B60°
HUB RADIATOR MINI 6.0 - 8.0 - 11.0 - 16.0
Patented high efficiency thermodynamic boiler with heat pump
with direct exchange refrigerant / water to produce
domestic hot water and heating for small utilities

2

3
HUB RADIATOR MINI heat pump
Modelli 6.0 - 8.0 - 11.0 - 16.0
Technical information
SECTION A - GENERAL INFORMATION
It contains all the news related to the description of the air-water heat pumps and their characteristics
techniques.
SECTION B - TECHNICAL NEWS FOR THE INSTALLER
It gathers all the indications and the prescriptions that the installer technician must observe for the optimal
realization plant.
SECTION C - USER'S INSTRUCTIONS FOR USE AND MAINTENANCE
It is the section reserved for the user and contains all the information necessary for correct operation and for
periodic checks
Important notes for consultation
1 For the purposes of a correct and safe use of the appliance, the installer, the user and the maintenance
technician, for
the respective competencies are required to comply with the instructions in this manual.
2 The word ATTENTION is followed by information which must be of importance
scrupulously observed and failure to comply with it may cause damage to the appliance and / or prejudice it
safe use.
3 The paragraphs highlighted in bold contain important information, warnings or advice
recommends to evaluate carefully.
4 The technical data, aesthetic characteristics, components and accessories shown in this manual are not
binding. The A2B Accorroni E.G. Srl reserves the right to make any changes at any time
changes deemed necessary for the improvement of your product.
- References to laws, regulations or technical rules mentioned in this manual are to be understood as a mere title
information and to be considered valid at the time of printing thereof, shown on the last page.
The entry into force of new provisions or amendments to those in force will not constitute a reason for any of the
company's obligations
The A2B Accorroni E.G. Srl towards third parties.
- The A2B Accorroni E.G. Srl is responsible for the compliance of its product with laws, directives and standards
of construction, in force at the time of marketing. Knowledge and observance of legislative provisions and rules
concerning the design of the systems, the installation, the operation and the maintenance are the exclusive
responsibility, for the respective competences, of the designer, the installer and User.
INDEX
1. MAIN FEATURES ...................................................................................................................... 6
1.1 Equipment classification ............................................................................................................. 6
1.2 Certifications - CE Marking .................................... .................................................................... 6
1.3 Construction features ................................................................................................................. 6
1.4 Contents of the packaging ......................................................................................................... 6
1.5 Standard equipment and accessories supplied upon request ................................................... 7
1.6 Field of application ...................................................................................................................... 7
1.7 Security rules .............................................................................................................................. 7
2. U.E. CONNECTIONS / IU ......................................................................................................... 8
2.1 General provisions ..................................................................................................................... 8
2.2 EU electrical connections ........................................................................................................... 8
2.3 Installation of the R410 refrigerant piping A .............................................................................. 8

4
3. INSTALLATION OF EXTERNAL UNIT ...................................................................................... 10
3.1 General indications ..................................................................................................................... 10
3.2 Distances of respect .................................................................................................................. 11
3.3 Roof installation .......................................................................................................................... 11
3.4 Elimination of air with the vacuum pump .................................................................................. 11
3.5 Evacuation ................................................................................................................................. 11
3.6 Pump Down ................................................................................................................................ 12
3.7 Recovery procedure .................................................................................................................. 12
4. INSTALLATION OF INTERNAL UNIT ....................................................................................... 13
4.1 Assembly procedure ................................................................................................................... 14
4.2 Internal and external unit dimensions ......................................................................................... 16
4.3 Performance characteristics of external units MINI HUB RADIATOR ....................................... 17
4.4 Technical data table MINI HUB RADIATOR .............................................................................. 18
4.5 ACS HUB RADIATOR MINI 7.0 sampling table ......................................................................... 18
5. ELECTRIC HUB RADIATOR MINI DIAGRAMS ........................................................................ 19
5.1. Wiring diagram HUB RADIATOR MINI 6.0 ............................................................................... 19
5.2. Wiring diagram HUB RADIATOR MINI 8.0................................................................................ 20
5.3. Wiring diagram HUB RADIATOR MINI 11.0............................................................................... 21
5.4. Wiring diagram HUB RADIATOR MINI 16.0.............................................................................. 22
6. HYDRAULIC AND OPERATIONAL DIAGRAMS MINI HUB RADIATOR ................................. 23
6.1. Hydraulic and operating diagram HUB RADIATOR MINI 8.0.................................................... 23
6.2. Hydraulic and operating diagram HUB RADIATOR MINI 16.0.................................................. 24
7. MINI HUB RADIATOR CIRCULATOR ..................................................................................... 25
8. DIVERTER HUB RADIATOR MINI ........................................................................................... 25
9. ELECTRIC RESISTANCE HUB RADIATOR MINI ................................................................... 25
10. WARNINGS .............................................................................................................................. 26
10.1 Qualification of the installer ............................... ........................................................................ 26
10.2 Preliminary information .............................................................................................................. 26
10.3 Transport and handling ............................................................................................................... 26
10.4 Use of instructions ...................................................................................................................... 26
10.5 General system checks ..................................... ........................................................................ 26
11. START-UP .................................................................................................................................. 27
11.1 Initial start-up mode .................................................................................................................... 27
11.2 First start-up checks ................................... ............................................................................... 27
11.3 Starting up ................................................................................................................................... 27
12. REPAIR - COMPONENT REPLACEMENT ............................................................................... 27
12.1 Refrigerant circuit ........................................................................................................................ 27
12.2 Drying and vacuum of the plant .................................................................................................. 28
12.3 Cleaning the circuit ..................................................................................................................... 28
12.4 Refrigerant charge ....................................................................................................................... 28
12.5 Verification of overheating ........................................................................................................... 28
13. DIGITAL CONTROL UNIT .......................................................................................................... 29
13.1 Display.......................................................................................................................................... 29
13.2 Icon and display............................................................................................................................ 29
13.3 Key Function ................................................................................................................................ 30

5
13.4 Function keys ............................................................................................................................... 30
13.5 Access to the parameters ............................................................................................................ 31
13.6 View and change the set point ..................................................................................................... 31
13.7 Main alarms ................................................................................................................................. 32
13.8 Main parameters ......................................................................................................................... 33
13.9 Digital control unit wiring diagram ............................................................................................... 33
14. MAINTENANCE .......................................................................................................................... 34
14.1 Cleaning the exchangers ............................................................................................................ 34
14.2 Annual inspection ....................................................................................................................... 34
15. GENERAL ................................................................................................................................... 34
15.1 Use of instructions ....................................................................................................................... 34
15.2 Improper Uses - Recommendations ........................................................................................... 34
16.WEEKLY PROGRAMMER CLOCK INSTRUCTIONS ................................................................ 35
16.1 Description ................................................................................................................................... 35
16.2 Operating Instructions .................................................................................................................. 35
16.3 Setting the current day and time .................................................................................................. 35
16.4 Programming ................................................................................................................................ 35
17.Acoustic Requirements ................................................................................................................ 36
16.5 Manual operation .......................................................................................................................... 35

6
1.MAIN FEATURES
1.1 CLASSIFICATION OF THE APPLIANCES
The fundamental elements that make up the system
MINI HUB RADIATOR are:
1) External motion-evaporator with electronic control
defined as: “Mono block air heat pump
split water ”, fed by cooling fluid
R410A with 7.0 kW ON - OFF compressor.
2) Internal unit defined as accumulator radiator
high performance closed circuit that holds
completely separated the technical water from the
water
sanitary and is realized through 2 accumulations
sequential octagonal section, inside the
which all copper exchangers are positioned.
1.2 CERTIFICATIONS - CE MARKING
The patented MINI HUB RADIATOR system is
compliant with directives 97/23 / EC and 98/37 / EEC.
They also comply with the provisions of the
following the normes: 73/23 / CEE, 89/336 / CEE,
as amended by Directive 93/68 / EEC
The internal unit of the MINI HUB RADIATOR system
has been designed to be installed only and
exclusively inside the buildings or on special purpose
external niche thermally insulated and protected by
the
atmospheric agents, if not respected
this indication invalidates any type of warranty
warranty.
1.3 CONSTRUCTION CHARACTERISTICS
All cars are equipped with a microprocessor for
control and adjustments of operation and safety of
the units.
The products of the HUB RADIATOR MINI series
thanks to the patented direct exchange capacitors
are able to achieve high standards of energy
efficiency and SCOP.
Other construction features:
- the covering unit of the outdoor unit is made for all
sheet metal models pre-painted with epoxy powder.
The room compressor is completely isolated from the
air / refrigerant exchanger compartment; it allows to
better protect the electro mechanical components;
- the compressor is of the high rotary type efficiency,
working with R 410A refrigerant mounted on elastic
anti-vibration mounts, operated from single-phase
electric motor for all models;
- the air / refrigerant gas exchanger it is made with
copper pipes and aluminium fins blocked by
mechanical expansion of the tubes, with high heat
exchange surface;
- the fan group consists of a fan helical driven directly
by engine single phase asynchronous with thermal
protection internal. The fan is equipped with a grid
accident prevention protection;
- the rapid exchanger DHW, is made in copper
directly immersed in technical water of the indoor unit
with the FIRST IN - FIRST method OUT, so as to
eliminate the problem of legionella.
- the refrigeration circuit and the connections
between the individual components are made of
specific copper for refrigeration. They are part of the
refrigeration circuit the rolling member, the reversing
valve cycle the liquid separator;
- the electric command and control panel is directly
positioned within the covering cabinet, above the
vessel of expansion.
- the microprocessor control system with keyboard is
located on the control panel accessible directly on
the part front of the cover cabinet, and can be
remoted using the appropriate panel command and
remote control, available as an accessory, to be
installed on the wall or collection.
- the indoor unit is supplied complete with all the
special internal copper exchangers, auxiliary back up
and backup support emergency, Freon attacks, DHW
attacks, air-operated jolly valve, safety valve, filling
tap, pressure gauge, valve diverter to give priority to
healthcare, flow switch, electronic circulator, vessel of
expansion, temperature probes.
1.4 CONTENT OF THE PACKAGING
The appliance is shipped on a wooden pallet, with
protections in extruded and wrapped polystyrene
foam in a layer of plastic fabric with air bubbles.
The identification data of the appliance are shown
both on the label on the packaging and on the data
plate applied to the inside of the cover cabinet.
Do not remove the license plate for any reason
technical data, since the references contained therein
are necessary for any interventions of
maintenance.
Inside the package there is also an envelope
containing this manual and the certificate of
guarantee, which must be delivered to owner of the
appliance to keep them carefully for any future use or
for consultation.

7
The extensive standard equipment and available
accessories on request they allow the optimal
exploitation of all the functions of the machines
and the plant to which they are enslaved.
1.6 FIELD OF USE
Devices designed and manufactured for water
heating in heating systems hydronic conditioning
and to produce DHW, they must only be used for
this purpose, in relation to their technical
specifications e performance. The quality and
dimensions of the materials used they guarantee
a good life span and they are suitable for the
operation of the appliances both in their own
together than in their individual components,
under reserve of an installation carried out
according to the rules of the art and in
mechanical, chemical and stress conditions
corresponding to a suitable use.
WARNING! All uses not expressly indicated in
this manual are considered improper and are
not allowed; in particular the use of the
devices is not foreseen in industrial processes
and / or installation in environments with a
corrosive or explosive atmosphere. The
manufacturer declines all responsibility for
damage to persons, animals or things arising
Table 1 - MINI HUB RADIATOR Cables
Specifications
Models Cable CableConnection cable
U.I. (INTERNAL UNIT)
Connection cable
U.E. (EXTERNAL UNIT) C-1-2 Pb3
SWITCH
MAGNETERMIC
Sezione Sezione Sezione Sezione Tipo
6.0 4.0 mm2 x 3 4.0 mm2 x 3 1,50 mm2 x 3 0,75 mm2 x 2 20 A curv. D
8.0 6.0 mm2 x 3 4.0 mm2 x 3 1,50 mm2 x 3 0,75 mm2 x 2 32 A curv. D
11.0 6.0 mm2 x 3 4.0 mm2 x 3 1,50 mm2 x 3 0,75 mm2 x 2 40 A curv. D
16.0 6.0 mm2 x 3 4.0 mm2 x 3 1,50 mm2 x 3 0,75 mm2 x 2 40 A curv. D
Models Connection cable Connection cable Switch
Cable Cable power supply QE indoor unit power
supply external unit C-1-2 Pb3 thermomagnetic
Section Section Section Section Type failure to
comply with the instructions of this letter manual,
from modifications or tampering with the product,
from installation errors, to adjustment, maintenance
and improper use. Failure to comply with what is
indicated in the present manual also involves the
forfeiture of the warranty conditions.
1.7 SAFETY STANDARDS
WARNING! Installation and maintenance
must be carried out exclusively by specially
trained personnel qualified.
The connection to the power supply must
be performed in accordance with current
regulations of national plant engineering.
During installation operations e maintenance, it
is always necessary to operate in the conditions
of maximum security, follow the instructions in
this manual and at any warning labels applied
on the product.
Respect the installation and operation limits
indicated in this manual, do not modify
in no case the internal and external electrical
wiring refrigeration pipes, do not modify or
disable safety and adjustment devices.
Before each inspection, maintenance, or
whatever else involves access to the internal
parts of the appliance, remove the general
power supply. In case of need or clarification for
the installation and maintenance contact a
Technical Assistance Center authorized by A2B
ACCORRONI E.G.

8
2. CONNECTIONS U.E. / U.I.
2.1 GENERAL PROVISIONS
1) The MINI HUB RADIATOR system is designed
to work exclusively with the indoor unit
positioned within the building to be heated
and the booster outside.
2) During the installation phase it must be verified
carefully that the distance and the height difference
between the 2 units comply with the data reported
above this manual.
3) Before installation, check that the wall where you
have chosen to place the internal storage be able to
support the weight itself accumulation and the water
contained in it.
4) In case of replacement of a generator make the
system clean and the addition of a special anti-algae
additive.
5) When you choose to install the MINI HUB
RADIATOR system, there is to keep considering the
electrical absorption of the unit external. Then prepare
all the works necessary to adapt the electrical system
(counter, cable section, switches circuit breakers,
etc.,) to guarantee the correct operation and a
constant voltage between 220 and 240 V at the
power cables of the outdoor unit.
2.2 ELECTRICAL CONNECTIONS
Connect the cable to the electrical panel:
1) The connection cable of the indoor unit
and external must be of the H07RN-F type.
2) Lift the panel of the electrical panel e
remove the screws, then remove the cover.
3) Connect the cables according to the markings.
Connect the cable to the external unit:
1) Remove the cover of the outdoor unit.
2) Connect the terminal cables according to the
numbers present on the terminal board of the unit,
respecting the sections shown in table 1
3) Fix the cables so that they do not come into
contact with electrical or metal parts.
2.3 INSTALLATION OF THE PIPES FOR THE
REFRIGERANT R410A
The main cause of refrigerant gas leaks
is due to a defect in the flaring. Make
the folders correctly respecting the following
indications:
A) Cut the pipes and the cable (Fig. 1)
- Use pipes with adequate dimensions for the unit
installed (table 2).
- Measure the distance between the indoor and
outdoor unit.
- Cut the tubes to a slightly length greater than the
measured distance.
- Cut the electric cable 1.5 mt. longer than tube
length.
B) Burr removal (Fig. 2)
- Completely remove all burrs from the
cross section of the tube.
- Processing must be performed with the end of the
tube down so that the burrs do not fall into the tube.
C) Flaring (Fig. 3)
Remove the nuts fixed on the internal unit and
outside, put them on the pipe and carry out the
flaring and the removal of burrs, as previously
indicated.
D) Placement of the nut Fix the copper tube firmly
with a nut of the size indicated in table 3.
E) Fixing the connection (Fig. 4)
Align the tubes. Tighten the nut sufficiently e
tighten it with two keys as shown in the figure
- Precautions Excessive torque can break the
nut.
Pipe Installation Table 2
Models Ø LIQUID Ø GAS
6.0 1/4” - 1/4” 3/8” - 3/8”
8.0 1/4” 5/8”
11.0 1/4” - 1/4” 3/8” - 5/8”
16.0 1/4” - 1/4” 5/8” - 5/8”

9
Table 4 - Refrigerant charge
Models Dislevel H Length
pipes max
(m) (m) Max
Maximum length
without additional gas
Max refrigerant
additional
refrigerant (g / m)
6.0 5 15 5 20
8.0 5 15 5 20
11.0 5 15 5 20
16.0 5 15 5 20
PIPE CONNECTIONS
Fig. 1
PIPE CONNECTIONS
(Flaring)
Fig. 3
PIPE CONNECTIONS
(CUTTING AND BURR REMOVAL)
Fig. 2
PIPE CONNECTIONS
(FIXING)
Fig. 4
Table 3 - Tightening torque
Diameter Torque Tightening min - max (N/m)
Ø 1/4 14 - 18
Ø 3/8 33 - 42
Ø 5/8 63 - 77

10
3. OUTDOOR UNIT INSTALLATION
3.1 GENERAL INDICATIONS
In choosing the installation position
accurately respect the following indications:
- Make sure that the difference between INTERNAL
UNITS
and the OUTDOOR UNIT is not greater than 5.0 m.
- The appliance must be installed so
that the influences of adjacent structures and / or i
effects of particular climatic conditions (snow,
wind etc ...), do not compromise the functioning
of the product and / or the safety of people e
of assets.
- Make sure the space in the back
unit is greater than 30 cm. The part
front must have more than 60 cm. of space.
- Make sure there are no obstacles to the
free circulation of air through the
heat exchangers: A) do not arrange plants or
animals directly behind the fluss air;
B) avoid installation in the corners where it is used
the depositing of dust, leaves and whatever
can reduce the efficiency of the exchangers
obstructing the passage of air (Fig 5).
-Avoid installation in tight and small spaces
get away because they could be favored
acoustic reverberations. Inquire about the
any limits on expected noise emissions
for the area of the municipal territory in which
it is install the appliance. In case of doubt it
is it is advisable to consult a acoustic
technician, qualified for an evaluation
of the impact, to prevent disputes from
third party.
-Prevent the air expelled by the fans penetrate
through adjacent doors and / or windows,
causing disturbance to people.
-Install the outdoor unit on a rigid base equipped
with special anti-vibration pads to avoid the increase
of vibrations and noise, so as not to disturb the
neighbours (Fig.6).
- Position the air exhaust so that the flow is not
hindered in any way. In In case of strong wind,
make sure the fan functions correctly, positioning
the unit longitudinally, along a wall or using a shield.
- If the appliance must be suspended on one
external wall, the support must respect the
Technical specifications. The wall where the unit
should be installed, must be brick or material of
similar consistency, otherwise it must be reinforced.
Support brackets must be stable, durable and with
adequate degree of protection against corrosion.
WARNING! Make sure of the capacity
carrier of the part on which the
shelves and wall anchoring system
itself, depending on the weight of the appliance
to install.
- Do not install the appliance near sources
of heat and / or areas with fire hazards.
- Installation in highly atmospheric areas corrosive is
not allowed; in condition particular climatic
conditions such as near the sea, it is mandatory to
provide for a duration of lower life of the product and
in any case one more frequent and accurate
maintenance.
- In the external unit, from which it is deleted
condensation water, provide a special one
drainage and / or channelling of the same, in
so as to avoid dangerous situations
due for example to ice formation
on transit areas.
Fig. 5
Fig. 6

11
- The outdoor unit is designed to be installed
outdoors and does not require a base
special, however it must be positioned
safely on a support surface
horizontal of adequate bearing capacity e
equipped with special anti-vibration pads.
3.2 DISTANCES OF RESPECT (Fig. 7) Respect
the minimum spaces, so as to allow the correct
functioning and all operations of installation and
maintenance.
3.3 ROOF INSTALLATION
- If the outdoor unit is installed above a roof,
be sure to level the unit. Make sure that the
roof structure is appropriate for mounting
unit.
- Consult the local codes regarding the
roof mounting.
- If the outdoor unit is installed on the roof or on the
external walls, this could cause excessive noise and
vibration and being classified as an unsuitable
installation at service.
3.4 ELIMINATION OF AIR WITH THE PUMP
OF THE VACUUM (Fig 8)
Air and moisture in the refrigeration system can
cause side effects as shown below:
- Increased pressure in the system.
- Increased current consumption.
- Decreased refrigerant efficiency
- Freezing and obstruction of the pipes
capillaries.
- Corrosion of the parts of the system of
refrigeration.
To avoid the above, the internal assembly and the
tubes, places between internal and external group,
must be tested for leaks and purged to remove
non-condensing elements and humidity from the
system.
Check that each tube, (is the gas side tubes
that of the liquid) between internal group and
external group, has been connected in the correct
way and that all wiring necessary for testing have
been carried out. Remove the valve cap on the
assembly external. Make sure that both are now
gas and liquid valves remain closed.
Check the length of the tube and its quantity
of the refrigerant, for a correct charge, check the
overheating value. The table values are
indicative.
When you change places in the unit, carry it out
bleeding with the vacuum pump. Make sure the
refrigerant inside the conditioner is always
in liquid state.
The outdoor unit is supplied with a gas charge
R410A refrigerant suitable to guarantee a correct
operation up to a maximum distance of 5 meters
from the indoor unit.
If you decide to install the 2 units at a distance
greater than 5 meters, be sure to add 20 g of
refrigerant gas for each extra meter of pipe (Tab. 3).
For example, if there are external and internal units
7 meters of piping add 40 g of R410A gas.
In any case, never exceed 15 meters.
Do the addition only after making the vacuum in the
pipes that connect the 2 units, such as illustrated in
chapter 3.4, after which you can proceed with the
opening of the gas taps, mounted on board
machine.
3.5 EVACUATION
Connect the end of the charging hose to the
vacuum pump to evacuate the air from the pipes
of the internal unit. Check that the knob
"LO" of the pressure gauge valve is open.
Then run the vacuum pump. The time of
operation varies depending on the length of the
tubes and pump capacity.
When the desired vacuum is reached, close
the "LO" knob on the pressure gauge valve e
stop the vacuum pump. In conclusion, using
a wrench for service valves, rotate the stem
of the gas side valve counter clockwise for
open it completely.
Loosen the charging hose connected to the socket
gas side service to relieve pressure, then
remove the tube. Replace the cover nut on the
gas valve and service outlet and tighten
well with an adjustable wrench.
This procedure is very important to avoid
plant leaks Replace the service valve caps either
on the gas side than on the liquid side and tighten
well.
This completes the air purge procedure with the
vacuum pump, make sure all the pipes are
connected correctly and that the valves of service of
the gas and liquid sides are completely
open.

12
3.6 PUMP DOWN
This procedure is performed when the group must
be moved or assistance is provided to the
refrigerant circuit.
Emptying allows you to collect everything
the refrigerant in the external unit without yes
verify losses
Fig. 7
Fig. 8 WARNING! To make sure
to perform the procedure of
emptying with the group in
COLD MODE.
3.7 RECOVERY PROCEDURE
- Connect a low pressure gauge with
a pipe to the service port of the gas valve.
- Open the gas valve in half and empty the air
from the pressure gauge piping using gas
refrigerant.
- Completely close the liquid valve.
- Turn on the machine in cooling mode.
- When the pressure of the pressure gauge moves
between
0 and 0.5 kg / cm 2G (between 14.2 and 7.1 P.S.G.I)
completely close the gas valve e turn off the air
conditioner quickly.
The complete recovery of the refrigerant of the
outdoor unit.
Vacuum pump
Open
Cylinder
gas
R410A
Close
pressure
gauge valve
Indicator of
pressure

13
4. INSTALLATION OF INDOOR UNITS
Always install the accumulator inside the building to
heat away from atmospheric agents and inside a
room with a controlled temperature.
Make sure the wall on which it will be installed
the indoor unit is able to support the entire weight in
system operation.
The main components are listed below make up the
internal unit.
Main components:
1 8 liter expansion vessel
2 Electrical panel
3 WILO YONOS PARA RS 25/6 circulator
4 Domestic hot water delivery
5 Drain cock "
6 3/4 ”heating system delivery
7 Safety valve with 3 bar setting
8 1/2 ”sanitary cold water inlet
9 Diverter valve with 1 "connections
10 3/4 ”system return
11 3/8 air venting jolly valve
12 Refrigerant connections for external booster (s)
13 Manual filling tap
14 Daily weekly programmer clock
15 Wall fixing bracket
16 System pressure gauge
17 Supplementary electric heater of 1.5 kW
18 Digital electronic control unit
19 Button ON OFF electrical resistance
20 Technical inertial storage tank of 70 liters
21 Cover for indoor unit
22 Emergency / integration key electrical resistance
19 2214181316
120 21
2
95 10
7
8
64
3
17
11
15 1212
14

14
4.1 ASSEMBLY PROCEDURE
A) Position the wall fixing bracket on the
wall where the indoor unit is to be installed.
Make sure the bracket is with a level
perfectly horizontal and that the support surface
is regular.
Use the bracket as a template and mark the position
of the holes to be made.
B) Once the position of the fasteners is
marked,make appropriate holes for the insertion of
wall plugs to choose based on the weight of the unit
internal in operation and the structural type of the
wall.
C) Insert the fixing bracket again and tighten
with the wall screws, chosen on the basis of the
indications
reported in point B.
D) Hang the indoor bracket unit just
fixed to the wall without cover cabinet using
the slots on the lower part of the bracket.
E) Once the indoor unit has been hung to the
bracket of wall mounting proceed with the
connection of the sanitary circuit 1/2
FLOW
DHW
ENTRY
WATER
F) Proceed with the connection of the delivery and
of the heating system return using 3/4 ”fittings
DELIVERY
PLANT
RETURN
PLANT
WARNING! the circulator mounted on board
machine is able to supply the water flow nominal
with the prevalence indicated in the table of
technical data. Check that your losses load do
not exceed the prevalence useful available.
However, it is recommended to comply with the
requirements below:
- the diameter of the pipe of the sampling line from
the network should never be less than that machine
attack;
- adequately fix the pipes, whose weight it must not
weigh on the appliance;
- properly insulate the pipes to prevent heat losses.

15
G) Connect a special safety drain in matching the
1/2 "female threaded connection of the safety valve.
SCARICO VALVOLA DI SICUREZZA
H)Make the electrical connections between the panel
power supply and the main power supply and
between the panel electric and the terminal block
located on the right side of the outdoor unit following
the instructions given in table 1.
Prepare a dedicated power line that starts directly
from the meter to bring the power supply main
electric to the electrical panel located inside the
covering mantle of the indoor unit.
This line must be equipped with appropriate
protection magneto-thermal placed upstream and
must be of section to avoid a voltage drop
higher than 2.5 V.
SAFETY VALVE DISCHARGE
WARNING! all electrical connections must
be performed by qualified personnel e
the electrical system must comply with all of them
the current regulations
I) Proceed with the refrigeration connections following
all the indications given in section 2.3 of this manual.
When shaping the pipes, avoid any crush type and
make sure each portion of piping is perfectly thermally
insulated from start to finish
WARNING! complies with all applicable regulations.
All refrigeration connections must be
performed by qualified personnel in possession
of the F-GAS certification (Presidential Decree 27
January 2012, n. 43)
L) Once all the connections have been made, request
the indoor unit with the appropriate cover cabinet that
you must first lean down on the top wall fixing bracket
and then turned towards the wall until it hooks onto
the appropriate pins a disappearance, placed on the
lower fixing plate
Terminal
Gas line connection
R410A pressure connection
2-way valve (open)
Gas line connection
R410A tap

16
4.2 DIMENSIONS OF INTERNAL AND EXTERNAL UNITS
Dimensions of outdoor units HUB RADIATOR MINI Dimensions of indoor unit HUB RADIATOR MINI
Booster
HR 3.0
HR 7.8
Values expressed in mm
L
700
902
H
552
650
P
256
307
I
275
350
II
435
620
kg
33
55
dB(A)
52
60
579 250
1200
P
H
I II
L
M) Before filling the system make sure that all of
them the pipes are well connected and that there are
not leaks, proceed with opening the tap filling, bleed
all the air in the system and put in pressure.
SCALA 1 : 6

17
4.3 PERFORMANCE CHARACTERISTICS EXTERNAL BOOSTER HUB RADIATOR MINI UNITS
BOOSTER 3.0 BOOSTER 7.8
6.2 CARATTERISTICHE PRESTAZIONALI UNITÀ ESTERNA BOOSTER HR 3.0
Model
Ta
( °C )
Thermal power supplied kW
Heating water delivery temperature ° C
30 35 40 45 50 55
1,074 -10 1,96 1,93 1,88 1,80 1,67 1,51
HR
3.0
-9 2,02 1,99 1,94 1,86 1,74 1,58
-8 2,08 2,05 2,01 1,93 1,81 1,66
-7 2,14 2,11 2,07 1,99 1,88 1,74
-6 2,20 2,18 2,13 2,06 1,96 1,81
-5 2,27 2,24 2,20 2,13 2,03 1,89
-4 2,33 2,31 2,26 2,19 2,10 1,96
-3 2,40 2,37 2,33 2,26 2,17 2,04
-2 2,47 2,44 2,39 2,33 2,24 2,11
-1 2,54 2,51 2,46 2,40 2,31 2,18
0 2,61 2,58 2,53 2,47 2,38 2,26
1 2,69 2,65 2,60 2,54 2,45 2,33
2 2,76 2,72 2,67 2,61 2,52 2,40
3 2,84 2,80 2,74 2,68 2,59 2,47
4 2,92 2,87 2,82 2,75 2,66 2,55
5 3,01 2,95 2,89 2,82 2,73 2,62
6 3,09 3,03 2,97 2,90 2,81 2,69
7 3,18 3,11 3,05 2,97 2,88 2,77
8 3,27 3,20 3,12 3,05 2,95 2,84
9 3,36 3,28 3,20 3,12 3,03 2,91
10 3,45 3,37 3,29 3,20 3,10 2,98
11 3,55 3,46 3,37 3,28 3,18 3,06
12 3,64 3,55 3,45 3,36 3,25 3,13
13 3,75 3,64 3,54 3,44 3,33 3,20
14 3,85 3,74 3,63 3,52 3,41 3,28
15 3,95 3,83 3,72 3,60 3,48 3,35
Modello
Ta
( °C )
Potenza elettrica assorbita kW
Temperatura mandata acqua riscaldamento °C
30 35 40 45 50 55
1,074 -10 0,66 0,75 0,84 0,94 1,05 1,19
HR
3.0
-9 0,66 0,75 0,84 0,94 1,06 1,19
-8 0,66 0,75 0,84 0,94 1,06 1,19
-7 0,66 0,75 0,84 0,94 1,06 1,19
-6 0,66 0,75 0,84 0,94 1,06 1,19
-5 0,66 0,75 0,84 0,94 1,06 1,20
-4 0,66 0,74 0,84 0,94 1,06 1,20
-3 0,66 0,74 0,84 0,94 1,06 1,20
-2 0,66 0,74 0,84 0,94 1,06 1,20
-1 0,66 0,74 0,84 0,94 1,06 1,20
0 0,66 0,74 0,84 0,94 1,06 1,20
1 0,66 0,74 0,84 0,94 1,06 1,20
2 0,66 0,74 0,84 0,94 1,06 1,20
3 0,66 0,74 0,84 0,94 1,06 1,20
4 0,66 0,74 0,83 0,94 1,06 1,20
5 0,65 0,74 0,83 0,94 1,06 1,20
6 0,65 0,74 0,83 0,94 1,06 1,20
7 0,65 0,74 0,83 0,94 1,06 1,20
8 0,65 0,74 0,83 0,94 1,06 1,20
9 0,65 0,73 0,83 0,94 1,06 1,20
10 0,65 0,73 0,83 0,94 1,06 1,20
11 0,65 0,73 0,83 0,94 1,06 1,20
12 0,65 0,73 0,82 0,93 1,06 1,20
13 0,64 0,73 0,82 0,93 1,06 1,20
14 0,64 0,73 0,82 0,93 1,06 1,20
15 0,64 0,72 0,82 0,93 1,05 1,20
Model
Ta
( °C )
C.O.P.
Heating water delivery temperature ° C
30 35 40 45 50 55
1,074 -10 2,96 2,59 2,25 1,91 1,59 1,27
HR
3.0
-9 3,04 2,67 2,32 1,98 1,65 1,33
-8 3,14 2,75 2,39 2,05 1,71 1,39
-7 3,23 2,84 2,47 2,12 1,78 1,46
-6 3,32 2,92 2,54 2,19 1,84 1,52
-5 3,42 3,01 2,62 2,26 1,91 1,58
-4 3,52 3,10 2,70 2,33 1,97 1,64
-3 3,63 3,19 2,78 2,40 2,04 1,70
-2 3,74 3,28 2,86 2,47 2,10 1,76
-1 3,85 3,37 2,94 2,54 2,17 1,82
0 3,96 3,47 3,02 2,61 2,23 1,88
1 4,08 3,57 3,11 2,69 2,30 1,94
2 4,20 3,67 3,20 2,76 2,37 2,00
3 4,33 3,78 3,29 2,84 2,43 2,06
4 4,46 3,88 3,38 2,92 2,50 2,12
5 4,59 4,00 3,47 3,00 2,57 2,18
6 4,73 4,11 3,57 3,08 2,64 2,24
7 4,87 4,23 3,66 3,16 2,71 2,30
8 5,01 4,35 3,76 3,24 2,78 2,36
9 5,16 4,47 3,86 3,33 2,85 2,42
10 5,32 4,60 3,97 3,42 2,92 2,48
11 5,48 4,73 4,08 3,51 3,00 2,54
12 5,64 4,86 4,19 3,60 3,07 2,61
13 5,81 5,00 4,30 3,69 3,15 2,67
14 5,99 5,15 4,42 3,78 3,23 2,74
15 6,17 5,29 4,54 3,88 3,31 2,80
6.5 CARATTERISTICHE PRESTAZIONALI UNITÀ ESTERNA BOOSTER HR 7.8
Modello
Ta
( °C )
Potenza elettrica assorbita kW
Temperatura mandata acqua riscaldamento °C
30 35 40 45 50 55
1,074 -10 1,78 2,00 2,25 2,52 2,83 3,19
HR
7.8
-9 1,78 2,00 2,25 2,53 2,84 3,19
-8 1,78 2,00 2,25 2,53 2,84 3,20
-7 1,78 2,00 2,25 2,53 2,85 3,20
-6 1,78 2,00 2,25 2,53 2,85 3,21
-5 1,78 2,00 2,25 2,53 2,85 3,21
-4 1,78 2,00 2,25 2,53 2,85 3,22
-3 1,78 2,00 2,25 2,53 2,86 3,22
-2 1,77 2,00 2,25 2,54 2,86 3,22
-1 1,77 2,00 2,25 2,54 2,86 3,23
0 1,77 2,00 2,25 2,54 2,86 3,23
1 1,77 1,99 2,25 2,53 2,86 3,23
2 1,77 1,99 2,25 2,53 2,86 3,23
3 1,76 1,99 2,24 2,53 2,86 3,23
4 1,76 1,99 2,24 2,53 2,86 3,23
5 1,76 1,98 2,24 2,53 2,86 3,23
6 1,76 1,98 2,24 2,53 2,86 3,23
7 1,75 1,98 2,23 2,52 2,86 3,23
8 1,75 1,98 2,23 2,52 2,85 3,23
9 1,75 1,97 2,23 2,52 2,85 3,23
10 1,74 1,97 2,22 2,52 2,85 3,23
11 1,74 1,96 2,22 2,51 2,85 3,23
12 1,73 1,96 2,22 2,51 2,84 3,22
13 1,73 1,95 2,21 2,50 2,84 3,22
14 1,73 1,95 2,21 2,50 2,83 3,22
15 1,72 1,95 2,20 2,49 2,83 3,21
Model
Ta
( °C )
Thermal power supplied kW
Heating water delivery temperature ° C
30 35 40 45 50 55
1,074 -10 5,12 5,05 4,91 4,69 4,36 3,93
HR
7.8
-9 5,27 5,20 5,07 4,86 4,55 4,13
-8 5,43 5,36 5,23 5,03 4,73 4,33
-7 5,58 5,52 5,40 5,20 4,92 4,53
-6 5,75 5,68 5,56 5,37 5,10 4,73
-5 5,91 5,85 5,73 5,55 5,28 4,92
-4 6,09 6,02 5,90 5,72 5,47 5,12
-3 6,26 6,19 6,07 5,90 5,65 5,31
-2 6,44 6,36 6,25 6,08 5,83 5,50
-1 6,63 6,54 6,43 6,26 6,02 5,70
0 6,82 6,73 6,61 6,44 6,20 5,89
1 7,01 6,91 6,79 6,62 6,39 6,08
2 7,21 7,10 6,97 6,80 6,57 6,27
3 7,42 7,30 7,16 6,99 6,76 6,46
4 7,63 7,50 7,35 7,17 6,94 6,65
5 7,84 7,70 7,55 7,36 7,13 6,84
6 8,06 7,91 7,75 7,56 7,32 7,03
7 8,29 8,12 7,95 7,75 7,51 7,22
8 8,52 8,34 8,15 7,95 7,70 7,41
9 8,76 8,56 8,36 8,15 7,90 7,60
10 9,00 8,79 8,57 8,35 8,09 7,79
11 9,25 9,02 8,79 8,55 8,29 7,98
12 9,51 9,26 9,01 8,76 8,49 8,17
13 9,77 9,50 9,24 8,97 8,69 8,36
14 10,04 9,75 9,47 9,19 8,89 8,56
15 10,32 10,00 9,70 9,40 9,09 8,75
Model
Ta
( °C )
C.O.P.
Heating water delivery temperature ° C
30 35 40 45 50 55
1,074 -10 2,87 2,52 2,18 1,86 1,54 1,23
HR
7.8
-9 2,96 2,60 2,25 1,92 1,60 1,29
-8 3,05 2,68 2,33 1,99 1,67 1,35
-7 3,14 2,76 2,40 2,06 1,73 1,41
-6 3,23 2,84 2,47 2,12 1,79 1,47
-5 3,32 2,92 2,55 2,19 1,85 1,53
-4 3,42 3,01 2,62 2,26 1,92 1,59
-3 3,53 3,09 2,70 2,33 1,98 1,65
-2 3,63 3,18 2,78 2,40 2,04 1,71
-1 3,74 3,28 2,86 2,47 2,11 1,77
0 3,85 3,37 2,94 2,54 2,17 1,82
1 3,96 3,47 3,02 2,61 2,23 1,88
2 4,08 3,57 3,10 2,68 2,30 1,94
3 4,20 3,67 3,19 2,76 2,36 2,00
4 4,33 3,77 3,28 2,83 2,43 2,06
5 4,46 3,88 3,37 2,91 2,49 2,11
6 4,59 3,99 3,46 2,99 2,56 2,17
7 4,73 4,10 3,56 3,07 2,63 2,23
8 4,87 4,22 3,65 3,15 2,70 2,29
9 5,02 4,34 3,75 3,23 2,77 2,35
10 5,17 4,47 3,86 3,32 2,84 2,41
11 5,32 4,59 3,96 3,40 2,91 2,47
12 5,48 4,72 4,07 3,49 2,98 2,53
13 5,65 4,86 4,18 3,58 3,06 2,60
14 5,82 5,00 4,29 3,68 3,14 2,66
15 5,99 5,14 4,41 3,77 3,21 2,72

18
4.4 Technical data table HUB RADIATOR MINI 6.0 - 8.0 - 11.0 - 16.0
4.5 Sampling table DHW HUB RADIATOR MINI 6.0 - 8.0 - 11.0 - 16.0
DESCRIPTION
DHW withdrawal at 40 ° C - accumulation at 55 ° C - inlet water at 10 ° C
DHW withdrawal at 40 ° C - accumulation at 55 ° C - inlet water at 15 ° C
Recovery time heat pump from 38 ° C to 55 ° C - External temperature 7 ° C *
Recovery time heat pump + resistance from 38 ° C to 58 ° C - External temperature 7 ° C *
Water withdrawal at 40 ° C with accumulation at 62 ° C with inlet water at 10 ° C
Water withdrawal at 40 ° C with accumulation at 62 ° C with water entering at 15 ° C
Recovery time heat pump + resistance from 38 ° C to 62 ° C - External temperature 7 ° C *
Recovery time from 10 ° C to 55 ° C - External temperature 7 ° C *
U.M.
l
l
min
min
l
l
min
min
HR MINI 8.0
51
62
18
15
63
77
22
39
HR MINI 6.0
50
60
21
17
62
76
25
45
HR MINI 11.0
52
64
14
11
65
80
16
30
HR MINI 16.0**
54
66
8
7
67
82
10
19
* Data calculated with heating system switched off
** Continuous domestic hot water supply on one user from 7 liters per minute (inlet water 10 ° C - outlet 40 ° C - outside temperature 7 ° C)
A+ / A++
Inversion cycle with immersion water
R410A
+ 20 / + 55
3
5
15
5
-15 / +45
70
3,3
6,2
3 - 45
8
1
3
1500
230V/1/50Hz
M
70
5
42
1/2” M
3/4” M
1,82
HR MINI 16.0
16,24
3,92
4,14
15,50
4,84
3,20
3,71
150,3
2,0 x 2
5/8” x2
1/4” x 2
58 - 58
92,81
153,31
79 / 134
55 x 2
(1) Heating: outdoor air temperature 7 ° C db - 6 ° C wb .; water inlet / outlet temperature 30/35 ° C
(2) Heating: outdoor air temperature 7 ° C db. - 6 ° C wb.; water inlet / outlet temperature 40/45 ° C
(3) Heating: average weather conditions; T.biv = -7 ° C; water inlet / outlet temperature 30/35 ° C
(4) Water 35 ° C / 55 ° C
DESCRIPTION
Thermal power (1)
Power consumption (1)
C.O.P. (1)
Thermal power (2
Power consumption (2)
C.O.P. (2)
S.C.O.P. (3)
Seasonal heating efficiency (ηs)
Energy efficiency (4)
Defrosting method
Type of refrigerant
Technical water temperature min/max
Quantity of refrigerant (pre-filled)
Min distance between outdoor and indoor unit
Max distance between outdoor and indoor unit without recharging
Max distance between outdoor and indoor unit with charging
Max height difference between outdoor and indoor unit
Refrigerant gas line connection
Fluid coolant line connection
External temperature operating limits
HR MINI accumulation water content
Max electronic inverter circulator flow rate
Max inverter electronic circulator head
Electronic absorption of the inverter electronic circulator
Expansion vessel volume
Preload expansion vessel
Safety valve calibration
Back up electrical resistance
Power supply
PERFORMANCE IN HEAT PUMP - DHW
Withdrawal profile (EN 16147)
Integrated storage tank for DHW production
Power absorbed in stand-by
ERP DATA
External unit sound power
Internal unit sound power (1Z / 2Z)
Seasonal yield (average climate, HT)
Seasonal yield (average climate, LT)
Hydraulic connections for cold water inlet and DHW outlet
System hydraulic flow and return connections
Heat loss internal unit accumulation
Internal weight of transport / operating unit
Outdoor unit weight
U.M.
kW
kW
W/W
kW
kW
W/W
W/W
%
°C
l
m
m
m
m
°C
l
m3/h
m
W
l
bar
bar
W
l
W
dB(A)
dB(A)
%
%
kWh/24h
kg
kg
HR MINI 11.0
11,23
2,71
4,14
10,72
3,34
3,21
3,72
150,6
2,0 + 1,1
5/8” - 3/8”
1/4” - 1/4”
52 - 58
91,05
153,56
79 / 134
55 + 33
HR MINI 8.0
8,12
1,96
4,14
7,75
2,42
3,20
3,71
150,3
2,0
5/8”
1/4”
58
92,81
153,31
70 / 125
55
HR MINI 6.0
6,22
1,49
4,17
5,94
1,81
3,28
3,78
153,1
1,1 x 2
3/8” x 2
1/4” x 2
52 - 52
89,28
153,81
79 / 134
33 x 2

19
5. ELECTRIC HUB RADIATOR MINI DIAGRAMS
5.1 ELECTRICAL SCHEME HUB RADIATOR 6.0
N.B. Before making the electrical connections, make sure you have dimensioned them correctly the section of the power cables based on the actual distance from the meter - Always provide a special magnetothermal protection
LEGEND
M1 - Terminal Booster Pb1 technical water probe Pb3 probe Booster Pb4 electric resistance probe St compressor thermal probe Tr 230v-12v transformer R1 electrical resistance relay RD diverter relay RP pump relay RT voltage monitoring relay TA room thermostat
R electrical resistance
CD dixell digital controller
VD diverter valve
P pump system CR remote command
TM minimum thermostat MT magneto thermal 20A curve C IR electric resistance switch DR electric resistance diverter R1 DHW priority management relay
VOLTAGE MONITORING RELAY SETTING
diverter valve powered flow towards system letter A diverter valve not powered domestic priority letter B

20
5.2 SCHEMA ELETTRICO HUB RADIATOR 8.0
N.B. Before making the electrical connections,
make sure you have dimensioned them correctly
the section of the power cables based on the
actual distance from the meter
- Always provide a special magnetothermal
protection
VOLTAGE MONITORING RELAY SETTING
