Abarth 595 2015 Technical manual

INDEX - VICS(VEHICLE INSTRUCTION CARD)
ABARTH VEHICLES
Page Vehicle Details
1Index n/a
2Supplement (Electronic Parking Brake, etc) n/a
3595 4 seats / 3 door hatchback
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
INDEX PAGE 1

Vehicle specications are subject to change. This vehicle does not include any manufacturer handbooks or manuals.
VEHICLE INSTRUCTION CARD SUPPLEMENT
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for
assistance.
ABARTH VEHICLES
24-10-2015
Don’t panic! Despite seeing a new light pop-up on your instrument panel, unless it is red it is likely the car is still running ne, and while there may be a
problem to attend to, proceed with condence and patience.
RED
Red indicates a potentially serious problem or safety issue. Attend to it! Red may also indicate an important reminder.
YELLOW
Yellow/orange means something needs to be serviced or repaired soon. If it is ashing, it is important that you contact your rental agent for advice.
GREEN
Green or blue is only telling you that a system is on or operating normally.
WARNING LIGHTS AND WHAT THEY MEAN
Deadlock / safelock messages shown on the instrument display when the engine is turned off simply indicate that once you exit the vehicle and lock the
doors, they’re effectively deadlocked and anyone left in the car wouldn’t be able to get out in the event of an emergency. The warning is nothing to worry
about and is just a standard advisory message.
DEADLOCKS

design and production by : Drake Enterprises Limited - Phone : [phone]
USEFUL INFORMATION ABOUT YOUR VEHICLE
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is tted with
an active airbag (SRS). Follow all
tting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in rst or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION! NOTE: SHOULD THIS VEHICLE NOT
BE SUPPLIED WITH A SPARE WHEEL,
PLEASE REFER TO THE TELEPHONE
NUMBERS SHOWN ON THE TAX DISC
HOLDER.
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
Key / remote control operated central dead locking. Depress the door central locking switch on the driver’s door to lock the
doors from the inside. Doors auto lock on vehicle motion.
Some models are tted with a remote anti-theft alarm. Passive arming of immobiliser when key is removed.
Centrally locked. Use the remote key or internal boot release switch to unlock / open. Press the badge logo on the boot to
open it.
Internal electric adjustment via a control pad on the driver’s door.
Electric front operated via control buttons adjacent to gear shift lever. Manually operated rear.
If tted. Electric tilt / slide panoramic sunroof. Use the roof mounted switchgear to operate it.
Ensure gear selector is in neutral (or N or P if automatic) and handbrake is on. Place ignition key into key slot and turn it to
start/stop the engine. Select desired gear. Release handbrake and brake pedal and gently press the accelerator to move the
vehicle. The vehicle may feature automatic engine start/stop technology - auto restart on depression of the clutch.
Located under ap on rear offside. Lift the edge of the ap to open it, centrally locked, twist off the cap anticlockwise.
Pull bonnet release lever located to the lower left of the front passenger footwell. Unhook catch under bonnet.
The rear seat is divided into sections which can be folded separately. To release the seat press the seat unlocking catch and
fold the seat down. To return the seat to normal use, raise the seat and push it rmly to engage the seat lock. Check it is
locked before using the seat.
Lift the carpet cover over the recess inside the boot to access the tyre repair kit, tools and jack. Move the vehicle to rm /
level ground. Turn the engine off, select rst gear (or P if automatic). Apply the handbrake. Only use the specic reinforced
jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Note: this vehicle does not carry a spare wheel -
follow directions on tyre repair kit or for assistance please refer to the phone numbers shown on the tax disc holder.
To change gears press the button on the shift lever and move the lever forwards or backwards in the gear gate. Select N
for neutral, P when leaving the vehicle, R for reversing (the vehicle must be at a complete standstill before this gear can be
selected). For normal driving select D where the transmission will use all available forward gears automatically (a ‘kickdown
‘ facility is provided when the accelerator is pressed all the way to the oor past the normal acceleration point forcing the
transmission to select a lower gear to obtain maximum acceleration. To manually select gears move the gear shift leaver into
the + and - positions to change gears up or down. Release pressure on the accelerator to return to normal accelerator use).
Whenever the vehicle is at a standstill apply the handbrake.
VIC-ABA-01 / 24-15-2015
ABARTH 595
10
Tilt
Lumbar
Legroom
3
4 SEATS
3 DOOR HATCH
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
ller ap).
Fuel Tank Capacity:
35.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
195/45 R16
205/40 R17
Consult the tyre pressure tables found on
the driver’s door B-pillar or inside the fuel
ller cap.
This vehicle may not carry a spare wheel
but is supplied with a tyre repair kit. For
assistance, please refer to the phone
numbers shown on the tax disc holder.
1 Heating & Ventilation
2 Hazard Lights
3 Starter Switch
4 Headlights
5 Sidelights
6 Indicators
7 Wipers
8 Rear Screen Wipers
9 Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
4 / 5 / 6
7 / 8
2
1
9
Height
11
Locking the doors?
Anti-theft system?
Opening the boot/
tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Starting the engine?
Opening fuel ller cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
12 / 13
1 3
2 4 R
5
P
R
N
D
or
Fold front seats to access rear.
+
-
