ABARTH595/695

AUSTRALIA VERSION

This supplement describes the main characteristics of the Fiat and Abarth right hand drive version.

To obtain peak engine condition and to ensure maximum performance of all of its components, it is necessary to observe the

instructions for vehicle use and vehicle maintenance described in this booklet.

FCA Australia recommends that customers have all maintenance and, where necessary, repairs, carried out at an authorised

Abarth repairer. Please see website www.fiat.com.au/fiat-dealers for a list of authorised Abarth repairers in your region (*).

Authorised Abarth repairers use highly qualified technical staff and ensure that only appropriate equipment and tools are used on

your vehicle.

Failure to carry out maintenance at the recommended intervals can result in deterioration of your vehicle.

Components have been fitted in accordance with the relevant Australian Design Rules for your vehicle.

This supplement contains information regarding the correct use and care of these vehicle components.

For any topic not specifically dealt with in this supplement, refer to the main Owner’s Handbook which should be read thoroughly to

ensure that the vehicle is used correctly and safely.

(*) Not all authorised Abarth dealers will also be authorised Abarth repairers. Please contact your dealer for more information.

3

AUSTRALIA VERSION

DASHBOARD

2

8

3

4

10

7

13

5

66

1

11

12

9

14

1 AB0A0468

1.Side vent – 2.Right stalk: controls wiper, washer, trip computer – 3.Instument panel and warming lights – 4.Left

stalk: external lights controls – 5.Turbo pressure gauge – 6.Central air vents – 7.Uconnect™ – 8.Passenger air bag –

9.Oddment compartment/document tray – 10.Heating/ventilation/climate control – 11.Power windows control – 12.Gear

lever – 13.Driver knee bag – 14.Driver air bag.

4

AUSTRALIA VERSION

2

7

3

2

9

6

12

4

5

1

10

11

8

13

2 AB0A0469

1.Side vent – 2.Levers on steering wheel (only versions with Abarth competizione transmission) – 3.Instument panel and

warming lights – 4.Turbo pressure gauge – 5.Central air vents – 6.Oddment/Car radio compartment – 7.Passenger air

bag– 8.Oddment compartment/document tray – 9.Heating/ventilation/climate control – 10.Power windows control–

11.Abarth competizione transmission – 12.Driver knee bag – 13.Driver air bag.



5

AUSTRALIA VERSION

CHILD RESTRAINTS

1)

The recommendation of the ISO child

(restraints) seats to be used with the

vehicle in the main Owner Handbook

complies with AS/NZS 1754-2013.

CHILD RESTRAINT

INSTALLATION

Your vehicle has been designed to

accommodate child restraints on

the rearmost seats. When using a

child restraint, read the Installation

Instructions supplied with the child

restraint and follow the directions for

fitment carefully.

Fasten the upper belt (that is supplied

together with the child seat) to the

fastener B-fig.3 set between the rear

back-rest and the boot floor.

3 F0S0134

INSTALLATION OF THE

ATTACHING CLIP

Correct engagement of the child

restraint attaching clip 1-fig.4 is

achieved by depressing the retainer

spring 2 and then passing through

the opening of the anchor fitting 3 as

shown in the illustration.

FRONT

1

2

3

4 F0S167Ab

WARNING

1) When installing a child restraint

ensure that head restraint is raised

and tether strap is placed underneath

directly on the top of the seat back. Child

restraint anchorages are designed to

withstand only those loads imposed by

correct-ly fitted child restraints. Under

no circumstances are they to be used

for adult seat belts, harnesses or for

attaching other items or equipment to the

vehicle.

6

AUSTRALIA VERSION

Child restraint system installation

The table provides guidelines on positioning child restraint systems on the car

seats. Each child restraint system position complies with the UNECE standards

Number of seats

Seat number 1 2

3

45*6

Airbag

ENABLED

Airbag

DISABLED

Seat suitable for rearward

facing child restraint systems

(U)

XX NO NO YES X YES

Seat suitable for forward

facing child restraint systems

(UF)

X X NO NO YES X YES

i-Size seat (i-U) X X NO NO NO X NO (1)

Seat suitable for ISOFIX side

fixtures (L1 / L2) X X NO NO NO X NO

Seat suitable for ISOFIX

rearward facing fixtures (R1/

R2 / R3) (IL)

X X NO NO NO X YES (R1 and

R2 only) **

7

AUSTRALIA VERSION

Number of seats

Seat number 1 2

3

45*6

Airbag

ENABLED

Airbag

DISABLED

Sear suitable for ISOFIX

forward facing fixtures (F2/

F2X / F3) (IUF)

XX NO NO YES X YES

Sear suitable for forward

facing Booster fixtures (B2/

B3 fixtures)

X X NO NO NO (1) X Only B2

U = Position suitable for a "universal" child restraint system approved for this weight category.

UF = Position suitable for a "universal" forward facing child restraint system approved for this weight category.

IUF = Position suitable for an "ISOFIX" universal forward facing child restraint system approved for this weight category.

i-U = Position suitable for an i-Size "universal" forward facing or rearward facing child restraint system.

i-UF = Position suitable for an i-Size "universal" forward facing child restraint system.

IL = Position suitable for specific listed ISOFIX child restraint systems (CRS). These ISOFIX CRS are classified as "car-specific", "restricted

use" and "semi-universal".

X = Not applicable. The seat is not approved for installation of child restraint systems.

** = Installation only possible by moving the corresponding front seat forward. In this configuration, the seat must not be occupied.

(1) = This seat is not approved for use with this category of child restraint systems. Nevertheless, it may still be possible to install this

category of child restraint system. Therefore, check the compatibility of this vehicle with the identified child restraint system on the

manufacturer's website.

NOTE For any further details on installation/use, refer to the instruction manual for the child restraint system.

8

AUSTRALIA VERSION

SUPPLEMENTARY

RESTRAINT

SYSTEM (SRS) -

AIRBAG

2)

FRONT AIRBAGS

Passenger side front

airbag

On this vehicle model it is not possible

to disable the passenger front Airbag.

Passenger side front

airbag and child

restraint systems

The vehicle is equipped with a

Supplementary Restraint System

airbag for the front passenger. Under

no circumstances attempt to install a

child seat or child restraint device on

the front passengers seat.

WARNING

2) NEVER use a rearward facing child

restraint on a seat protected by an

ACTIVE AIRBAG in front of it, DEATH

or SERIOUS INJURY to the CHILD can

occur.

5 AB0A0308

FUEL TYPE

The engine in this vehicle is designed

to use only unleaded fuel with an

octane rating (RON) not less than 95.

For the type of fuel to use and for

information regarding what to do if

your car is accidentally filled with other

types of fuel see the main owner’s

manual. Use unleaded fuel only.

9

AUSTRALIA VERSION

TYRES

In the label fig. fig.6 shows the type

of tyre adopted and the required infl

ation pressure. Refer to the “Technical

data” chapter for futher information.

6 F0S158Ab

10

AUSTRALIA VERSION

NOTE

................................................................................................................................................................................................................................................................................................

11

AUSTRALIA VERSION

...............................................................................................................................................................................................................................................................................................

FCA Italy S.p.A. – MOPAR – Technical Service Operations - Service Library

Largo Senatore G. Agnelli 3 – 10040 Volvera – Torino (Italy)

Print N. 603.53.929– 04/2021 – 1 Edition

OWNER HANDBOOK

A B A R T H 5 9 5 / 6 9 5

DearCustomer,WewouldliketocongratulateandthankyouforchoosinganAbarth595/695.Wehavewrittenthishandbooktohelpyougettoknowallthefeaturesofyourcaranduseitinthebestpossibleway.Youshouldreaditrightthroughbeforetakingtotheroadforthefirsttime.Hereyouwillfindinformation,adviceandimportantwarningsaboutusingthecarandhowtoachievethebestperformancefromthetechnologicalfeaturesofyourAbarth595/695.Italsoprovidesadescriptionofspecialfeaturesandessentialinformationforthecareandmaintenanceofyourcarovertimeaswellasforsafedriving.IntheattachedWarrantyBookletyouwillalsofindadescriptionoftheServicesthatAbarthofferstoitscustomers,theWarrantyCertificateandthedetailofthetermsandconditionsformaintainingitsvalidity.WeareconfidentthatthesewillbringyouclosertoyournewcarandmakeyouappreciatetheassistanceprovidedbytheAbarthteam.Enjoyreading.Happydriving!ThisOwnerHandbookdescribesallversionsoftheAbarth595/695;pleaseconsideronlytheinformationrelevanttothetrimlevel,engineandversionofyourcar.Alldatacontainedinthispublicationarepurelyindicative.FCAItalyS.p.A.canmodifythespecificationsofthevehiclemodeldescribedinthispublicationatanytime,fortechnicalormarketingpurposes.Forfurtherinformation,contactanAbarthDealership.

READTHISCAREFULLYREFUELLINGOnlyrefuelwithunleadedpetrolwithoctanerating(RON)notlessthan95,incompliancewiththeEuropeanspecificationEN228.Theuseofotherproductsormixturesmaydamagetheenginebeyondrepairandconsequentlyinvalidatethewarranty,duetothedamagecaused.STARTINGTHEENGINEVersionwithmanualtransmission:makesurethatthehandbrakeisengaged;setthegearlevertoneutral;fullydepresstheclutchpedalwithoutpressingtheaccelerator,thenturntheignitionkeytoAVVandreleaseitassoonastheenginehasstarted.Versionswithrobotisedsequentialtransmission:makesurethatthehandbrakeisengagedandthatthegearleverisinP(Parking)orN(Neutral),fullydepressthebrakepedal,thenturntheignitionkeytoAVVandreleaseitassoonastheengineisstarted.PARKINGONFLAMMABLEMATERIALThecatalyticconverterdevelopshightemperaturesduringoperation.Donotparkthecarongrass,dryleaves,pineneedlesorotherflammablematerial:firehazard.RESPECTINGTHEENVIRONMENTThevehicleisfittedwithasystemthatcarriesoutacontinuousdiagnosisoftheemission-relatedcomponentsinordertohelpprotecttheenvironment.ELECTRICALACCESSORIESIf,afterbuyingthecar,youdecidetoinstallelectricalaccessories(withtheriskofgraduallydrainingthebattery),contactanAbarthDealership.Theywillcalculatetheoverallelectricalconsumptionandcheckthatthecar’selectricalsystemcansupporttherequiredload.CODECard(whereprovided)Keepitinasafeplace,notinthecar.WerecommendthatyoualwayscarrytheelectroniccodeprovidedontheCODECardwithyou,incaseyouneedtoperformanemergencystart.

SCHEDULEDSERVICINGCorrectmaintenanceofthecarisessentialforensuringthatitmaintainsitsperformanceanditssafetyfeatures,itsenvironmentalfriendlinessandlowrunningcostsforalongtimetocome.THEOWNERHANDBOOKCONTAINS...importantinformation,adviceandwarningsforcorrectuse,drivingsafetyandmaintenanceofyourcarovertime.Specialattentionmustbepaidtothesymbolsprovided(safetyofpersons)(environmentalprotection)(carintegrity).SYMBOLSSomecarcomponentshavecolouredlabelswhosesymbolsindicateprecautionstobeobservedwhenusingthiscomponent.Underthebonnetthereisalsoalabelthatsummarisesallthesymbols.

CHANGES/ALTERATIONSTOTHECARWARNINGAnychangeoralterationofthecarmightseriouslyaffectitssafetyandroadholding,thuscausingaccidents,inwhichtheoccupantscouldevenbefatallyinjured.ACCESSORIESPURCHASEDBYTHEOWNERIfafterbuyingthecar,youdecidetoinstallelectricalaccessoriesthatrequireapermanentelectricalsupply(e.g.radio,satelliteanti-theftsystem,etc.)oraccessoriesthatinanycaseburdentheelectricalsupply,contactanAbarthDealership,whosepersonnelwillcheckwhetherthecar’selectricalsystemisabletowithstandtheloadrequired,orwhetheritneedstobeintegratedwithamorepowerfulbattery.IMPORTANTTakecarewhenfittingadditionalspoilers,alloywheelrimsornon-standardwheelhubs:theycouldreducetheventilationofthebrakesandaffectefficiencyundersharp,repeatedbrakingoronlongdescents.Makesurethatnothingobstructsthepedalstroke(mats,etc.).INSTALLINGELECTRICAL/ELECTRONICDEVICESElectricalandelectronicdevicesinstalledafterbuyingthevehicleinthecontextofafter-salesservicemustcarrythefollowinglabel.FCAItalyS.p.A.authorisestheinstallationoftransceiversprovidedthatinstallationiscarriedoutataspecialisedcentre,inaworkmanlikefashionandincompliancewithmanufacturer'sspecifications.IMPORTANTTrafficpolicemaynotallowthecarontheroadifdeviceshavebeeninstalledwhichmodifythefeaturesofthecar.Thismayalsocauseinvalidationofwarrantyinrelationtofaultscausedbythechangeeitherdirectlyorindirectlyrelatedtoit.FCAItalyS.p.A.shallnotbeliablefordamagecausedbytheinstallationofaccessorieseithernotsuppliedorrecommendedbyFCAItalyS.p.A.and/ornotinstalledincompliancewiththeprovidedinstructions.RADIOTRANSMITTERSANDMOBILEPHONESRadiotransmitterequipment(carmobilephones,CBradios,amateurradioetc.)cannotbeusedinsidethecarunlessaseparateaerialismountedontheroof.WARNINGTheuseofthesedevicesinsidethepassengercompartment(withoutanexternalaerial)maycausetheelectricalsystemstomalfunction.Thiscouldcompromisethesafetyofthecarinadditiontoconstitutingapotentialhazardforpassengers'health.Inaddition,transmissionandreceptionofthesedevicesmaybeaffectedbytheshieldingeffectofthecarbody.AsfarastheuseofEC-approvedmobilephonesisconcerned(GSM,GPRS,UMTS,LTE),followtheusageinstructionsprovidedbythemobilephoneManufacturer.

USEOFTHEOWNERHANDBOOKOPERATINGINSTRUCTIONSEachtimedirectioninstructions(left/rightorforwards/backwards)aboutthevehiclearegiven,thesemustbeunderstoodasregardinganoccupantinthedriver'sseat.Specialcasesnotcomplyingwiththisrulewillbespecifiedasappropriateinthetext.ThefiguresintheOwnerHandbookareprovidedbywayofexampleonly:thismightimplythatsomedetailsoftheimagedonotcorrespondtotheactualarrangementofyourcar.Inaddition,theHandbookhasbeenconceivedconsideringvehicleswithsteeringwheelontheleftside;itisthereforepossiblethatonvehicleswithsteeringwheelontherightside,thepositionorconstructionofsomecontrolsisnotexactlymirror-likewithrespecttothefigure.ToidentifythechapterwiththeinformationneededyoucanconsulttheindexattheendofthisOwnerHandbook.Chapterscanberapidlyidentifiedwithdedicatedgraphictabs,atthesideofeachoddpage.Afewpagesfurtherthereisakeyforgettingtoknowthechapterorderandtherelevantsymbolsinthetabs.Thereisinanycaseatextualindicationofthecurrentchapteratthesideofeachevenpage.IMPORTANTNOTESANDPRECAUTIONSWhilereadingthisOwnerHandbookyouwillfindaseriesofWARNINGStopreventproceduresthatcoulddamageyourvehicle.TherearealsoPRECAUTIONSthatmustbecarefullyfollowedtopreventincorrectuseofthecomponentsofthecar,whichcouldcauseaccidentsorinjuries.ThereforeallWARNINGSandPRECAUTIONSmustalwaysbecarefullyfollowed.IMPORTANTNOTESandPRECAUTIONSarerecalledinthetextwiththefollowingsymbols:personalsafety;vehiclesafety;environmentalprotection.NOTEThesesymbols,whennecessary,areindicatedbesidesthetitleorattheendofthelineandarefollowedbyanumber.Thatnumberrecallsthecorrespondingwarningattheendoftherelevantsection.

GETTINGTOKNOWYOURCARKNOWINGTHEINSTRUMENTPANELSAFETYSTARTINGANDDRIVINGINANEMERGENCYSERVICINGANDMAINTENANCETECHNICALSPECIFICATIONSMULTIMEDIACONTENTS
