Abilia IRZ-REC4 User manual

Rev D GB
Manual
How to program Control Omni with Andromeda
IRZ-REC4, Andromeda Socket, Schneider Radio
Pushbutton, Schneider Binary Adapter and
Schneider DimmerAdapter

2
Content
1Introduction................................................................................................ 4
1.1Different steps...................................................................................... 4
2Before starting........................................................................................... 5
2.1Important issues .................................................................................. 5
2.2Reset Andromeda IRZ-REC4.............................................................. 5
2.3Reset Schneider Radio Push Button................................................... 6
2.4Reset Andromeda Socket.................................................................... 6
2.5Reset Schneider Binary Adapter and Schneider Dimmer Adapter...... 6
3Include all units to the Control Omni library............................................... 7
3.1Include Gewa Andromeda IRZ-REC4.................................................. 7
3.2Include Andromeda Socket.................................................................. 8
3.3Include Schneider Binary Adapter....................................................... 9
3.4Include Schneider Dimmer Adapter................................................... 10
3.5Include Schneider Radio Push Button............................................... 11
4Set functions on a page in Control Omni................................................. 12
4.1Controlling an Andromeda receiver IRZ-REC4.................................. 12
4.2Controlling an Alert function in combination with Andromeda receiver
IRZ-REC4................................................................................................... 15
4.3Controlling an Andromeda Socket..................................................... 17
4.4Controlling a Schneider Binary Adapter............................................. 19
4.5Controlling a Schneider Dimmer Adapter.......................................... 21
5Associate the Schneider Radio Push Button (double switch).................. 23

3

4
1 Introduction
This instruction shows how to program Control Omni, Z-wave transmitters
and receivers and make a network of them.
1.1 Different steps
1. Reset units
2. Include all units to Control Omni
3. Set functions on a Control Omni page
4. Associate other Z-wave transmitters
Control Omni
Gewa Andromeda
IRZ-REC4 Schneider
Binary Adapter
and Dimmer
Adapter
Schneider Radio
Push Button
Andromeda
Socket

5
2 Before starting
2.1 Important issues
It is important to reset all the units before starting. See below how to do
this.
Warning: Please make sure that the Schneider Radio Push Button is
ALWAYS idle before starting a step. If not, you can get undefined
behavior. You see that it is idle by looking at all LEDs, the one in this
manual has 2 LEDs. They both should be unlit. That is, not green or
red.
Control Omni must always be a Master unit, which means that all units
must be included in the Control Omni library.
The relay units must be connected to power.
2.2 Reset Andromeda IRZ-REC4
Press the button
Setting Press the button
GR-Units Press the button Exclude GR-Unit Press the button
Exclude GR-Unit

6
2.3 Reset Schneider Radio Push Button
Do exactly the same as in section 2.2 but press one of the
buttons 3 times. Be very distinct and do it quick.
2.4 Reset Andromeda Socket
Do exactly the same as in section 2.2 but press the
programming area 3 times. Note the red arrow. Be very distinct
and do it quick.
2.5 Reset Schneider Binary Adapter and Schneider
Dimmer Adapter
Do exactly the same as in section 2.2 but press the
programming area 3 times. Note the red arrow. Be very distinct
and do it quick.
Press 3 times on
the programming
button. Be very
distinct and do it
quick. The relay in
Andromeda will
click 3 times when
success.
Press the button
as next picture

7
3 Include all units to the Control Omni library
Control Omni must work as a master unit, which means that all units in the
network must be included in the Control Omni library.
3.1 Include Gewa Andromeda IRZ-REC4
Name the unit and
press the green
s
y
mbo
l
. Read
y
!
Press 3 times on
the programming
button
Press the button
Setting Press the button
GR-Units Press the button
Include GR-Unit Press the button
as next picture

8
3.2 Include Andromeda Socket
Name the unit and
press the green
symbol. Ready!
Press the button
Setting Press the button
GR-Units Press the button
Include GR-Unit Press the button
as next picture
Press 3 times on
the programming
area.

9
3.3 Include Schneider Binary Adapter
Name the unit and
press the green
symbol. Ready!
Press 3 times on
the programming
area.
Press the button
Setting Press the button
GR-Units Press the button
Include GR-Unit Press the button
as next picture

10
3.4 Include Schneider Dimmer Adapter
Name the unit and
press the green
symbol. Ready!
Press 3 times on
the programming
button
Press the button
Setting Press the button
GR-Units Press the button
Include GR-Unit Press the button as next picture

11
3.5 Include Schneider Radio Push Button
Name the unit and
press the green
symbol. Ready!
Press 3 times on
any button (quick)
Press the button
Setting Press the button
GR-Units Press the button
Include GR-Unit Press the button
as next picture

12
4 Set functions on a page in Control Omni
4.1 Controlling an Andromeda receiver IRZ-REC4
For demonstrating this, a page is prepared in Control Omni which is called
“Test page”.
It is possible to make a button with a toggling function which
means On/Off on the same button or with one button for On and
one button for Off. In this example we make two buttons.
Press the button
Setting
Press the button
Send GR
Press the button
Environment
Press the button
Pages/Buttons Press the button Select page
Press the button
Function
Select a button by
pressing Edit
button
Select a page

13
Press the button
GR-Unit Select the right
unit. In this
example the
Andromeda
receiver.
Select channel,
which is the same
as relay 1-4 and
press the green
s
y
mbo
l
.
Select Basic ON. It is possible to test
the function and
after that, set the
function to the
button.
Do you want to
activate the function
when you press or
when you release
the button? Select!
Press the button
Control Press the button
Switch Binary

14
You are now ready
with the first button
(On). Press button
Done.
Go on with the next
button, the Off
function. Start from
the beginning of
this section.
After that you can
go on and program
other relays on
Andromeda
receiver.

15
4.2 Controlling an Alert function in combination with
Andromeda receiver IRZ-REC4
Press the button
Setting Select System Select Alert
function Select Send GR
Select GR-UnitPress the button
Change setting Select the right
unit, (ID:10)
Andromeda
receiver
Press the button
Control

16
Press the button
Switch Binary It is possible to test
the function and
after that, set the
function to Alert.
You are now ready
with configuration.
Press Done.
Press the button
Basic
Press the button,
Turn on Send GR.
Select channel,
which is the same
as relay 1-4 and
press the green
s
y
mbo
l
.

17
4.3 Controlling an Andromeda Socket
For demonstrating this we have prepared a page in Control Omni
as we call “Test page”.
It is possible to make one button with a toggling function,
On/Off on the same button or with one button for On and
one button for Off. In this case we make two buttons.
Press the button
Setting
Press the button
Send GR
Press the button
Environment
Press the button
Pages/Buttons Press the button Select page
Select a button
Select a page
Press the button
Function

18
Press the button
GR-Unit Select the right
unit.
Select Basic ON It is possible to test
the function and
after that, set the
function to the
button.
Do you want to
activate the function
when you press or
when you release
the button? Select!
Press the button
Control Press the button Switch Binary
You are now ready
with the first button
(On). Press button
Done.
Go on with the next
button, the Off
function. Start from
the beginning of
this section.

19
4.4 Controlling a Schneider Binary Adapter
For demonstrating this we have prepared a page in Control Omni
as we call “Test page”.
It is possible to make one button with a toggling function,
On/Off on the same button or with one button for On and
one button for Off. In this case we make two buttons.
Press the button
Setting
Press the button
Send GR
Press the button
Environment
Press the button
Pages/Buttons Press the button Select page
Select a button
Select a page
Press the button
Function

20
Press the button
GR-Unit Select the right
unit.
Select Basic ON It is possible to test
the function and
after that, set the
function to the
button.
Do you want to
activate the function
when you press or
when you release
the button? Select!
Press the button
Control Press the button Switch Binary
You are now ready
with the first button
(On). Press button
Done.
Go on with the next
button, the Off
function. Start from
the beginning of
this section.
