Ablerex ATS-16A User manual

ATS-16A/20A/30A/32A
Automatic Transfer Switch
User Manual

1
Table of Contents
1. Safety Instructions..................................................................................2
2. Product Description................................................................................3
3. Installation and Operating Instructions...................................................6
3.1.Packaging...............................................................................................6
3.2.Choose an installation location ..............................................................6
3.3.Product Introduction...............................................................................7
3.4.Product Installation and Operation.......................................................14
4. Troubleshooting....................................................................................17
5. System Specifications..........................................................................18
6. Appendix A. Dry contacts available for configuration...........................20
7. Appendix B. SNMP Card available Error Code....................................21
8. Appendix C. LCD available Error Code................................................22

2
1. Safety Instructions
SAVE THESE INSTRUCTIONS. This manual contains important
instructions that should be followed during installation and
maintenance of the ATS.
1. Do not disassemble this product without a technician from the original
manufacturer or authorized distributor. Doing so voids your warranty and is
also a shock hazard.
2. Every component of this product is checked for high specification standards.
Performance maintenance or parts replacement should only be done by a
qualified technician or authorized distributor.
3. Do not install the product at the following locations without a qualified
technician:
Medical equipment directly related to human life preservation;
Equipment on elevators or rapid transit systems related to personal safety;
Critical computing hardware for public systems;
Other equipment similar to the ones mentioned above.
4. Please discuss with your distributor before installing the product at the
locations mentioned above. Special considerations and designs are required
for the operation, setup, management, and maintenance of critical equipment
and emergency backup power generators related to personal safety and
public facilities.
5. Do not place vases or other water containers on top of the main unit. Water
spilled into the machine may damage internal components and pose a shock
hazard.
6.Using this product in locations with sparks, smoke, or natural gas may result in
arcing, personal injury, and fire hazards.
7.The operating environment and storage method affects the product lifespan
and malfunctions. Thus, please keep the product away from the following
operating environments:
Locations specified in the operating manual as high temperature, low
temperature, and high humidity (temperatures outside -5 to 40 a℃nd
relative humidity outside 0% to 90%);
Locations with sparks;
Locations with dust, corrosive material, salt content, or flammable gas;
Outdoors.
8.Immediately stop using this product in the event of abnormal sounds or odors.
Contact your distributor for maintenance.
9.Improper grounding results in electrical leakage. Please make sure your AC
input power is properly grounded.
10.Please confirm the input voltage does not exceed the rated capacity of the
ATS.

3
2. Product Description
ATS Feature:
The ATS (Automatic Transfer Switch) features two independent power
supply circuits supplying power to the load (as shown in Figure 1 below). In the
event of a power failure in the main circuit, the ATS automatically switches to the
other circuit to supply power to the load. The ATS automatically switches back to
the main circuit after power is restored. In addition, the ATS also provides user
configurable power states (voltage or frequency) for the ATS switching condition.
Figure 1. ATS block diagram
ITS Feature:
ITA is a ATS module plus maintenance function. It can continue to
power its output load during maintain or replace the ATS module.
Figure 2. ITS HOT SWAP block diagram
Load
SOURCE A
SOURCE B

4
Procedure for replacing or maintaining ATS module in ITS product
1. To turn “Source Switch” to “Source A” position if ATS module powers
load by Source A, otherwise to turn “Source Switch” to “Source B”
position.
ATS
Source A
Source B
LOAD
SourceSwitch
OutputSwitch
1.
2.
2. To turn “Output Switch” from “Normal” to “Bypass” position. It will have
4ms maximum breaker time at this step. Now the load power comes
from Bypass loop.
Source A
Source B
LOAD
SourceSwitch
OutputSwitch
1.
2.
3. To maintain or replace ATS module.
4. To command output source of ATS module same as Bypass loop.
5. To turn “Output Switch” from “Bypass” to “Normal” position. It will have
4ms maximum breaker time at this step. Now the load power comes
back to ATS loop.

5

ATS
Source A
Source B
LOAD
SourceSwitch
OutputSwitch
1.
2.

6
3. Installation and Operating Instructions
3.1. Packaging
3.1.1. Remove the PE foam.
3.1.2. Inspect accessories
○
1RS-232 cable x1 pcs
○
2USB cable x1 pcs
○
3CD (monitoring software, Setting tool ) x1 pcs
○
4User manual
○
5Handle and screws x1 set
○
6Backplate and screws x1 set (only ATS Standard Series)
3.2. Choose an installation location
An appropriate installation location will optimize system performance,
reduce the chances of malfunctions, and prolong product lifespan. Please follow
the guidelines below for an appropriate location:
3.2.1. Avoid excessive high temperature or high humidity;
3.2.2. Keep away from dust, volatile gases, excessive salt content, or
corrosive gases;
3.2.3. Do not use outdoors.

7
3.3. Product Introduction
3.3.1. Front Panel
No. Item Description/function
○
1Mute button Turns off alarm
○
2Source selection button Select source to view info: Input A, Input B, or
Load
○
3Info selection button Select source info to view: Voltage, current,
frequency, load capacity
○
4Input selection button Switch input source: Input A Input B
○
5LCD System status display
○
6Error indicator Lit: System malfunction or abnormal
Dim: System normal
○
7Input indicator B Lit: Normal input voltage and frequency
Dim: Abnormal input voltage and frequency
Flashing: Indicates higher priority
○
8Input indicator A Lit: Normal input voltage and frequency
Dim: Abnormal input voltage and frequency
Flashing: Indicates higher priority
○
9USB port Connection for software setup or monitoring
software
○
10 RS-232 port Connection for software setup or monitoring
software
○
11 Dry contact port Dry Contact
○
12 External communication
slot For external communication cards, e.g. RS- 485, SNMP

8
3.3.2. LCD
Symbol Description/function
Input A error or power failure
Input B error or power failure
Overload
System malfunction or abnormal
Alarm on
Alarm off
Digital display showing input/output power
connected to load
ATS numeric display

9
3.3.3. Rear Panel
ATS Standard Series:
ATS-120(120V-20A)
ATS- 130(120V-30A)
ATS-216(230V-16A)
ATS- 232(230V-32A)

10
①Power input
(B) ⑤Output socket
②Power input (A) ⑥Output breaker
③,④Input breaker (optional, sold separately)
⑦Power output

11
ITS HOT SWAP Series:

12
3.3.4. Interface
The ATS provides three communication ports and one external
communication slot (optional) for the user.
Standard communication ports: RS-232, USB, and 5 dry contacts
External communication slot: SNMP, RS-485
3.3.4.1. RS-232
3.3.4.2. USB
Pin Signal Type
1 N/A N/A
2 TX Output
3 RX Input
4 N/A N/A
5 GND Ground
6 N/A N/A
7 N/A N/A
8 N/A N/A
9 N/A N/A
Pin Signal
1 VBUS
2 D-
3 D+
4 GND
7. Input Power (B)
8. Input Power (A)
9. Cable tie mount
10.Source switch
11.Source A indicator
12.Source B indicator
1. Output switch
2. Normal indicator
3. Bypass indicator
4. Output Breaker
5. Output socket
6. Output terminal

13
3.3.4.3. Dry Contact
The ATS provides five user configurable dry contacts for customized
features. The capacity of each contact is 24Vdc/1A, additional information is
provided in Appendix A.
Pin Definition Signal (default)
1 Common 3 N/A
2 Relay 3 Overload
3 Relay 4
Overload time out
4 Common N/A
5 Relay 5
Over temperature
6 Common 1 N/A
7 Relay 1
Source A abnormal
8 Common 2 N/A
9 Relay 2
Source B abnormal

14
3.4. Product Installation and Operation
3.4.1. Installation Procedure:
1. Open package and note the packaging layers. Keep the box and
packaging material in case further transportation is required.
2. Check for damage to the ATS from shipping and handling. Please
contact your local distributor if the product is damaged.
3. Check the input power cable/socket and output socket of the delivered
ATS model with your order.
4. Affix the backplate (Figure 1) onto the ATS (Figure 2). Affix the ATS onto
the frame of the chassis (Figure 3).
5. Insert the load plugs into the ATS sockets labeled "OUTPUT" and
spreading them as evenly as possible.
6. Check that the total load does not exceed ATS specifications (e.g.
voltage, current).
7. Supply power to the ATS. The ATS automatically boots up after 1
second and supplies the capacity power to the connected load.
Figure 1 & 2
Figure3

15
3.4.2. ATS HOT SWAP Series Installation Steps:
1. Open package and note the packaging layers. Keep the box and
packaging material in case further transportation is required.
2. Check for damage to the ATS from shipping and handling. Please
contact your local distributor if the product is damaged.
3. Check the input power cable/socket and output socket of the delivered
ATS model with your order.
4. Affix the backplate (Figure 1) Affix the ATS onto the frame of the
Maintenance Box (Figure 2) .
5. Insert the load plugs into the ATS sockets labeled "OUTPUT" and
spreading them as evenly as possible.，Then enter the product's rated
operating power connection。
6. Check that the total load does not exceed ATS specifications (e.g.
voltage, current).
7. Supply power to the ATS (Figure 3),. The ATS automatically boots up
after 1 second and supplies the capacity power to the connected load.
8. Finally, the ATS host body with screws to the rack (Figure 4), to
complete the installation
F
ig
ure1 Figure2
Figure3 Figure4

16
3.4.3. Boot up
Once input power is connected, the ATS automatically boots up. The LCD
display during boot is as shown in Figure 5 and all LEDs ( , , )
are lit. LCD display is as shown in Figure 6 after boot up, only the LEDs for
Power A ( ) and Power B ( ) are lit.
Figure5 Figure6
3.4.4. Switch input source
This products supports manual switching between power supplies as instructed
below:
Push and hold the button for 2 seconds until you hear two short beeps.
The system then needs to reconfirm the power transfer (LCD display as shown
in Figure 7), so push and hold the button for 2 seconds to confirm. The
system will switch to the other input (LCD display as shown in Figure 8) if the
power supply is normal, otherwise the transfer is not made and a warning is
shown (LCD display as shown in Figure 9).
Figure7 Figure8 Figure9

17
4. Troubleshooting
If your ATS is not working normally, use the following status and
troubleshooting table to make the appropriate adjustments. Please contact your
distributor as soon as possible if the issue cannot be resolved.
Issue Possible reason Solution
ATS is OFF
Not connected to the
electrical grid Check the connection from the electrical grid to the ATS input
Abnormal electrical grid Request service by professional
electrician
Input breaker has been
tripped Reset breaker
Internal components
have been damaged Please contact the distributor
Power is supplied to
the load but panel
remains off
Internal components
have been damaged Please contact the distributor
Error code Er03 to
Er06 Not connected to the electrical grid Check the connection from the electrical grid to the ATS input
Abnormal electrical grid Request service by professional
electrician
Error code Er16 Overload Check the load capacity
Error code Er22 to
Er33 Abnormal internal components Please contact the distributor
*Only Er16, Er30, Er31, Er32, Er33 error codes are available displayed on LCD.
All error codes are available for SNMP card event.

18
5. System Specifications
Model ATS-120 ATS-130 ATS-216 ATS-232
Input
Input voltage 100/110/115/120/127
( +/- 5% / 10% / 15% / 20% ) 200/208/220/230/240 ( +/- 5% / 10% / 15% / 20% )
Input voltage range 75Vac~150Vac 150Vac~300Vac
Input frequency 50 / 60Hz
( +/- 5% / 10% / 15% / 20% )
Input current 20A 30A 16A 32A
Output
Output voltage 100/110/115/120/127 200/208/220/230/240
Output current 20A 30A 16A 32A
Protection Input Breaker(option)
Electronic circuit
Communication RS-232, USB, Dry contact
external slot for option card(SNMP, RS-485)
Transfer time(ms) 8~12ms (Typical) *
Efficiency 99%(with full linear load)
Display LCD+LED
Connection
Input NEMA 5-20 x 2 NEMA L5-30 x 2 IEC C20 x 2 Terminal Block 6P
output NEMA 5-20 x 8 NEMA L5-30R x 1
NEMA 5-20x 8 IEC C19 x 1
IEC C13 x 8 IEC C19 x 2 IEC C13 x 16
Physical
Dimension,
D X W X H (mm) 275x440x44 275x440x88 275x440x44 275x440x88
Net Weight (kgs) 4646
Environment
Operating
temperature -5~40∘C @ 0~90% RH(non-condensing)
Standards
compliance Safety UL 60950-1/ CAN/CSA C22.2 No. 60950-1 / IEC 60950-1
EMC FCC Part 15 / EN62310-2

19
Model ITS - 130 ITS - 130F ITS - 232 ITS - 232F
Input
Input voltage (V) 100V / 110V / 115V / 120V / 127V
(±5%、±10%、±15%、±20%) 200V / 208V / 220V / 230V / 240V (±5%、±10%、±15%、±20%)
Input voltage
range 75Vac~150Vac 150Vac~300Vac
Input frequency
(Hz) 50 Hz /60Hz (±5%、±10%、±15%、±20%)
Input current (A) 30A 30A 32A 32A
Output
Output voltage (V) 100V / 110V / 115V / 120V /
127V 200V / 208V / 220V / 230V / 240V
Output current (A) 30A 30A 32A 32A
Protection Input Breaker(option)
Electronic circuit
Communication RS-232, USB, Dry contact
external slot for option card(SNMP, RS-485)
Transfer time
(ms) 8~12 ms (Typical) *
Efficiency 99%(with full linear load)
Display LCD+LED
Connection
Input Terminal Block
6P Terminal Block 6P Terminal Block 6P Terminal Block 6P
Output NEMA5-15 x 8 NEMA L5-30R x
2 IEC-C13 x 8
IEC-C19 x 2 NEMA L6-30 x 2
Physical
Dimension,
D X W X H (mm) 325x440x88
NetWeight(kgs) 6
Environment
Operating
temperature -5~40∘C @ 0~90% RH(non-condensing)
Standards
compliance Safety UL 60950-1/ CAN/CSA C22.2 No. 60950-1 / IEC 60950-1
EMC FCC Part 15 / EN62310-2
