Abocom CFE100 User manual

CFE100
CompactFlash Size
10/100 Fast Ethernet
LAN Card
GENERAL
This CompactFlash Size 10/100 Fast Ethernet LAN Card is
designed for Windows CE-based PDA/palm-sized PCs,
handheld PC and any computer with a CompactFlash slot.
With this CompactFlash LAN Card, you can access to 10BaseT
or 100BaseTX networks for high speed internet browsing and
E-mail anytime, anywhere in the office.
Also, it will rapidly synchronize and exchange data with
Windows-based PCs and enterprise systems nearly 2000 times
faster than 56K serial connection. Plus, with the included
CompactFlash PC Card Adapter, this CompactFlash Fast
Ethernet LAN Card turns into a PC card that plugs into any
computer with a PCMCIA slot. A 3.3/5V auto-switch circuit are
designed in, so you can inserted this PC card into any notebook
PC with PCMCIA or CardBus interface. The CompactFlash
10/100 Fast Ethernet LAN Card is simple to use, providing
automatic installation, and no external power is required.
FEATURES
For PDA/Palm PC: (Compact Card Only)
CompactFlash sized package
CF+/CompactFlash specification rev. 1.4 compliant.
For WinCE PDA/Palm-sized PC, Handheld PC with
CompactFlash slot
Complete installation software for easy setup and adapter
configuration.
Designed for Windows CE 2.0 or newer supports
synchronization from Microsoft Windows 95/98/NT4.0/
2000/ME/XP
For Notebook PC: ( with accessory adapter)
PCMCIA 2.0/2.1compliant
10/100 Mbps (auto-negotiation and full duplex)
Supports most network operating systems (NOS)
Hot-swap supported and True Plug & Play
Menu-driven installation utility and LAN diagnostics
program included
Low power consumption
Diagnostics LED indicator: Link, Speed, Full Duplex,
Transmit, Receive and Collision.
SPECIFICATION
Network Interface Specifications
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseTX
10/100 Mbps data rate and double in Full Duplex Mode
Operating Systems
For PDA/Palm PC: (Compact Card Only)
Windows CE 2.0 or newer supports synchronization
from Microsoft Windows 95/98/NT4.0/2000/ME/XP
For Notebook PC: ( with accessory adapter)
Novell Netware 3.x, 4.x
Microsoft LAN Manager
Packet Driver Applications
Microsoft Windows for Workgroups 3.11
Windows 3.1
Microsoft Windows NT 3.51, NT 4.0
Windows 95/98/ME
Windows 2000/XP
Linux, SCO Unix
Card and Socket Service Support
PCMCIA PC Card Standard Ver.2.0 and newer
I/O Address Support
Any 32 continuous I/O space
Interrupt Support
3,4,5,7,9,10,11,12,15
Media Coupler Support
UTP (RJ45)
Power Requirements
3.3/5V auto-switch circuit
Normal Operation: + 3.3V , 155mA max
+ 5V , 175mA max
Host Interface & Physical Specifications
For Notebook PC: ( with accessory adapter)
PCMCIA 2.0/2.1 compliant.
Type II PC Card
137mm x 54mm x 5.0mm
55gw with Compact PC Card Adapter
For PDA/Palm PC: (Compact Card Only)
CF+ and CompactFlash Spec. Rev. 1.4 compliant.
Type I CompactFlash I/O Card
88mm x 42.8mm x 3.3mm, 30gw
LED Indicators
Six LEDs on the Direct Port
Link (Green, On)
100 (Orange, On)
Full (Green, On)
RX (Green, Blink)
COL (Orange, On)
TX (Green, Blink)
EMI and PTT Conformance
FCC part 15 Class B
CE Mark EN55002 Class B, EN50081-2
VCCI Class B
