Abode G2S3002 P User manual

Hot Pink, Lime Green or Poppy Red 1.7 Litre Kettle
Model number: G2S3002 P/G/R
Please read these instructions carefully and keep them for future reference
User manual
For Customer Services & Spare Parts please call 0845 209 7461
Opening times: Monday - Friday 9am –5pm & Saturday 9am –1pm or visit us at www.productcareuk.com

Contents
Page
Unpacking your kettle……………..…..........................
Safety instructions..................................................
Feature diagram.....................................................
Using your kettle……………......................................
Cleaning and care...................................................
Connection to the mains supply.............................
2
3
5
6
7
8

Unpacking your kettle
Before you use your kettle
1. Remove all the packaging and ensure none has been left inside.
2. Check the kettle after unpacking for any visual damage such as:
●Misaligned or damaged cabinet parts
●Damage to the base assembly
●Damage to the plug or cable
●If you can see any damage do not use the kettle
3. Check that the filter is located correctly below the spout, to ensure it hasn’t become
loose during transit or storage.
This kettle must be put on a stable horizontal surface, away from walls and cabinets.
The kettle must be placed away from high temperatures and steam.
Do not install the kettle over, on, or near a cooker or other heat producing appliance, or
in a heated oven.
To prevent damage to the heating element, do not operate without water.
2
For Customer Services & Spare Parts please call 0845 209 7461
Opening times: Monday - Friday 9am –5pm & Saturday 9am –1pm or visit us at www.productcareuk.com

Safety instructions
➢Read all instructions.
➢Do not touch hot surfaces. Use the handle or the switch.
➢To protect against electrical shock do not immerse cord, plug, or appliance in water or other
liquid.
➢Do not let the cord hang over the edge of the worktop or touch hot surfaces.
➢Unplug from the mains outlet when not in use and before cleaning.
➢Do not operate any appliance with a damaged cord or plug, or after the appliance
malfunctions or is dropped or damaged in any manner. The supply cord cannot be replaced. If
the cord is damaged the appliance should be scrapped.
➢The use of accessory attachments not recommended by the appliance manufacturer may
cause fire, electric shock or injury.
➢Only use with the stand provided.
➢This appliance must not be immersed
➢Never remove parts from the appliance, such as the feet, screws and so on.
When using electrical appliances, basic safety precautions should always be observed,
including the following:
3

Safety instructions
4
➢Avoid contact with steam from the spout when boiling water or just after it has switched
off. Do not open the lid while the water is boiling. Care should be taken when opening the lid
for refilling.
➢Never overfill the kettle. If overfilled, boiling water may be ejected from the spout. Always
take care to pour the boiling water slowly and carefully without tipping the kettle too fast
➢Do not operate this appliance for anything other than its intended use.
This product is intended for household use only. Do not use outdoors.
This product is only intended for boiling water.
Warning: it is hazardous for anyone other than a competent person to carry out any service or
repair operation which involves the removal of a cover which gives protection against exposure
to electrical parts.
Warning: children should not use this appliance. Close supervision is necessary when any
appliances are used near children.
Warning: this appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to make sure that they do not play with the
appliance.

Feature diagram
5
Warning - Do not touch hot surfaces.
1. Spout
2. Lid
3. On/Off switch
4. Handle
5. Water level indicator
6. Base
7. Power ON indicator
1
2
3
4
5
6
For Customer Services & Spare Parts please call 0845 209 7461
Opening times: Monday - Friday 9am –5pm & Saturday 9am –1pm or visit us at www.productcareuk.com
7

Using your kettle
6
It is recommended that you boil the kettle several times following the below
instructions and discard the water before first use. This will remove any loose dust
or materials that may have remained from the manufacturing process.
1. Open the lid and fill with water. Fill to the required level and close the lid. We
recommend you fill to the maximum line for first use and discard the water as
suggested above.
2. Always fill the kettle between the MIN and MAX lines. If you fill below the MIN
line the kettle may run dry and you may damage the heating element. If the
kettle runs dry the safety cut-out will operate and the power will be removed
from the element to prevent possible damage. To reset, allow the kettle to cool
down or carefully add water. If you fill above the MAX line, then boiling water
may be ejected from the spout.
3. Insert the mains plug into a suitable 13 Amp mains socket.
4. Press the power switch to the ON position ‘I’. The power light will light up.
When the water has boiled the kettle will switch off automatically. Avoid lifting
the kettle from the base while boiling.
For Customer Services & Spare Parts please call 0845 209 7461
Opening times: Monday - Friday 9am –5pm & Saturday 9am –1pm or visit us at www.productcareuk.com

Cleaning and care
➢Do not use harsh detergents, abrasives or spray on cleaners.
➢Don’t allow water to seep into the openings or come into contact with electrical
connection.
➢To prevent scale build up on the element, descale your kettle regularly with a
descaler readily available from most super markets and stores.
WARNING: Electrical Shock Hazard.
Before you clean the appliance, disconnect the mains plug from the wall socket.
Do not immerse cord, plug or appliance in any liquid or allow moisture to come into
contact with electrical parts.
7
➢Allow the kettle to cool off before cleaning.
➢Clean the outer surface using a moist cloth and wipe over with a dry, soft cloth.
For Customer Services & Spare Parts please call 0845 209 7461
Opening times: Monday - Friday 9am –5pm & Saturday 9am –1pm or visit us at www.productcareuk.com

Connection to the mains supply
WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of AC230V ~ 50HZ.
Check that the voltage marked on the product corresponds with your supply voltage.
This product is fitted with a 13A plug complying with BS1363 and is fitted with an appropriate fuse
complying with BS1362. Always replace the fuse with one of the same rating. If the plug is unsuitable for
your mains socket or needs to be replaced, please note the following:
Important: The wires in the mains lead must be connected as per the following diagram -
Always ensure that the plug cord grip is fastened correctly.
If your appliance is supplied with a non-rewireable plug, you will find that it incorporates a fuse, the value
of which is indicated either on the base of the plug or on the fuse carrier. Always replace the fuse with
one of the same rating. If you need to remove the plug, cut it from the mains lead and dispose of it. Never
attempt to re-use this plug or insert it into a socket outlet, as there is a very great risk of an electric shock.
Rated voltage: AC 220V –240V ~50/60Hz,
Power consumption: 1850W –2200W
Capacity: 1.7 Litre
8

For Customer Services & Spare Parts please call 0845 209 7461
Opening times: Monday - Friday 9am –5pm & Saturday 9am –1pm or visit us at www.productcareuk.com

This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that
the product/batteries should not be disposed of with your general household waste. Only discard electrical/electronic/battery
items in separate collection schemes, which cater for the recovery and recycling of materials contained within. Your co-operation
is vital to make sure the success of these schemes and for the protection of the environment. For your nearest disposal facility,
visit www.recycle-more.co.uk or ask in store for details.
We reserve the right due to possible changes to design to alter the instruction manual without prior notice.
Revision 1
