Accu-Scope SKYE WiFi 3 User manual

Manual
73 Mall Drive, Commack, NY 11725 • 631-864-1000 (P)
www.accu-scope.com • [e-mail]
Camera Set Up
& Installation

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 2 -
Contents
CONTENTS.........................................................................................................................................................- 2 -
NOTES AND SAFETY REQUIREMENTS..........................................................................................................- 4 -
CAUTIONS AND NOTES .......................................................................................................................................- 4-
SOFTWARE SYSTEM REQUIREMENTS..........................................................................................................- 5 -
SYSTEM REQUIREMENTS UNDER USB WORK MODE............................................................................................- 5-
SYSTEM REQUIREMENTS UNDER WIFI WORK MODE (MOBILE DEVICE)..................................................................- 5-
PACKAGE CONTENTS......................................................................................................................................- 6 -
FUNCTION INTRODUCTION .............................................................................................................................- 7 -
HARDWARE INTRODUCTION ................................................................................................................................- 7-
OPTIONALACCESSORY INTRODUCTION................................................................................................................- 8-
Connection methods and types.....................................................................................- 9 -
CONNECTION METHODS ...............................................................................................................................- 10 -
CAMERA WORK MODES................................................................................................................................- 11 -
USB WIRED WORK MODE................................................................................................................................ - 11 -
Install SKYE View Software......................................................................................... - 11 -
Connect to the Camera............................................................................................... - 11 -
Open Software ............................................................................................................ - 11 -
WIFI WORK MODE –WINDOWS PC.................................................................................................................. - 11 -
Install SKYE View software......................................................................................... - 11 -
Connect to the Camera...............................................................................................- 12 -
Open Software ............................................................................................................- 12 -
Start to Use.................................................................................................................- 12 -
WIFI WORK MODE -IOS SYSTEM (APPLE)........................................................................................................- 12 -
Install SKYE View app for iOS (iPhone, iPad).............................................................- 12 -
Connect to Device.......................................................................................................- 12 -
Start to Use.................................................................................................................- 13 -
WIFI WORK MODE -ANDROID SYSTEM .............................................................................................................- 14 -
Install SKYE View app for Android ..............................................................................- 14 -
Connect to Camera.....................................................................................................- 14 -
Start to Use.................................................................................................................- 15 -
ETHERNET (LOCALAREA NETWORK –LAN) CONNECTION .................................................................................- 15 -
Connect to LAN...........................................................................................................- 15 -
Install SKYE View app.................................................................................................- 15 -
Connect to Camera.....................................................................................................- 15 -
Viewing Images via LAN .............................................................................................- 15 -
Start to Use.................................................................................................................- 16 -
HDMI CONNECTION.........................................................................................................................................- 17 -
Connect HDMI cable...................................................................................................- 17 -
Install SKYE View app.................................................................................................- 17 -

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 3 -
Connect to Camera.....................................................................................................- 17 -
Start to Use.................................................................................................................- 17 -
TROUBLESHOOTING......................................................................................................................................- 18 -
USB MODE:IMAGE ACQUISITION PROBLEMS .....................................................................................................- 18 -
Images are not acquired..............................................................................................- 18 -
WIFI MODE:IMAGE ACQUISITION PROBLEMS .....................................................................................................- 18 -
Cannot connect to WiFi...............................................................................................- 18 -
Image acquisition failure or large delay in image refresh rate.....................................- 18 -
No image display in WiFi output mode........................................................................- 19 -
INTERFACE PROBLEMS .....................................................................................................................................- 19 -
External HDMI monitor does not display / display exceptions.....................................- 19 -
LIMITED WARRANTY ......................................................................................................................................- 19 -
DIGITAL CAMERAS FOR MICROSCOPY................................................................................................................- 19 -

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 4 -
Notes and Safety Requirements
Cautions and Notes
1) To avoid danger or damage incurred to the lens, do not touch the lens or sensor
directly with your fingers.
2) To avoid failure or electric shock hazard and so on, do not disassemble or modify
the internal structure of the device.
3) Do not plug in or unplug the USB port when hands are wet.
4) Do not use alcohol and other organic solvents to clean.
5) If the lens or sensor is dirty or damp, it is better to use dry and non-linen fabric or
professional lens tissue to wipe them. To avoid scratches on the surface, do not
touch the lens with your fingers. Wipe the lens or sensor lightly.
6) The products are not designed for outdoor use. Do not expose it to outdoor
environment without any protection. Excessive temperature and humidity will
damage the lens. Please avoid using the product under the following environment:
high temperature or high humidity environment, places with direct sunlight, dirt or
vibration and places near heat source.
7) Please use and store in the following environment:
Operating temperature ：0℃~ 60℃
Storage temperature：-10℃~ 60℃
Operating Humidity ：30~60%RH
Storage Humidity：10~80%RH
8) If any foreign matter, water or liquid enters the device, disconnect the USB cable
immediately. Please send it to ACCU-SCOPE for maintenance. DO NOT use a
hair dryer to dry it by yourself.
9) To prevent microscope from being tripped over or dropped, please put away the
device's USB cables in use or standby.
10)To avoid electric shock by accident, please power off microscope before you move
your computer or laptop.
11)The cleanliness of the device lens will directly affect clarity degree of contents
from the computer screen during preview. Problems like various circles or spots
on the screen may mostly be incurred by dirt on the lens. When cleaning, please
use professional lens tissue or other professional detergent to clear the dirt on the
lens.

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 5 -
Software System Requirements
System Requirements under USB Work Mode
Macintosh OS not supported.
•Windows 10 (64-bit) or higher
•i5 (10th gen.) processor or later
•512GB hard disk space or more
•16GB RAM
•Graphics card: Core graphics
•USB 2.0 high-speed port
•Internet connection for software download
•Wireless network card, IEEE802.11ac compatible
•LAN network card for Ethernet operation, 10/100/1000Mb auto adaptive
System Requirements under WiFi Work Mode (mobile device)
Android
•Android v7.0 or higher
•Dual-Core processor, 1.7GHz or later
•32GB storage space or more
•3GB RAM
•Supports 5GHz WiFi wireless protocol
IEEE802.11ac
iOS (Apple)
•iOS 11.0 or later
•Dual-Core processor, 1.8GHz or later
•32GB storage space or more
•2GB RAM
•Supports 5GHz WiFi wireless protocol
IEEE802.11ac
Windows PC
•Windows 10 (64-bit) or higher
•i5 (10hgen.) processor or later
•512GB hard disk space or more
•16GB RAM
•Graphics card: Core graphics
•USB 2.0 high-speed port
•Internet connection for software download
•Wireless network card: IEEE802.11ac

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 6 -
Package Contents
1. SKYE WiFi 3 Camera
2. USB power adapter
3. Gigabit Ethernet cable (2m)
4. HDMI cable (2m)
5. Package insert sheet with quick
connection guide
6. USB stick with software and instruction
manual

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 7 -
Function Introduction
Hardware Introduction
①Antenna
⑤C-mount
②Power indicator LED
⑥HDMI port
③Mode switch (WiFi / Off / USB)
⑦Ethernet port
④ACT indicator LED
⑧USB / power cord (attached)
①
②
③
⑤
⑥
⑦
⑧
④

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 8 -
①Antenna (5G)
②Power indicator LED:
•Red: Power is off
•Green: Power is on and camera is in WiFi or USB mode.
③Mode Switch:
Divided into Three modes：
•Toggle left (USB icon): Enables PC connection and power supply via USB
•Toggle middle (switch icon): Off
•Toggle right (WiFi icon): wireless mode or Ethernet mode; power via USB to AC outlet
④Activity (ACT) indicator LED:
•Blue: Camera in WiFi mode. Camera is ready for connection by smart device via WiFi.
•Off: Camera is operating in another mode (USB)
⑤C-mount:
Camera can be installed onto the microscope camera port using a standard C-mount adapter for the given
microscope. Refer to Product Assemble below, or your microscope’s instruction manual.
⑥HDMI Port:
Connect HDMI cable to camera and HDMI-ready monitor/TV to view images from the camera. Camera must be
controlled by mobile device or PC via WiFi connection or by PC via USB or Ethernet connection.
⑦Ethernet Port:
Connect Ethernet cable (RJ46) to Local Area Network or router using Ethernet cable (not included). Connect PC
to LAN via Ethernet cable or to router via Ethernet cable or WiFi. Switch Mode Switch to WiFi mode –camera will
automatically switch to Ethernet mode. Use software on PC to control camera and view images.
⑧USB/Power Cable (USB Type A connector; hard-wired to the camera):
Cable is “cut-off” in illustration.
Two operations:
•Power only: Connect end to USB power adapter to draw power from AC receptacle. Camera control and
data transfer occurs via WiFi or Ethernet connection to the camera.
•Power and Data Transfer: Connect USB end to Windows PC USB port. Camera draws power from PC
through the USB cable, and camera control and data transfer shares the same USB cable.
Optional accessory Introduction
C-mount Adapter for Microscope Photo Port: The SKYE WiFi 3 camera
can be adapted to most photo ports of most manufacturer’s microscopes.
Contact your microscope dealer for the appropriate C-mount adapter to fit
your particular model of microscope.

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 9 -
Connection methods and types
1. Remove dust plug from the C-mount on the bottom of the camera.
2. Thread C-mount adapter into C-mount of camera. For the SKYE WiFi 3, the optimal C-mount
adapter magnification is 0.5x. NOTE: Hold the camera and adapter sideways to minimize any
dust from entering the camera. Dust degrades the image quality.
3. Set the bottom of the C-mount adapter (with camera attached) into the camera port of the
microscope and secure in place with the locking screw.
Some microscopes may require other adapters to attach the camera to the microscope. Please
consult your microscope manual, microscope sales representative or the microscope manufacturer for
the required adapter(s).

SKYE WiFi 3TM Set Up & Installation Manual
ACCU-SCOPE, Inc. 73 Mall Drive, Commack, NY 11725 • 631-864-1000 • www.accu-scope.com - 10 -
Connection Methods
