ACD DS210 Series Operator's manual

Automation
Computertechnik
Datentechnik
Hardware Documentation
DS210 Docking Station
Version: 1.50
© Copyright ACD
Gruppe
Dieses Dokument darf ohne Zustimmung weder vervielfältigt
noch Dritten zugänglich gemacht werden.

DS210_HardwareDocu_V1.50_EN.doc 2 / 20
Content
Content...............................................................................................................2
1 Overview......................................................................................................3
2 Security advices...........................................................................................4
3 Scope of supply............................................................................................5
3.1 ACD DS210 Standard.................................................................................................5
3.2 ACD DS210 Ethernet..................................................................................................5
3.3 ACD DS210 Modem 56K TTL.....................................................................................5
3.4 ACD DS210 ISDN.......................................................................................................5
4 Operation of the DS210................................................................................6
4.1 Status LED of the DS210............................................................................................6
4.1.1 POWER...................................................................................................................... 6
4.1.2 CHARGE .................................................................................................................... 6
4.1.3 2. BATTERY............................................................................................................... 6
4.1.4 CONNECT.................................................................................................................. 7
4.1.5 LED on the RJ45 connector........................................................................................ 7
4.2 Placing the M210 in the docking station DS210 .........................................................7
4.3 Remove the M210 out of the docking station DS210 .................................................8
4.4 Data transfer via USB to a PC ....................................................................................8
4.5 Connection of a USB end device................................................................................8
4.6 Connection to the Ethernet (optional interface) ..........................................................8
5 Hardware Configurations..............................................................................9
5.1 Hardware Configuration ACD DS210 Standard..........................................................9
5.2 Hardware configuration ACD DS210 Ethernet .........................................................11
5.3 Hardware configuration ACD DS210 Modem 56K TTL............................................13
5.4 Hardware configuration ACD DS210 ISDN...............................................................15
6 Accessories................................................................................................17
6.1 USB Data cable.........................................................................................................17
6.2 Ethernet connection cable ........................................................................................17
6.3 Manuals.....................................................................................................................17
7 Cleaning and care advices.........................................................................18
8 Technical specifications .............................................................................19
9 Versions / Changes....................................................................................20
Autor: Bruno Staudenrausch / 15.08.16

DS210_HardwareDocu_V1.50_EN.doc 3 / 20
1 Overview
The docking station DS210 is a charging and communication station for the mobile data acquisition terminal
M210.
Features of the standard version are:
•Charging the M210.
•Charging one replacement battery.
•Data transfer via USB interface to a PC.
•Connection of a USB end device e.g. a USB memory stick.
Optional following interfaces are available:
•Ethernet 10/100 Base T.
Following components can also be integrated as an option:
•Analogue Modem.
or
•ISDN Adapter.
Remark:
Design and specifications are subject to change without notice.

NOTE
This is a EN55022 Class A equipment. O
peration of this
equipment in a residential area is likely to cause interference
in which case the user, at his or her own expense, will be
required to take whatever measures may be required to
correct the interference.

NOTE
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
Reasonable protection against harmful Interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to
correct the interference at his own expense.

DS210_HardwareDocu_V1.50_EN.doc 4 / 20
2 Security advices
ATTENTION
For operation of the ACD docking station DS210 you may only use
power supply packs allowed by ACD!
ATTENTION
For indoor use only.
ATTENTION
The power pack must not be covered while it is in operation.
ATTENTION
Do not place the device near heat sources (e.g. fan heaters) and do
not expose it to direct sun beams, exceeding dust sources or
agitations.
ATTENTION
All changes/modifications not approved by ACD Elektronik GmbH
can void the user’s authority to operate the equipment.

DS210_HardwareDocu_V1.50_EN.doc 5 / 20
3 Scope of supply
You will find a list of the scope of supply of each device type in the following.
3.1 ACD DS210 Standard
•DS210 Standard
•Power supply pack
•Country specific power cord
3.2 ACD DS210 Ethernet
•DS210 with Ethernet 10/100 Base T
•Power supply pack
•Country specific power cord
•CAT 5e FTP cable
3.3 ACD DS210 Modem 56K TTL
•DS210 with Analogue Modem
•Power supply pack
•Country specific power cord
•Country specific modem cable
3.4 ACD DS210 ISDN
•DS210 with ISDN
•Power supply pack
•Country specific power cord
•ISDN cable RJ45

DS210_HardwareDocu_V1.50_EN.doc 6 / 20
4 Operation of the DS210
Plug the power cord into the power supply pack. Plug the power cord into the power plug. Plug the low
tension connector of the power supply pack into the plug socket at the back of the DS210 on the left side
(see picture 2). The device is now ready for operation.

NOTE
Disconnection of the equipment from the line voltage is done by
pulling the mains plug.
4.1 Status LED of the DS210
The status LED of the DS210 are placed at the front.
Pic. 1: Status LED of the DS210
4.1.1 POWER
The POWER LED glows green when the DS210 is supplied with voltage via power supply pack.
4.1.2 CHARGE
The LED CHARGE is red when the M210 is being charged. When the M210 is completely charged, the LED
becomes green. For correct display, the M210 has to be switched off. When the M210 is switched on, the
LED CHARGE might possibly glow red, although the battery is already charged.
4.1.3 2. BATTERY
The LED 2. BATTERY glows red when the replacement battery is being charged. Then the replacement
battery is charged, the LED glows green.

DS210_HardwareDocu_V1.50_EN.doc 7 / 20
4.1.4 CONNECT
The CONNECT LED has a different meaning for each of the four device versions.
At the DS210 Standard the CONNECT LED glows green when the USB slave conductor has established a
connection with the PC as well as with the M210. It is not checked if the software driver is also loaded for the
connection!
At the DS210 Ethernet the CONNECT LED blinks green, when the DS210 is connected with the network
cable to the LAN (Ethernet) and the M210 has loaded the Ethernet driver. The CONNECT LED has the
same function as the green Link LED at the network connector (RJ45 with two integrated LED) at the back of
the unit.
At the DS210 Modem 56K TTL the CONNECT LED glows green when the analogue modem has established
a connection.
At the DS210 ISDN this LED can be compared with the status LED at standard ISDN adapters. The
CONNECT LED glows when the ISDN adapter has established a physical connection with the ISDN
conductor, this means when the ISDN RJ45 connecting cable is plugged in the plug socket of the ISDN
network as well as in the RJ45 connector of the DS210. The signaling of the CONNECT LED can also be
programmed inverted.
4.1.5 LED on the RJ45 connector
At the DS210 Ethernet two LED are integrated in the RJ45 connector at the back of the unit. The green LED
is the Link LED. It blinks when the DS210 is connected to the LAN (Ethernet) with a network cable and the
M210 has loaded the Ethernet driver. The yellow LED is the Tx LED. This one blinks when data are
transferred from the M210 via DS210 into the LAN.
Pic. 2: RJ45 connector with LED
4.2 Placing the M210 in the docking station DS210
Pic. 3: Placing the M210 in the docking station DS210
Link
-
LED
Tx
-
LED
Connect. Power
supply pack

DS210_HardwareDocu_V1.50_EN.doc 8 / 20
4.3 Remove the M210 out of the docking station DS210
Pic. 4: Remove the M210 out of the docking station DS210
ATTENTION
The charging and communication contacts are sensible!! Please
remove the device only as descibed above. Do not touch the
contacts! Not with your fingertips nor with tools like ball pen,
screwdriver etc.
4.4 Data transfer via USB to a PC
A usual USB A-B cable is used. Plug the USB-B plug of the cable in the USB-B connector of the DS210 and
the USB-A connector of the cable in the PC. A connection via USB with ActiveSync from Microsoft is
possible from version number 3.7.
ATTENTION
You have to wait at least 3s between taking out the M210 and
placing it in the docking station again. Otherwise the ActiveSync
connection might possibly not be established properly. As the
Connect LED does not check if the driver is being loaded, it will
show a connection in this case anyway!
4.5 Connection of a USB end device
USB end devices can be connected to the USB-A connector of the DS210. The driver of the USB memory
stick is integrated in the image of the M210 by default. A USB memory stick will be recognized automatically
as a further drive of Windows CE.
Other software drivers for other USB end devices can be integrated by ACD in the image of the M210 on
request.
4.6 Connection to the Ethernet (optional interface)
Plug the network cable in the RJ45 connector with the LED at the back of the DS210. After placing the M210
in the DS210 wait approx. 15s until the USB Ethernet driver has loaded completely. After these 15s the Icon
USB Ethernet driver (MOSUSBCE1) will appear in the task bar. You can modificate different settings when
double-clicking this Icon.
Via DHCP an IP address can be assigned automatically to the M210 in the DS210. Alternatively a fix IP
address can also be entered manually.

DS210_HardwareDocu_V1.50_EN.doc 9 / 20
5 Hardware Configurations
There are four hardware configurations of the DS210 which will be described in the following.
5.1 Hardware Configuration ACD DS210 Standard
The ACD DS210 Standard is suitable for charging the M210, for charging a replacement battery, for data
transfer via USB interface to a PC and for the connection of a USB end device e.g. a USB memory stick.
Pic. 5: Back ACD DS210 Standard
Connections from left to right:
•Connection power supply pack.
•The USB-B connector is occupied according to USB Standard. Usual USB-A-B cables can be
connected.
•The USB-A connector is also occupied according to USB Standard. According to the application usual
USB A-B, USB A-miniB cable, USB A-male – A-B-female extension cable or a USB stick can be
connected.
The USB interfaces of the M210 are only put through the DS210 Standard.
Connect. Power
supply pack USB-B USB-A

DS210_HardwareDocu_V1.50_EN.doc 10 / 20
Pic. 6: Block diagram ACD DS210 Standard
USB-
Host USB-
Slave Power supply.
M210
USB-B
M210
USB-A Con.
Po.Su
..
DS210
standard version

DS210_HardwareDocu_V1.50_EN.doc 11 / 20
5.2 Hardware configuration ACD DS210 Ethernet
The ACD DS210 Ethernet is suitable for charging the M210, for charging a replacement battery, for data
transfer via USB interface to a PC and for connection of a USB end device e.g. a USB memory stick.
Furthermore it is possible to connect the DS210 to the LAN (Ethernet) with a network cable. Therfore plug
the network cable in the RJ45 connector with the LED at the back of the DS210.
Pic. 7: Back ACD DS210 Ethernet
Connections from left to right:
•Connection power supply pack.
•The RJ45 connector with the LED is the Ethernet interface.
•The USB-B connector is occupied according to USB standard. Usual USB A-B cables can be connected.
•The USB-A connector is also occupied according to USB standard. According to the application usual
USB A-B, USB A-miniB cable, USB A-male – A-female extension cable or a USB stick can be
connected.
USB-AUSB-B
Connect. power
supply pack LAN RJ45

DS210_HardwareDocu_V1.50_EN.doc 12 / 20
Pic. 8: Block diagram ACD DS210 Ethernet
USB-
Host USB-
Slave Voltage supply.
M210
USB-B
USB – HUB
USB – Ethernet
converter
RJ45
with LED‘s
M210
USB-A Conn
P.S..
N
etzteil
DS210
Ethernet

DS210_HardwareDocu_V1.50_EN.doc 13 / 20
5.3 Hardware configuration ACD DS210 Modem 56K TTL
The ACD DS210 Modem 56K TTL is delivered with integrated analogue modem.
This version of the DS210 is able to charge a M210, to charge one replacement battery, to transfer data
either directly from the M210 or via USB interface to a PC, or per remote data transmission via analogue
modem. Plug the modem cable in the RJ11 connector. Due to RTS/CTS – control lines you can
communicate with the modem with hardwarehandshake. The modem is activated via virtual COM port driver
at COM5. The modem is reset when the M210 is placed in the DS210. Furthermore it is possible to connect
a USB end device e.g. a USB memory stick to the USB-A connector.
Pic. 9: Back ACD DS210 Modem 56K TTL
Connections from left to right:
•Power supply pack.
•The USB-B connector is occupied according to USB standard. Usual USB A-B cables can be connected.
•The USB-A connector is also occupied according to USB Standard. According to the application usual
USB A-B, USB A-miniB cable, USB A-male – A-female extension cable or a USB stick can be
connected.
•A usual modem cable can be connected to the RJ11 connector at the right.
The modem is configured by ACD as follows:
&F Presetting (see modem manual)
S0=0 Modem does not answer incoming calls
&D2 Modem hangs up in dependence of DTR
&K3 RTS/CTS Modem flow control (Hardwarehandshake)
M0 loudspeaker always off
S10=50 5s after loss of carrier the modem hangs up
ACD provides an analogue modem manual.
Connect. Power
supply pack USB-B USB-A Modem RJ11

DS210_HardwareDocu_V1.50_EN.doc 14 / 20
Pic. 10: Block diagram ACD DS210 Modem 56K TTL
USB-B
USB – HUB
USB-
Host
M210
USB-A Conn.
P.S.
USB-
Slave Power supply
M210
DS210
Analogue Modem
USB serial
converter
analogue
modem
adapter
RJ11

DS210_HardwareDocu_V1.50_EN.doc 15 / 20
5.4 Hardware configuration ACD DS210 ISDN
The ACD DS210 ISDN is delivered with integrated ISDN Adapter. In this version the DS210 can charge a
M210, charge one replacement battery, data can be transferred from the M210 either directly via USB
interface to a PC, or per remote data transfer to a ISDN adapter. Plug the ISDN cable into the RJ45
connector without LED at the back of the unit on the right. Due to RTS/CTS – control lines you can
communicate with the ISDN adapter with hardwareshake. The ISDN adapter is activated via virtual COM port
driver at COM5. The ISDN adapter is reset when the M210 is placed in the DS210. Furthermore it is possible
to connect a USB end device e.g. a USB memory stick to the USB-A connector.
Pic. 11: ACD DS210 ISDN
Connections from left to right:
•Connection power supply pack.
•The USB-B connector is occupied according to USB standard. Usual USB-A-B cables can be connected.
•The USB-A connector is also occupied according to USB Standard. According to the application usual
USB A-B, USB A-miniB cable, USB A-plug – A-connector extension cable or a USB stick can be
connected.
•A usual ISDN cable can be connected to the RJ45 connector at the right
The ISDN adapter is configured by ACD as follows:
&F Presetting (see ISDN adapter manual)
S0=0 ISDN adapter does not answer incoming calls
&D2 ISDN adapter hangs up in dependence of DTR
X3 After connection establishment the message „CONNECT“ is displayed with the
corresponding connection speed. The message „NO DIALTONE“ is not displayed.
&K3 RTS/CTS modem flow control (hardwarehandshake)
ACD provides an ISDN adapter manual.
USB-B USB-A
Connect.
Power
supply pack ISDN RJ45

DS210_HardwareDocu_V1.50_EN.doc 16 / 20
Pic. 12: Block diagram ACD DS210 ISDN
USB-B
USB – HUB
USB-
Host
M210
USB-A Conn.
P.S.
USB-
Slave Power supply
M210
DS210
ISDN
USB serial
converter
ISDN
adapter
RJ45

DS210_HardwareDocu_V1.50_EN.doc 17 / 20
6 Accessories
6.1 USB Data cable
Please use a usual USB ‚A – B‘ cable, like e.g. for a printer. You need a type A plug on the PC side, on the
DS210 side a type B plug. You can get such a cable directly from ACD Elektronik: Article number 12100321,
lenght of cable 1,8 m
6.2 Ethernet connection cable
You can get a Ethernet connection cable directly from ACD Elektronik: Article number 12100207, Patch
cable CAT5E screened, RJ45 plugs on both sides, length 2 m.
6.3 Manuals
ACD provides manuals of the analogue modem and of the ISDN adapter.

DS210_HardwareDocu_V1.50_EN.doc 18 / 20
7 Cleaning and care advices
Clean the device while it is seated stable on a surface (e.g. desk top). This ensures a stable halt and the
device cannot drop out of your hands during the cleaning process. Please use a soft and wet cloth for
cleaning.
ATTENTION
Do not use corrosive chemicals, cleaning lotions or acid cleaning
supplies.
ATTENTION
The charging and communication contacts are sensible!! Never
touch the contacts while cleaning the device!

DS210_HardwareDocu_V1.50_EN.doc 19 / 20
8 Technical specifications
Operating temperature 0°C – 40°C / 32°F – 104°F
Storage temperature 0°C – 60°C / 32°F – 140°F
Rel. humidity 5% - 90% non-condensable
Input voltage power supply pack 90 – 264 VAC / 47 – 63 Hz
Protection IP20

DS210_HardwareDocu_V1.50_EN.doc 20 / 20
9 Versions / Changes
Version Date Description
1.00 16.03.07 Docking Station DS210
1.10 20.04.07 Changes Chapter. 3.3 data transmission USB – PC and 3.1.4 Connect
1.20 26.07.07 Minor changes
1.30 30.06.09 Insertation of chapter 4.3 Remove M210 out of the docking station
DS210; Minor changes
1.40 25.10.12 Changes in the layout
1.50 15.08.16 Remove of the part name of the power supply pack.
Tab. 1: Versions / Changes
