ACE TONE RHYTM ACE Full Auto User manual

ACE TONE
RHYTHM ACE
Full Auto
model F R - 2 L
Scan by Manual Manor
http://www.markglinsky.com/ManualManor.html

FRONT PANEL LAYOUT
SPECIAL FEATURES
1) Troublefree
It is an established and well known fact that Electronic
Organs produce sound through electronic device. Likewise,
electronic rhythm instruments have been developed on the
same principle. Hitherto, percussive sounds were produced
mechanically through usage of rotary disc, etc. and since
the operation was dependent almost entirely on its mechanical
make-up, defects caused by mechanical malfunction was by far
the biggest drawback. To over-come such drawbacks, our
revolutionary "RHYTHM ACE" Full Auto has been devel
oped on new principles a nonmechanical solid state elec
tronic brain incorporating modern precision manufactured
transistors.
2) Always start from the first beat.
Rhythm will always start from the first beat. Start, stop
and re-start operations can be done with ease through the
use of a footswitch.
Scan by Manual Manor
http://www.markglinsky.com/ManualManor.html

3) Unlimited Rhythm Variations
Mixing two or more rhythms arithmatically at a time
will produce interesting variations of rhythms. Three cancel
buttons enabling cancellations of Cymbal, Claves, and
Snare Drum will give added rhythm varieties.
PREPARATIONS
1. Insert the power cord into the power outlet.
2. For connection to an amplifier, insert one end of the output
cord into the output jack "low", and the other end into the
amplifier input jack. If the amplifier is not including pre
amplifier or being low inpedance, insert the output cord into
the output jack "high"
BACK PANEL LAYOUT
Start Jaek High Low Power Cord
Output
3. Connect the footswitch plug to the start jack on the rear
panel.
4. Clock-wise turning of the volume knob located on the left
hand corner of the front panel will turn-on power and
further movement in the same direction will increase volume
Scan by Manual Manor
http://www.markglinsky.com/ManualManor.html

of sound. For reproduction of rhythms, press the start button
located on the right hand corner of the panel and then
press any of the 16 rhythm selector buttons. Adjust tone
level of Model FR-2L and the amplifier to which it is con
nected for balanced tonal effects.
SPEED ADJUSTMENTS
5. Clock-wise turning of the Tempo knob will increase tempo
speed. The pilot lamp will light-up on the first beat but
only
for Slow-Rock rhythms, light will come on the first
and third beats.
START BUTTON AND FOOTSWITCH
6. Rhythms will always start from the first beat when you
press the start button. If your hands are occupied in playing
the piano or any other instruments, use the footswitch in
place of the start button but be sure to release the start
button to its original position. To stop the rhythm, either
release the start button to its original position or press the
footswitch again.
CANCEL BUTTONS
7. If any of the three sounds in the rhythm namely, Cymbal,
Claves and Snare Drum is not wanted, press the cancel
button corresponding to the sound that needs cancellation.
Scan by Manual Manor
http://www.markglinsky.com/ManualManor.html

RHYTHM COMBINATIONS
Mixing two(2)or more rhythms simultaneously will produce
interesting rhythm combinations.
For example:
Tango + Mambo =
Tango + Rock'n'Roll =
Slow Rock + Shuffle =
Swing + Western =
Swing + Tango + Waltz =
Shuffle + Swing + Dixieland =
Rock'n'Roll and Bosa Nova, or Rock'n'Roll and Rumba
will be interesting.
PRECAUTION
1) Avoid playing near fluorescent lights, neon lights, transform
ers etc, as such will have the effect creating undesirable
noise.
2) The Model FR-2L Rhythm Ace has been designed to with
stand heavy punishment and. is absolutely free from sound
distortion but should be played within the capacity rating of
the amplifier. It is always advisable to connect to amplifiers
having big output power as this will give you a comfortable
percentage of allowance.
3) Since it covers a very wide range of tones, the quality of
tones may vary according to the types of amplifiers used.
Use any amplifiers having high selective qualities.
Scan by Manual Manor
http://www.markglinsky.com/ManualManor.html

SPECIFICATIONS
ACE ELECTRONIC IND. INC., JAPAN.
