V-Drums V-Tour TD-9KX2 User manual

* 5 1 0 0 0 1 7 0 4 8 - 0 1 *
01 Stand
02 03
Connection procedure
04
01
05
Adjusting the tension
Assembly procedure
■VH-11 (Hi-hat)
02
Turn back to
x the cables
Leave some
slack in the
cables
Tighten it
not to slip
Wind the
cable tie
once
Compatible Stand
TD-9KX2 parts
1/4” plug (mono)
Stereo
1/4" plug
Amplied
speakers, etc.
Stereo
headphones
(indicator)
to AC outlet
AC adaptor
Power cord
1. Adjust the gap between the metal portion in the center of the lower
hi-hat and the sensor’s center tip to a clearance of approximately 3
mm, then tighten the clutch screw.
3mm
2. Change the spring tension by adjusting the hi-hat stand.
* The tension may not be adjustable on some stands.
1. Loosen the clutch screw and let the hi-hat rest naturally on
the motion sensor unit.
2. Press the [SETUP]-[F1] (TRIG) button.
The “TRIGGER TYPE” screen will appear.
3. Use the [CURSOR] button to move the cursor to “H” (HI-HAT).
4. Press the [F3] (ADVNCD)-[F3] (HI-HAT) button.
The following screen will appear.
5. While you watch the meter that’s displayed in the right side of the
screen, turn the VH-11’s VH oset adjustment screw to adjust it.
Adjust the screw so that the black appears in the meter.
T3
T2
CR1
SNR
KIK
TD-9
T1
RD
RDB
HH
HHC
Setup Guide
Kick pad (KD-9) V-Hi-hat (VH-11) V-Pad for snare
(PD-105)
V-Pad for tom
(PD-85 x 3) Percussion sound
module (TD-9)
Connection cable
(special for TD-9)
AC adaptor Drum key
Assemble the stand Attach the parts
Connect the AC adaptor and speakers
Attach the snare (PD-105) and toms
(PD-85)
Attach the hi-hat (VH-11)
Attach the crash cymbal (CY-12C) and ride cymbal (CY-13R)
Attach the sound module (TD-9)
1
3
4
2
5
6
Tuning bolt
Hoop
Washer
Gap
1. Finger-tighten all six of the tuning bolts in
the sequence shown in the illustration.
2. The appropriate amount of tension is one
that will provide approximately the same
striking response as on an acoustic drum.
3. Use the drum key to adjust the tension as
needed.
Rod Rod
Tighten
Loosen
Tighten
Loosen
PD-105
PD-85
PD-85
PD-85
CY-12C CY-13R
KD-9
VH-11
TD-9
Adjusting the oset.
* When performing, make sure that the name “Roland” on the hi-hat is on
the opposite side of the stand from the hi-hat pedal.
Detailed explanation of each part
* Use a commercially available hi-hat stand.
* To prevent malfunction and/or damage to
speakers or other devices, always turn down the
volume, and turn o the power on all devices
before making any connections.
Adjusting the hi-hat.
* The parts required for mounting the cymbals and the
hi-hat are included in the TD-9KX2 attachment box.
V-Cymbal for crash
(CY-12C)
V-Cymbal for ride
(CY-13R)
Diameter: 6.0–7.0 mm
(0.236"–0.276")
Diameter: 11.7 mm (1/2") Max.
CONTROL OUT
jack TRIGGER OUT
jack
HHC plug HH plug
If you’re using the VH-11 V-hi-hat, execute the oset adjustment from the TD-9 after making connections.
This adjustment is required in order to correctly detect open, close, and pedal operations.
Fixing the cables
VH oset
adjustment
screw
OPEN CLOSE
If the closed hi-hat sound is dicult to attain, rotate the VH oset
adjustment screw towards “CLOSE.”
If the open hi-hat sound is dicult to attain, rotate the screw
towards “OPEN.”
* If the sound cuts o when you strike the hi-hat forcefully, rotate the
VH Oset adjustment screw towards “OPEN.”
* Although the gap can be adjusted
to a clearance that makes playing
the hi-hat easier, setting too
narrow or wide a gap can cause
improper function of the unit and
prevent the hi-hat from sounding
as you intend. Setting the gap to
3 mm provides the most natural
feel when playing the VH-11.
* Continuous playing may cause dis-coloration of the pad, but this will not aect the Pad’s function.
* If the hi-hat clutch has been detached from the hi-hat, refer to “If the Clutch Was Apart from the Hi-Hat” in
the owner’s manual.
Insulating plate
Sponge side up
Hi-hat
“Roland” logo
on the farther side
Motion sensor unit
CONTROL OUT jack
on the farther side
Clutch screw
Hi-hat clutch
Check to make sure that the
cymbal rod has been tightened
suciently
Attach the kick pedal (KD-9)
* Use a commercially available hi-hat stand.
* Adjust the position at
which the TD-9 is attached
so it doesn’t make contact
with the VH-11.
As seen from the front
Copyright © 2010 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of
ROLAND CORPORATION.
Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT NOTES.” These
sections provide important information concerning the proper operation of the unit. Additionally, in order to feel
assured that you have gained a good grasp of every feature provided by your new unit, Owner’s manual should be
read in its entirety. The manual should be saved and kept on hand as a convenient reference.
Roland, V-Drums, V-TOUR, V-CYMBALS, and V-HI-HAT are
registered trademarks of Roland Corporation in the United
States and/or other countries.
Check the included items
Stand (MDS-9) Hi-hat mount Cymbal mount
x 2
Cable tie x 6
Drum key
Owner’s Manual
Manual set
Setup Guide (this document)
Quick Start
Owner’s Manual
1. Loosen the hand knobs
(A, two locations) and
spread open the left and
right legs of the stand as
shown in the illustration.
3. Adjust the pad mounts
(C, four locations) as
shown in the illustra-
tion.
2. Loosen the hand knob of
the snare pipe (B), and pull
out the snare pipe toward
the side of the performer.
4. Attach the cymbal
mounts (D, two
locations) as shown in
the illustration.
1.2m
135˚ 135˚
* Do not spread open the stand farther than 135 degrees
as shown in the illustration. Nor should you spread the
stand wider than 1.2 meters (48 inches).
Tighten the wing nut to
obtain an appropriate
amount of sway.
Wing nut
Felt washer
Install the kick pedal
securely.
Connect the pads to the sound module * Use cable ties to fasten the cables at the circled locations “ ” so that they do
not interfere with your performance.
Make sure to wrap the cable ties around the pipes.
* To prevent the inadvertent disruption of power to your unit (should the plug be
pulled out accidentally), and to avoid applying undue stress to the AC adaptor jack,
anchor the power cord using the cord hook, as shown in the illustration.
3. Connect the AC adaptor,
and fasten it to the cable
hook as shown in the
illustration to prevent it
from being accidentally
unplugged.
2. Labels indicating the
pad to be connected are
attached to the cable.
Make connections as
shown in the illustration.
Knob
BOW/EDGE
OUTPUT jack
BELL OUTPUT jack
RD plug
RDB plug
■To learn about the TD-9’s wide range of unique functionality, refer to “Quick Start.”
■If you need further information regarding the set up of TD-9K2, refer to the section “If you don’t hear any
sound in the Owner’s Manual.
This completes assembly and connections.
NOTE
NOTE
Other side
Tighten the bolt with a drum key.
Stopper
Attach the stopper so that
the bolt is on the right-hand
side, from the performer’s
perspective.
1. Connect the cable to the
TD-9 as shown in the
illustration.
Insert the connector all
the way, then turn the
knobs to fasten it securely.
* Insert the plug
rmly, making sure
it’s all the way in.
D: Cymbal mounts
C: Pad mounts
A: Hand knobs
B: Snare pipe
If the stand wobbles,
loosen this hand
knob and adjust the
height.
You do not need
to attach the
hi-hat mount.
As soon as you open the package, check to see that all items are included. If anything is missing, please contact your dealer.
* Use a commercially available kick pedal.

Head replacement procedure
* Be sure to adjust the head tension of
the PD-85 / PD-105 before use.
* Striking the head when the head
tension is loose may damage the
sensor and head.
* Do not apply excessive force to the
sensor located below the center of the
head of the PD-85/PD-105. Doing so
can interfere with accurate detection,
and may damage it.
* Due to the nature of the materials
used in the sensor of the PD-85/
PD-105, changes in room temperature
may aect the sensitivity of the
sensor.
* The rubber portion of the hoop is a
consumable item that will undergo
wear with use over time, depending
on the number and strength of rim
shots. Playing rim shots on the worn
rubber portion may cause malfunc-
tions. If this occurs, the hoop rubber
should be replaced. Please contact
Roland customer service regarding
replacement of the hoop rubber.
Detailed explanation of each part
■PD-85 (Tom)
PD-85 component names PD-105 component names
1. Remove all tuning bolts and washers.
* While you remove the tuning bolts, press your nger against the lock
bushing so that it does not come out of the frame.
* The lock bushing is a part that prevents vibration of the hoop from
turning and loosening the tuning bolts when you play rim shots.
2. Remove the hoop.
3. Remove the old head.
4. Place the new head on the frame.
5. Place the hoop on the head.
6. Pass the washers over the tuning bolts, and attach them to the
hoop and frame.
7. Adjust the head tension.
For details, refer to the explanation on the opposite side of this
leaet.
If a lock bushing comes out of the frame while you’re
replacing the head, align the lock bushing’s slots with the
“+” shaped portion of the frame, and press it rmly into the
frame.
■PD-105 (Snare)
■CY-12C (Crash) ■CY-13R (Ride)
* Continuous playing may cause dis-coloration of the pad, but this will not aect the Pad’s function.
CY-12C component names CY-13R component names
01
■KD-9 (Kick)
Position the beater so that it strikes the
center of the head, then secure the kick
pedal and KD-9 rmly in place.
Step on the kick pedal and make sure
that it’s properly attached and in a stable
position.
Adjusting the Anchor Bolts
When using the kick pedal on a carpet or on
a drum mat (TDM series), the slip-prevention
tape that’s on the base should prevent the
KD-9 from moving around.
However, if that’s not enough to keep the
KD-9 in a xed position, you can adjust
things so that the tips of the anchor bolts
protrude through the base. That should keep
it in place and make it easier for you to play.
KD-9 component names
* Use a commercially available kick pedal.
Attach the kick pedal
Check to make sure that the base of the KD-9 and
the kick pedal both make contact with the oor.
When Using a Twin Pedal
Position the two beaters equally apart from the center of
the pad as shown in the gure at left. If one of the beater is
further away from the center than the other, the sound from
the further beater will be lower in volume, or will not sound
as desired. Using a twin pedal will result in lower sensitivity as
compared to when a single pedal is used.
Raise the sensitivity on the sound module. For details, see
“Editing the pad settings [F2] (BASIC)” in the owner’s manual.
* Install the kick pedal securely.
* Take care not to pinch your
ngers.
* When used on ooring, the
anchor bolts may damage the
oor.
* The tips of the anchor bolts are
sharp. Handle with care.
When using on the
carpet or drum mat
When using on the oor
Beater
Install the kick pedal
securely.
02
03
Check to be sure they’re making
contact with the oor
Bolt
Head
Anchor bolts
Base
OUTPUT jack
Mounting plate
for the kick pedal
* Depending on how
you’re using the unit,
the bolts that attach the
pedal to the plate could
become loose, causing
the pedal to rattle
during performance.
In such cases, use
commercially available
tools to tighten the
bolts.
Hoop (Rim)
Tuning bolt
Washer
Sensor
Wing bolt
Head
OUTPUT jack
Frame
Holder
Wing nut
Head
Hoop (Rim)
Tuning bolts
Lugs
OUTPUT jack
Shell
Bracket
Frame
NOTE
The head is an expendable item that eventually will wear out and need to be replaced. Replace the head when the following occurs:
Slack portions remain in the head even when the head tension is properly adjusted.
* To obtain replacement heads, please contact the nearest Roland Service Center or an authorized Roland distributor, as listed in “Information.”
Drum key
Loosen Tighten
Hoop
Hoop’s
rubber portion
Lock bushing
Washer
Frame
Tuning bolt
Lock bushing
Frame
NOTE
Edge
Pad face
Bow
BOW/EDGE
OUTPUT jack
Edge
Pad face
Bow
Bell
BELL
OUTPUT jack
BOW/EDGE
OUTPUT jack
Fixing the cables
(CY-12C/CY-13R)
Secure the cable
in place with the
cable tie
Leave some slack
in the cable
Be sure to make
this small plastic
hook visible
from you.
Wind a cable tie
around the pipe
and tighten it in
order to not to
slip.
Wind a cable tie around a cable.
Insert the small plastic hook to
a hole to secure the cable to
the cymbal arm.
NOTE
WARNING
• Do not open or perform any internal
modications on the unit.
• Do not attempt to repair the unit, or
replace parts within it (except when this
manual provides specic instructions
directing you to do so). Please consult
an authorized Roland distributor or the
nearest Roland Service Center; a list
of these can be found in the owner’s
manual for the device to which you are
connecting.
• Never install the unit in any of the
following locations.
• Subject to temperature extremes
(e.g., direct sunlight in an enclosed
vehicle, near a heating duct, on top
of heat-generating equipment);
or are
• Damp (e.g., baths, washrooms, on
wet oors); or are
• Exposed to steam or smoke; or are
• Subject to salt exposure; or are
• Humid; or are
• Exposed to rain; or are
• Dusty or sandy; or are
• Subject to high levels of vibration
and shakiness.
• This unit should be used only with
a stand (MDS series) that is recom-
mended by Roland.
• When using the unit with a stand (MDS
series) recommended by Roland, the
stand (MDS series) must be carefully
placed so it is level and sure to remain
stable. If not using a stand (MDS series),
you still need to make sure that any
location you choose for placing the
unit provides a level surface that will
properly support the unit, and keep it
from wobbling.
WARNING
• Do not place containers containing
liquid on this product. Never allow
foreign objects (e.g., ammable objects,
coins, wires) or liquids (e.g., water or
juice) to enter this product. Doing
so may cause short circuits, faulty
operation, or other malfunctions.
• In households with small children, an
adult should provide supervision until
the child is capable of following all the
rules essential for the safe operation of
the unit.
• Protect the unit from strong impact.
(Do not drop it!)
CAUTION
• Try to prevent cords and cables from
becoming entangled. Also, all cords
and cables should be placed so they are
out of the reach of children.
• Never climb on top of, nor place heavy
objects on the unit.
• Should you remove nuts, washers,
screws, anchor bolts, etc., keep them
in a safe place out of children’s reach,
so there is no chance of them being
swallowed accidentally.
Placement
• Do not expose the unit to direct sunlight, place
it near devices that radiate heat, leave it inside
an enclosed vehicle, or otherwise subject it to
temperature extremes. Excessive heat can deform or
discolor the unit.
• When moved from one location to another where the
temperature and/or humidity is very dierent, water
droplets (condensation) may form inside the unit.
Damage or malfunction may result if you attempt to
use the unit in this condition. Therefore, before using
the unit, you must allow it to stand for several hours,
until the condensation has completely evaporated.
• Do not allow rubber, vinyl, or similar materials to
remain on this unit for long periods of time. Such
objects can discolor or otherwise harmfully aect
the nish.
Maintenance
• For everyday cleaning wipe the unit with a soft,
dry cloth or one that has been slightly dampened
with water. To remove stubborn dirt, use a cloth
impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly with
a soft, dry cloth.
(KD-9)
As routine maintenance, you should wipe the striking
surface using a dry, soft cloth.
• Never use benzine, thinners, alcohol or solvents of
any kind, to avoid the possibility of discoloration and/
or deformation.
Additional Precautions
• Use a reasonable amount of care when using the
output jacks. Rough handling can lead to malfunc-
tions.
• When connecting / disconnecting all cables, grasp
the connector itself—never pull on the cable. This
way you will avoid causing shorts, or damage to the
cable’s internal elements.
• To avoid disturbing your neighbors, try to keep
the unit’s volume at reasonable levels. You may
prefer to use headphones, so you do not need to be
concerned about those around you.
• This instrument is designed to minimize the
extraneous sounds produced when it’s played.
However, since sound vibrations can be transmitted
through oors and walls to a greater degree than
expected, take care not to allow these sounds to
become a nuisance to neighbors, especially when
using headphones.
• When you need to transport the unit, package it
in the box (including padding) that it came in, if
possible. Otherwise, you will need to use equivalent
packaging materials.
• Some connection cables contain resistors. Do not use
cables that incorporate resistors for connecting to
this unit. The use of such cables can cause the sound
level to be extremely low, or impossible to hear. For
information on cable specications, contact the
manufacturer of the cable.
• The rubber portion of the striking surface is treated
with a preservative to maintain its performance. With
the passage of time, this preservative may appear on
the surface as a white stain, or reveal how the pads
were struck during product testing. This does not af-
fect the performance or functionality of the product,
and you may continue using it with condence.
• Continuous playing may cause dis-coloration of the
pad, but this will not aect the Pad’s function.
• The hi-hat stand is supported by means of a tripod.
When installing the hi-hat, make sure the legs of
the tripod are opened wide enough to keep the
equipment from falling over.
• Do not remove the special VH-11 clutch from the
hi-hat or disassemble the clutch.
• When not using the hi-hat for extended periods,
store the hi-hat in the open position to prevent
placing any stress on the motion sensor unit.
• High-precision sensors are located at the portion of
the motion sensor unit indicated by the arrow in the
left gure below. Take care not to subject this area to
excessive shock, and do not allow any foreign objects
to enter any gaps.
• Over long periods of use, the portion of the motion
sensor unit that comes into contact with the hi-hat
(the damper) may become worn at the points
indicated by the arrows in the right gure above.
Such damper wear may prevent proper adjustment
of the oset and may cause the hi-hat to swing
with an unnatural motion. If this occurs, replace
the damper. For more information on replacing the
damper, contact Roland Service.
• In the interest of product improvement, the specica-
tions and/or appearance of this unit are subject to
change without prior notice.
IMPORTANT NOTES For EU Countries
For China
WARNING
This product contains chemicals known to cause cancer, birth defects and other reproductive harm, including lead.
For C.A. US
(
Proposition 65
)
Used for instructions intended to alert the
user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse eects caused with
respect to the home and all its
furnishings, as well to domestic animals
or pets.
Used for instructions intended to alert the
user to the risk of death or severe injury
should the unit be used improperly.
The symbol alerts the user to things that must be
carried out. The specic thing that must be done is
indicated by the design contained within the circle. In the
case of the symbol at left, it means that the power-cord
plug must be unplugged from the outlet.
The symbol alerts the user to important instructions or
warnings.The specic meaning of the symbol is
determined by the design contained within the triangle. In
the case of the symbol at left, it is used for general
cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never be
carried out (are forbidden). The specic thing that must
not be done is indicated by the design contained within
the circle. In the case of the symbol at left, it means that
the unit must never be disassembled.
About WARNING and CAUTION Notices About the Symbols
ALWAYS OBSERVE THE FOLLOWING
Base
Slip-prevention tape
