1
IEEE 802.11b Wireless USB Adapter
User’s Guide
Version: 3.0 — August 2001

1
Copyright Statement
No part of this publication may be reproduced, stored in any retrieval
system, or transmitted in any form or by any means, whether electronic,
mechanical, photocopying, recording or otherwise without the prior
writing of the publisher.
Windows 95/98 and Windows 2000 are trademarks of Microsoft Corp.
Pentium is trademark of Intel.
All copyright is reserved.

2
Table of Contents
1. Welcome……………………………………………………………4
1.1 Kit Contents................................................................................5
1.2 Main Feature of WLAN USB Adapter.......................................7
1.3 Wireless Networking Scenarios..................................................9
1.4 Advantages for Using Wireless Network..................................12
2. Quick Start to Wireless Networking……………….……………14
3. Step-by-Step Installation Guide…………………………………18
3.1 Install the IEEE802.11b USB WLAN Utility / Driver.............19
3.2 Install the USB Adapter............................................................24
3.3 IEEE802.11b USB WLAN Utility...........................................26
3.3.1 Setting................................................................................27
3.3.2 Statistics.............................................................................29
3.3.3 Site Survey .........................................................................30
3.3.4 Encryption .........................................................................31
3.3.5 Advanced ...........................................................................34
3.3.6 Version...............................................................................36
3.4 Remove your USB Adapter......................................................37
3.5 Uninstall the IEEE802.11b USB WLAN Utility / Driver.........38
4. Network Application…………………………………………….40
4.1 Surveying the Network Neighborhood.....................................41
4.2 File Sharing in Microsoft Windows 98.....................................43
4.3 Printer Sharing in Windows 98.................................................46
4.4 Using the Shared Folder...........................................................48
4.5 Using the Shared Network printer ............................................49

3
5. Specifications……………………………………………………..50
5.1 Physical Specifications.............................................................50
5.2 Available Channels in Each Country........................................51
5.3 Networking Compliant Standards.............................................52
5.4 Operating Specifications...........................................................53
6. Troubleshooting………………………………………………….56
6.1 Check the Various Properties of the Card ................................57
6.2 Microsoft Networking Checklist ..............................................59
6.3 Others.......................................................................................64
Regulatory Information……………………………………………65

4
1. Welcome
Thank you for purchasing our IEEE802.11b Wireless LAN USB Adapter,
and welcome to Wireless LAN—the easy way to wireless networking.
This user guide introduces to you the IEEE802.11b USB Adapter and
describes the most common configurations, which will help you connect
to your network easily.
Please read this manual to get familiar with the IEEE802.11b Wireless
LAN. This manual contains detailed instructions in operation of this
product. Please keep this manual for future reference.
As this product is designed to run under Microsoft Windows, it is
recommended to be installed by people who are familiar with the
installation procedures for network operating systems under Microsoft
Windows.

5
1.1 Kit Contents
The IEEE802.11b USB Wireless LAN kit should include the following
items:
a. 1 USB Adapter
b. 1 USB Cable.

6
c. 1 CD including:
1. IEEE802.11b USB WLAN Utility &
Driver software
2. Acrobat Reader 4.05
3. User Manual PDF file
d. Quick Start Guide
e. The User’s Manual (this document)
If any of the items mentioned above are damaged or missing, please
contact your distributor.

7
1.2 Main Feature of WLAN USB Adapter
A. Power ON/OFF LED
B. Status LED
! Off: No wireless activity
! Blinking: Sensing/transmitting wireless
data
! Solid Yellow Green: Standard operational
mode
C. USB Connector

8
USB WLAN Adapter features:
1. High-speed wireless connection, up to 11 Mbps
2. IEEE802.11b (DSSS) standard for 2.4 GHz Wireless
LAN
3. Plug-and-Play installation
4. Solid design with an integrated antenna
5. Full mobility and seamless cell-to-cell roaming
6. Automatic scale back at per packet level
USB WLAN Adapter supports:
1. Automatic load balancing for optimized bandwidth
2. Advanced power management
3. Supports Windows98/2000/Me,CE
