Acopino Oderzo User manual
CONTENTS
Make your Espresso ............................................................ 38
Use the milk frothing device ............................................. 42
Make your Cappuccino/Latte/Macchiato ...................... 46
Make your Espresso with powder ...................................... 52
Make your hot water ......................................................... 56
Operation
Safety .................................................................................. 02
Getting to know your machine .......................................... 13
Installing the machine ........................................................ 15
First trial on your machine .................................................. 17
Getting to know touch screen .......................................... 21
Information
Cleaning and maintenance .............................................. 63
Storage ............................................................................... 68
Trouble shooting.................................................................. 68
Excessive powder protection ............................................ 70
Maintenance
Specifications ..................................................................... 72
Accessories included in the machine ............................... 73
Others
1
Information
This user manual is provided to assist you
with its operation, to familiarize yourself with
the machine.
2 3
SAFETY GUARDS
When using electrical appliances, basic safety precautions should always be followed.
Including the following:
01. Read all Instructions.
02. Do not touch hot surfaces. Use handles or knobs.
in water or other liquid.
04. Unplug from outlet when not in use and before cleaning. Allow to cool before putting
on or taking off parts, and before cleaning the appliance.
05. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner. Return appliance to the nearest
06. The use of accessory attachments not recommended or sold by the appliance
07. Do not use outdoors.
08. Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
09. Do not place on or near a hot gas or electric burner, or in a heated oven.
10. To disconnect, turn any control to "off". Then remove plug from wall outlet.
11. Do not use appliance for other than intended use.
12. Avoid contacting moving parts.
13. Don't move the covering lid away when the appliance is in working.
14. Scalding may occur if the brewing unit is removed during the brewing cycles.
15. Close supervision is necessary when any appliance is used by or near children.
16. Power cord
Safty Safty
4 5
(1) A short power-supply cord is to be provided to reduce risks resulting from becoming
entangled in or tripping over a longer cord.
(2) Longer detachable power-supply cords or extension cords are available and may be
used if care is exercised in their use.
(3) If a long detachable power-supply cord or extension cord is used:
a. the marked electrical rating of the (detachable power supply cord or) extension
cord should be at least as great as the electrical rating of the appliance;
b. the appliance is of the grounded type, the extension cord should be a grounding
type 3-wire cord;
c. the longer cord should be arranged so that it will not drape over the countertop
or tabletop where it can be pulled on by children or tripped over.
17. If the detachable is less than 2 meters, cord of 3G0,75mm2 should be used, otherwise
at least cord of 3G1,0mm2 must be used.
18. The appliance must not be immersed in water.
THANK YOU FOR CHOOSING OUR COFFEE MACHINES!
Thank you for purchasing our Fully Automatic Coffee Machine.
This user manual is provided to assist you with its operation, to familiarize yourself with the
Please read this manual carefully and keep it for future reference.
Please note– Each person's coffee is unique. Experimentation is recommended to ensure
you are making the perfect coffee for your particular taste.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
This appliance can be used by children aged from 8 years and above if they have been
Safty Safty
6 7
given supervision or instruction concerning use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children aged less than 8 years.
This appliance can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
This appliance is intended to be used in household and can't be used in similar
applications such as:
-- farm houses;
-- by clients in hotels, motels and other residential type environments;
-- bed and breakfast type environments.
Attention:
If the appliance or the supply cord is damaged, it must be repaired by
The connector must be removed before the appliance is cleaned and that the
appliance inlet must be dried before the appliance is used again.
The appliance must not be immersed in water.
Warning:
Danger of scalding.
can only be released 30 minutes after the appliance is unplugged.
Safty Safty
8 9
Meaning of crossed-out wheeled dustbin:
Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
Contact you local government for information regarding the collection
systems available.
substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally
obligated to take back your old appliance for disposals at least free of
charge.
Safty
Never use a damaged
power cord
Keep the cable away
from fire and hot
surfaces
Never squeeze the
power cord
SaftySafty Safty
10 11
Keep the machine
away from fire and
high temperatures
Do not immerse the
machine in water or
other liquid
Never allow child
to play with the
machine
Safty
Do not touch the hot
water and steam
exhaust
No hands on warming
cup plate
Use carbon dioxide
extinguisher
Safty
12 13
Plug into an AC outlet Place the machine
on a level and clean
surface
Leave at least 100mm
between the wall and
the machine
Suggest to pre-warm
cup
Safty
Coffee bean tank
Cup warming plate
Powder funnel
Powder cover
Touch Screen
Water tank
Steam/frother knob
Milk frother
Power cord
Drip tray
Brewing unit
Brewing door
Dreg plate
Dreg drawer
Coffee spout/hot water
Machine components
Getting to know your machine
14 15
Installing the machine
Installing the machine
1Install the drip tray 2Take out Spoon and Milk tube
Control panel
Menu
Power
Add powder
Double cups
Single cup
Hot water
milk froth
Getting to know your machine
16 17
Installing the machine
3 4Clean metal tube and nozzle to
keep the spout expedite
Check brewing unit
Nozzle
Milk-Frothing
Metal tube
First trial on the machine
1Take off water tank and infuse fresh
water to 3/4 capacity
2Put coffee bean into bean tank
3/4
First trial on the machine
Dry coffee bean only
18 19
First trial on the machine
3Plug into an AC outlet and turn on switch 4Touch the screen 5Waiting 6Self cleaning
Hot water
First trial on the machine
20 21
First trial on the machine
7 8 9Place a cup under the
Coffee spout
spout
Ready for use
Getting to know touch screen
Getting to know touch screen
1 2 3Touch the screen Starting machine Working mode
22 23
Getting to konw touch screen
7 9
4 6
Menu 8Power On/Off Add Powder
Steam button for
making milk
5Hot water Single/Double
cups of coffee
Getting to know touch screen
Touch Menu, then the following options could be chosen
1Language Mode
Touch OK
2Temperature Mode
24 25
Getting to konw touch screen
6
3
7
4 5
Sound set Mode Product Data Mode 8Factory Set Mode
Energy-saving Mode Water Hardness Mode
Getting to know touch screen
In the language mode, touch OK button then enter into language choosing
interface. Choose your desired language and then touch OK to complete the operation.
Touch OK
Descaling Mode
26 27
Getting to konw touch screen
In the descaling mode, touch OK button then enter into it, then touch OK to
complete the operation.
Touch OK
In the Temperature Mode
Getting to know touch screen
Touch OK
28 29
Getting to know touch screen Getting to konw touch screen
In the Energy Saving Mode, touch OK button to set whether the machine
automatically going to energy saving mode after a certain period of time.
Touch OK
Water hardness mode
Sound set mode
Touch OK
Touch OK
Choose the water
hardness level and
your selection.
Choose and touch
selection.
30 31
Getting to know touch screen Getting to konw touch screen
Product data mode
Factory set mode
Touch OK
Touch OK Touch OK to restore
the factory settings.
Remindings
Lack of water
If this message is indicated on the Screen, there is either no
water in the water tank or it is not installed properly. Add
fresh water and make sure it is set in the correct position.
Lack of beans
If this message is indicated on the Screen, add beans into
the coffee bean container.
32 33
Getting to know touch screen Getting to konw touch screen
Brewing unit missing
Brewing unit is not in the position, please check if the
brewing unit is installed, or if correctly installed.
Dreg drawer full
If this message is indicated on the Screen, dreg drawer is
full, remove the dreg drawer and empty it.
Ventilate
The machine is in a vacuum state, please carry out
drainage action (please refer to former drainage section).
Decalcify
When Screen shows " DECALCIFY " , that means the
machine needs to be descaled.
Touch " ESC " to cancel decalcify, ( The warning will be
repeated next time )
Touch " OK " to continue.
