ACOPOWER HY-P30 User manual

User Manual
173Wh/11.1V
Model:HY-P30 HY-P40 HY-P50
Welcome to Use Our Portable Refrigerator.
This Manual Carefully Before Using Your Unit.
Car Refrigerator

CONTENTS
1. Features
2. Safety instructions
3. Charge Way
4. Discharge time
5. The function and operation setting
6. FAQ
7. Food storage
8. Defrosting
9. Care and Cleaning
1
1
2
3
3
5
6
6
7
8
8
9
5
10.Following Situations are Normal
11.Technical Specification
12.Guidelines for protection of the environment
13.Packing List

1
1. Features
2. Safety instructions
• High efficiency DC inverter compressor and conversion module with high
reliability and long life.
• Fluoride-free insulation with good heat preservation performance and low energy
consumption.
• 12/24VDC and 110~240VAC power supply, allow use in the car ,outdoor or at
home.
• Compressor delay protection
• Quick cooling to -20°C(based on 25°C ambient temperature).
• Intelligent car battery protection system.
• Dual door opening direction.
• Wide range electronic temperature control.
• Built-in power accumulator 15600mA/11.1V Lithium Ion battery 18650
• Warning: Do not attempt or continue to operate your unit ifi t is wet. The
installation of the DC power source in the boat should be handled by the qualified
personnel.
• Make sure the voltage is within the correct range for socket and cable being
used.
The technical data label on the side of the unit shows the voltage ranges.
• No electrical devices inside the refrigerator as they may be damaged.
• During transportation, slope less than 45° and handle carefully.
• Your unit requires good ventilation, allow the following free space for the air
circulation:
Back: 200mm
Side:100mm
• The unit must be placed in dry and ventilated place which is far from heat source
(such as stove, flue) and avoid direct sun-shine.
• It is recommended to operate the unit on a flat surface. Maximum operation.

2
3.Charge Way
• One piece inner tank allows water filled, but no allows pouring out water by invert
the unit. Keep the shells of the unit drying after rained. Not allow dump the unit
in the water.
• Although the units has been cleaned before leaving factory, we strongly
recommend to use soft cloth dampened with warm water and a little neutral
detergent to clean it again, after that wipe it with dry soft cloth.(Warning:Electrical
parts can be wiped by dry cloth only)
• Warning: Do not allow children to play games with the refrigerator such as
climbing or standing in the refrigerator. They could damage the refrigerator and
seriously injure themselves.
Car Refrigerator Built-in 10A solar charge controller three kinds of charging method
(Use Accessory 1) (Weather Dependent,
use Accessory 2) (Use Accessory 3)
How to Charge

3
4. Discharge time
5.The function and operation setting.
Wall Charger (112W)
Car Charger (48W)
Solar Charger (50W)
Solar Charger (70W)
Solar Charger (105W)
Battery Capacity 173wH/18650Li
AC
DC
Solar Panel
Solar Panel
Solar Panel
2hours
4hours
About 4hours
About 3hours
About 2hours
Charge Way Time
Product storage battery dischagrge time using instructions
(Based on “ECO and L”mode)
Refrigeration
Freezing
Discharge time
over 20h
over 5h
Note：More than 1 months without use, please charge in time
Power supply: 12/24V DC or 110~240V AC (enclose adapter) .
Power cable connection:

4
Solar Charge:
Please through the solar charge cable insert into the refrigerator the
“PV” terminals
Max Solar input Voltage：50V
Max Solar input Current：10A
ON/OFF: Press the Power Button to turn the unit on/off
TEMPERATURE ESET: Can be adjusted by the “+” button up to 20℃ (Max) and
down to -20℃ (Max) by the “-“ button
“SET” BUTTON: Press the button “ ” to enter the Energy-saving mode /Quick
cooling mode:
1. ECO (Energy-saving mode)
2. MAX(Quick cooling mode)
Operation setting:
Power Button “SET” Button USB
Temperature
UP
Temperature
Down

5
6.FAQ
• The appliance is out of working:
Check the power supply connection
Whether the plug and the socket have a good connection.
Whether the fuse has been burned out.
Whether the appliance has been turned on
Whether the compressor is in delay start protection when the appliance
is starting up.
Press the Setting button to control the modes of operation. Short press to
change between MAX and ECO modes. Long press for 3 seconds to set battery
protection levels between H-M-L.. Note when “MAX” or “ECO” is flashing, battery
voltage protection levels cannot be set.
1. Battery Protection: Selecting the H, M, L positions, you can choose different
levels for battery protection. When the unit is on working, press the “ ” button for 3S,
then the LCD will display as below:
L: Low power protection9.6V(factory default)
M: Middle power 10.8V
H: High power protection 11.3 V
When the unit is connect to the car, we suggest you setting the battery
protection to (H) level. (M) and (L) are suggested when the unit is connect to the
backup battery. Different car may have different power output voltage. If the voltage
protection display (F1 display in the LCD), then setting the battery portection from H
to M or L，（If the F1 error is still present, please charge the unit with the adapter
for more than 30 seconds and normal operation will resume.）
Most car will stop power supply if engine is stopped. But some car will
continue power supply even engine is stopped. If your refrigerator is still working
when the engine of the car is stopped, then you should adjust the battery protection
to (H), otherwise, the power of your car battery may run out and your car battery
may not have enough power to start car.
2. USB Output: +5VDC /2.1A

• Freezer (below-20 °C)
Meat should be cut and wrapped tightly, and then averagely placed in the
freezer.
After buying frozen food, put it in the freezer as soon as it is still in frozen condition.
Do not put the fresh food and frozen food together.
Do not put the fruit and vegetable in the freezer to avoid freeze-drying.
Do not put the glass container or other container with sealed liquid in
freezer. Or there is a possibility of explosion.
6
7.Food storage
• Display F3 code
The compressor protection is activated. Please turn off the unit and restart
the unit after 30 minutes. If the F3 is still displayed, please contact the after-sales
person.
• Display F5 code
Compressor controller module protection is activated. Please turn off the
unit,keep it at ventilated place and restart the unit after 30 minutes. If the F5 code
is still displayed, please contact the after-sales person.
• Display F7/F8 code
Temperature sensor error. Please restart the unit. If the F7/F8 code is still
displayed, please contact the after-sales person.
• The food inside is frozen:
The setting temperature is too low.
• Hear the sound of water from the inside place.
It is normal, due to the flow of refrigerant.
• Display F1 code
Low power protection, setting the protection from H3 (H) to H2 (M) or
H1 (L)
• Display F2 code
Fan overload protection, turn off the unit and restart the unit after 30
minutes. If the F2 is still displayed, please contact the after-sales person.

7
8.Defrosting
9.Care and Cleaning
• After the refrigerator working for a period, frost could be seen on surfaces in the
freezer, which reduces refrigerating effect and increases power consumption. In the
case, you need to defrost it.
• Unplug the refrigerator and open the doors, take the food in the refrigerator to
cool place. Use defrosting shovel to remove ice and frost (also can just let the door
open, then ice and frost will be thawed by the raising temperature). Then use
dishtowel to wipe off the ice water. After that, place the food back to the refrigerator
and plug in.
Note: Do not use sharp metal tools to defrost which will damage the refrigerator.
Unplug the refrigerator before cleaning!
• Use soft cloth dampened with warm water to wipe the inner surfaces and
external appearance of the refrigerator.
• Use neutral detergent to clean the heavy stains, and dry with clean soft
cloth.
• For long vacation or absences, remove food and unplug the refrigerator. Clean
the refrigerator and leave the doors open a little. Then place the refrigerator in
ventilated place.
NOTE: Do not sprinkle water on the refrigerator during cleaning because that
would reduce the insulating property of electrical components and erode the
metal parts.
• Do not use cleansers containing corrosive and deliquescent material ( such as
scouring powder, bleach, soap powder, alkaline cleansers, benzene, gasoline,
acid, hot water and etc.) to clean the appearance panels, door gaskets and
• Refrigerator (0°C ~10°C)
Eggs, butter, milk and bottled drink can be put in refrigerator.
Fruit and vegetable should be put in the crisper for moisture retaining.
Hot food should be cooled down before it’s placed in, which could help to
save power.
Food must be packed into fresh keeping bags. Leaving space between
packaged foods to keep the circulation of cool air.

8
10.Following Situations are Normal
11.Technical Specification
12.Guidelines for protection of the environment
MODEL
CLIMATIC CATEGORY
RATED VOLTAGE DC (V)
DC FUSE (A)
TOTAL INPUT POWER (W)
RATED CURRENT FOR DC(A)
REFRIGERANT (g)
N.W (kg)
30/40/50L
T/ST/N/SN
12/24V
15A
45W
3.75A/1.875A
32g
11.6kg/12.6kg/13.9kg
The flow of refrigerant through the evaporator may create a boiling or gurgling
sound.
• In the raining and high humidity weather, moisture may form on the outside of
refrigerator or door gaskets. You can wipe damp surfaces with dry cloth.
• The temperature on the back panel may be high (particularly in summer) due to
heat emission of the condenser.
• The temperature on external surface of the compressor may be high when
compressor is working.
• The compressor may cause a high hum or pulsating sound when it is at starting
or stopping step.
• It's normal to hear metal hit noise from compressor when refrigerator is bumped.
PROTECTIVE CLASSIFICATION OF ELECTRIC
SHOCK RESISTANCE III

9
13.Packing List
DISPOSAL: Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for special treatment
is necessary.
Meaning of crossed-out wheeled dustbin: Do not dispose of
electrical appliances as unsorted municipal waste. Use
separate collection facilities.
Danger!
(1) Do not put the portable power pack into water or get it wet.
(2) Do not charge or store near fire or under extreme heat, especially when
leakage happens.
(3) Do not mix up positive electrode and negative electrode.
(4) Do not connect directly to AC power source.
(5) Do not transport or store with necklace or other metal material, which may
cause short circuit.
(6) Do not puncture or open , stamp or impale.
(7) The terminals cannot be welded directly.
(8) Cannot be decompos ed.
(9) Do not place in microwave ovens or pressure vessels.
(10) Do not combine with one-shot battery or battery with different capacity,
model or type.
(11) Do not use if abnormalities are noticed such as smoke , heat etc.
ltem Model Refrigerator DC power
cord
AC
adapator
Solarcharge
cable
User's
manual
30L
40L
50L
×1
×1
×1
×1
×1
×1
×1
×1
×1
×1
×1
×1
×1
×1
×1
Contact your local government for information regarding the collection systems
available.
If electrical appliances are disposed ofi n landfills or dumps, hazardous
substances can leak into the groundwater and get into the food chain, damaging
your health and well-being.

Tel: [phone] Cell: [phone] Fax: [phone]
Add: 4120 Valley Blvd, Walnut, CA 91789,USA
Email: [email protected]
Thanks for choosing ACOPOWER
Power Your Green Life!
