Dometic – Cruise In Comfort
Dometic is a world-leading supplier of dedicated
systems and equipment for pleasure boats.
A partnership of innovative design and the highest standard of quality ensures
that Dometic products satisfy and surpass the expectations of the most
discriminating boat owner.
Index: nFront Loading, CR Series 4 – 9
nFront Loading, TJ Series 10 – 13
nRetrofit Applications: Refrigerators 14
nAt-A-Glance Chart: Refrigerators 15
nTop Loading, CB Series 16
nDrawer Fridges, CD Series 17
nPortable, CF Series 18 – 19
nCooling Kits, Adler/Barbour Series 20 – 21
nCooling Kits, 80 Series 22
nCooling Kit, CS-NC-15 23
nCooling Kits, Grunert Series 24 – 27
nCooling Kits, KRA Series 28 – 29
nIce Crushing Systems, Eskimo Ice Series 30 – 31

AWARD WINNING DESIGN
“Beyond pleasing aesthetics, the new CR
Series compressor refrigerators offer several
clever design touches, including a lock to
allow the cabinet to ventilate when not in use
and a very positive latching mechanism.”
D
Front Loading Refrigerators
CR SERIES
QUALITY FEATURES
4
Light Handle Frame
As commented by the awards jury at METS Amsterdam—the
world’s leading trade show for marine equipment.
esigned for the rigors of marine use, the
CR Series provides built-in refrigerators
for every application. Each unit includes
a flush-mount frame that will compliment
any on-board galley or cockpit.
High-tech design: Each CR Series appliance is equipped with a
premium Danfoss DC compressor, providing excellent cooling
performance, minimal power consumption when operating on
either DC or AC power, and superbly quiet operation.
Patented Double-Lock
Door Mechanism:
During rough sea conditions, the
refrigerator door remains securely
closed, at the top and bottom, as a
result of the patented double-lock door
mechanism. It also incorporates the
“vent" position, which holds the door
slightly open when the refrigerator is not
in use for easy defrosting and to prevent
mildew.
Luxury Meets Performance and
Top-of-the-Line Technology
Premium front loading refrigerators with freezer compartments
z Totally encapsulated freezer compartment eliminates the
risk of ice-pick damage.
z Diagnostic troubleshooting indicator lights.
z Separate insulated freezer compartment with door.
z Door with double-lock (top/bottom) and
dual function (locking/ventilation).
z Full-length recessed door handle provides
comfortable opening and closing.
z Door with magnetic sealing gasket.
z Cool-blue interior light.
z Door hinge and locks (right/left) allows for reversible
door opening. Left or right — the choice is yours.
z Interchangeable face panel to match decor.
z Flush mount flange provides a pleasing cosmetic
appearance and eliminates protruding handle or locks.
Space-saving flange is available as an option, when
cabinet depth is limited.

www.DometicEnviro.com 5
ELEGANT DESIGN
>Inside: Refreshing white
interior with “Cool-Blue" light
>Outside: Choice of
face panels: black,
white*, stainless-steel,
brushed stainless-steel
>Secure self-locking door
>Smooth face: The handle is
recessed into the fridge door
>Flexible installation with flush
mount flange (accessory:
space-saver flange available)
HIGH-GRADE
WORKMANSHIP
>Metal frame construction
>Stainless-steel hardware
>Door with double lock
(top/bottom) and dual
functions (locking/ventilation)
>Reversible door mount
(left or right-side opening)
HOME-LIKE CONVENIENCE
>Similar to quality household
refrigerators, standard features
include: egg tray, bottle holder,
extra-large vegetable bin, versatile
repositionable shelves and racks.
LUXURY EQUIPMENT
>Unique:
All CR Series models feature
a separate full-width freezer
compartment.
*on select models only.
PREMIUM COOLING
TECHNOLOGY
>Danfoss BDF compressor
from the market leader
PREMIUM FREEZING
>Separate freezer compartment
with insulated door
>Protected evaporator eliminates
risk of ice-pick damage
>Collection tray to capture
defrost water or unit can be
set up to drain to the bilge

6
CR Series
Bright Stainless-Steel Finish
CR-1065ST-SS
Shown without ange.
CR-1110ST-SS
Shown without ange.
CR-1050ST-SS
Shown without ange.

www.DometicEnviro.com 7
CR Series
Bright Stainless-Steel Finish
z Exclusive, protected evaporator eliminates
the risk of ice-pick damage.
z Collection tray captures defrost water or
can be configured to drain to the bilge.
z Cool-blue contemporary interior light.
Diagnostic circuitry installed with green
and red LED indicator lights.
z Patented double-lock door mechanism
securely closes door at the top and bottom.
z "Computer style" AC socket enables
easy-to-change-to-overseas cord and plugs.
z Face panel is interchangeable—even while
installed in the boat.
Quality Features
CR-1080ST-SS
Shown without ange.

CR SERIES
CR-1050 CR-1065
8
CR-1065E/F-W
Gross Capacity: 1.7 cubic feet (48.1 liters), 4.8 quarts
(4.5 liters) in the freezer compartment
Voltage: 12/24 volts DC, 110/220 volts AC
Average Power
Consumption: 40 watts / 3.3 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: CR-1050U/F: black face panel, black door
surround, black ush mount ange;
CR-1050E/F-W: white face panel, silver
door surround, silver ush mount ange;
CR-1050E/F-SS: stainless-steel face
panel, silver door surround, silver ush
mount ange
CR-1050ST/F-SS: brushed stainless-
steel face panel, bright silver door surround,
bright stainless-steel ush mount ange
Cut-Out 16"W x 21"H x 19.4"D (ush mount ange)
Dimensions: 406mm x 533mm x 492mm
15"W x 21"H x 17.6"D (space-saver ange)
381mm x 533mm x 447mm
Net Weight: 42 lbs. / 19 kg.
Flange Options: EST-0050U: black space-saver
EST-0050E: silver space-saver
EST-0050ST: stainless-steel space-saver
Replacement EFM-0050U: black ush mount
Flange: EFM-0050E: silver ush mount
EFM-0050ST: stainless-steel ush mount
Gross Capacity: 2.3 cubic feet, (65.1 liters), 4.8 quarts
(4.5 liters) in the freezer compartment
Voltage: 12/24 volts DC, 110/220 volts AC
Average Power
Consumption: 40 watts / 3.3 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: CR-1065U/F: black face panel, black door
surround, black ush mount ange;
CR-1065E/F-W: white face panel, silver
door surround, silver ush mount ange;
CR-1065E/F-SS: stainless-steel face
panel, silver door surround, silver ush
mount ange
CR-1065ST/F-SS: brushed stainless-
steel face panel, bright silver door surround,
bright stainless-steel ush mount ange
Cut-Out 18.6"W x 20.7"H x 21"D (ush mount ange)
Dimensions: 472mm x 525mm x 533mm
17.8"W x 20.7"H 19.1"D (space-saver ange)
452mm x 525mm x 485mm
Net Weight: 46 lbs. / 20 kg.
Flange Options: EST-0065U: black space-saver
EST-0065E: silver space-saver
EST-0065ST: stainless-steel space-saver
Replacement EFM-0065U: black ush mount
Flange: EFM-0065E: silver ush mount
EFM-0065ST: stainless-steel ush mount
CR-1065E/F-W. Freezer door shown open.
CR-1050U/F
CR-1065ST/F-SS

CR-1080 CR-1110
9
www.DometicEnviro.com
Gross Capacity: 2.8 cubic feet, (79.1 liters), 4.8 quarts
(4.5 liters) in the freezer compartment
Voltage: 12/24 volts DC, 110/220 volts AC
Average Power
Consumption: 40 watts / 3.3 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: CR-1080U/F: black face panel, black door
surround, black ush mount ange;
CR-1080E/F-SS: stainless-steel face
panel, silver door surround, silver ush
mount ange
CR-1080ST/F-SS: brushed stainless-
steel face panel, bright silver door surround,
bright stainless-steel ush mount ange
Cut-Out 19.7 W x 25"H x 20.6"D (ush mount ange)
Dimensions: 500mm x 635mm x 523mm
18.8"W x 25"H x 18.7"D (space-saver ange)
477mm x 635mm x 474mm
Net Weight: 52 lbs. / 23 kg.
Flange Options: EST-0080U: black space-saver
EST-0080E: silver space-saver
EST-0080ST: stainless-steel space-saver
Replacement EFM-0080U: black ush mount
Flange: EFM-0080E: silver ush mount
EFM-0080ST: stainless-steel ush mount
Gross Capacity: 3.8 cubic feet, (79.1 liters), 8.9 quarts
(8.4 liters) in the freezer compartment
Voltage: 12/24 volts DC, 110/220 volts AC
Average Power
Consumption: 45 watts / 3.75 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: CR-1110U/F: black face panel, black door
surround, black ush mount ange;
CR-1110E/F-SS: stainless-steel face
panel, silver door surround, silver ush
mount ange
CR-1110ST/F-SS: brushed stainless-
steel face panel, bright silver door surround,
bright stainless-steel ush mount ange
Cut-Out 21.5"W x 29"H x 21.7"D (ush mount ange)
Dimensions: 546mm x 736mm x 551mm
20.6"W x 29"H x 19.9"D (space-saver ange)
523mm x 739mm x 505mm
Net Weight: 62 lbs. / 28 kg.
Flange Options: EST-0110U: black space-saver
EST-0110E: silver space-saver
EST-0110ST: stainless-steel space-saver
Replacement EFM-0110U: black ush mount
Flange: EFM-0110E: silver ush mount
EFM-0110ST: stainless-steel ush mount
CR-1080E/F-SS
CR-1110U/F

D
Front Loading Refrigerators
QUALITY FEATURES
10
Light
Handle
APPROVED
All models are UL, CSA,
and CE Approved.
TJ42RE-SS Refrigerator
TJF42-SS Full Size Freezer
Wrapped
door
TJ SERIES
ometic’s TJ Series of refrigerators and
freezers are now available with a stain-
less-steel finish. These state-of-the-art
units are designed to replace existing
refrigerators and give your galley a more
modern look.
Rugged Door Latch and
Shelving Systems:
All models offer a number of refinements
and improvements in the door and
latch assembly. The doors and shelving
systems are exceptionally strong. The latch
system has been designed to withstand
extraordinary rough treatment and to resist
accidental opening. When heavily-weighted
with beverages, the latch keeps the door
securely closed, even in severe conditions.
The moveable shelves are locked in place
and will not budge under rough seaways.
Unparalleled Reputation for
Long-Lasting Performance
Premium front loading refrigerators with
freezer compartments
z Freezer compartment with door.
z Adjustable locking shelves for efficient use of
interior space and safety underway.
z New, stronger refrigerator latch system.
z Door with magnetic sealing gasket.
z Bright interior light.
z Stainless-steel available on all models.
z Flush mount flange provides a pleasing cosmetic
appearance and eliminates protruding handle or
locks. TJ18S has a non-flush flange.
z All models are UL / CSA / and CE approved.

www.DometicEnviro.com 11
PREMIUM FREEZING
>Separate freezer compartment with insulated door
HIGH-GRADE WORKMANSHIP
>Rigid external metal chassis
>Stainless-steel hardware
>Magnetic door seal
>New, stronger latch system
BETTER THAN HOME CONVENIENCES
>Adjustable and locking shelves for efficient
use of interior space and safety underway
APPROVED!
>Unique:
All TJ Series models are UL, CSA, and CE Approved
PREMIUM COOLING
TECHNOLOGY
>Danfoss BDF compressor
from the market leader
EXCEPTIONAL QUALITY
AND STYLE
>All stainless-steel models
feature a “wrapped door"
ELEGANT DESIGN
>Inside: Refreshing white interior with light
>Outside: black or stainless-steel
>Secure self-locking door
PREMIUM FREEZING
>Separate freezer compartment with insulated door
HIGH-GRADE WORKMANSHIP
>Rigid external metal chassis
>Stainless-steel hardware
>Magnetic door seal
>New, stronger latch system
BETTER THAN HOME CONVENIENCES
>Adjustable and locking shelves for efficient
use of interior space and safety underway
APPROVED!
>Unique:
All TJ Series models are UL, CSA, and CE Approved

12
TJ18, TJ18S TJ22
TJ SERIES
Gross Capacity: 1.8 cubic feet (51 liters), 4.8 quarts
(4.5 liters) in the freezer compartment
Voltage: 12/24 volts DC
Optional 115/230 volts AC, add “AC" to part #
Average Power
Consumption: 40 watts / 3.3 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: TJ18-SS: stainless-steel (ush mount ange)
TJ18S-SS: stainless-steel (non-ush ange)
TJ18: black (ush mount ange)
TJ18S: black (non-ush ange)
Cut-Out 15.75"W x 21.06"H x 19.75"D (ush mount ange)
400mm x 535mm x 502mm
Dimensions: 15.625”W x 20.563”H x 18.25”D (non-ush)
397mm x 523mm x 464mm
Net Weight: 40 lbs. / 18.14 kg.
Option: Space-saving ange: #TJ18S-SS
Gross Capacity: 2.2 cubic feet (63 liters), 4.8 quarts
(4.5 liters) in the freezer compartment
Voltage: 12/24 volts DC
Optional 115/230 volts, add “AC" to part #
Average Power
Consumption: 40 watts / 3.3 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: TJ22-SS: stainless-steel
TJ22: black
Cut-Out 18.31"W x 21.06"H x 21"D (ush mount ange)
Dimensions: 466mm x 535mm x 534mm
Net Weight: 46 lbs. / 20.87 kg.
TJ18-SS
TJ22-SS
TJF42-SS. Full size freezer.

TJ42
TJ85AC
13
www.DometicEnviro.com
Gross Capacity: 4.2 cubic feet (119 liters), 8.9 quarts
(8.4 liters) in the freezer compartment
Voltage: 12/24 volts DC
Optional 115/230 volts, add “AC" to part #
Average Power
Consumption: 45 watts / 3.75 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: TJ42-SS: stainless-steel refrigerator with
freezer
TJ42: black refrigerator with freezer
TJ42RE-SS: stainless-steel refrigerator
only
TJ42RE: black refrigerator only
TJF42-SS: stainless-steel freezer only
TJF42: black freezer only
Cut-Out 21.37"W x 30.625"H x 21.5"D (ush mount ange)
Dimensions: 543mm x 778mm x 548mm
Net Weight: 69 lbs. / 31.30 kg.
Gross Capacity: 8.5 cubic feet (241 liters), 1.6 cubic feet
(45 liters) in the freezer compartment
Voltage: 12/24 volts DC, 115/230 volts
Average Power
Consumption: 65 watts / 5.4 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Stainless-steel ttings, plastic interior, door
frame in plastic body with coated metal frame
Color Options: TJ85AC: black
TJ85AC-SS: stainless-steel
Cut-Out 23.5"W x 53"H x 23.81"D (ush mount ange)
Dimensions: 599mm x 1347mm x 605mm
Net Weight: 112 lbs. / 50.80 kg
TJ42RE-SS. Full size refrigerator.
TJ85AC-SS
Available as a right hand opening door as an AC/DC model. Specify "RT".
Example: TJ42AC-RT. "RE" is refrigerator only. Use TJ42RE side-by-side with TJF42. Available as a right hand opening door. Specify "RT". Example: TJ85AC-RT.
Light in freezer is photographer's effect only. Equipped with light in refrigerator.

14
Marine Refrigerators Retrofit Applications
Front Loading
CURRENT CURRENT DOMETIC
BRAND MODEL REPLACEMENT MODELS)
Indel CR 42 CR-1050 or TJ18-SS
Indel CR 49 CR-1050 or TJ18-SS
Indel CR 65 CR-1065 or TJ22-SS
Indel CR 85 CR-1080 or TJ22-SS
Indel CR 90 TJF42RE-SS
Indel CR 130D TJ42RE-SS
Indel CR 130 CR-1110 or TJ42-SS
Indel CR 195 TJ85AC, TJ85AC-SS
NovaKool R1600 CR-1050 or TJ18-SS
NovaKool R2600 CR-1065, CR-1080 or TJ22-SS
NovaKool R3800 CR-1110 or TJ42-SS
Norcold DE-0040 CR-1050 or TJ18-SS
Norcold DE-0051 CR-1065 or TJ22-SS
Norcold DE-490 CR-1080
Norcold DE-0041 CR-1110 or TJ42-SS
Norcold DE-461 TJ85AC, TJ85AC-SS
Dometic TJ18 CR-1050
Dometic TJ22 CR-1065
Dometic TJ42 CR-1110
WAECO RPD-50 CR-1050 or TJ18-SS
WAECO RPD-65 CR-1065 or TJ22-SS
WAECO RPD-80 CR-1080
WAECO RPD-110 CR-1110 or TJ42-SS
WAECO RPD-1190 TJ85AC, TJ85AC-SS

15
www.DometicEnviro.com
Marine Refrigerators At-A-Glance
Specialty Appliances
Choice of: Choice of:
Front Loading
PART # DESCRIPTION CAPACITY COMPRESSOR VOLTAGE CUT-OUT MATERIAL
CUBIC FEET DIMENSIONS
CD-030 Drawer 31 quarts Danfoss 12/24V DC 17"W x 9.8"H x 28.7"D Metal Housing,
Refrigerator Plastic Interior
CB-036 Refrigerator or 1.3 Danfoss 12/24V DC 23"D x 16"H x 16"W Stainless-Steel
Freezer Interior
CB-040 Refrigerator or 1.4 Danfoss 12/24V DC 19.7"D x 26"H x 13.3"W Stainless-Steel
Freezer Interior
CF-035 Portable Danfoss 12/24V DC 22.8"L x 15.1"H x 14"W High Impact
Refrigerator or Freezer 1.1 110/220V AC Polypropylene
CF-040 Portable Danfoss 12/24V DC 22.8"L x 17.5"H x 14"W High Impact
Refrigerator or Freezer 1.3 110/220V AC Polypropylene
CF-050 Portable Danfoss 12/24V DC 24.8"L x 19.4"H x 14"W High Impact
Refrigerator or Freezer 1.7 110/220V AC Polypropylene
CF-080 Portable Danfoss 12/24V DC 31"L x 18"H x 19.6"W Coated
Refrigerator or Freezer 2.8 110/220V AC Sheet Steel
CF-110 Portable Danfoss 12/24V DC 31"L x 22"H x 19.6"W Coated
Refrigerator or Freezer 3.7 110/220V AC Sheet Steel
PART # DESCRIPTION CAPACITY COMPRESSOR VOLTAGE CUT-OUT FACE PANEL FLANGE
CUBIC FEET DIMENSIONS COLOR COLOR
CR-1050 Refrigerator with 1.7 Danfoss 12/24V DC, 16"W x 21"H x 19.4"D Black, Black,
Freezer Compartment 110/220V AC White, Stainless, Silver,
Br. Stainless Br. Stainless
CR-1065 Refrigerator with 2.3 Danfoss 12/24V DC, 18.6"W x 20.7"H x 21"D Black, Black,
Freezer Compartment 110/220V AC White, Stainless, Silver,
Br. Stainless Br. Stainless
CR-1080 Refrigerator with 2.8 Danfoss 12/24V DC, 19.7"W x 25"H x 20.6"D Black, Black,
Freezer Compartment 110/220V AC Stainless, Silver,
Br. Stainless Br. Stainless
CR-1110 Refrigerator with 3.8 Danfoss 12/24V DC, 21.5"W x 29.1"H x 21.7"D Black, Black,
Freezer Compartment 110/220V AC Stainless, Silver,
Br. Stainless Br. Stainless
TJ18-SS Refrigerator with 1.8 Danfoss 12/24V DC 15.75"W x 21."H x 19.75"D Black, Black,
Freezer Compartment (option: 110/220V AC) Stainless Stainless
TJ22-SS Refrigerator with 2.2 Danfoss 12/24V DC 18.3"W x 21."H x 21"D Stainless Stainless
Freezer Compartment (option: 110/220V AC)
TJ42-SS Refrigerator with 4.2 Danfoss 12/24V DC 21.3"W x 30.6"H x 21.5"D Stainless Stainless
Freezer Compartment (option: 110/220V AC)
TJ42RE-SS All Refrigerator 4.2 Danfoss 12/24V DC 21.3"W x 30.6"H x 21.5"D Stainless Stainless
(option: 110/220V AC)
TJF42-SS All Freezer 4.2 Danfoss 12/24V DC 21.3"W x 30.6"H x 21.5"D Stainless Stainless
(option: 110/220V AC)
TJ85AC Refrigerator with 8.5 Danfoss 12/24V DC, 23.5"W x 53"H x 23.8"D Black, Black,
Freezer Compartment 110/220V AC Stainless Stainless
Flush Mount Flange:

Top Loading Refrigerators / Freezers
CB SERIES
CB-036 CB-040
16
Space Saving Built-Ins
Can be set to operate as either a refrigerator or freezer
z Permanent installation in cupboard space.
z Lid can accommodate laminate to match
countertops.
z Ideal for use as a bait freezer or refrigerator.
z Stainless-steel interior housing.
z Impeccable operation in inclined positions.
z Lift-off lid with superior seal and insulation.
z Top loading for improved
efficiency and better performance.
Gross Capacity: 1.3 cubic feet
(36 liters)
Voltage: 12/24 volts DC
Optional accessory
for 110/220 volts AC
Average Power
Consumption: 45 watts / 3.75 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Zinc coated sheet steel with stainless-steel
interior; shock resistant plastic base
Color: CB-036: gray body with dark gray lid
Cut-Out 23"D* x 16"H x 16"W
Dimensions: (584mm x 406mm x 406mm)
*of which, 7"D (177mm) compressor
can be remote mounted up to 5’ away
Net Weight: 41 lbs. / 18.59 kg.
Gross Capacity: 1.4 cubic feet
(39 liters)
Voltage: 12/24 volts DC
Optional accessory
for 110/220 volts AC
Average Power
Consumption: 45 watts / 3.75 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Zinc coated sheet steel with stainless-steel
interior; shock resistant plastic base
Color: CB-040: gray body with dark gray lid
Cut-Out 19.7"D x 26"H x 13.3"W
Dimensions: (500mm x 660mm x 337mm)
Net Weight: 44 lbs. / 19.95 kg.

17
www.DometicEnviro.com
Drawer Refrigerators
CD SERIES
CD-030DC
Cooling Comfort for
Confined Spaces
Smart compressor appliance turns any unused nook
into a practical 31 quart cooler
z Permanent installation in cupboard space.
z Continually variable thermostat will not accidentally
freeze items.
z Cooling unit can be mounted on the rear,
left or right side, or up to 5’ away.
z Very energy efficient.
Gross Capacity: 31 quarts (29 liters)
Voltage: 12/24 volts DC
Optional accessory for 110/220 volts AC
Average Power
Consumption: 40 watts / 3.3 amps
Insulation: CFC-free polyurethane
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: Sturdy metal housing with
injection molded parts
Color Options: CD-030DC: black drawer
CD-030DCW: white drawer
Cut-Out 17"W x 9.8"H x 28.7"D**
(431mm x 248mm x 728mm)
Dimensions: **of which, 8.7"D (220mm) compressor
can be remote mounted up to 5’ away
Net Weight: 44 lbs. / 19.95 kg.

Portable Refrigerators / Freezers
CF SERIES
CF SERIES
18
Refrigerate or Freeze — to 0°F (-17°C)
Can be set to operate as a refrigerator or freezer
z High impact polypropylene (CF-35, 40, 50) cabinet,
or polymer coated metal (CF-80, 110) cabinet,
with weather-resistant polyethylene lid.
z Quick chill / turbo function runs the compressor
at maximum performance until the desired
temperature has been reached.
z Memory feature will maintain preset settings
if the system if turned off.
z Perfect operation in inclined positions.
z Three stage battery monitor with low voltage
shut-off to protect against a dead battery.
z Removable coated wire basket or grid divider
eases loading of contents and keeps foods
from adhering to interior walls.
z Quickly find contents in the dark with interior light.
z Convenient carrying handles aid in transport
and can be easily removed.
Gross Capacity: CF-035AC110: 33 qts, 1.1 cubic feet (31 liters) Holds 41 cans
IC-CF-35: Insulated cover for the CF-35
CF-040AC110: 39 qts, 1.3 cubic feet (36 liters) Holds 48 cans
IC-CF-40: Insulated cover for the CF-40
CF-050AC110: 52 qts, 1.7 cubic feet (48 liters) Holds 68 cans
IC-CF-50: Insulated cover for the CF-50
Voltage: 12/24 volts DC, 110 volts AC
Average Power
Consumption: 45 watts / 3.75 amps
Insulation: CFC-free polyurethane foam
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: high impact polypropylene cabinet
weather resistant polyethylene lid
Color: dark gray / pale gray
Dimensions: CF-035AC110: 22.8"L x 15.1"H x 14"W (579mm x 383mm x 355mm)
CF-040AC110: 22.8"L x 17.5"H x 14"W (579mm x 444mm x 355mm)
CF-050AC110: 24.8"L x 19.4"H x 14"W (629mm x 492mm x 355mm)
Lid: Removable
Net Weight: CF-035AC110: 33 lbs. / 14.96 kg.
CF-040AC110: 37 lbs. / 16.78 kg.
CF-050AC110: 44 lbs. / 19.95 kg.
Features: CF-035AC110: Removable coated wire grid divider
CF-040AC110 & CF-050AC110: Removable coated wire basket
Easily transport foods from
grocery store to galley.

CF-40
CF-80
CF-35
CF-50
CF-110
19
www.DometicEnviro.com
CF SERIES
Gross Capacity: CF-080AC110: 85 qts, 2.8 cubic feet (79 liters) Holds 103 cans
IC-CF-80: Insulated cover for the CF-80
CF-110AC110: 113 qts, 3.77 cubic feet (106 liters) Holds 144 cans
IC-CF-110: Insulated cover for the CF-110
Voltage: 12/24 volts DC, 110 volts AC
Average Power
Consumption: 55 watts / 4.5 amps
Insulation: CFC-free polyurethane foam
Compressor: Danfoss BD35F
Refrigerant: Environmentally-safe R134a
Material: coated sheet steel cabinet
weather resistant polyethylene lid
Color: dark gray / pale gray
Dimensions: CF-080AC110: 31"L x 18.1"H x 19.6"W (787mm x 459mm x 497mm)
CF-110AC110: 31"L x 22"H x 19.6"W (787mm x 558mm x 497mm)
Net Weight: CF-080AC110: 62 lbs. / 28.12 kg.
CF-110AC110: 73 lbs. / 33.11 kg
Features: Removable coated wire basket and coated wire grid
CF-50 fits in most
marine slide drawers.
Insulating and Protective Covers
Available For All CF Series Models.

Do-It-Yourself Cooling Kits
ADLER / BARBOUR SERIES
20
Performance, Efficiency
and Quality ...
... all hallmarks of dependable marine refrigeration by the
Adler / Barbour Series. The versatility provides for all-
freezer or combination refrigerator/ freezer systems.
Your appreciation of 12/24 volt DC refrigeration on-board
will be determined by its ability to develop and maintain
freezing temperatures quickly without running your
batteries down.
Adler / Barbour’s popularity today has grown from its
proven and extraordinary ability to perform efficiently in
a wide variety of installations. Its uncompromised quality
has become the standard by which other systems are
measured.
Specifically designed to survive the rigors of
harsh marine environment: heat and humidity,
erratic or low voltage, continuous use. Unmatched
in performance and efficiency. Designed and
manufactured in the USA. Join the 50,000 owners
who won’t settle for less.
z Oversized air condensers.
z Accommodates large refrigerators — up to
15 cubic feet (424 liters) with 3" (76mm) of
polyurethethane.
z Danfoss BD50F compressor — resulting in 25%
more cooling performance (as compared to the BD35F).
z Stainless-steel construction.
z Shrouded forced air condensers.
z Modular phone-jack connection for thermostat.
z Quick connect couplings.
z High CFM fan.
z Built-in trouble-shooting diagnostics.
z Can be installed up to
15’ (457cm) from evaporator.
z Precharged and ready to install!
