BLOOMSBURY GAS STOVE
INSTALLATION,USER & SERVICING INSTRUCTIONS
(TO BE LEFT WITH THE CUSTOMER)
UK & IRELAND
Bloomsbury Gas Stove
For use in UK & Ireland on Natural gas at a supply pressure of 20mbar or
Butane/propane at a supply pressure of 28mbar/37mbar
GB
IE

Page 2
AB-G200L-REM-I01-150914
INSTALLATION INSTRUCTIONS
CONTENTS
Important Notes
Page 2
Commissioning the Stove
Page 8
Technical Information
Page 3
Check for Spillage
Page 8
Dimensions and Clearances
Page 4
Customer Briefing
Page 9
Installation
Page 5
IMPORTANT NOTES
This stove is a fuel effect radiant convector. Before installation, ensure that the
local distribution condition (identification of the type of gas and pressure) and the
adjustment of the appliance are compatible. The data label is located at the rear of
the stove. The installation must be in accordance with these Instructions and
National Regulations and must be carried out by a qualified installer.
Any flue damper plate or flue restrictor must be removed or fixed permanently in
the fully open position, or shall only be fitted in accordance with National
Regulations.
If the chimney has previously been used to burn solid fuel, the chimney should be
swept before the stove is installed.
Before the stove is installed a flue test in accordance with National Regulations
should be carried out. The gas connection must be in accordance with National
Regulations.
The stove is fitted with a spillage monitoring system consisting of a thermal switch
connected to a thermocouple interrupter. This system is not adjustable, and must
not be put out of action. If any parts of the spillage monitoring system require
replacement only original manufacturers’ parts must be used.
All surfaces except the control unit are considered to be working surfaces.
The stove should not be used for any other purpose than as a room heater and a
decorative stove.

Page 3
AB-G200L-REM-I01-150914
TECHNICAL INFORMATION
Natural Gas Settings
BLOOMSBURY GAS STOVE
GAS
GATEGORY
I2H
I2E
I2E+
HEAT INPUT (NETT)
HIGH/LOW
6.08kW/3.14kW
6.08kW/3.14kW
6.08kW/3.14kW
SUPPLY PRESSURE
20 mbar
20 mbar
20/25 mbar
INJECTOR SIZE
82/440
82/440
82/440
GAS CONNECTION
8mm O.D. Tube
8mm O.D. Tube
8mm O.D. Tube
GAS
CONSUMPTION
0.65m³/h
0.65m³/h
0.65m³/h
NOX CLASS
5
5
5
EFFICIENCY CLASS
2
2
2
COUNTRIES OF
DESTINATION
AT, CH, CZ, ES, FI,
GB, IE, DK, EE, GR,
LT, IT, PT, SE, LV,
NO, SI,SK
DE, LU
BE, FR
OXYPILOT
Seagas P 456
Seagas P 456
Seagas P 456
LPG Settings
BLOOMSBURY GAS STOVE
GAS
GATEGORY
I3+
I3P
I3B/P(30)
HEAT INPUT (NETT)
HIGH/LOW
6.28kW/3.14kW
6.28kW/3.14kW
6.28kW/3.14kW
SUPPLY PRESSURE
28/37 mbar
37 mbar
30 mbar
INJECTOR SIZE
92/200
92/200
92/200
GAS CONNECTION
8mm O.D. Tube
8mm O.D. Tube
8mm O.D. Tube
GAS
CONSUMPTION
0.19m³/h
0.19m³/h
0.19m³/h
NOX CLASS
5
5
5
EFFICIENCY CLASS
2
2
2
COUNTRIES OF
DESTINATION
BE, CH, ES, FR,GB,
GR, CZ, IE, IT, PT,
LT, SK
BE, CH, CZ, ES, FR,
GB, GR, IE, IT, PT,
SI, SK
CZ, FI, IT, SE, GR,
NO, DK, EE, LT, SI
OXYPILOT
Seagas P 457
Seagas P 457
Seagas P 457

Page 4
AB-G200L-REM-I01-150914
DIMENSIONS AND CLEARANCES
Fig 1 –Bloomsbury Gas Stove Dimensions

Page 5
AB-G200L-REM-I01-150914
INSTALLATION
Install the stove in accordance with the requirements given below. If a concealed gas
connection is to be made prepare the pipe work prior to installing the stove.
Positioning the Stove
Clearances from non-combustible material in the fireplace opening must be at least
50mm on the left side, 150mm on the right hand side and 75mm at the back. These
distances must be extended to a minimum clearance of 400mm from any combustible
material.
Hearth
The stove must stand on a fireproof hearth made of non-combustible material of a
minimum thickness 12mm and be of sufficient size to accommodate the stove (see
Fig.1).
Fire Surround & Shelves
It is recommended that a fire surround should not be closer than 400mm from the
stove, if manufactured from a combustible material.
A combustible shelf may be fitted provided that it is not more than 150mm deep and
there is at least 400mm clearance from the top of the stove.
Log Arrangement
The logs should only be arranged as shown in the layout given in the Installation
Instructions by a qualified person.
The stove must only be fitted with the ceramics supplied. DO NOT use any extra logs or
coals.
Flue Connection
The flue should be a minimum of 3m high and at least 125mm diameter or
equivalent area.
Horizontal or negative gradients in the flue pipe should be avoided.
It is recommended that a minimum height of 610mm from the stove should be
established before any significant change in the direction of the flue.
An optional rear flue attachment is available as an accessory from
www.acquisitions.co.uk (see Fig.1).

Page 6
AB-G200L-REM-I01-150914
Ventilation
Ventilation should be in accordance with National Regulations. In the United Kingdom,
purpose provided ventilation is not normally required, except in new build houses.
For Republic of Ireland refer to I.S813 issued by the National Standards Authority of
Ireland.
Gas Connection
The gas supply connection is at the right hand side of the stove on the gas valve.
A nut and olive (strapped to the valve body), tail pipe and a pressure test elbow are
supplied with the stove for easy connection.
The gas supply should incorporate a service tap, be purged and any loose matter
removed.
Connect the gas supply pipe and check for gas soundness.
TTB (Thermocouple interrupter)
Fig. 2 Shows the TTB connection on the back of the gas valve.

Page 7
AB-G200L-REM-I01-150914
Positioning the Logs
1. Slacken the screw securing the door handle and open the stove door.
2. Position the back board into the burner tray ensuring that is correctly seated
behind Tab A and that the flame strip is not obstructed (Fig 2).
3. Locate LOG1DMR and LOG2DMR into position on the back board as shown (Fig 3).
4. Locate LOG3DMR into position as shown (Fig 4)
5. Locate LOG4DMR into position as shown (Fig 4)
6. Close the stove door.
7. Tighten the door locking screw.
Fig.2
Tab A
Fig.3
Fig.4
LOG2DMR LOG1DMR LOG4DMR LOG3DMR
Under no circumstances should the stove be operated with the door
open, without the door attached or the glass in the door damaged,
broken or missing

Page 8
AB-G200L-REM-I01-150914
COMMISSIONING THE STOVE
Once the fire is in place, connected, flued correctly, and the logs are in place, you can
proceed with lighting the stove and ensuring the all the features are working correctly.
The Fire control unit is located behind the right-hand foot of the stove.
The pilot light is located at the front toward the left hand side of the burner.
Should the stove be extinguished for any reason wait 3 minutes before attempting
re-ignition.
Connect a suitable pressure gauge to the pressure test point to check the correct
inlet pressures.
Fit AA batteries to the Fire control unit. The control requires 3 AA size alkaline
batteries to be inserted under the battery compartment cover. The orientation of
these is shown moulded into the battery compartment.
After fitting the batteries and replacing the cover the fire can now be operated.
Slide the Master switch to the right to the ON position (I symbol).
To start the fire, press the ON/OFF button and hold for 1 second then release. The
burner will within around 1 to 10 seconds ignite and adjust to the maximum power
setting. . This can take longer on the first lighting as it has to clear out any air
locks, also if it is an LPG burner and has been stood unused for time, the gas could
have settled in the pipework.
The power of the burner can be adjusted up and down by pressing the + and -
buttons.
To stop the fire, simply press the power button again and the burner will stop.
Once the fire has been successfully lit and extinguished, you can then put batteries in
the Remote control and check that this is functioning correctly (See user instructions for
how to set the time and date on the handset).
CHECK FOR SPILLAGE
Close all doors and windows in the room containing the appliance. Light the stove and
set the control unit to ‘HIGH’, leave the appliance for 5 minutes.
Apply a smoke match along the bottom edge of the draught diverter. The installation is
satisfactory if the smoke is drawn into the stove. If in doubt wait a further 10 minutes
and then repeat the test.
If there is a nearby room with an extractor fan the spillage test should be repeated with
the fan running and all connecting doors between the stove and the fan left open.
If in doubt disconnect the appliance and seek expert advice.

Page 9
AB-G200L-REM-I01-150914
CUSTOMER BRIEFING
Hand these Instructions to the customer.
Advise the customer how to use the stove.
Explain to the customer that the stove has a flame failure and spillage monitoring
system.
Point out the explanation of this system is in the Operating the Stove section of the
instructions.
Advise that if the monitoring system repeatedly shuts off the stove, it should be
switched off and a specialist consulted.
Advise that if the fire goes out for any reason, wait at least three minutes before re-
lighting.
Advise the customer that due to the newness of materials the stove may give off a
slight smell for a period of time after commissioning. This is quite normal and any
odours should disperse after a few hours operation.
Stress that no extra logs must be added over and above those supplied with the
appliance and that any replacements must only be authorized Acquisitions spares.
Recommend that the stove is regularly serviced and the flue system checked by
qualified persons.
Installer’s Name
Installer’s Telephone Number
Installer’s Company
Appliance Serial Number

Page 10
AB-G200L-REM-I01-150914
USER INSTRUCTIONS
CONTENTS
General Notes
Page 10
Spillage Monitoring System
Page 23
Important Notes
Page 10
Error Codes
Page 23
Positioning the Logs
Page 11
Cleaning
Page 27
Stove Controls
Page 12
Servicing
Page 27
Operating the Stove
Page 15
GENERAL NOTES
This stove has been individually designed to add charm and character to your
home. Providing a highly efficient heat source, the stove has the look and charm of
a wood burning stove coupled with the convenience of clean burning gas.
Due to the newness of materials the stove may give off a slight smell for a period of
time after commissioning. This is quite normal and any odours should disperse
after a few hours operation.
IMPORTANT NOTES
The installation must be in accordance with National Regulations and must be
carried out by a qualified installer. Under no circumstances should the appliance
be operated with the door open, without the door attached or the door glass
damaged broken or missing.
All surfaces except the control unit are considered to be working surfaces. Most
parts of the stove will get hot during and after use. If young children, the elderly or
infirm are likely to be near the stove, then a suitable fireguard to BS8423 is
recommended.
Do not drape clothes, fabrics or other combustible materials over the stove.
Curtains must be at least 400mm above the top of the stove.
A combustible shelf may be fitted over the appliance provided that in the case of a
150mm or less deep shelf there is at least 400mm clearance above the top of the
stove.
The stove should not be used for any other purpose than as a room heater and a
decorative stove.
When starting the fire the burner usually take around 1 to 10 seconds to ignite and
adjust to the maximum power setting. This can take longer on the first lighting as it

Page 11
AB-G200L-REM-I01-150914
has to clear out any air locks, also if it is an LPG burner and has been stood unused
for time, the gas could have settled in the pipework and again this could take
longer.
POSITIONING THE LOGS
The logs should only be arranged as detailed below and by a qualified person.
The stove must only be fitted with the ceramics supplied. DO NOT use ant extra logs or
coals.
1. Slacken the screw securing the door handle and open the stove door.
2. Position the back board into the burner tray ensuring that is correctly seated
behind Tab A and that the flame strip is not obstructed (Fig 5).
3. Locate LOG1DMR and LOG2DMR into position on the back board as shown (Fig 6).
4. Locate LOG3DMR into position as shown (Fig 7)
5. Locate LOG4DMR into position as shown (Fig 7)
6. Close the stove door.
7. Tighten the door locking screw.
Fig.5
Tab A
Fig.6
Fig.7
LOG2DMR LOG1DMR LOG4DMR LOG3DMR

Page 12
AB-G200L-REM-I01-150914
Under no circumstances should the stove be operated with the door
open, without the door attached or the glass in the door damaged,
broken or missing
STOVE CONTROLS
This stove is fitted with a gas valve which can be operated via the remote control or
using the control unit which is located behind the right-hand foot of the stove.
Fig 8 - Control unit

Page 13
AB-G200L-REM-I01-150914
1
Red indicator LED:
OFF: Burner is in standby and ready for start, or already in continuous operation
Fast flashing: Control unit is busy and will not accept commands.
Medium fast flashing: Control unit is preparing a (re)start of the burner.
Slow flashing: Control unit is detecting an error.
One short flash every 8 seconds: Low battery warning.
Always ON: Burner is locked.
2
Master switch:
Left position: Control unit is disconnected from all power supplies and does not
consume power.
Right Position: Control unit is powered and ready to operate.
3
(-) Button:
Burner in operation: Use this button to reduce the power level.
4
ON/OFF Button:
Burner in operation: Use this button to stop burner operation.
Standby: Use this button to start burner operation.
Burner locked: Use this button to unlock the burner and to reset from error state.
If control unit is preparing to restart: Use this button to stop the restart and
disable further automatic starts.
5
(+) Button:
Burner in operation: Use this button to increase the power level.
6
Battery box:
Insert here 3x AA-type Alkaline batteries.
7
Thermocouple connector.
8
High voltage and flame sensing output.
9
Gas inlet.
10
Pilot burner outlet.
11
Main burner outlet.
12
TTB connection socket.
13
Control unit mounting points.

Page 14
AB-G200L-REM-I01-150914
Fig 9 –Remote Control Handset
Grasp around the handset covering the back and sides to unlock its functions. The green
unlock light will illuminate to show when the handset is unlocked and ready to accept
commands. (N.B. Keep a grip of handset to keep it unlocked, to continue to operate the
command buttons).

Page 15
AB-G200L-REM-I01-150914
OPERATING THE STOVE
Quick start user instructions
Control unit
The control unit is situated on your fire. Figure 8 shows the main features of the control.
The control requires 3 AA size alkaline batteries to be inserted under the battery
compartment cover. The orientation of these is shown moulded into the battery
compartment.
After fitting the batteries and replacing the cover the fire can now be operated.
Slide the Master switch to the right to the ON position (I symbol).
To start the fire, press the ON/OFF button and hold for 1 second then release. The
burner will within around 1 to 10 seconds ignite and adjust to the maximum power
setting.
The power of the burner can be adjusted up and down by pressing the + and - buttons.
To stop the fire, simply press the power button again and the burner will stop.
NOTE: For safety reasons a button must be pressed and released for the command to be
recognised. Keeping hold of a button when pressing (unless otherwise instructed) will
not be recognised as a command press.
Remote control handset
Figure 9 shows the main features of the Remote control handset
The remote control handset requires 2 AA size alkaline batteries to be inserted under
the battery compartment cover. The orientation of these is shown moulded into the
battery compartment.
To start the fire, with one hand grasp around the rear and both sides of the button area
control. The green unlock light will illuminate.
Keep the handset held to keep the control unlocked, to enable operation of the buttons.
Then with the other hand touch and hold a finger on the power button for about 3
seconds. A short beep and a flash of the unlock light will happen.

Page 16
AB-G200L-REM-I01-150914
When the word “pilot” appears at the bottom left hand corner of the display,
immediately release the power button.
A second flash of the unlock light and a longer beep will also sound at the time to
release the power button.
The Fire should be lit within a few seconds.
If power button is held for more than a few seconds after second flash/beep/word pilot
appears, the command is ignored for safety reasons.
Similarly if it is released too soon before the word pilot appears, the command is also
ignored.
With this system, the control has been designed to ensure that only intended ignition of
the fire occurs.)
To stop –with handset held to unlock it, press then release power button.
Detailed user instructions
Setting the Remote control handset
Upon successful insertion of the batteries in the Handset
the display will be as shown right.
The handset will be supplied paired to the fire and all that is
required is to set the time of day and select if a 24h hour
clock or 12 hour clock display is required and if temperature
display is on Celsius or Fahrenheit.

Page 17
AB-G200L-REM-I01-150914
Setting the time
Holding the handset as described previously to unlock the
keypad, press and hold “SET” for a few seconds and the
display will be as shown.
Setting the display for 12 or 24 Hour display
As always when pressing the remote control buttons keep
the control held to keep the green light on and therefore
handset safety feature, unlocked. The H indicates that it is
time to set the timer to either 24 hour display or 12 Hour
(AM or PM) display. Press the + or –button on the handset
to toggle between the two settings. When you are ready to
confirm the setting you want press the “SET” button to
progress to setting the day of the week.
Setting the day of the week
Press and release the + and –buttons until the correct day
of the week is shown on the display.
(Mo = Monday, Tu = Tuesday, We = Wednesday, Th =
Thursday, Fr = Friday, Sa=Saturday and Su=Sunday).
Press “SET” to accept the day of the week and to progress to
setting the Hour of the day.
Note: Whilst doing this setup pressing “SET” advances to the
next display and pressing “MODE” will return you to the
previous display setting.

Page 18
AB-G200L-REM-I01-150914
Setting the Hour
Press and release the + or –button to change the hour to
the correct hour and press set to store and to move to
setting the minute. Repeat this for setting the minutes.
Setting the temperature display to Celsius or Fahrenheit.
Press and release the + or - button to toggle between °C
and °F.
When the display shows the desired symbol, press the SET
button to store the setting.
As the important settings above have now been done. Press
and hold (not releasing straight away) the “SET” button for a
few seconds and this will exit the setup menu.(alternatively
you can press and release the set button several more times
until the time of day is displayed on the handset.
The control is now ready for use with the Fire Control.
Note: the legend at the bottom shows the battery condition of both the batteries in the
hand set and in the fire control alternately. RC = Remote Control handset and FC = Fire
control.

Page 19
AB-G200L-REM-I01-150914
The control is designed to get the most out of the batteries but when eventually the
display shows they are spent(when the battery legend is an empty area, we recommend
you change the batteries in the handset before they are flat, to avoid having to
reprogram the time of day in again. N.B. Pairing is not lost, even if the batteries are
removed or flat. The pairing is not lost when the batteries are flat but replacing them
quickly before they have gone flat will avoid having to set the time of day, day of the
week again)
Paging the handset
If you have misplaced the handset (and it is in range of the fire), you can page it by
pressing the + button only on the Control unit for around 5 seconds.
The handset will flash and make a noise to help you to locate it.
Once you pick up and grasp the handset to unlock it, the Control unit will detect this and
so the sound stops.
The flashing and sound will last for 60 seconds each time the handset is paged as
described. If not found in 60 seconds, page again and so on.
NOTE: PRESS “+” Button ONLY, NOT + and - Together as you will accidentally break the
handset pairing and have to reset handset to factory state and pair again (seethe pairing
handset section if this happens).

Page 20
AB-G200L-REM-I01-150914
Subsequent hand set pairing
Display handset
The handset should be supplied already paired with your fire, however if it becomes
necessary to cancel the pairing and re pair it again do the following steps below. (NOTE:
A new pairing can be accidentally started by accidentally pressing the plus and minus
buttons together at the same time on the Control unit and held for 5 seconds.
Factory Reset of display handset
(To enable handset to be paired again) To reset a handset
to factory conditions to enable it to be paired with a
control.
Hold the handset to unlock. Press and hold set
until handset beeps and release the set button.
PROG will be at the top left corner.
Press and release the mode button until the word
SETUP is flashing in the top right corner.
Press and release SET to enter the SETUP menu.
Press and release the set button around 9 times
until you see CA0 on the display.
Press then release the + (or –button) to change
the display to CA1 and press and release the SET
button again.
The word TESC will appear in the window to show
that this handset is now reset and ready to pair
again.
The handset is paired originally in the factory follow instructions over
leaf only if handset is unpaired or replaced
