Acson AWM 25GR User manual

Wall Mounted Split Systems
AWM-G-2005
AWM 07G/GR
AWM 09G/GR
AWM 10G/GR
AWM 15G/GR
A5WM 07G/GR
A5WM 10G/GR
A5WM 15G/GR
Models:
ISO 9002
REGISTERED

1. NOMENCLATURE
1
AWM 10 GR
Brand
A : ACSON
Capacity
10 : 9,500 Btu/h
Series
G : G series
Model Type
R : Heatpump
Omitted if Cooling
I B
AC A-
Refrigerant
5 : R410A
Omitted if R22
Model Name
WM : Wall Mounted
Electrical
A : 220 - 240V/1Ph/50Hz
Others
A : First issue
Grille Type
B : Grille B
Market Region
C : Export with CE mark
U : UTL Spec.
Air Treatment Devices & Control
I : Negative Ion with wireless controller
N : NTP with wireless controller
X : Oxygen unit
Indoor

2
ALC 10 CR
Brand
A : ACSON
Capacity
10 : 9,500 Btu/h
Series
C : C series
Model Type
R : Heatpump
Omitted if Cooling Only
5 P O
AC A-
Model Name
LC : Single Split Condensing Unit
Electrical
A : 220 - 240V/1Ph/50Hz
Others
A : First issue
Outdoor
Compressor
P : Matsushita Rotary T : Toshiba Rotary
M : Mitsubishi Rotary S : Samsung Rotary
Specification Variation
O : Standard Unit I : Gold Fins
B : With Contactor L : Long Piping Unit
G : Low Ambient Kit S : With H/L Pressure Switch
H : High Ambient Kit X : Oxygen Unit
Market Region
C : Export with CE marking
E : Export without marking
U : ETL Spec.
Refrigerant
5 : R410A
Omitted if R22 Model

3
Outdoor
ALC 30 C R
Brand
A : ACSON
Capacity
30 : 30,000 Btu/h
Model Type
R : Heatpump
Omitted if Cooling
4F FA A-
Electrical
A : 220 - 240V/1Ph/50Hz
F : 380 - 415V/3Ph/50Hz
Product Specification Variation
Series
B : B series
C : C series
Model Name
LC : Single Split Condensing
Unit
Refrigerant
4 : R410A
Omitted if R22
Type of Connection
F : For Flare

2. FEATURES
xEASY INSTALLATION
-The wall mounted fan coil unit is easily installed because of its compact size, slimness and light weight.
- Slim and short outdoor unit can be easily installed even in a narrow balcony and passageway and yet
have a stable profile.
xSPACE SAVING
- No space is required on either floor or ceiling. This newly developed super slim design for wall mounting
maximizes floor space usage and enhances ceiling appearance where ceilings are low.
xQUIET OPERATION
- Cooling comfort is improved by whisper-quiet operation which is achieved by a tangential fan.
xEXCELLENT AIR DISTRIBUTION
- Air discharge direction can be adjusted in four directions, manually or automatically by using LCD
remote control.
- The new double louver design with automatic air swing function fully optimizes the room comfort by
distributing the air evenly to the room.
- The unique skew fan design with larger diameter creates better air flow to the operating environment.
xFACILITATED MAINTENANCE ENSURED
-The new design of air discharge housing whereby the fan blower can be easily accessed by just loosing
two screws on the unit to provides a flexible, faster and easier way to clean up the fan blower and
ionizer.
- Maintenance is easy for electrical components, piping and wiring as these are all easily accessible by
merely removing front plastic panel.
xWIRELESS REMOTE CONTROL
- The compact LCD transmitter is able to operate the air conditioner unit within the distance of 9 meters.
- Fan motor speed can be set at low/medium/high or automatic.
- Sleep mode auto control will gradually increase or decrease the setting temperature to provide a
comfortable surrounding for sleeping.
- Air flow direction can be controlled automatically.
- Room temperature is controlled by electronic thermostat.
- The real time timer allows the air conditioner to be switched On and Off automatically based on user
settings.
- Turbo mode function is available to enables the required set temperature to be achieved in a short time.
- Ionizer or non-thermal plasma is available to create better air quality.
- Personalized Setting allows user to preset and store 2 groups of personal settings (including timer
setting) in the handset.
- Auto random restart is a function whereby when there is power failure occurred during operation, the
unit will automatically restart as the last setting condition once the power is resumed.
xx
xx
xMOISTURE REMOVAL
-Dry mode with super low indoor fan speed can achieve more affective moisture removal.
-If the room temperature is lower than the set temperature (Cooling mode only), the compressor will cut
out and force on after 9 minutes to remove moisture effectively.
4

xHIGH EFFICIENCY HEAT EXCHANGER
- The compact design of the 3-fold structure heat exchanger provides a large surface are for better and
efficient heat exchange.
-The unique Hydrophilic slit fin has greatly improved the air flow and the contact surfaces with the air thus
to boost the cooling capacity.
xROTARY COMPRESSOR
-The ever popular rotary compressor is more energy efficient and has a higher output to weight ratio.
xSELF DIAGNOSIS
-This function is able to detect and to diagnose any faults occurring in the system by blinking of the LED
lights.
-Simplify and ease for troubleshooting.
5

6
INDOOR UNIT
A5WM-G SERIES PRODUCT LINE UP
Marking
Grille
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
ACXBCX X XXX XX
ACIBC X X X X X X
ACNBC X X X X X X
ACXBCX X XXX XX
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
311AFCAXXXX X
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
ACIBC X X X X X X
ACNBC X X X X X X
301R AFCA X X X X X
15GR
20GR
25GR
25G
07GR
09GR
10GR
CLASSIFICATIONS
Nomenclature
U1.5
Non-Thermal Plasma (NTP)
Handset
G12 (W/O Turbo mode)
D2.0
Saranet Filter
PCB
B
Cooling ModelHeatpump Model
A5WM
L2.0
G12
07G
09G
10G
15G
20G
CE
O2Theraphy
Air Purification
Ionizer Filter
Nano Technology Air Filteration
Negative Ion

OUTDOOR UNIT
A5LC PRODUCT LINE UP
7
Special Grille Compressor Marking Others
Cap. Tube
Gold Fin
Contactor
HP
LP
O
2
Theraphy
Back Panel Grille
Mat. Rotary
CE Marking
Drain Elbow
07C ACPOE X X X
ACPOB X X X
ACPXB X X X X
ACPOA X X X
ACPXA X X X X
20C ACPOC X X X
25C ACPOC X X X
28C ACPOA X X X
07CR ACPOE X X X X
10CR ACPOB X X X X
15CR ACPOA X X X X
20CR ACPOC X X X X
25CR ACPOC X X X X
28CR ACPOA X X X X
Heat Pump Model
CLASSIFICATIONS
Safety Devices
15C
Refrigerant
Ctrl + Fin
A5LC
Cooling Model
Nomenclature
10C

11. CONTROLLER
G12 REMOTE CONTROLLER
Temperature Setting
xTo set the desired room
temperature, press the button to
increase or decrease the set
temperature.
xThe temperature setting range is
from 16qC to 30qC
xPress both buttons simultaneously
to toggle the temperature setting
between qC and qF
Turbo Mode
xPress the TURBO button to
achieve the required set
temperature in a short time.
ON Timer Setting
xPress the SET button will activate
the on timer function.
xSet the desired on time by pressing
the SET button continuously.
xPress the CLR button to cancel the
off timer setting
Sleep Mode
xPress the button to activate sleep
mode. This function is available
under COOL, HEAT & AUTO
mode.
xWhen it is activated in COOL
mode, the set temperature will be
increased 0.5qC after 30mins, 1qC
after 1 hour and 2qC after 2 hours.
xWhen it is activated in HEAT
mode, the set temperature will be
decreased 1qC after 30mins, 2qC
after 1 hour and 3qC after 2 hours.
Personalised Setting
xPress and hold the button for 3s to
initiate personalized setting.
xSet the individual setting e.g.
MODE, SET TEMP or FAN SPEED
and leave for 4s to save
x2 groups of settings are allowed to
stored in the handset
Fan Speed Selection
xPress the button until the desired
fan speed is achieved.
Operating Mode
xPress the MODE button to select
the type of operating mode.
xFor Cooling only unit, the available
modes are: COOL, DRY & FAN.
xFor Heatpump unit, the available
modes are: AUTO, COOL, DRY,
FAN & HEAT.
OFF Timer Setting
xPress the SET button will activate
the off timer function.
xSet the desired off time by
pressing the SET button
continuously.
xPress the CLR button to cancel the
off timer setting
Automatic Air Awing
xPress the SWING button to activate
the automatic air swing function.
xTo distribute the air to a specific
direction, press the SWING button
and wait until the louver move to
the desired direction and press the
button once again.
On/Off Button
xPress Once to start the air
conditioner
xPress again to stop the unit
Clock Time Setting
xPress button + or - to increase or
decrease the clock time.
Ionizer
xPress the button to activate the
negative Ion function, which will
refresh the indoor air effectively.
8

9
INDICATOR LIGHTS
AWM / A5WM - G SERIES
IR signal receiver
When there is infrared remote control operating
signal, the signal receiver on indoor unit will made a
(beep) for signal acceptance confirmation.
Cooling unit / Heatpump unit
The table below shows the LED indicator light for air
conditioner unit under normal operation and fault
condition. The LED indicator lights are located at the
middle of the air conditioner unit.
The heat pump units is equipped with an “auto” mode,
whereby the unit will provide reasonable room
temperature by switching the unit automatically to
either “cool” mode or “heat” mode, according to the
temperature setting set by the user.
LED Indicator Lights : Normal Operation And Faulty Indication Table
COOL/HEAT
(GREEN/RED)
Normal Operation / Fault Indication Action
|/z
|/z
|/z
|
Red
|/z
|
Green
|/z
|
|/z
|
||
||
Red
Cool mode
Heat mode
Auto mode in Heating operation
Auto mode in Cooling operation
Timer on
Sleep mode on
Ionizer on
Fan mode on
Indoor coil sensor open
Outdoor coil sensor open
Room air sensor contact Loose / Short
Call your dealer
Call your dealer
-
-
-
-
-
-
-
-
|- ON |/z- ON or OFF - Blinking
LED Indicator Lights for Cooling Unit / Heatpump
Unit
|
Red
|
Green
|/z
|/z
||
/z
||
/z
-
Dry mode on
1 time
3 times
1 time
Compressor overload /
Indoor coil sensor short /
Outdoor coil sensor short
3 times
5 times
6 times
Defrost operation
Gas leak
Outdoor coil sensor exist (MS mode)
Hardware error (tact switch pin short)
Call your dealer
Call your dealer
Call your dealer
Call your dealer
Call your dealer

LED Indicator Lights : Normal Operation And Fault Conditions For Cooling Unit
Operation / Fault Indication Action
|Timer on
Sleep mode on
Dry mode on
Frost prevention
Sensor contact problem, compressor overload
protection trip or gas leak
Indoor coil sensor contact loose / short
Room air sensor contact loose / short Call your dealer
Clean the filter and switch to high fan
-
-
-
|- ON |/z- ON or OFF - Blinking
LED Indicator Lights For Cooling Unit
Power Dry Timer Sleep
|
|
|
|
|/z
Continuously
|
once every 2 sec.
twice every 2 sec.
3 times every 2 sec.
Call your dealer
Call your dealer
10
AWM 301 / 301R , A5WM 311 / 301R

LED Indicator Lights : Normal Operation And Fault Conditions For Cooling Unit
Normal Operation / Fault Indication Action
|Cooling mode
Dry mode
Fan mode
Heat mode
Auto mode in cooling operation
Auto mode in heating operation
Call your dealer
-
|- ON |/z- ON or OFF - Blinking
Cool Dry Fan Heat
|
|
|/z
|
LED Indicator Lights For Heatpump Unit
Cooling mode Dry mode Heat/Fan mode
(red/green)
Sleep mode
|/z
|/z
|/z
|
|
Defrost operation
Compressor overload protection
-
-
-
-
Call your dealer
Call your dealer
Call your dealer
-
-
Indoor coil sensor contact loose/short
Outdoor coil sensor contact loose/short
Room air sensor contact loose/short
If the system is in cool mode or heat mode (with the sleep function off), the
sensor may have a contact problem, compressor overload protection trip or
gas leak.
Sleep
11

12
18qC
(A) 3 HOT SYSTEM (HEATING CYCLE)
a) Hot start
At the beginning of heating operation (cold start, after defrosting or thermostat resumes operation) the indoor
fan operation is controlled in accordance with the temperature of the indoor heat exchanger to send warm air
from the start.
b) Hot keep (Apply to AWM301R)
After thermostat cut out, the indoor fan operation is controlled in accordance with the indoor heat exchanger
temperature to utilize the extra heat and preserve indoor comfort.
The indoor fan can be switched to ON, OFF, INTERVAL by setting the slide switch shown in the diagram. This
slide switch is located at the front frame cover.
18qC
Note 2: Fan OFF
SET AIR FLOW
COMP
& OF
RUN
STOP
INDOOR
FAN
LOW FAN
FAN OFF
LOW FAN
30s
30s
120s
Note 3 : Interval
Note 1 : Fan ON (default)
HOT KEEP
OFF
INTERVAL
ON
ON/OFF
Slide Switch
CONTROLLER SPECIFICATIONS

13
Hot Keep (Apply to AWM-GR)
After thermostat cut out, the indoor fan operation is controlled in accordance with the indoor heat exchanger
temperature to utilize the extra heat and preserve indoor comfort.
The indoor fan can be switched to ON, OFF by setting the slide switch shown in the diagram. This slide switch is
located at the front frame cover.
Multisplit Model Selection
The indoor unit can be changed to multisplit model by just selecting MS through the slide switch.
c) Hot spurt
During cold start, the set temperature of controller is increased by 2oC to stabilize the room temperature quickly.

14
(B) TURBO MODE (APPLY TO AWM-GR)
TURBO function is available in COOL, HEAT and DRY modes only. When TURBO function is set, working
temperature for cooling cycle is decreased by 2oC, working temperature for heating cycle is increased by 2oC.
The indoor fan will force to HIGH fan. After 20 minutes, this function will clear automatically, no more offset
temperature for set temperature and indoor fan will restore. Cold start will be overridden when TURBO function
is activated. If TURBO and SLEEP are activated at the same time, the SLEEP mode timer will be reset, it will
resume after TURBO function is cleared.
(C) OVERLOAD PREVENTION IN HEATING OPERATION
During heating operation, if the room temperature and outdoor temperature are high, or when the indoor air
filter is choked, the condensing pressure will increase rapidly. To prevent the burn out of compressor, the M.
C. controller will stop the operation of the air conditioner under this condition.
COMP.,
OUTDOOR FAN &
4-WAY VALVE
xFor manual reset type, the ON / OFF button must be pressed to reset the system.
Temperature °C
20 min 30 min
TURBO MODE
CONVENTIONAL
(D) OVERLOAD PROTECTION IN COOLING OPERATION
When outdoor and indoor air temperature raise beyond the operation limit, or when the outdoor coil choked
with dirt, the M.C. controller detects abnormal increase in condensing temperature. It will stop the operation
to prevent compressor burn out.

15
(E) FROST PREVENTION AND FILTER CHECK
In order to prevent the freezing of indoor coil, the controller will operate as follow.
(F) AUTO RANDOM RESTART
When power resumed, the unit will automatically restart and operate at the previous setting as before power
failure occurred.
1qC

13. SERVICING AND MAINTENANCE
MOff the unit
NUnscrew the air discharge housing
OFlip open the air discharge housing
PClean the blower
QClose the air discharge housing and tighten it with screw
The unit is designed to give a long life operation with minimum maintenance required. However, it should be regularly
checked and the following items should be given due attention.
16
Components Maintenance Procedure Recommended Schedule
Indoor Air Filter 1 . Remove any dust adhering on the filter by using a
vacuum cleaner or wash in lukewarm water (below
40qC/104qF) with a neutral cleaning detergent.
2. Rinse the filter well and dry before placing it back onto
the unit.
3. Do not use gasoline, volatile substances or chemicals
to clean the filter.
At least once every 2 weeks.
More frequently if necessary.
Indoor Unit 1. Clean any dirt or dust on the grille or panel by wiping it
with a soft cloth soaked in lukewarm water (below
40qC/104qF) and a neutral detergent solution.
2. Do not use gasoline, volatile substances or chemicals to
clean the indoor unit.
At least once every 2 weeks.
More frequently if necessary
Condensate Drain
Pan and Pipe
1. Check and clean. Every 3 months.
Indoor Fan 1. Check for unusual noise. As necessary.
Indoor/Outdoor
Coil
1. Check and remove dirt which are clogged between fins.
2. Check and remove obstacles which hinder air flow in
and out of indoor/outdoor unit.
Every month.
Every month.
Electrical 1. Check voltage, current and wiring.
2. Check faulty contacts caused by loose connections,
foreign matters, etc.
Every 2 months.
Every 2 months.
Compressor 1. No maintenance needed if refrigerant circuit remains
sealed. However, check for refrigerant leak at joints
and fittings.
Every 6 months.
Compressor
Lubrication
1. Oil is factory charged. Not necessary to add oil if circuit
remains sealed.
No maintenance required.
Fan Motors
Lubrication
1. All motors pre-lubricated and sealed at factory. No maintenance required.

14. TROUBLESHOOTING
17
When a malfunction of the air conditioner unit is detected, immediately switch off the main power supply before
proceeding with the following troubleshooting procedures.
The following are common fault conditions and simple troubleshooting tips. If any other fault conditions which
are not listed occur, contact your nearest local dealer. DO NOT attempt to troubleshoot the unit by yourself.
No Fault conditions Possible causes / corrective actions
1 The air conditioner unit will not resume after
power failure.
xThe auto restart function is not functioning. Please
turn on the unit with the wireless / wired controller.
2 The compressor does not operate 3 minutes
after the air conditioner unit is started.
xProtection against frequent starting.
xWait for 3 or 4 minutes for the compressor to start
operating by it self.
3 The airflow is too slow or room cannot be
cooled sufficiently.
xThe air filter is dirty.
xThe doors and windows are opened.
xThe air suction and discharge of both indoor and
outdoor units are clogged or blocked.
xThe regulated temperature or temperature setting
is not low enough.
4 Discharge airflow has bad odor. xCigarettes, smoke particles, perfume and others,
which might have adhered onto the coil, may
cause odor.
xContact your nearest dealer.
5 Condensation on the front air grille of the indoor
unit.
xThis is caused by air humidity after an extended
period of operation.
xThe set temperature is too low. Increase the
temperature setting and operate the unit at high
fan speed.
6 Water flowing out from the air conditioner. xSwitch off the unit and contact your nearest
dealer. This might be due to tilted installation.
7 Hissing airflow sound from the air conditioner
unit during operation.
xLiquid refrigerant flowing into the evaporator coil.
8 The wireless controller display is dim. xThe batteries are discharged.
xThe batteries are not correctly inserted.
xThe assembly is not good.
9 Compressor operates continuously. xDirty air filter. Clean the air filter.
xTemperature setting too low (cooling). Use higher
temperature setting.
xTemperature setting too high (heating), Use lower
temperature setting.
10 No cool air comes out during cooling cycle, or
no hot air comes out during heating cycle.
xTemperature setting too high (cooling). Use lower
temperature setting.
xTemperature setting too low (heating). Use higher
temperature setting.
11 On heating cycle, warm air does not come out. xUnit is in defrost mode. Heating operation will
resume after defrost cycle ends.

15. EXPLODED VIEW AND PARTS LIST
18
INDOOR UNIT
MODEL: A5WM / AWM 07G / 07GR / 09G / 09GR / 10G / 10GR / 15G / 15GR

19
A5WM / AWM 07G / 09G / 10G / 15G
A5WM / AWM 07GR / 09GR / 10GR / 15GR
No Descriptions Part No No Descriptions Part No
1 Assy., Chassis 12 Air Discharge Housing
A5WM / AWM 07/09G A50124064147 A5WM / AWM 07/09G A50124062325
A5WM / AWM 10/15G A50124064151 A5WM / AWM 10/15G A50124062326
2 Fan, Motor 13 Lower Louver
A5WM / AWM 07/09G A03034064425 A5WM / AWM 07/09G A12014060538
A5WM / AWM 10/15G A03034064426 A5WM / AWM 10/15G A12014061364
3 Cross Flow Fan 14 Upper Louver
A5WM / AWM 07/09G A03029019462 A5WM / AWM 07/09G A12014060537
A5WM / AWM 10/15G A03029019461 A5WM / AWM 10/15G A12014061363
4 Fan, Bush A11014029514 15 Saranet Air Filter
5Assy., Coil A5WM / AWM 07/09G A12014062320
A5WM / AWM 07/09G A50024063765 A5WM / AWM 10/15G A12014062321
A5WM / AWM 10/15G A50024064225 16 Titanium Oxide Filter A03089015250
6Piping, Clamp A12014060544 Anti-Mirobial Filter A03089019984
7Assy., Drain Pan 17 Assy., Negative Ionizer A04239019730
A5WM / AWM 07/09G A50124064148 18 G12 handset A04084065327
A5WM / AWM 10/15G A50124064152 19 Air Swing Motor A03039004235
8Drain Hose A10024018204 20 Assy, Mounting Plate
9Assy., Control Box A12014060545 A5WM / AWM 07/09G A50014061333
10 Assy., Control Box Cover A50124064666 A5WM / AWM 10/15G A50014062324
11 L2 Control Module 21 Assy., Front Cover
A5WM / AWM 07/09G A04084064633 A5WM / AWM 07/09G A50124064664
A5WM / AWM 10/15G A04084064634 A5WM / AWM 10/15G A50124064675
No Descriptions Part No No Descriptions Part No
1 Assy., Chassis 12 Air Discharge Housing
A5WM / AWM 07/09GR A50124064147 A5WM / AWM 07/09GR A50124062325
A5WM / AWM 10/15GR A50124064151 A5WM / AWM 10/15GR A50124062326
2 Fan, Motor 13 Lower Louver
A5WM / AWM 07/09GR A03034064425 A5WM / AWM 07/09GR A12014060538
A5WM / AWM 10/15GR A03034064426 A5WM / AWM 10/15GR A12014061364
3 Cross Flow Fan 14 Upper Louver
A5WM / AWM 07/09GR A03029019462 A5WM / AWM 07/09GR A12014060537
A5WM / AWM 10/15GR A03029019461 A5WM / AWM 10/15GR A12014061363
4 Fan, Bush A11014029514 15 Saranet Air Filter
5Assy., Coil A5WM / AWM 07/09GR A12014062320
A5WM / AWM 07/09GR A50024063765 A5WM / AWM 10/15GR A12014062321
A5WM / AWM 10GR A50024064225 16 Titanium Oxide Filter A03089015250
A5WM / AWM 15GR A50024066054 Anti-Mirobial Filter A03089019984
6Piping, Clamp A12014060544 17 Assy., Negative Ionizer A04239019730
7Assy., Drain Pan 18 G12 handset A04084067315
A5WM / AWM 07/09GR A50124064148 19 Air Swing Motor A03039004235
A5WM / AWM 10/15GR A50124064152 20 Assy, Mounting Plate
8Drain Hose A10024018204 A5WM / AWM 07/09GR A50014061333
9Assy., Control Box A12014060545 A5WM / AWM 10/15GR A50014062324
10 Assy., Control Box Cover A50124064667 21 Assy., Front Cover
11 L2 Control Module A04084067263 A5WM / AWM 07/09GR A50124064664
A5WM / AWM 10/15GR A50124064675
