ActionTec ScreenBeam Pro User manual

ScreenBeamPro
Wireless Displayfor
IntelProWiDi
Firmware: V2.11.x.x/V9.11.x.x
User Manual
V0.93
ForCatalog#SBWD100BE02/SBWD950P/SBWD960A

Warning
Thisdevicecomplieswithpart15 ofthe FCC Rules.Operation issubjecttothe condition
thatthisdevicedoesnotcauseharmfulinterference(1)thisdevicemaynotcauseharmful
interference,and(2)thisdevicemustacceptanyinterferencereceived,including
interferencethat maycauseundesired operation.
Changesormodificationsnotexpresslyapproved bythe partyresponsibleforcompliance
couldvoidthe user'sauthoritytooperatetheequipment.
NOTE:Thisequipmenthasbeen tested and found tocomplywiththe limitsforaClass B
digitaldevice,pursuanttoPart15 ofthe FCC Rules.Theselimitsaredesigned toprovide
reasonableprotection againstharmfulinterferenceinaresidentialinstallation.This
equipment generates,usesandcan radiateradiofrequencyenergyand,if notinstalled and
used inaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguarantee thatinterferencewill notoccurina
particularinstallation.
Ifthisequipment doescauseharmfulinterferencetoradioortelevision reception,whichcan
bedetermined byturningtheequipmentoff and on,the userisencouraged totrytocorrect
the interferencebyoneormoreofthe followingmeasures:
lReorient orrelocatethe receivingantenna.
lIncreasetheseparation between theequipment and receiver.
lConnect theequipmentintoanoutlet on acircuitdifferentfromthattowhichthe receiver
isconnected.
lConsult the dealeroran experiencedradio/TVtechnician forhelp.
TomaintaincompliancewithFCCsRFExposureguidelines,Thisequipmentshouldbe
installed andoperatedwithminimumdistancebetween 20cmthe radiatoryourbody:Use
onlythe supplied antenna.

TableofContents
PartI.GettingStarted......................................................................................................................1
1.1.Contentsin theBox.......................................................................................................1
1.2.MeetingScreenBeamPro.............................................................................................1
1.2.1.SBWD100BE02......................................................................................................2
1.2.2.SBWD950P/SBWD960A.........................................................................................2
1.3.SystemRequirements...................................................................................................3
1.3.1.Receiver.................................................................................................................3
1.3.2.CompatibleDevices...............................................................................................3
1.3.3.BestKnownConfigurations(BKCs)forIntelProWiDi...........................................3
PartII.InstallingtheReceiver...........................................................................................................4
2.1.ConnectingtheReceivertoanHDTV............................................................................4
PartIII. SettingUpfortheFirstTime.................................................................................................6
3.1.ConnectingviaWindows8.1.........................................................................................6
3.2.ConnectingviaWindows10........................................................................................10
3.3.ConnectingviaIntel WiDiApp (Gen4).....................................................................13
3.4.ConnectingviaIntel ProWiDiApp (Gen6)...............................................................16
3.5.TipsforOptimalPerformance.....................................................................................20
PartIV.Control and Display.............................................................................................................21
4.1.IntelProWiDiand ManagedMeeting........................................................................21
4.2.Display Mode..............................................................................................................22
4.3.USB overNetwork.......................................................................................................22
PartV.DeviceManagementforITAdministrator..........................................................................24
5.1.LogintotheLocalManagementWebServer..............................................................24
5.1.1.WhenAutonomousGOisEnabled......................................................................24
5.1.2.WhenAutonomousGOisDisabled.....................................................................25
5.1.2.1.WhenSSID BroadcastisDisabled................................................................25
5.1.2.2.WhenSSID BroadcastisEnabled.................................................................29
5.1.3.LogOut................................................................................................................32
5.2.ChangingLocalManagementConsole’sDisplay Language.........................................32
5.3.ConfiguringtheReceiver.............................................................................................33
5.3.1.RenamingtheReceiver.......................................................................................33
5.3.2.SettingupLogin Usernameand PasswordfortheLocalManagementConsole.34
5.3.3.SettinguptheReceiver’sDisplay Language........................................................35
5.3.4.ModifyingtheReceiver’sHostName..................................................................35
5.3.5.SettingupManagedMeetings............................................................................36
5.3.6.Settingup Inactive SourceGracePeriod forManagedMeetings.......................37
5.3.7.SettingupModeratedModeforManagedMeetings.........................................37
5.3.8.SettingupPINPairingMethod............................................................................38
5.3.9.ManagingHDMI/VGAPortOutput.....................................................................39
5.3.10.Settingup WiDiLowerBandwidth......................................................................40
5.3.11.Settingup ForceEDID atRTSPM3......................................................................41

5.3.12.Settingup HDCPEncryption................................................................................42
5.3.13.SettinguptheVGACompatibilityMode.............................................................43
5.3.14.Settingup USBLocalAccess................................................................................43
5.3.15.AdjustingTV ScreenSize.....................................................................................44
5.3.16.Settingup OutputAspectRatio..........................................................................45
5.3.17.Settingup OneTouchPlay (HDMI-CEC)..............................................................46
5.3.18.Settingup TransmitPower..................................................................................46
5.3.19.UpdatingtheReceiver’sBackground Image.......................................................47
5.3.20.UpdatingtheReceiver’sScreensaverImage.......................................................48
5.3.21.Settingup Network Information Display onTV Screen.......................................49
5.3.22.Settingup AutonomousGroup Owner(AGO).....................................................50
5.3.23.Settingup Communication Channel...................................................................51
5.3.24.SettingupGroup OwnerIntent...........................................................................52
5.3.25.SettingupP2PNetwork Parameters...................................................................53
5.3.26.Settingup Wireless Network Parameters...........................................................54
5.3.27.ModifyingtheReceiver’sWireless Network Name(SSID)..................................56
5.3.28.SettingupBroadcastNetwork Name..................................................................57
5.3.29.Settingup Wireless Connection Properties........................................................57
5.3.30.SettinguptheReceiver’sIPAddress...................................................................59
5.3.31.Specifyinga DNSServerfortheReceiver............................................................60
5.3.32.SpecifyingScreenBeamCMSfortheReceiver....................................................60
5.3.33.SpecifyingaLocalManagementCommunication PortfortheReceiver.............61
5.3.34.RebootingtheReceiver.......................................................................................62
5.3.35.ResettingtheReceivertoDefault.......................................................................62
5.4.UpgradingtheReceiver...............................................................................................63
PartVI.FAQsand Troubleshooting..................................................................................................66
6.1.FAQ..............................................................................................................................66
6.2.Troubleshooting..........................................................................................................68
Appendix I. Specifications(Model:SBWD960A)............................................................................70

1
PartI. Getting Started
Thankyouforyourpurchaseof Actiontec sScreenBeamProWireless DisplayReceiverfor
IntelProWiDi(hereinafterrefertoas “ScreenBeamPro”).
The Receiverletsyou wirelesslystreamwhatson yourIntelWiDiorMiracast™compatible
devicetoyourHDTV,includingmovies,videos,photos,music,and more.TheReceiver
freesyoureyesfromatinyscreen.
The Receiverboastssomegreatfeatures,includingfastsetup,enhancedsecurityandIT
manageability, Managed Meetings(Gen 6ProWiDi), smoothvideo playback, full 1080pHD
support, ultra-lowdelay,Windows8.1optimization,versatilecompatibility,lowpower
consumption, and more.
WithScreenBeamPro,it'seasytomakepresentationsand impromptumeetingsinthe
conferenceroomabreeze,asusersdon'tneedtoscrambletofind therightHDMIorVGA
cableinordertoshareaspreadsheetorpresentationon the bigscreen.And the Managed
Meetingsfeatureallowsmeetingparticipantstointeractivelysharetheirownscreenson the
bigscreen.
Thisusermanualwill takeyou throughtheproceduresneededtoinstall,connectto,operate,
configure,and upgrade the receiver,and alsodescribeafewdifferentpossiblescenarios
about locatingfaults.
Foroptimalwireless displayexperience,westronglyrecommend youupdateyourreceiver
tothelatest firmware. Check firmwareupdatenowon actiontec.com/sbupdate.
1.1.Contents intheBox
Contentsinthe Receiver spackagearelisted below:
lScreenBeamProWireless DisplayReceiver(1)
lHDMI Cable(1)
lHDMI-to-VGAAdapter&3.5mmaudiocable(1)(forSBWD100BE02 only)
lACPowerAdapter(1)
lInstallation Guide
1.2.MeetingScreenBeamPro
Thismanualisapplicabletothe followingcatalog#s:
lSBWD100BE02
lSBWD950P/SBWD960A

2
1.2.1.SBWD100BE02
lLEDIndicator, indicatingpowersupplystatus
lUSBPort,forconfiguringCMSconnection data,firmwareupdate,and USB over
networkcontrol(UIBC/UoIP)
lResetButton, forresettingthe devicetodefault
lVideoOutPort (HDMI), forconnectingtoHDTV/projectorforvideo and audiooutput
lPowerInputPort,forpowersupply
1.2.2.SBWD950P/SBWD960A
lETHERNET,forconnectingtoScreenBeamCentralManagementSystemviaEthernet
forreceivermanagement
lHDMIOUT,forconnectingtoHDTV/projectorwithan HDMIportforvideo and audio
output
lPOWER, forpowersupply
lRESET, forresettingthe devicetodefaults
lLEDIndicator, indicatingpowersupplystatus
lAUDIO OUT, foroutputtingaudiotospeaker(SBWD960Aonly)
lUSB,forconfiguringCMSconnection data,firmwareupdate,and USB overnetwork
control(UIBC/UoIP)
lVGA-OUT, forconnectingtoan HDTV/projectorwithaVGAport forvideo output
lVGA-IN, VGAinput forVGAbypass

3
1.3.System Requirements
Systemrequirementsforthe receiverareshownbelow:
1.3.1.Receiver
Toinstall the Receiver, you must havethe followingitems:
lAdisplaydevicewithone HDMI port (TypeA)orone VGAport
lAnavailablepoweroutlet
1.3.2.CompatibleDevices
TheReceiveriscompatiblewiththe followingdevices:
lTablets,Ultrabook™devices,and 2-in-1deviceswiththelatestIntel®Core™vPro™
processorsand IntelWiDi6
lTablets, Laptops, and Notebooks withIntelWiDi4(orhigher)*
lWi-FiCertified Miracast™deviceswithWindows8.1orWindows10*
*Note:Recommended deviceswithIntelDual-Band Wireless-ACorWireless-Nmodels
(7260 or7265)
1.3.3.BestKnownConfigurations(BKCs)forIntel ProWiDi
ForoptimalexperiencewithIntelProWiDi,werecommend toupdateyoursystemdrivers
and IntelWiDi application tothelatestversionsprovided byIntel.You canfind thelatest
version byvisitingIntel swireless displaysupportwebsite
http://www.intel.com/p/en_US/support/highlights/wireless/wireless-display/
•4thGenorHigherIntel CorevPro*PlatformwithpGFX
•Corem, I5, ori7withvPro
•Graphics Package:v15.36.x.x
•Wireless Driver:v10.18.x.x
•IntelWiDiApp:v6.x.x.x

4
PartII. Installing theReceiver
ThischapterexplainshowtoconnecttheReceivertoan HDTV.Makesureyouhaveall the
contentsfromthe Receiver spackageavailablebeforestarting.
2.1.ConnectingtheReceivertoanHDTV
It isquiteeasyand fasttosetupthe Receiver.You can completethe connectioninjustone
minute.
Toconnect theReceivertoan HDTV:
1.Get the Receiver, ACpoweradapter, and HDMI cable fromthe Receiver spackage.
2.Plugone endofthe supplied HDMIcableintothe HDMIport(“VideoOut”or
“HDMI-OUT”)on the Receiver,and the otherend intoan availableHDMIporton the
HDTV.
3.Plugthe connectorofthepowercordtothe Receiver spowerinputportlabeled "5V
DC"or “POWER”, and plugthe poweradaptertoapoweroutlet.
When Steps1,2,and 3arecomplete,the hardwareshouldbeconnected asshownin
the figurebelow:
4.Turnon theHDTVandsetittodisplaythe inputfromthe correctHDMIport(the one you
haveplugged intoinStep2).
5.Verifythat the “Readytoconnect”screen appearson theHDTV.

5
TheReceiverisconnected totheHDTV, and it isreadyforuse.
Note: Connectionstootherdisplaydevicesaresimilar.
6.(Optional)VGAbypass connection isshownbelow:
Note:The VGAbypass connectionisformodelSBWD950P/SBWD960Aonly.

6
PartIII.Setting UpfortheFirstTime
ThischapterexplainshowtoconnectScreenBeamProforthe firsttimetothesourcedevice.
Thereareseveralsourcedeviceoptions:IntelWiDi (IntelProWiDi),Windows8.1,and
Windows10.
lForWindows8.1devices,pleaseproceed toSection 3.1. Connecting viaWindows
8.1;
lForWindows10 devices,pleaseproceed toSection3.2. Connecting viaWindows10;
lForWindows7/8devices(Gen 4WiDi),pleaseproceed toSection3.3. Connecting via
Intel WiDiApp (Gen4);
lForIntelProWiDi (Gen 6)devices,pleaseproceedtoSection 3.4. Connecting via
Intel ProWiDiApp (Gen6).
3.1.ConnectingviaWindows8.1
ThissectionexplainshowtoconnectadevicerunningWindows8.1toScreenBeamPro.
1.Fromthe Windowsdesktop,gotothe Charms menuandselect Devices toopen the
Devices menu. You can alsousethe shortcut keys, Windows logo+ K.
2.Fromthe Devices menu, click Project.

7
3.Fromthe Project menu,select Add awireless display.Windowswillsearchfor
availabledevices.
Note: Ifyou arerunningWindows8.1and thescreensabovedo notappear, goto
http://www.actiontec.com/widi81 forthe latestsoftwareupdate.Or,youcanupdateyour
Windows8.1viathe WindowsUpdate application.
4.Selectyourreceiverfromthe devicelist.
5.APINentryboxisdisplayedonthe screenofyourWindows8.1device,andaPINcode
and hostname(QA-PC01 inthisexample)ofthe connectingdevicearedisplayedon
the HDTV.Typethe PINinthePINentryboxonyourdevice, and then click Next.

8
Note:YoushouldobtainthesecurityPINfromyournetworkadministratorifno PINis
displayed ontheconnecteddisplaydevice.
6.Yourdevicewill connect tothe receiver withinafewseconds.

9
Note:
lIntelProWiDi (Gen 6)will run automaticallyifyourdeviceiscompatiblewithIntel
ProWiDi (Gen 6)and hastheapp installed.
lYourdevicesscreen will bedisplayed on the HDTVinabouttensecondsifIntel
WiDi(Gen 6)/IntelProWiDi(Gen 6)appisnotinstalled on yourdevice.Referto
5.3.6. Settingup InactiveSourceGracePeriod forManagedMeetings fordetail.

10
3.2.ConnectingviaWindows10
ThissectionexplainshowtoconnectadevicerunningWindows10 toScreenBeamPro.
1.Press the shortcutkeys, Windows logo + K,on yourkeyboardtodisplaythe
wireless displayreceiverlist.
Note:Thereareotherwaystoopen the wireless displayreceiverlist:
lClick the Startbutton,and then select Settings > Devices > Connecteddevices >
Add adevice toopen the wireless displayreceiverlist.
lClick the Notification icon on the task barorpressthe shortcutkeys, Windows
logo + A,toopenthe Action Center,and thenselect Connect toopen the
wireless displayreceiverlist.
lPress the shortcutkeys, Windows logo + P,toopen the Project menu,and
then select Connecttoawireless display toopenthe wireless displayreceiver
list.
2.Selectyourreceiverfromthe devicelist.

11
3.APINentryboxisdisplayed on the screenofyourWindows10 device, and aPINcode
and hostname(QA-PC01 inthisexample)ofthe connectingdevicearedisplayedon
the HDTV.Typethe PINinthePINentryboxonyourdevice, and then click Connect.

12
Note:YoushouldobtainthesecurityPINfromyournetworkadministratorifno PINis
displayed ontheconnecteddisplaydevice.
4.Yourdevicewill connect tothe receiver withinafewseconds.
Note:
lIntelProWiDi (Gen 6)will run automaticallyifyourdeviceiscompatiblewithIntel

13
ProWiDi (Gen 6)and hastheapp installed.
lYourdevicesscreen will bedisplayed on the HDTVinabouttensecondsifIntel
WiDi(Gen 6)/IntelProWiDi(Gen 6)appisnotinstalled on yourdevice.Referto
5.3.6. Settingup InactiveSourceGracePeriod forManagedMeetings fordetail.
3.3.ConnectingviaIntel WiDi App (Gen4)
Thissection explainshowtoconnectadevicerunningIntel's WiDi application tothe
receiver.
Followthe procedurebelowtoconnectyourdevicetothe receiver:
1.Launchthe Intel Wireless Display application on thedevice.Tofind the application, go
to WindowsSearch on the deviceand searchfor “IntelWiDi”.
2.The IntelWiDi application scansforavailablereceiversautomatically.Selectyour
receiverand click Connect. (The “ConnectAutomatically”checkboxisoptional.)
Note: Ifyourreceiverisnot found, you canclick the Scan button toscanagain.
3.APINentryboxisdisplayed onthe screen ofthe WiDi device, and aPINcode and host
name(QA-PC01 inthisexample)of the connectingdevicearedisplayed on theHDTV.
TypethePINinthe PINentryboxon the WiDidevice, andthen click Connect.

14
Note:YoushouldobtainthesecurityPINfromyournetworkadministratorifno PINis
displayed ontheconnecteddisplaydevice.
4.Withinafewseconds, yourdevicewill connect tothereceiver.

15
5.A"Connection Successful"screen appearson the device'sscreen.Click Finished,
and the devicesscreen will bedisplayed on the HDTVinabout tenseconds.

16
3.4.ConnectingviaIntel Pro WiDiApp(Gen6)
ScreenBeamProsupportsManaged Meetings, whichisonlyavailablewithIntel®ProWiDi.
Tousethisfeature, ScreenBeamPromust havethe AGO featureenabled.
Note:
lTousethe Intel®ProWiDiManaged Meetingfeature,you mustinstall theIntelPro
WiDisoftwareon anIntel®Haswell orbettersystemwithIntel®Core™vPro™
processor.
lFordetailsaboutAGO settings,refertoSection 5.3.22. Settingup AutonomousGroup
Owner(AGO).
Followthe procedurebelowtoconnectyourdevicetoScreenBeamPro:
1.Launchthe Intel ProWiDi application on yourdevice.
2.The Intel ProWiDi application scansforavailablereceiversautomatically.Select your
receivertostart the connection procedure.
3.APINentryboxisdisplayed onthe screen ofthe WiDi device, and aPINcode and host
name(QA-PC01 inthisexample)of the connectingdevicearedisplayed on theHDTV.
TypethePINinthe PINentryboxon the WiDidevice, andthen click Connect.
