ACTiSYS BT5711U User manual

BT5711U provides a bridge solution between Bluetooth & Raw
IR on data transmission.
It converts Data received through Bluetooth (SPP Bluetooth
profile support) from sender to traditional RAW-IR data or vice
versa. It is battery powered in addition to AC power operation.
So user can use it in the field application.
ACT-BT5711U
Bluetooth
Bluetooth- -to to- -Raw IR Bridge Raw IR Bridge
Battery Powered
Battery Powered
Application Scenario
Features and Benefits:
BT5711U enables any devices with Bluetooth capability to connect with Raw IR devices.
Configurable Bluetooth baud rate 1200 bps ~ 1843200bps at the Bluetooth side;
configurable IR baud rate: 1.2k, 2.4k, 4.8k, 9.6k, 19.2k, 38.4k, 57.6k and 115.2k bps at the
IR side.
1.63 μs IR pulse.
256 bytes outbound buffer and 256 bytes inbound buffer at IR side.
Supports Virtual COM port at both IR & Bluetooth sides.
Provides optional ACT-BT5711U-PEK Download Kit and Configuration Utility for
Bluetooth and Raw IR parameters setting. Supports for pairing mode, device name, PIN
code.
Sniff mode available at Bluetooth side for power saving.
Supports UART interface & RTS/CTS hardware flow control.
Supports Bluetooth SPP (Serial Port Profile) as a slave or a master.
Auto-connect feature when interconnecting two Bluetooth adapters.
Example of Cable Replacement application
Class 2

BCR01
Bluetooth RS232 Wireless Cable Solution
Bluetooth RS232 Wireless Cable Solution
ACT-BT5711U
Bluetooth
Bluetooth- -Raw IR Bridge Raw IR Bridge Class 2
Specifications
Model No. ACT-BT5711U
Standard Bluetooth SIG 1.2
Bluetooth Profile Serial Port Profile (SPP) only
Baud Rate Bluetooth side: 1200 bps ~ 1843200 bps
IR side:1.2k, 2.4k, 4.8k, 9.6k, 19.2k, 38.4k, 57.6k and 115.2k bps
Configurable Parameters at Bluetooth
side Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow Control, COM Port, Device Name, Control Flag, PIN Code,
Master or Slave,
Watchdog Timeout,
Supervision Timeout,
BD Address
RF
Specifications
Frequency Band 2.400~2.4835 GHz unlicensed ISM band
Spectrum FHSS (Frequency Hopping Spread Spectrum)
Modulation GFSK
Output Power 4 dBm (typical)
Receiving Sensitivity -82 dBm (typical)
Power Class Class 2
Antenna Internal embedded
Range Up to 10 m (open-air)
LED Indicators Battery Low,Power & Connection Activities LED
Power 1. AAA size 1.5V x 4 batteries ; or
2. 7.5 V / 300 mA AC-DC power adapter
Physical
Dimensions &
Environment
Dimensions 76.5 x 48.5x 28.0 mm (3.01 x 1.91 x 1.10 in.) (L x W x H)
Weight 50 g (1.76 oz) without batteries
Operating / Storage
Temperature 0o C ~ 55o C (32o F ~ 131 o F)/-20
o C ~ 80o C (-4o F ~ 176o F)
Specifications could be changed without prior notice.
All trademarks, logos, organization & company names, and product model names are the
properties of the respective organizations or companies.
