ACTiSYS BT5711S User manual

BT5711S enables any RS232 devices with Bluetooth capability and
eliminates RS232 cable connections.This unit can be configured as a
Bluetooth Piconet or as a point-to-point RS232 cable replacement set.
It is an ideal wireless link solution for industrial, medical and commercial
applications which require freedom from cable connections.
It supports SPP profile as a Master or a Slave.It is battery powered in
addition to AC power or external power option. So user can use it in the
field application.
ACT-BT5711S
Bluetooth Serial (RS232)
Bluetooth Serial (RS232)
Intelligent Adapter,
Intelligent Adapter,
Battery Operated
Battery Operated
Application Scenario
Features and Benefits
BT5711S enables any devices with Bluetooth capability and eliminates RS232 cable connections.
Battery powered in additional to AC power or external power operation.
No Driver Required for Non-Windows Based Communication (Client) Devices.
Configurable as an RS232 Cable Replacement Set using external RJ45 to serial
cable.
Supports Class 2 Output Power Up to 10 m Operation Range (open air).
Bluetooth SIG 1.2 Compliant
Profile Supported: Serial Port Profile (SPP) as a Master or as a Slave
Baud Rate Supported: 1200 bps ~ 1843200 bps
Configurable for Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow
Control, BD Address, Device Name, Control Flag, PIN Code, Watchdog Timeout,
Supervision Timeout, and Peer BD Address (only used in Master)
Example of Cable Replacement application
Class II
Bluetooth enabled PC or PDA with
RS232 application program
Example of RS232 Piconet application

BCR01
Bluetooth RS232 Wireless Cable Solution
Bluetooth RS232 Wireless Cable Solution
ACT-BT5711S
Bluetooth Serial (RS232)
Bluetooth Serial (RS232)
Intelligent Adapter,
Intelligent Adapter,
Battery Operated
Battery Operated Class II
Specifications
Model No. ACT-BT5711S
Standard Bluetooth SIG 1.2
Bluetooth Profile Serial Port Profile (SPP) only
Chip Set RFMD
Baud Rate 1200 bps ~ 1843200 bps
Configurable Parameters Baud Rate, Data Bit, Parity Check, Stop Bit, RTS/CTS Flow Control,
COM Port, Device Name, Control Flag, PIN Code,
Master or Slave,
Watchdog Timeout,
Supervision Timeout,
BD Address
RF
Specifications
Frequency Band 2.400~2.4835 GHz unlicensed ISM band
Spectrum FHSS (Frequency Hopping Spread Spectrum)
Modulation GFSK
Output Power 4 dBm (typical)
Receiving Sensitivity -82 dBm (typical)
Power Class Class 2
Antenna Internal embedded
Range Up to 10 m (open-air)
LED Indicators Battery low, Power & Connection Activities LED
Power
1. AAA size 1.5V x 4 600mAh batteries
(Battery life: 10 hours running in active mode continuously); or
2. 7.5 V / 300 mA AC-DC power adapter (optional); or
3. +5~12V input through pin 9 of DB9M connector (optional).
Physical
Dimensions &
Environment
Dimensions 76.5 x 48.5x 28.0 mm (3.01 x 1.91 x 1.10 in.) (L x W x H)
Weight 50 g (1.76 oz) without batteries
Operating / Storage
Temperature 0o C ~ 55o C (32o F ~ 131o F)/-20
o C ~ 80o C (-4o F ~ 176o F)
Specifications subject to change without prior notice.
921 Corporate Way, Fremont, CA 94539
Tel: [phone], Fax: [phone]
E-mail: [email protected], http://www.actisys.com
