ACTIVE STATION ASD48-1A User manual

Electric Height Adjustable Desk
Models:
ASD48-1A
ASD48-1B
ASD72-1A
ASD72-1B
Desk frame assembly instructions

Inappropriate use of this product may cause injury.
Do not move around, crawl or lie under the desk frame
while operating. Do not sit or stand on the desk.
Check that cables have enough slack to move with the
frame.
This desk is designed for indoor use only. Avoid
excessive humidity environment.

Controller:
Input Voltage : AC 110V /220V Output Voltage: DC 24V
DutyCycle: Max.10%
Columns:
Desk frame part: Built-in limit switch
Dynamic load: 265lbs
The maximum static load: 310lbs
Load speed: 1.2in/s
Lift range: 25in-51in
Desk top:
Size: 30in deep X 48in or 72in wide
3/4in thick laminated on both sides
with vinyl edging
Gross Weight : 110lbs

Part drawing
(A) Legs 2PCS
Controller 1PC
M6X10 M8X10 M8X25
4PCS 12PCS 8PCS
Controller Bracket 1 PC
Brace 1PC
Motor wires 2PCS
Power cable 1PC
Switch 1PC
Connecting Plate
(B)
(C)
(D)

2: Connect horizontal frame pieces to legs
3: Install 2 feet pieces (B)
Lay 2 Long (C) and 2 Horizontal (D) tubes
on a flat surface as shown. Line screw
holes up and bolt tight using M8X10
locking bolts (6 per leg)
Bolt 2 leg pieces (B) to legs
using M8X25 bolts (4 per leg)

5: Install controller
6: Plug in 2 Motor cables, 1 console cable and power cable.
Console Instruction
Use 4M6X10 bolts to install the
controller bracket as shown. Slide
controller in bracket from side.
Push and hold to
lower desktop
Height display
Sets desk top to a
height of 29in
Preset memory height
buttons
Push and hold to
raise desktop

Console operation
1. Lightly touch up/down button and hold the key to rise and low the
desk height
2. Press HOME button to take the desktop to 29in height
3. Ml,M2 press and hold the key in 5 seconds (until beep sounds) to set
current position in memory. Press and quickly release at any time to
take desktop height to set position
4. Touch up or down button to turn console on if screen is off
