ACU-RITE 06058 User manual

Instruction Manual
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets:................ 4
Setup .................................... 7
Placement Guidelines ............. 8
Using the Weather Station...... 9
Expand the System................11
Troubleshooting ....................12
Care & Maintenance.............14
Specications........................14
FCC Information ...................14
Customer Support .................15
Warranty..............................15
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
[phone] or visit www.AcuRite.com.
Records
47
High Resolution
Weather Station Display
model 06058
This product requires an AcuRite 5-in-1 Weather Sensor
(sold separately) to be operational.

2
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LED screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display with Tabletop Stand
2. Power Adapter
3. Mounting Bracket
4. Instruction Manual
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

3
BACK OF DISPLAY
1. Plug-in for Power Adapter
2. Display Stand
3. Mounting Bracket
For easy wall mounting.
FRONT OF DISPLAY
4. Button
For menu access and setup
preferences.
5.
V
Button
For setup preferences and cycling
through messages on the Weather
Overview dashboard.
6. Button
Press to view a different dashboard.
7.
T
Button
For setup preferences and cycling
through messages on the Weather
Overview dashboard.
8. Button
For setup preferences.
Records
47
4 5 6 7 8
Features & Benets
Display
1
2
3

4
Records
47
Features & Benets
Weather Overview Dashboard
1
2
3
4
5
7
6
8
9
10
1218 1316 141514 1720
22 1921
11

5
1. Alarm ON Indicator
Indicates alarm is activated to emit an
audible alert when conditions exceed
your presets (see page 9).
2. Current Outdoor Humidity
Arrow icon indicates direction
humidity is trending.
3. Current “Feels Like” Temperature
4. Seasonal Information
Heat Index calculation displays when
temperature is 80°F (27°C) or higher.
Dew Point calculation displays when
temperature is 79°F (26°C) or lower.
Wind chill calculation displays when
temperature is 40°F (4°C) or lower.
5. Barometric Pressure
Arrow icon indicates direction
pressure is trending.
6. 12 to 24 Hour Weather Forecast
Self-Calibrating Forecasting pulls data
from your 5-in-1 sensor to generate
your personal forecast.
7. Clock
8. Date & Day of the Week
9. Rainfall Rate/Most Recent Rainfall
Displays rainfall rate of current
rain event, or total from the most
recent rainfall.
10. Rainfall History
Displays rainfall records for current
week, month & year.
11. Today’s Rain Indicator
Illustrates rainfall collection up to 2
inches (50 mm) once rain is detected.
12. Messages
Displays weather information and
messages (see page 14).
13. Peak Wind Speed
Highest speed from the last 60 minutes.
14. Previous 2 Wind Directions
15. Current Wind Speed
Background color changes based on
current wind speed.
16. Current Wind Direction
17. Average Wind Speed
Average wind speed over the past
2 minutes.
18. Sensor Low Battery Indicator
19. Outdoor High Temperature Record
Highest temperature recorded since
midnight.
20. Current Outdoor Temperature
Arrow indicates direction temperature
is trending.
21. Outdoor Low Temperature Record
Lowest temperature recorded since
midnight.
22. 5-in-1 Sensor Signal Strength

6
1. Current Indoor Temperature
Arrow indicates direction temperature
is trending.
2. Daily High & Low
Temperature Records
Highest and lowest temperature
recorded since midnight.
3. Daily High & Low
Humidity Records
Highest and lowest humidity recorded
since midnight.
4. Current Indoor Humidity
Arrow indicates direction humidity
is trending.
5. Humidity Level Indicator
Indicates a high, low or ideal
humidity comfort level.
Features & Benets
Indoor Overview Dashboard
1
2
4
5
3

7
Settings
After powering on for the rst time, the display will automatically enter setup
mode. Follow the on-screen instructions to set up the display.
To adjust the currently selected item, press and release the “T” or “
V
“
buttons.
To save your adjustments, press and release the “ ” button again to adjust
the next preference. The preference set order is as follows:
TIME ZONE (PST, MST, CST, EST, AST, HAST, NST, AKST)
AUTO DST (Daylight Saving Time YES or NO)*
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
PRESSURE UNITS (inHg or hPa)
TEMPERATURE UNITS (ºF or ºC)
WIND SPEED UNITS (mph, km/h, knots)
RAINFALL UNITS (inches or mm)
DISTANCE UNITS (miles or kilometers)
AUTO DIM (YES or NO)**
AUTO CYCLE (OFF, 15 sec., 30 sec., 60 sec., 2 min., 5 min.)
ALERT VOLUME
*If you live in an area that observes Daylight Saving Time, DST should be set to YES,
even if it is not currently Daylight Saving Time.
**For more information see page 12, under “Display”.
Enter setup mode at any time by pressing the “ ” button to access the menu,
then navigate to “Setup” and press and release the “ ” button.
Display Setup
Plug Power Adapter into Electrical Outlet
SETUP

8
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and the sensor are critical to the accuracy and
performance of this unit.
Display Placement
Place the display in a dry area free of dirt and dust. Display
stands upright for tabletop use and is wall-mountable.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct sunlight
and away from any heat sources or vents.
• Display and sensor(s) must be within 330 feet (100 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place units at least 3 feet (.9 m) away from
electronic devices (TV, computer, microwave, radio, etc.).
Records
47

9
Using the Weather Station
OPERATION
Menu
Records
Display
Sensor
Setup
Factory Reset
Units
Alarms
Calibrate
press to exit menu
15
26
37
4 8
Navigate to the main menu at any time by pressing the “ ” button. From the main
menu, you can view records, set alarms, setup an additional sensor and more.
1. Records
Access the “Records” sub-menu to view high and low values recorded
for each location by date and view trends for the sensor’s readings on a
graphic chart.
2. Alarms
Access the “Alarms” sub-menu to set and edit alarm values, including
temperature, humidity, wind speed and rainfall. The display also includes
an alarm clock feature (time alarm) and storm alarm (activated when
barometric pressure drops).
3. Setup
Access the “Setup” sub-menu to enter the initial setup process.
4. Display
Access the “Display” sub-menu to adjust display settings (brightness, contrast,
tint), display mode (screen cycle) and backlight (auto dim, sleep mode).
When auto dim mode is activated in display setup, the backlight automatically
dims the brightness based on the time of day. When “Sleep Mode” is
activated, the display automatically dims during the timeframe you choose
and shows only the most important readings for at-a-glance viewing.

10
5. Sensor
Access the “Sensor” sub-menu to add, remove or view information about
a sensor.
6. Units
Access the “Units” sub-menu to change measurement units for barometric
pressure, temperature, wind speed, rainfall and distance.
7. Calibrate
Access the “Calibrate” sub-menu to adjust display or sensor data. First,
select the display or sensor for which you wish to calibrate readings.
Second, select the reading you wish to calibrate. Lastly, follow the on-screen
prompts to adjust the value.
8. Factory Reset
Access the “Factory Reset” sub-menu to revert the display back to factory
defaults. Follow the on-screen prompts to perform the reset.
Weather Overview Dashboard
Weather Forecast
AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast
of weather conditions for the next 12 to 24 hours by collecting data from
a sensor in your backyard. It generates a forecast with pinpoint accuracy -
personalized for your exact location.
Self-Calibrating Forecasting uses a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the self-calibrated pressure is tuned in to your location and the
unit is ready for superior weather prediction.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day.
6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 15% brightness
Moon Phase
The moon phase is displayed between 7:00 p.m. to 5:59 a.m. when conditions
allow for moon visibility. The phases of the moon are conveyed through simple
lunar phase icons:
FULL
NEW WAXING
CRESCENT
WANING
CRESCENT
1ST
QUARTER
3RD
QUARTER
