ACU-RITE 06086 User manual

Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Wi-Fi Setup............................ 3
Features & Benets: Display.... 5
Setup .................................... 8
Display Setup ........................ 8
Placement Guidelines ............. 9
Set the Time, Date & Units .....10
Backlight Settings..................10
Using the Weather Center ..... 11
Programmable Alarms...........12
Troubleshooting ....................13
Care & Maintenance.............15
Specications........................16
FCC Information ...................16
Customer Support .................17
Warranty..............................17
Professional Weather Display
model 06086
Questions? Contact Customer Support at
www.AcuRite.com/support or email [e-mail]
This product requires an AcuRite 5-in-1 Weather Sensor
(sold separately) to be operational.

2
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display with Tabletop Stand
2. Power Adapter
3. Instruction Manual
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

3
Weather UndergroundTM is a commercial weather service providing real-time
weather information via the Internet. Weather UndergroundTM provides weather
reports for most major cities across the world on its website, as well as local
weather reports for newspapers and websites. Its information comes from the
National Weather Service, and over 250,000 personal weather stations.
About Weather UndergroundTM
Wi-Fi Setup for Weather UndergroundTM
This weather station features wireless Internet connectivity in order to connect
and send your data to Weather UndergroundTM. If you do not already have a
WU (Weather UndergroundTM) account, please create your account at
wunderground.com prior to the following Wi-Fi setup.
4. Open your web browser on the device that is connected to the AcuRite
display. Type "192.168.4.1" in the address bar and hit enter to access the
AcuRite Wi-Fi display settings website.
5. Enter or select your wireless network name, network password, and the
WU Station ID and Station Key (created in step 1).** Press "Save" to save
your credentials.
6. A Wi-Fi status message will appear conrming your connection to the dis
play. If the connection was not successful, please verify your credentials
and/or visit the Troubleshooting section (see page 13).
7. Once connected, data from your 5-in-1 sensor will automatically begin
to upload to Weather UndergroundTM. Monitor sensor data remotely at
www.wunderground.com or from a mobile device using the Weather
UndergroundTM app, available from the iOS App Store or Google Play Store.
*Wi-Fi setup page is available for 30 minutes after the display is powered on.
After 30 minutes, press and release the " " button to re-activate the setup
page.
** This weather station display only supports 2.4 GHz wireless networks
2. Power on the display (using included power cord).*
3. Connect to the Wi-Fi signal (named AcuRite 06086M) of the AcuRite
display from your computer or mobile device.
1. Add this weather station to your Weather UndergroundTM account:
Sign in to your Weather UndergroundTM account.
Navigate to My Prole > My Weather Stations > Add New PWS.
Enter all required location info.
When prompted for “Station Hardware”, select “AcuRite Pro Weather Center”.
You will be provided with a WU Station ID and Station Key
once you have submitted all required info (record for step 5, below).

4

5
7
DISPLAY BACK
1. Backlight Button
For momentary backlight and dimmer
settings.
2 . In tegrated Hang Holes
For easy wall mounting.
3. Backup Battery Compartment
4. A-B-C Switch
ID code that must match sensor’s A-B-C
switch to ensure units synchronize.
5. Plug-in for Power Adapter
6. Battery Compartment Cover
7. Power Adapter
8. RESET Button
Press and release to clear historical record.
Press and hold for 10 seconds for full reset
to factory defaults.
Features & Benets
4
3
2
5
1
6
8
DEVICE ID
############

6
Features & Benets
Display
1 2 4 567910 11 12
13 14 15 16 17 17
18 19 20 22 23 25
3
21 24
8

7
DISPLAY FRONT
1. Seasonal Display
Heat Index calculation displays
when temperature is 80°F (27°C)
or higher. Dew Point calculation
displays when temperature is
79°F (26°C) or below. Wind
chill calculation displays when
temperature is 40°F (4°C) or
lower.
2. Current Outdoor Temperature
Arrow icon indicates direction the
temperature is trending.
3. Sensor Low Battery Indicator
4. Current Outdoor Humidity
Arrow icon indicates the direction the
humidity is trending.
5. Outdoor Sensor Signal Strength
6. Current Wind Direction
7. Wind Speed
now: indicates current wind speed.
avg: indicates the average of all
speeds over the past 2 minutes.
peak: indicates the highest speed
form the last 60 minutes.
8. Icon
Indicates display is connected to your
wireless network.
9. Moon Phase
10. Current Rainfall
Rainfall recorded since 12:00 am.
11. Icon
Indicates an alarm value has
been activated.
12. Previous Rainfall Data
13. Current Barometric Pressure
14. 12 to 24 Hour Weather Forecast
Self-Calibrating Forecasting pulls
data from outdoor sensor to
generate your personal forecast.
15. Button
For viewing high and low records.
16. Icon
Indicates display is in auto-dimming
brightness mode (see page 9).
17. V and
V
Buttons
For setup preferences.
18. Clock
19. Date
20. Button
For setup preferences.
21. Display Low Battery Indicator
22. Button
For alarm setup.
23. Current Indoor Temperature
24. Humidity Level Indicator
Indicates a low, high or ideal humidity
comfort level.
25. Current Indoor Humidity
Arrow icon indicates the direction
the humidity is trending.
auto

8
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to
be used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of
used batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries
in re, as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT
recharge non-rechargeable batteries. DO NOT short-circuit the supply terminals.
SETUP
Display Setup
Install Backup
Batteries
3 AAA Batteries
(optional)
Plug in
Power Adapter
A B C A-B-C Switch
Set to match sensor's
ABC switch
IMPORTANT: Batteries are a backup power source to preserve records in the event of a
power outage. Power adapter is required as the primary power source to enjoy the full
functionality of this product.
Set the A-B-C Switch
Locate the A-B-C switch inside the
battery compartment. Set the A-B-C
switch to A, B or C. You must select
the same letter choices for both the
sensor and the display in order for
the units to synchronize.
Install or Replace Backup
Batteries (optional)
1. Remove the battery
compartment cover.
2. Insert 3 x AAA batteries into the
battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
Plug in Power Adapter
For the best performance, plug
in the power adapter as the main
power source for this product.
23
1
Display Setup

9
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and the sensor are critical to the accuracy and
performance of this unit.
Display Placement
Place the display in a dry area free of dirt and dust. Display
stands upright for tabletop use and is wall-mountable.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct sunlight
and away from any heat sources or vents.
• Display and sensor(s) must be within 330 feet (100 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place units at least 3 feet (.9 m) away from
electronic devices (TV, computer, microwave, radio, etc.).

10
AUTO DIM MODE: Automatically adjusts display brightness based on time of day.
6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 15% brightness
Display Backlight Settings
This weather station’s color display features three different lighting settings:
High (100%) brightness, Medium (60%) brightness and Low (15%) brightness.
When display is powered with the power adapter, backlight remains on at
100% brightness. Press the “ ” button once to dim to 60% brightness; press
again to dim to 15%, press a third time to enter AUTO-DIM mode. “ ” will
appear next to the clock.
NOTE: Pressing and holding the “ ” button for 5 seconds will disable the backlight.
Once any button is pressed, the backlight will return to your selected
setting.
Set the Time, Date & Units
Press the “ ” button, located on the front of the display, to enter SET MODE. Once in
set mode, the preference you are currently setting will blink on the display.
To adjust the currently selected (ashing) item, press and release the “
V
“ or
“
V
“ buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “ ” button to adjust the next
preference. The preference set order is as follows:
AUTO DST (ON or OFF)*
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºF or ºC)
WIND SPEED UNITS (mph, km/h, knots)
RAINFALL UNITS (inches or mm)
PRESSURE UNITS (inHg or hPa)
You will automatically exit SET MODE if no buttons are pressed for 8 seconds. Enter SET
MODE at any time by pressing and holding the “ ” button.
*If you live in an area that observes Daylight Saving Time, DST should be set
to ON, even if it is not currently Daylight Saving Time.
