ADA INSTRUMENTS GroundDrill - 14 User manual

Operating manual
Ground drill
Model: GroundDrill - 14 / GroundDrill - 14 Reverse
INSTRUMENTS

Reverse
GroundDrill-14
INSTRUMENTS
1. Introduction .......................................................................................................................................................................................3
2. Precautions..........................................................................................................................................................................................3
3. Features...............................................................................................................................................................................................5
4. Specications......................................................................................................................................................................................6
5. Preparation before operation.............................................................................................................................................................6
6. Operation ............................................................................................................................................................................................8
7. Stopping..............................................................................................................................................................................................9
8. Daily maintenance ............................................................................................................................................................................9
9. Long term storage............................................................................................................................................................................12
10. Warranty ..........................................................................................................................................................................................13
11. Exceptions from responsibility .......................................................................................................................................................13
Appendix 1. Warranty card
Appendix 2. Certicate of acceptance and sale
Table of contents

MEASUREMENT FOUNDATION
GroundDrill-14
INSTRUMENTS
3
1. Introduction
Power auger Ground Drill 14 is used for work with two operators. During operation seizure of the auger may occur and the equip ment
may rotate in reverse - that’s why both operators must be very careful during operation and know and follow all precautions and possi-
ble risks. Return stroke is partly reduced by the power auger structure. You should know how to use the instrument to avoid damages.
Options can be changed by the manufacturer without notice.
2. Precautions
Wear a long-sleeved shirt and long pants closed at the cuff.
Do not wear neck-tie or other loosely danging garments. Such articles may become entangled in the drill when working.
Wear protective goggles.
Wear helmet when working.
Wear work shoes equipped with no-slip tread.
Wear ear plugs to protect the ear drum from noise.
Do not work for long periods of time in summer and winter. Take breaks frequently.
Do not use the auger in the rain. The possibility of your slipping is increased when the ground is wet.
Do not use the auger indoors or in poorly ventilated places.
Do not smoke in the vicinity of the auger. This equipment runs on gasoline. Keep the equipment from ames and sparks.
Do not remove the gas cap or refuel while the engine is running or hot.
Wipe the auger body of any spilled gasoline after refueling.
Store fuel in approved containers and keep in a cool place.
CHECK BEFORE START-UP
Check all bolts and nuts are securely tight. Tighten where necessary.
Check the cutting blades to avoid chipping, cracking or bending. NEVER use a drill when damaged.

MEASUREMENT FOUNDATION
Reverse
GroundDrill-14
INSTRUMENTS
4
CAUTIONS DURING USAGE
Do not allow other persons within 5 meters of the worksite. IT IS DANGEROUS for pets and children to be near the equipment when
operating.
Be careful when drilling through rocky ground. This equipment may rotate in reverse and damage.
Work only in a stable position.
Be sure to stop the engine before allowing persons to approach within 5 m of the equipment.
Do not allow children or anyone who is unskilled in equipment usage to operate the equipment.
Never touch the drill bit when the engine is running. Be sure the engine is off and the drill has stopped rotating before handling.
Beware of the rotating drill bit.
Be sure the drill bit has stopped moving before placing on the ground.
When deep drilling, do not attempt to complete work in one stretch. Extract soil in 2 or 3 steps.
Before servicing the auger or making repairs, always stop the engine, remove the plug cap from the spark plug and allow the engine to
cool down.
Before storing the auger drain all remaining fuel and wipe the equipment clean of dirt and debris.
NEVER store the auger near live ames.

MEASUREMENT FOUNDATION
GroundDrill-14
INSTRUMENTS
5
1. Auger
2. Gas handle
3. Frame
4. Reduction gear
5. Engine
6. Engine switch
7. Fuel tank
8. Fuel tank cap
9. Fuel line
10. Air lter
11. Throttle lever
(air throttle)
12. Fuel-valve
13. Starter handle
14. Throttle cable
15. Frame handles
16. Reverse handle
3. Features
1
2
3
5
6
7
8910
11
12
13
14
15
4
GroundDrill-14
1
2
4
5
6
10
78
11
12
13
16
14
15 GroundDrill-14
Reverse

MEASUREMENT FOUNDATION
Reverse
GroundDrill-14
INSTRUMENTS
6
4. Specications
Engine type 4 stroke, air-cooled
Engine volume 172 cm³
Air-fuel mixture unleaded gasoline with a minimum of 92 octane
Ignition TCI
Power 8 HP
Carburetor Diaphragm type
Fuel tank capacity 3,6 L
Oil capacity in the engine 1,1 L
Lower
limit
Upper
limit
5. Preparation before operation
Handles must be placed on the frame in the following way: handle with gas handle must be located on the right side of the starter handle.
Place the screws into the holes of handles and frame. Fix them with nuts. Tighten the screws with the instrument from the complete set.
CONNECTION OF THE THROTTLE CABLE
Connect the throttle cable to the throttle level.
CONNECTION OF THE AUGER TO THE REDUCTION GEAR
Special construction of the reduction gear shaft allows to set augers with different diameters: 32 mm and 20 mm. Combine drive shaft
and shank end. Insert the shaft into the shank end. Fix the connection with the help of screw.
AUGER CHECKUP
1. Check availability of all parts. This goes especially for the spark plug.
2. Check the air intake and outlet for clogging.
3. The auger uses an air-cooled engine. If the air passage is blocked, the engine may overheat.
4. Check the air lter for dirt. A dirty air cleaner will cause the auger to burn excess fuel.

MEASUREMENT FOUNDATION
GroundDrill-14
INSTRUMENTS
7
THE LEVEL OF OIL IN THE ENGINE
Caution: Oil is a major factor affecting performance and service life. Use detergent
oil. It’s not recommended to use vegetable-based uid. Check the engine oil level
with the engine stopped and in a level position.
Note: SAE 10W-30 is recommended for general use. Use oil SAE Synthetic 5W-
30 when the average temperature in your area is within the recom mended range.
Check the engine with the engine stopped and in a level position.
1.Remove the oil ller cap/dipstick and wipe it clean.
2. Insert the oil ller cap/dipstick into the oil ller neck as shown, but do not screw
it in, then remove it to check the oil level.
3. Add the oil. If the oil level is near or below the lower limit mark on the dipstick.
Note: The Lubricating oil alarm system is used to prevent engine damage due to the
lack of lubricating oil in the crankcase. When the lubricating level of crankcase is
lower than the safety line, the alarm system will shut down the engine automatical-
ly (The engine switch is still in the ON position). If engine can’t start after stopping,
before check other problems, rst check the machine oil level.
THE LEVEL OF OIL IN THE GEAR CASE (for the model GD-14)
Check the level of the oil before running the engine. Check it via monitoring win-
dow. If the level is lower that required, remove the cap of the gear case ller neck
and add oil up to the red dot in the window (as shown in the picture). API GL-4/5
(Volume ~0.7 l. ) is recommended for general use.

MEASUREMENT FOUNDATION
8
Reverse
GroundDrill-14
INSTRUMENTS
FUEL
1. Remove the fuel tank cap and check fuel lever. If necessary add some fuel.
2. Use only motor gasoline (with a minimum of 92 octane or unleaded or low leaded gasoline).
Never use mixture of oil-fuel or sour gasoline. Avoid getting dirt or water in the fuel tank.
STARTING ENGINE
1. Turn main switch to ON.
2. Turn the choke valve switch to the OFF position. Attention: If the engine is very hot or the temperature is high, do not close the
choke valve.
3. Start the engine: turn the engine switch to the ON position, slowly pull the handle until there is sensation of resistance, and then
pull quickly and strongly.
Attention: Don’t loosen the handle suddenly in order to avoid rebounding and hitting the engine. You should replace it along the
direction of resilience force of starting.
6. Operation
Caution: Ground drill is designed for the operation with 1 (density 600...1600 kg/m3) and 2 ( density 1600... 1900 kg/m3) classes of
soil. Continuous working time of the ground drill with 1 class of soil (sand, clay sand, vegetable soil, peat) doesn’t exceed 5 min. Con-
tinuous working time of the ground drill with 2 class of soil (light loam, sand with crushed stone) is no more than 3 min. Recommended
interval between continuous usage is no less than 15 min with full stoppage of the engine. It’s forbidden to decline the ground drill from
the axis of drilling more than 3°. Excessive deviation can lead to the breakage of the gear case parts.
Never try to drill the hole on full depth of the auger bit. Drill step-by-step.
Excessive pressure on the ground drill can lead to the breakage of the gear case, overheating of the engine and its breakdown. Deep
the auger drill on 20-30 cm and raise it slightly in the hole. Remove earth from the auger bit. Don’t take out the whole rotating auger
bit from the hole. It can lead to the injury. Don’t speed up if the auger bit is jammed in the ground. It can lead to the breakage of the
gear-wheel of the gear case and the parts of the engine. Slow down the engine and disconnect it from the auger bit. Set the pivot of
appropriate diameter into the hole of pin – release the auger bit turning it back.

MEASUREMENT FOUNDATION
GroundDrill-14
INSTRUMENTS
9
1. Let engine warm for at least 1 min.
2. Press or release throttle lever to get desired rpms. If the engine reduce rpms on load, adjust the position of throttle lever.
Important! Do not work without workmate. Otherwise it can lead to the damages. Avoid running at high rpms for long periods. The
unit needs time for lubricant to get to all internal parts. Do not run the motor at high rpms without load.
THE SELECTION OF THE GEAR CASE ROTATION DIRECTION (for the model GD-14 Reverse)
The gear case of ADA GD-14 Reverse allows to change the rotation direction. Use the reverse function when drilling with auger bit of
big diameter from 300 mm and complicated grounds. Release gas handle when the auger bit is fully dipped into the earth. Then it is
necessary to stop drilling. Change the direction of rotation. Shift the handle for the reverse operation into the extreme position from the
engine. Press gas handle. At that slowly move the ground drill up. Use the reverse function for getting the auger bit out from the earth.
Never use the reverse function for drilling. Reverse handle must be in the extreme position towards the engine when drilling.
7. Stopping
1. Release throttle to idle speed.
2. Move main switch on/off to OFF.
Note: When storing for long periods, remove all fuel from the gas tank. Do not leave the gas tank at an angle. The pressure inside the
tank can cause the gas to spill out. The working parts of the engine can get very hot.
8. Daily maintenance
Make sure the engine is off before you begin any maintenance or repairs. To prevent accidental engine start disconnect spark plug cap.
Note: Check and adjust regularly the engine if you want to achieve high performance of it. Regularly maintenance extends engine life.
In the table below there is a maintenance schedule with regular service periods.

MEASUREMENT FOUNDATION
10
Reverse
GroundDrill-14
INSTRUMENTS
Elements to checkup/ period Before each use First month
or 5 Hrs.
Every 3 months
or 25 Hrs.
Every 6 months
or 50 Hrs.
Every 100 Hrs.
Oil check *
change * * *
Air lter check *
clean * * *
Spark plug check - clean *
Fuel tank and lter clean *
Fuel line check Every 2 years (Replace if necessary)
Note:
(1) Clean more often under dusty conditions or when airborne debris is present.
(2) Change engine oil every 25 hours when used under heavy load or in high ambient temperatures.
CHANGE ENGINE OIL
1. Drain the used oil while the engine is warm.
2. Remove the ller cap/dipstick, the drain bolt and sealing washer. Drain oil.
3. Reinstall the drain bolt and sealing washer, and tighten it securely.
4. With the engine in a level position, ll to the upper limit mark on the dipstick with the recommended oil. Check the oil level.
5. Reinstall the oil ller cap/dipstick securely.

MEASUREMENT FOUNDATION
11
GroundDrill-14
INSTRUMENTS
MAINTENANCE OF AIR FILTER
A dirty air lter will restrict air ow to the carburetor, reducing engine performance. If you operate the engine in very dusty areas, clean
the air lter more often than specied in the maintenance schedule.
a) Unscrew y-nut and remove the air lter cap. Detach the element;
b) Rinse the detail in the non-ammable solvent. Let it dry out.
c) Dip the detail into the clean engine oil to soak. Squeeze excessive oil. Otherwise the engine will smoke for some time when starting it.
d) Put the detail on its place.
Caution: Never use gasoline or other dissolvents to clean air lter. Ignition could result. Operating the engine without an air lter, or with
a damaged air lter, will allow dirt to enter the engine, causing rapid engine wear.
FUEL FILTER CLEANING
Caution: Gasoline and its vapors are extremely ammable and explosive. Fire or explosion can cause severe burns or death. Don’t smoke
on the worksite. Keep gasoline away from sparks, open ames, pilot lights, heat, and other ignition sources.
1. Remove fuel lter and fuel line.
2. Clean fuel lter (remove dirt from the grid of the lter and check the grid for damages).
SPARK PLUG SERVICE
Recommended spark plugs: F7RTC or other equivalents.
Caution: An incorrect spark plug can cause engine damage. Install spark plug with correct electrode gap. Avoid thing coating on it.
1. Remove the spark plug with a spark plug wrench.
Caution: Mufer is very hot during engine running. Be careful, don’t touch it until it gets cold.
2. Inspect the spark plug.
3. Replace it if the electrodes are worn, or if the insulator is cracked or chipped.

MEASUREMENT FOUNDATION
12
Reverse
GroundDrill-14
INSTRUMENTS
4. Measure the spark plug electrode gap with a suitable gauge. The gap should be 0.70 - 0.80 mm. Correct the gap, if necessary, by care-
fully bending the side electrode.
5. Install the spark plug carefully, by hand, to avoid cross-threading. Tighten the spark plug with a spark plug wrench.
Note: If installing a new spark plug, tighten 1/2 turn after the spark plug seats. If reinstalling the used spark plug, tighten 1/8 - 1/4 turn
after the spark plug seats.
Caution: A loose spark plug can overheat and damage the engine. Over tightening the spark plug can damage the threads in the cylinder head.
GEAR CASE SERVISE
For the model GD-14
Change the oil in the gear case every 100 hours of operation. Drain the oil from the gear case through the drain plug.
Do not drain oil on the ground.
For the model GD-14 Reverse
Add lubricating oil into the gear case and the mechanism of reverse operation every 100 h. Add 0.2-0.25 kg of lubricating oil of high
quality for the power transmission.
Add lubricating oil through the plug that is located on the reverse mechanism and on the gear case housing.
9. Long term storage
When storing for more than a month:
1. Remove a fuel from tank.
2. Run engine until it runs out of fuel.
3. Clean the inside of fuel tank and fuel lter with clean gasoline.
4. Remove the spark plug and put small amount of clean motor oil in the spark plug oil.
5. Pull the starter about 2 or 3 times, then stop pulling when the piston is at the top. Replace the plug.
6. Clean the external part of the motor with a cloth soaked in oil.
7. Store the motor in a dry place away from re and heat.

MEASUREMENT FOUNDATION
GroundDrill-14
INSTRUMENTS
13
Warranty
This product is warranted by the manufacturer to the original purchaser to be free from defects in material and workmanship under
normal use for a period of one (1) year from the date of purchase.
During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or similar model at
manufactures option), without charge for either parts of labour.
Warranty also applies to spare parts. In case of a defect please contact the dealer where you originally purchased this product. The
warranty will not apply to this product if it has been misused, abused or altered. Without limiting the foregoing, leakage of the bat-
tery, bending or dropping the unit are presumed to be defects resulting from misuse or abuse.
To get warranty support, apply service center: in full complete set; with warranty card; with rest of the fuel (no less 100 ml) in fuel tank.
The instrument must be clean. Service center can refuse warranty support in case of non-observance of these claims.
Exceptions from responsibility
The user of this product is expected to follow the instructions given in operators’ manual.
Although all instruments left our warehouse in perfect condition and adjustment the user is expected to carry out periodic checks of
the product’s accuracy and general performance.
The manufacturer, or its representatives, assumes no responsibility of results of a faulty or intentional usage or misuse including any
direct, indirect, consequential damage, and loss of prots.
The manufacturer, or its representatives, assumes no responsibility for consequential damage, and loss of prots by any disaster
(earthquake, storm, ood ...), re, accident, or an act of a third party and/or a usage in other than usual conditions.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of prots due to a change of data, loss
of data and interruption of business etc., caused by using the product or an unusable product.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of prots caused by usage other thsn
explained in the users’ manual.
The manufacturer, or its representatives, assumes no responsibility for damage caused by wrong movement or action due to connect-
ing with other products.

WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:
- damage to products or parts caused by misuse, including, without limitation, misapplication or nrgligence of the terms of service
instruction. Usage of expendable materials (oil, belts, lters, plugs|) that are not recommended by factory. Or if the instrument was
exposed to the self-dependent repair or disassembling during warranty period;
- the instrument that has damages, defects because of outer mechanical, thermal, chemical effects, unproper maintenance, storage or
acts of God;
- defects caused by reasons that are not depended on the manufacturer, such as usage of fuel that has inadmissible state standard, usage
of oil and mixture of inadmissible quality, and also voltage drop of power;
- instrument has damages caused by presence of any liquids and foreign objects inside the product. Ventiducts, fuel and oil holes are
clogged up;
- normal runout of the instrument, inner or outer clogging;
- the instrument is overload (continuous operation with max load) that leads to the breakage of piston-cylinder-unit;
- the instrument with breakage of piston-cylinder-unit because of continious operation at idle;
- damaged parts as a result of operation with unrepaired defects caused by service support, repair or modications by anyone other
than an authorized service center;
- periodic maintenance (cleaning, adjustment, lter replacement and so on);
- if the standard or serial product number will be changed, erased, removed or will be unreadable;
- parts: chains, lters, details of adhesion, cutters, disks, cords, driving belts, shock-absorbers, details of starter group, carbon brushes,
AC cables, pressure hoses, plugs, fuel lters, bearings, that don’t have visible defects and also life time of details that depends on
regular maintenance of the instrument.

WARRANTY CARD
Name and model of the product ________________________________________________
Serial number ________________date of sale_______________________
Name of commercial organization _____________________stamp of commercial organization
Warranty period for the instrument explotation is 12 months after the date of original retail purchase.
During this warranty period the owner of the product has the right for free repair of his instrument in case of manufacturing defects.
Warranty is valid only with original warranty card, fully and clear lled (stamp or mark of thr seller is obligatory).
Technical examination of instruments for fault identication which is under the warranty, is made only in the authorized service center.
In no event shall manufacturer be liable before the client for direct or consewuential damages, loss of prot or any other damage which
occur in the result of the instrument outage.
The product is received in the state of operability, without any visible damages, in full completeness. It is tested in my presence. I have no
complaints to the product quality. I am familiar with the conditions of qarranty service and i agree.
purchaser signature _______________________________
Before operating you should read service instruction!
If you have any questions about the warranty service and technical support contact seller of this product

Certicate of acceptance and sale
__________________________________________________________________________
__________________________________________________________________________
___________________________________________________________№_____________
name and model of the instrument
Corresponds to ______________________________________________________________
designation of standard and technical requirements
Data of issue _______________________________________________________________
Stamp of quality control department
Price
Sold ___________________________________ Date of sale ______________________
name of commercial establishment
Мотобур
Модель: GroundDrill - 14 / GroundDrill - 14 Reverse

Руководство по эксплуатации
Мотобур
Модель: GroundDrill - 14 / GroundDrill - 14 Reverse
INSTRUMENTS

Reverse
GroundDrill-14
INSTRUMENTS
1. Введение ............................................................................................................................................................................................19
2. Инструкция по безопасности ...........................................................................................................................................................19
3. Техническое описание .....................................................................................................................................................................21
4. Технические характеристики .........................................................................................................................................................22
5. Подготовка к работе .......................................................................................................................................................................22
6. Работа ..............................................................................................................................................................................................24
7. Конец работы...................................................................................................................................................................................25
8. Ежедневное техобслуживание ........................................................................................................................................................26
9. Подготовка к консервации ..............................................................................................................................................................29
10. Гарантия ........................................................................................................................................................................................30
11. Освобождение от ответственности .............................................................................................................................................30
Приложение 1. Гарантийный талон
Приложение 2. Свидетельство о приемке и продаже
Содержание

MEASUREMENT FOUNDATION
19
GroundDrill-14
INSTRUMENTS
1. Введение
Мотобур Ground Drill-14 предназначен для работы с двумя операторами. При работе возможно заклинивание шнекового бура
и обратный удар. Поэтому оба оператора должны быть внимательны во время работы и знать все правила безопасности и
возможные риски. Обратный удар, возможный при сверлении, частично гасится конструкцией мотобура. Вы должны уметь
использовать мотобур, чтобы избежать возможных травм.
Завод-изготовитель оставляет за собой право на изменение комплектации, внешнего вида изделия и модернизацию отдельных
узлов и деталей без уведомления пользователя.
2. Инструкция по безопасности
Надевайте одежду с длинными рукавами и длинные брюки с закрытыми отворотами.
Не надевайте галстук, шарфы, украшения или что-то подобное. Эти предметы могут намотаться на бур в процессе работы.
Используйте защитные очки.
Надевайте шлем во время работы.
Надевайте обувь с нескользящей подошвой.
Используйте защитные наушники для защиты от сильного шума.
Не работайте долгое время летом и зимой. Делайте перерывы в работе.
Не работайте в дождь. Так как поверхность земли влажная и вы можете подскользнуться.
Не работайте внутри помещения или в плохо проветриваемом помещении.
Не курите вблизи бура. Инструмент работает на бензине. Держите бур подальше от огня.
Не снимайте крышку топливного бака и не пытайте дозаправиться топливом, если бур работает или нагрет.
Если вы дозаправили бур, протрите поверхность от пролитого топлива.
Храните топливо во взрывобезопасных контейнерах в прохладном месте.

MEASUREMENT FOUNDATION
Reverse
GroundDrill-14
INSTRUMENTS
ПРОВЕРКА БУРА ПЕРЕД РАБОТОЙ
Проверьте все болты и гайки. Они должны быть плотно затянуты. При необходимости затяните болты.
Проверьте лезвие шнека на наличие изъянов, трещин, изгибов.
НИКОГДА не пользуйтесь буром, если лезвие шнека повреждено.
ПРЕДУПРЕЖДЕНИЯ ВО ВРЕМЯ ИСПОЛЬЗОВАНИЯ БУРА
Не позволяйте посторонним людям подходить менее, чем на 5м к рабочему месту. ОПАСНО для детей и животных находиться
около инструмента во время его работы.
Будьте осторожны при работе на каменистом грунте. Шнек может заклинить и бур может вырваться из рук и причинить
травмы.
При работе с буром операторы должны крепко стоять на ногах.
Заглушите двигатель, если к вам приближается посторонний человек.
Не позволяйте детям и не обученным людям работать с инструментом.
Не дотрагивайтесь до шнека при включенном двигателе. При транспортировке всегда выключайте двигатель и дождитесь, пока
шнек прекратит вращение.
Во время вращения шнека находитесь на безопасном расстоянии от него.
Перед тем, как бур положить на землю, убедитесь, что шнек прекратил вращаться.
Если вам необходимо глубоко пробурить землю, не пытайтесь это сделать за один раз. Сделайте это за 2-3 попытки.
Во время технического обслуживания или замены частей, заглушите двигатель, снимите колпачок свечи зажигания и дайте
двигателю охладиться.
Храните инструмент в чистом виде. Промойте бур от остатков топлива.
НИКОГДА не храните бур около огня.
