Adaptec 2126600 - DuoConnect For Notebooks 1422 User manual

R
Adaptec AUA-1422
DuoConnect for Notebooks
User’s Guide

i
Copyright
© 2004 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the
prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec and the Adaptec logo are trademarks of Adaptec, Inc., which may be
registered in some jurisdictions.
Windows 2000 and Windows XP are trademarks of Microsoft Corporation in the US
and other countries, used under license.
FireWire is a registered trademark of Apple Computer, Inc., used under license.
All other trademarks are the property of their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without
reservation and without notification to its users.
Disclaimer
IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE
PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID
VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER
REMEDIES.

ii
Adaptec Customer Support
If you have questions about installing or using your Adaptec product, check this
document first—you will find answers to most of your questions here. If you need
further assistance, use the support options listed below.
Technical Support Identification (TSID) Number
■Before contacting Technical Support, you need your unique 12-digit TSID
number. The TSID number identifies your product and support status.
■The TSID number is included on a white, bar-coded label, like the example
below.
Support Options
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for
articles, troubleshooting tips, and frequently asked questions for your product.
■For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask.adaptec.com.
■ To order Adaptec products, including accessories and cables, call [phone].
Or, you can order cables online at www.adaptec.com/buy-cables.
Europe
■Visit our Web site at www.adaptec-europe.com.
■German: Search the Adaptec Support Knowledgebase (ASK) at
ask-de.adaptec.com for articles, troubleshooting tips, and frequently asked
questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-de.adaptec.com.
■ French: Search the Adaptec Support Knowledgebase (ASK) at ask-fr.adaptec.com
for articles, troubleshooting tips, and frequently asked questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-fr.adaptec.com.
■ English: Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com
for articles, troubleshooting tips, and frequently asked questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask.adaptec.com.
■To order Adaptec products, including accessories and cables, go to
www.adaptec.com/buy-cables.
Japan
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.co.jp.
■Visit our Web site at www.adaptec.co.jp.

iii
Limited 5-Year Hardware Warranty
1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from
defects in material and workmanship for a period of five (5) years from the date of purchase.
If the product should become defective within the warranty period, Adaptec, at its option,
will repair or replace the product, or refund the purchaser’s purchase price for the product,

iv
Software License Agreement
PLEASE READ CAREFULLY: THE USE OF THIS SOFTWARE IS SUBJECT TO THE SOFTWARE
LICENSE TERMS OF ADAPTEC, INC. AND OTHER LICENSORS WHOSE SOFTWARE MAY
BE BUNDLED WITH THIS PRODUCT.
BY YOUR USE OF THE SOFTWARE INCLUDED WITH THIS PRODUCT YOU AGREE TO THE
LICENSE TERMS REQUIRED BY THE LICENSOR OF THAT SOFTWARE, AS SET FORTH
DURING THE INSTALLATION PROCESS. IF YOU DO NOT AGREE TO THE LICENSE
TERMS APPLICABLE TO THE SOFTWARE, YOU MAY RETURN THE ENTIRE UNUSED
PRODUCT FOR A FULL REFUND.
In return for acquiring a license to use the Adaptec software, which may include software from
third party licensors and patches made available by Adaptec (“Software”), and the related
documentation, you agree to the following terms and conditions:
1. License. This Agreement grants you, the Licensee, a license to:
a. Use the Software on a single computer system, which is not intended for use by more
than five (5) users; and:
b. Make one copy of the Software in machine readable form solely for back-up purposes,
provided you reproduce Adaptec's copyright proprietary legends. Notwithstanding the
foregoing, the Software may be used on the home, laptop or other secondary computer
of the principal user of the Software, and an additional copy of the Software may be
made to support such use. As used in this license, the Software is “in use” when it is
either loaded into RAM or installed on a hard disk or other permanent memory device.
The Software may be “in use” on only one computer at any given time. (Different license
terms and fees are applicable for networked or multiple user applications.) As a specific
condition of this license, you agree to use the Software in compliance with all applicable
laws, including copyright laws, and that you will not copy, transmit, perform or
distribute any audio or other content using the Software without obtaining all necessary
licenses or permissions from the owner of the content.
2. Restrictions. You may not distribute copies of the Software to others or electronically
transfer the Software from one computer to another over a network. You may not post or
otherwise make available the Software, or any portion thereof, in any form, on the Internet.
You may not use the Software in a computer service business, including in time sharing
applications. The Software contains trade secrets and, in order to protect them, you may not
decompile, reverse engineer, disassemble, or otherwise reduce the Software to a human-
perceivable form. YOU MAY NOT MODIFY, ADAPT, TRANSLATE, RENT, LEASE, LOAN,
RESELL FOR PROFIT, DISTRIBUTE, NETWORK OR CREATE DERIVATIVE WORKS
BASED UPON THE SOFTWARE OR ANY PART THEREOF.
3. Ownership of Software. As Licensee, you own the media upon which the software is
recorded or fixed, but Adaptec and its licensors retain title and ownership of the Software
recorded on the original media and all subsequent copies of the Software, regardless of the
form or media in which or on which the original and other copies may exist. This license is
not a sale of the Software or any copy.
4. Confidentiality. You agree to maintain the Software in confidence and that you will not
disclose the Software to any third party without the express written consent of Adaptec. You
further agree to take all reasonable precautions to preclude access of unauthorized persons
to the Software.
5. Term. This license is effective until January 1, 2045, unless terminated earlier. You may
terminate the license at any time by destroying the Software (including the related
documentation) together with all copies or modifications in any form. Adaptec will have the
right to terminate our license immediately if you fail to comply with any term or condition
of this Agreement. Upon any termination, including termination by you, you must destroy
the Software (including the related documentation), together with all copies or
modifications in any form.
6. Special Terms Applicable to Databases. Where a database is included with the Software, you
acknowledge that it is licensed only in connection with the use of the Software to perform
disc creation, and that the database and all data derived therefrom must be maintained in
confidence in accordance with the provisions of Section 4. This license does not grant you
any rights to distribute or disclose such database or data.

v
7. Limited Warranty. Adaptec and its Licensor warrant only that the media upon which the
Software is furnished will be free from defects in material or workmanship under normal
use and service for a period of thirty (30) days from the date of delivery to you. ADAPTEC
AND ITS LICENSORS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR
RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION. THE
FOREGOING STATES THE SOLE AND EXCLUSIVE REMEDIES ADAPTEC AND ITS
LICENSORS WILL PROVIDE FOR BREACH OF WARRANTY. EXCEPT FOR THE
FOREGOING LIMITED WARRANTY, ADAPTEC AND ITS LICENSORS MAKE NO
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED, AS TO
NON-INFRINGEMENT OF THIRD PARTY RIGHTS, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the above
limitations may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from state to state.
8. The entire liability of Adaptec and its licensors, and your exclusive remedy for a breach of
this warranty, shall be:
a. The replacement of any media not meeting the above limited warranty which is
returned to Adaptec; or:
b. if Adaptec or its distributor is unable to deliver replacement media which is free from
defects in materials or workmanship, you may terminate this Agreement by returning
the Software and your money will be refunded.
9. Limitation of Liability. IN NO EVENT WILL ADAPTEC OR ITS LICENSORS BE LIABLE TO
YOU FOR ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES,
INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR LOSS OF DATA, EVEN IF
ADAPTEC OR A LICENSOR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. Some states do not allow the
exclusion or limitation of special, incidental, or consequential damages, so the above
limitation or exclusion may not apply to you.
10. Export. You acknowledge that the laws and regulations of the United States and other
countries may restrict the export and re-export of the Software. You agree that you will not
export or re-export the Software or documentation in any form in violation of applicable
United States and foreign law.
11. Government Restricted Rights. The Software is subject to restricted rights as follows. If the
Software is acquired under the terms of a GSA contract: use, reproduction or disclosure is
subject to the restrictions set forth in the applicable ADP Schedule contract. If the Software is
acquired under the terms of a DoD or civilian agency contract, use, duplication or disclosure
by the Government is subject to the restrictions of this Agreement in accordance with
48 C.F.R. 12.212 of the Federal Acquisition Regulations and its successors and 49 C.F.R.
227.7202-1 of the DoD FAR Supplement and its successors.
12. General. You acknowledge that you have read this Agreement, understand it, and that by
using the Software you agree to be bound by its terms and conditions. You further agree that
it is the complete and exclusive statement of the agreement between Adaptec and you, and
supersedes any proposal or prior agreement, oral or written, and any other communication
between Adaptec and you relating to the subject matter of this Agreement. No additional or
any different terms will be enforceable against Adaptec unless Adaptec gives its express
consent, including an express waiver of the terms of this Agreement, in writing signed by an
officer of Adaptec. You assume full responsibility for the use of the Software and agree to
use the Software legally and responsibly. This Agreement shall be governed by California
law, except as to copyright matters, which are covered by Federal law. This Agreement is
deemed entered into at Milpitas, California by both parties. Should any provision of this
Agreement be declared unenforceable in any jurisdiction, then such provision shall be
deemed severable from this Agreement and shall not affect the remainder hereof. All rights
in the Software not specifically granted in this Agreement are reserved by Adaptec.
Should you have any questions concerning this Agreement, you may contact Adaptec by
writing to:
Adaptec, Inc.
Legal Department
691 South Milpitas Boulevard
Milpitas, California 95035

vi
Regulatory Compliance Statements
Federal Communications Commission Radio Frequency Interference Statement
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. However, if this
equipment does cause interference to radio or television equipment reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between equipment and receiver.
■Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
■Consult the dealer or an experienced radio/television technician for help.
■Use a shielded and properly grounded I/O cable and power cable to ensure compliance of
this unit to the specified limits of the rules.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept
any interference received, including interference that may cause undesired operation.
European Union Compliance Statement
This Information Technology Equipment has been tested and found to comply with
EMC Directive 89/336/EEC, as amended by 92/31/EEC and 93/68/EEC, in
accordance with:
■EN55022 (1998) Emissions
■EN55024 (1998) Immunity:
➐EN61000-4-2 (1998) Electrostatic discharge: ±4 kV contact, ±8 kV air
➐EN61000-4-3 (1998) Radiated immunity
➐EN61000-4-4 (1995) Electrical fast transients/burst: ±1 kV AC, ±0.5 kV I/O
➐EN61000-4-5 (1995) Surges ±1 kV differential mode, ±2 kV common mode
➐EN61000-4-6 (1996) Conducted immunity: 3 V
➐EN61000-4-11 (1994) Supply dips and variation: 30% and 100%
In addition, all equipment requiring U.L. listing has been found to comply with EMC
Directive 73/23/EEC as amended by 93/68/EEC in accordance with EN60950 with
amendments A1, A2, A3, A4, A11.
Canadian Compliance Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur
le matériel brouilleur du Canada.
Adaptec, Inc. AUA-1422
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE

1
In this Guide
This User’s Guide explains how to install your AUA-1422
DuoConnect for Notebooks adapter and its associated drivers,
describes how to connect your AUA-1422 DuoConnect for
Notebooks to a USB device and a digital video camera, and
contains an overview of USB and 1394 (FireWireTM) technology.
Kit Contents
Your Adaptec DuoConnect for Notebooks kit includes:
■Adaptec AUA-1422 DuoConnect for Notebooks adapter
■DuoConnect for Notebooks CD containing device drivers and
the DuoConnect for Notebooks User’s Guide
■Adaptec DuoConnect for Notebooks Installation Guide
Kit Contents 1
System Requirements 2
Installation Overview 2
Inserting the Adapter 3
Connecting Devices 12
Removing the Adapter 15
Troubleshooting 16
About USB Devices 17
About 1394 Technology 18

2
System Requirements
To use your DuoConnect for Notebooks adapter, you need a
PC-compatible notebook computer with:
■Pentium II processor or equivalent (400 MHz or faster)
■Microsoft Windows 2000®or Windows XP®
■Available CardBus slot
■CD-ROM or DVD-ROM drive
Installation Overview
You install your DuoConnect for Notebooks in three simple steps:
1Insert the DuoConnect for Notebooks adapter. (See page 3.)
2Install the device drivers. (See page 4.)
3Connect your devices. (See page 12.)

3
Inserting the Adapter
To successfully install your DuoConnect for Notebooks adapter:
1Power on your computer, if you haven’t already.
2Disconnect any devices that are connected to the adapter.
3Carefully insert the adapter into the CardBus slot of your
computer, as shown.
4Insert the DuoConnect for Notebooks CD into your CD-ROM
drive, if you haven’t done so already.

4
Installing the Device Drivers
The DuoConnect for Notebooks adapter contains two controllers,
one FireWire (IEEE 1394) controller and one USB 2.0 controller.
Device drivers must be installed for each controller.
Note: Depending on which Windows operating system you
have, the USB 1.1 and FireWire drivers may be installed
automatically (without user intervention).
When successfully installed, both controllers are displayed in the
Windows Device Manager.
Follow the instructions for your operating system:
■For Windows XP, see page 5.
■For Windows 2000, see page 8.
Controller
Type Number of Controllers Description
USB 2.0 1 Adaptec AUA-1422 CardBus USB Enhanced
Host Controller
FireWire 1 Texas Instruments OHCI-compliant IEEE 1394
Controller

5
Windows XP
When you insert your DuoConnect for Notebooks adapter,
Windows recognizes the new hardware and automatically opens
the Found New Hardware Wizard.
To complete both driver installations:
1Select Install the software automatically..., then click Next.
2Click
Finish .

6
3Select Install the software automatically..., then click Next.
4When the installation is complete, click Finish.
5If you are prompted to restart your computer, click Yes.

7
Verifying Driver Installation
To verify that the drivers are installed:
1Right-click the My Computer desktop icon, select Properties,
click the Hardware tab, then click the Device Manager button.
2
Expand IEEE 1394 Bus host controllers and Universal Serial Bus
controllers
and verify that the drivers called-out below appear.
USB 2.0 driver
FireWire driver

8
Windows 2000
When you insert your DuoConnect for Notebooks adapter,
Windows recognizes the new hardware and automatically opens
the Found New Hardware Wizard.
To complete the installation:
1Click Next.
2Select Search for a suitable driver..., then click Next.

9
3Select only CD-ROM drives, then click Next.
4Click Next.

10
5When the installation is complete, click Finish.
6Restart your computer if prompted to do so.

11
Verifying Driver Installation
To verify that the drivers are installed:
1Right-click the My Computer desktop icon, select Properties,
click the Hardware tab, and click the Device Manager button.
2Expand IEEE 1394 Bus host controllers and Universal Serial

12
Connecting Devices
You can connect standard USB 1.1 and high-speed USB 2.0 devices
to your DuoConnect for Notebooks adapter. To ensure proper
functioning, Adaptec recommends using only standard USB cables
with a maximum length of 6 feet (2 meters).
You can also connect FireWire devices to your DuoConnect for
Notebooks adapter, as discussed in Connecting Multiple Devices on
page 14. Use standard FireWire cables to connect your FireWire
devices.
High-quality USB and FireWire cables are available for sale on the
Adaptec Web site at www.adaptec.com.
External Power Source
You may need to connect an external power source to the
DuoConnect for Notebooks adapter if you are connecting it to
multiple USB and/or FireWire devices with varying power
requirements.
If necessary, use a UL-approved power supply rated at 12 Volts and
capable of 2.1 Amps, with connector size 3.5 mm outside/1.3 mm
inside diameter, 10 mm length. Refer to your device’s
documentation for other power requirements.

13
Connecting a Digital Video Camera
Two types of FireWire connectors are commonly used: a 4-pin and
a 6-pin. The DuoConnect for Notebooks adapter contains one 6-pin
and one 4-pin connector; digital video cameras use 4-pin
connectors. To connect a digital video camera to your DuoConnect
for Notebooks adapter, use a 6-to-4 pin FireWire cable.
To connect a digital video camera:
1Connect the 6-pin connector end of a FireWire cable to the
FireWire port on your DuoConnect for Notebooks adapter.
2Carefully insert the smaller, 4-pin connector end of the FireWire
cable into the FireWire port on your digital video camera.
Caution: Ensure that the connector and the port are properly
aligned to avoid bending and damaging the pins in the port.
