Fujitsu Stylistic CE CT2000 Series User manual

These instructions provide details on using the FPCCC51
bump case. This case is designed for use with your Stylistic®
CT2000 Series CE Tablet. The bump case provides added
protection when transporting, using, or storing the tablet.
Prior to installing your tablet in the bump case,
be sure to do the following:
• Install a screen protector on the screen. It is
difficult to install a screen protector once the
system is in the bump case.
• If you intend to use the system in the case,
remove the pen from the system holder and
insert it in the pen holder on the top front of
the case.
• Remove the covers from any of the ports
you intend to use.
INSTRUCTIONS
Bump Case
Installation Guide
FPCCC51
Fujitsu Computer Systems
Bump Case.fm Page 1 Tuesday, April 13, 2004 1:48 PM

2
Description
There are three flaps on the bump case. When the case is
held as shown in Figure 2, the flaps are on the left, right, and
bottom.
The left flap has a slot in it to allow access to the USB jack,
audio jack, and Compact Flash slot. The right flap can be
opened to remove and install a battery pack. Two openings
on the back of the case provide access to the battery release
latches. The top edge of the case has slots in it to allow access
to the PC Card slot and serial port.
Figure 1. Pen Tablet PC Bump Case - Rear
Velcro Strips (behind flaps)
Handstraps
D-RIngs (four places)
Top
Bottom
Bump Case.fm Page 2 Tuesday, April 13, 2004 1:48 PM

3
Installation
To install your tablet into the bump case, open the bottom
flap and either one of the side flaps. The flaps are secured by
Velcro® str ips (see Figure 1).
Slide the pen tablet into the case, with the display screen
facing the open window (see Figure 2). Reattach the flap(s)
on the bump case.
Hand straps
The bump case has two elasticized hand straps on the back
(see Figure 1). Insert your hand between the straps and the
case in whichever orientation is most comfortable for you.
Figure 2. Pen Tablet PC Bump Case - Front
Pen Holder
PWR
PWR
CLR
CLR
BKS
BKS
F1
F1
F2
F2
F3
F3
F4
F4
1
2
3
4
5
6
7
8
9
0
CLR
BS
F1 F2
F3 F4
ENT
Bump Case.fm Page 3 Tuesday, April 13, 2004 1:48 PM

4
Pen holder
When you have the tablet installed in the case, store the
tablet pen in the pen holder (Figure 2) to simplify access to it
when using the system.
Shoulder strap
To secure the shoulder strap, attach the strap clips to two of
the D-rings. The bump case can be carried vertically or hori-
zontally, depending on how you attach the clips.
Caring for the bump case
The bump case is made of rugged materials, and is designed
to withstand daily use. Treat the case as you would a brief-
case or purse. Occasionally, the bump case may become
soiled. To clean it, use a clean cloth and warm soapy water to
wash the soiled area.
