Adaptive Star AXIOM improv User manual
2 | P a g e
Frequently Asked Questions
Can I roller blade with my Axiom Push Chair?
We do not recommend this: it is just too easy to lose control and cause possible harm to
your passengers or yourself.
What if I break my Axiom Pushchair?
No problem! Just call us for help at 1-800-278-9626. We’ll get you back up and on the road in
no time.
Is the fabric on my Axiom Pushchair washable?
Yes! The seat, canopy, and basket are removable and machine washable in cold water with
mild detergent. After washing, place the seat back onto the pushchair for drying. Machine
drying is not recommended. Please remember to remove the seat panels before washing and
place them back on when finished drying.
Reminders
ALWAYS
use your safety wrist strap any time a passenger is in the Pushchair.
ALWAYS
attach wrist strap to the bottom of rear axle.
ALWAYS
engage rear foot brake when loading and unloading a passenger.
NEVER
leave a passenger unattended in or around the Pushchair.
NEVER
overload the Pushchair. Overloading the Pushchair may cause it to become unstable and tip over.
DO NOT
allow your passenger to stand in the pushchair. This may cause the pushchair to tip and cause
injury to the passenger, yourself, or others.
DO NOT
throw away the box that the chair came in until you are sure that everything is complete and in
working order. (See Warranty Section)
www.adaptivestar.com 1-800-278-9686
3 | P a g e
Your Axiom Pushchair is almost completely assembled when you receive it. The following short
series of instructions will help you through the final steps so you can get out and start having
fun!
Remove the Axiom from the box, cut all zip ties and unwrap all the component pieces. Please
keep your box until you are sure you are keeping your chair and have confirmed that the
content in the box matches the photo above. I you are missing something, please call 1-800-278-
9626 and talk with one of our helpful Technicians.
LETS GET STARTED!
To unfold the Axiom into its upright use position. Holding onto the adjustable handle and
placing your foot on the rear brake pull up on the handle while holding the rear brake down
with your foot. You will hear a click once it is secure.
Your Axiom Improv folds to a convenient size that will allow you to transport it in many
automobile trunks. However, if you require a more compact folded size, simply remove the
wheels.
www.adaptivestar.com 1-800-278-9686
4 | P a g e
To fold your Axiom, unfasten the front basket straps on the bottom of chair, unbutton
the seat anchor strap located under the release lever, and locate the primary folding
release lever located on the left side upright of the Axiom. Please squeeze one time
and release while pressing down gently on the handlebar.
To install or remove the rear wheels simply push the button on the outside of the
wheel and hold it in while either installing it into the AXIOM axle or removing it. Be
sure the rear foot brake is in the upright position when installing or removing the
wheels.
Inside of Rear
wheel
Outside of Rear
wheel
Big button on the quick release Axle
Folding
Release
Lever
Anchor
Strap
5 | P a g e
First unlock the rear brake by
Pulling the black loop upwards
Rear Wheel Installation
Next, push the
black button and
while holding it in.
Insert the wheel
axle all the way into
the pushchair
frame and release
the button.
Now repeat to
install
the other wheel.
Start by tipping
the push chair
backwards so
the fork
assembly is
pointing upward.
This will make it
easier to install
the wheel.
Front Wheel Installation
The front wheel is the
same as a bicycle. Place
the tire be-tween the
brake pads and orient your
wheel so that the flat
sections of the wheel axle
align with the slotted
metal fork tips and push
the wheel so that it seats
allthe way in the back of
the fork tip
Position the silver
lever straight out
from the
frame as shown.
Now tighten the
black knob on
the opposite side
of the lever until it
just starts to
become snug.
Now swing the lever
closed as shown here.
If you are unable to
swing
the lever completely
into the locked
position, open it back
straight out, loosen
the black knob
slightly, and close the
lever again.
Check to make
sure your wheels
are locked in
before each use.
6 | P a g e
Adjustable Height Handle
Your pushchair is equipped with a height adjustable handle. To
adjust the handle to best suit your comfort, simply press the
buttons located on the inside of the handle near the end of the
foam handle grip. Whileholding the buttons in, adjust the
handle up or down to the height that is correct for you. Once
there, release the buttons and the handle will
lock into place.
Wrist Strap
www.adaptivestar.com 1-800-278-9686
Your Axiom pushchair is equipped with a safety wrist strap which you should always use when
there is a passenger loaded. The wrist strap is the link between you and the pushchair and keeps
the pushchair from rolling away out of your control by accident. Never leave a passenger
unattended in the pushchair. The wrist strap is constructed with loops on each end. The wrist
strap should be attached to the pushchair at the frame member that runs between the rear
wheels, by looping around it, and inserting the one loop end through the other loop, pulling it
tight. The loop may now be wrapped around your wrist attaching you to the push chair.
NEVER attach the wrist strap to the
adjustable handle.
Never attach the wrist strap to an
animal
www.adaptivestar.com
1-800-278-9626
Adjustments
Front Brake Adjustment
The front brake on your Axiom pushchair may require periodic
adjustment. By turning the adjusting barrel, indicated by the red arrow,
outward it will cause the brake pads to move closer to the front wheel.
There is a similar adjuster located underneath the pushchair, near the
front wheel, on the brake caliper itself. This caliper style brake system is
the same as on a bicycle, and if you require more detailed assistance, a
local bicycle show will be able to provide it for you.
Tracking
If your pushchair is pulling to the left or right while using the fix front
wheel, check to see if it is one of the following: Tire pressure, check to
see if all 3 tires are fully inflated.
Be sure that the front wheel hasn’t been installed too tight. Release
the QR lever, push the front wheel all the way back into the fork tips
and when closing the lever make sure that it is only snug, not HE-MAN
tight. If it is, loosen the thumb nut on the other side and close the
lever. You may have to make several small adjustments until the lever
closes snuggly.
Seat Recline
To recline the seat, simply slide the two straps behind the seat. To put
the seat back to the upright position, pull the webbing taut until in the
upright position.
Tire Pressure
If your tire pressure is low the PSI is located on the side of the tire. A
large difference can cause pulling to one side.
Braking system
Your pushchair is equipped with a brake for the front wheel and a brake
for the rear wheels.
The front wheel brake ONLY works with the standard front wheel, It
WILL NOT work with the accessory swivel wheel axis kit.
The rear brake works by pushing down on the back bar with the look
that runs between the rear wheels. It will lock into the black toothed
hubs on the rear wheels.
8 | P a g e
Pull up the webbing through the seat and up on the shoulder harness area.
Place the passenger in the seat.
Adjust the padded center strap forward or backward to fit your passenger.
Adjust the padded shoulder harness up or down on the Velcro strips to fit your passenger.
Buckle the
two buckles to the padded center strap.
Pull the adjustment strap until the padded center strap and the padded shoulder harness are both snug.Adjust
the chest strap to a comfortable length and connect the buckles.
If the harness is too small for the passenger harness extensions are available for purchase.
Always check that the seat anchor straps are attached properly before each use.
Harness Adjustment
You will want to do a onetime general positioning of the harness before placing the passenger in the
seat. Once the passenger is in the seat then do the final harness adjustments as follows:
Undo both the buckles from
the padded center pelvic
strap.
Push up the black cam buckle located between
the passenger’s knees and pull the webbing out
the end. Once it is at the desired length flip the
cam buckle down to secure it into place.
Cam
buckle
up:
Cam
buckle
Down:
Please visit our YouTube
channel Adaptive Star
Mobility, to see our
instruction Videos.
www.adaptivestar.com
1-800-278-9626
Maintenance
We recommend that you have an experienced dealer perform these maintenance check at least once each
year. Lubricationof thesefollowingitemsisnecessary:
•
Pivot point and cable of hand brake
•
Pivot point and cable of brake caliper
•
Front wheel axle
•
Front wheel quick release lever
•
Insert in frame for rear wheels
•
Wheel hub and bearings of rear wheels
•
Locking bars of folding mechanism
•
All folding joints of pushchair
Check to make sure all the bolts are tight and that springs are secure on the rear foot brake.Check
fabric seams and straps for fraying and tearing.
Keep pushchair out of the sun and in a dry place when not in use, to prevent mold and mildew.Check
the frame for loose rivets, cracks, and wear.
Check to make sure all nuts and bolts are tight on the frame.
We recommend that you put a rust preventative type coating on your wheels, nuts, bolts, brake springs and
brake caliper on your pushchair. These parts can also be maintained by cleaning with a damp cloth
and
keepingthese parts dry and free from debris.
The tires on your pushchair are a standard bicycle size and have an inner tube. If one of your tires will not
hold air, the inner tube can be replaced and both tires and inner tubes can be found at
professional bicycle
storesandmostmajorretailers.
The front brake uses a standard bicycle style caliper and brake pad. If replacement brake pads are need- ed,
they can be found at professional bicycle stores and most major retailers.
10 | P a g e
WARRANTY CARD
Thank you for purchasing an Adaptive Star Indoor/Outdoor Mobility Push Chair. We have created a warranty that
will keep your unit in top condition and headache free. The following warranty is on workmanship and materials
from the date of original consumer purchase:
•A 5-year warranty on the frame.
•A 1-year warranty on parts and soft goods. Exclusions include
oParts that require replacement under normal use.
oDamage or malfunctions caused by negligence or abuse
oFoam grips, inner tubes, tires, and brake pads are specifically excluded.
Adaptive Star will, at its option, repair or replace defective parts upon delivery to our service center
accompanied by proof of date of first consumer purchase, such as a copy of a sales receipt. Please refer to the
store where you made your purchase for returns and refunds as Adaptive Star does not give direct refunds.
Purchaser is responsible for initial shipping charges required to ship the product for warranty service. Purchaser
is also responsible for all applicable duties and/or custom charges. The return charges will be at Adaptive Stars
expense. Please include your name, address, telephone number, email address and a brief description of the
problem. Adaptive Star does not accept delivery of any product without a Return Authorization# clearly marked
on the return shipment box and shipping label.
All implied warranties, including warranties of merchantability and fitness for a particular purpose are limited in
duration to the length of this warranty. Adaptive Star will not be liable for any incidental, consequential, or other
damages, including, without limitation, damages resulting from loss of use. Always keep the box the chair came
in until you know the chair is complete in working order. In the event of UPS damage call them so that a driver
can come out and inspect the package. A claim cannot be file without the box the chai came in. Some states do
not allow limitation on ow long a implied warranty last and/or do not allow the exclusions or limitations of
incidental or consequential damages, so the about limitations my not apply to you. This limited warranty gives
you specific legal rights, and you may also have other rights, which vary from state to state.
Please complete product warranty on our website. For any helpful hits or video instructions, please visit our
YouTube channel.
