Generally speaking, when making connections to the loudspeakers from the amplifier, it is
very important to use the correct type and size of wire in order to avoid unnecessary loss of
amplifier power in the cable, reduction of amplifier damping factor (DF) and other
undesirable conditions. For runs up to 12 feet, ordinary "zip" or lamp cord, made of AWG18
stranded wire and available in a variety of insulation colors may be used. For runs up to 40
feet, AWG16 stranded wire should be used to prevent power losses. For lengths over 40 feet
and not exceeding 60 feet, use AWG14 stranded wire only. Runs exceeding 60 feet require
the use of heavier conductors such as AWG12 stranded wire. If you find it difficult to obtain
the correct-size wire for your specific connecting length, you can parallel two runs of the next
smaller gauge of wire to keep wire resistance at a minimum. For example, if you require a
run of 35 feet to your loudspeakers and AWG16 wire is not readily available, you can parallel
two 35-foot lengths of identical AWG18 stranded wire for use with each speaker (you'll
require a total of four 35-foot lengths in such an instance) and solder the two conductors of
each wire making up each double cable, at both the speaker and amplifier ends, to insure
good electrical and mechanical connections of the conductors.
Regardless of the cables you select to connect your loudspeakers, there are some other
requirements which you should observe in order to insure maximum performance from your
amplifier. It is most important that you make certain the wiring you have selected has as
Iower capacitance as possible. All amplifiers, particularly wide-bandwidth audio amplifiers,
are susceptible to the capacitance cables present to their outputs at extremely high
frequencies. This capacitance, in conjunction with the inductance of the wire itself and the
reactive load of the loudspeakers, can create anomalies at ultrasonic frequencies which,
although inaudible, can affect performance in the audible range.
There are different ways to connect the wiring to the RIGHT/LEFT STEREO SPEAKER
OUTPUTS. The methods used will depend on the specific type of connectors supplied with
the loudspeakers, the speaker cables, etc. As a matter of course, we prefer to use double
banana plugs because it is generally the most secure method of connection. Also, the
plated-bronze springs of the banana plugs effect a self-cleaning action which insures the
best contacts between the binding posts and the connectors themselves. There are
"sockets" provided in the center of the binding posts' studs which permit secure seating of
the banana plugs. Make certain, however, that the round head of the binding post is securely
tightened before inserting the banana plugs firmly into the binding posts' sockets.
Additionally, when connecting the cables to the amplifier and loudspeakers, it is important
that you "tin" the wires with good solder (preferably high-silver-content solder) in order to
