ADDAC System ADDAC604 User manual

September.2020
ADDAC604 Assembly Guide
ADDAC SYSTEM page 2

ADDAC SYSTEM page 3
STEP 1:
Start by separating the pcbs and trim the excess material with cutting pliers like shown below.
ADDAC604 Assembly Guide

ADDAC SYSTEM page 4
STEP 2:
Next locate the 3 pin male and female pinheaders and use a pliers to remove the middle pin like shown
below.
STEP 3:
Locate the remaining pinheaders and place them like shown below.
Then proceed to solder all pins on both boards.
ADDAC604 Assembly Guide

ADDAC SYSTEM
STEP 4:
Next locate and solder the 2x5 power connector, notice the hole orientation marking on the pcb.
page 5
STEP 5:
Proceed by placing the spacer.
ADDAC604 Assembly Guide

STEP 6:
Next locate all 6 plastic shaft trim pots and flatten out their legs with the help of some pliers, like
shown below.
ADDAC SYSTEM page 6
ADDAC604 Assembly Guide

ADDAC SYSTEM
STEP 7:
Next place all parts in the pcb.
All pots are B103 but notice that 2 of them have the MID STOP indent.
Once all parts are in the pcb proceed to place the front panel, tighten the nuts and then solder all pads.
MID STOP
POTS
page 7
ADDAC604 Assembly Guide

ADDAC SYSTEM page 8
STEP 8:
Next solder the jumper pinheader,
start by trimming the pot pad with a cutter then solder the pinheader.
finish by removing the black plastic and trim the excess pin length
ADDAC604 Assembly Guide

ADDAC SYSTEM page 9
STEP 9:
Place the bottom screw.
ADDAC604 Assembly Guide

ADDAC SYSTEM page 10
Congratulations you’re all done!
Happy patching!
ADDAC604 Assembly Guide

For feedback, comments or problems please contact us at:
[email protected]
ADDAC604 ASSEMBLY GUIDE
September.2020Revision.01
