HRT LineStreamer+ User manual
LineStreamer +
High Performance external USB sound card
High Resolution Technologies is proud to offer the LineStreamer +, the product for tomorrow, available today.
Everyone deserves great sound!
Specification
Electrical
Full Scale Sensitivity
Input Impedance
Frequency Response (20 Hz / 20 kHz)
S/N Ratio (DC to 30 kHz)
S/N Ratio (A-weighted)
THD+N (1 kHz Full Scale)
THD+N (1kHz -20 dB)
Jitter contribution (DC to 30 kHz)
Indicators
Interface
Sample Rate
Bit Depth
USB transfer protocol
Power Requirements (bus powered)
Dimensions
LineStreamer +
2.25 Volts RMS
5k Ohm
+0 / -.4 dB
104 dB
109 dB
.003%
.001%
> 130 dB below full scale
peak, sample rate & mute
up to 96 kHz
24 bit
asynchronous
450 mA
2.9” x 2.4” x 5.8”
The LineStreamer + is a high performance external sound card that connects
between a computer and any line level analog source. USB connected and
powered, the LineStreamer + is simple to use and allows anyone to digitize any
analog source at a level of qualtiy previously available only to the elite
professional.
With its high performance asynchronous USB transceiver and ultra high
performance 24 bit analog to digital converter, the LineStreamer + is a complete
single box solution. All power requirements for the LineStreamer + are supplied
from the USB cable, operation is simple, just plug into any available USB port
and in a matter of seconds, you will be ready to start recording.
With its jitter free interface, the LineStreamer + will transform your computer
into a professional quality digital audio recorder. Utilizing native Audio Class
1.0 drivers (present in all modern PC, Mac & Linux computers) there are no
drivers nor software to install. Simply connect it to your computer via a USB
cable, select the LineStreamer + and you are ready to go.
LED indicators show the current sample rate (32k, 44k1, 48k, 88k2 & 96k) as well as the state of the mute circuit. On the input end of the
LineSteamer + a pair of peak indicators are provided so you can monitor the recording level to obtain perfect results. High Resolution Technologies’
UpStream utility allows the LineStreamer + firmware to be updated right from the computer’s desktop in a matter of seconds.
High Resolution Technologies LineStreamer +, designed and manufactured in Southern California.
ultra low noise
& distortion
