AdDent CoMax User manual

OPERATION AND FIRST TIME USE
The CoMax Composite Dispenser is intended for use with most standard composite
compules. Insert the compule by pulling back on the front ange. (See Fig.1on
reverse side)
Release the ange to keep compule in place. Place 4 ngers on trigger and pull back
to express composite. (See Fig.2 on reverse side)
To remove compule, pull back on ange and compule will drop out by itself. (No need
to touch compule, see Fig. 3 on reverse side)
OPERATION AND FIRST TIME USE
The CoMax Composite Dispenser is intended for use with most standard composite
compules. Insert the compule by pulling back on the front ange. (See Fig.1on r
everse side)
Release the ange to keep compule in place. Place 4 ngers on trigger and pull back
to express composite. (See Fig.2 on reverse side)
To remove compule, pull back on ange and compule will drop out by itself. (No need
to touch compule, see Fig. 3 on reverse side)
Safety Precautions
Before expressing composite, always ensure that the compule is fully seated
in the barrel and secured with the spring loaded collar.
Always ensure that your brand and style of compule is compatible with the
CoMax. Test compatibility by expressing material onto a pad or tabletop
prior to patient use.
Safety Precautions
Before expressing composite, always ensure that the compule is fully seated
in the barrel and secured with the spring loaded collar.
Always ensure that your brand and style of compule is compatible with the
CoMax. Test compatibility by expressing material onto a pad or tabletop
prior to patient use.
INSTRUCTIONS FOR USE INSTRUCTIONS FOR USE
! !
! !
Cleaning and Sterilization
The CoMax Composite Dispenser may be autoclaved in a steam autoclave.
It is not recommended that it be chemclaved. It may also be wiped down
with a disinfectant such as CaviCide®, Envirocide®or Cidex®.
DO NOT SOAK THE COMAX DISPENSER IN DISINFECTANT SOLUTION.
Cleaning and Sterilization
The CoMax Composite Dispenser may be autoclaved in a steam autoclave.
It is not recommended that it be chemclaved. It may also be wiped down
with a disinfectant such as CaviCide®, Envirocide®or Cidex®.
DO NOT SOAK THE COMAX DISPENSER IN DISINFECTANT SOLUTION.
WARRANTY
The CoMax Composite Dispenser has a warranty for a period of 2 years. For a
no cost extended warranty register at www.addent.com.
REPLACEMENT PARTS
There are no replacement parts.
PN 120000 CoMax Composite Dispenser
WARRANTY
The CoMax Composite Dispenser has a warranty for a period of 2 years. For a
no cost extended warranty register at www.addent.com.
REPLACEMENT PARTS
There are no replacement parts.
PN 120000 CoMax Composite Dispenser

Figure 1
Loading the compule into
the CoMax dispenser
Figure 1
Loading the compule into
the CoMax dispenser
MANUFACTURER
AdDent, Inc.
43 Miry Brook Road, Danbury CT 06810
Phone: [phone], Fax: [phone]
Email: [email protected]
Website: www.addent.com
MANUFACTURER
AdDent, Inc.
43 Miry Brook Road, Danbury CT 06810
Phone: [phone], Fax: [phone]
Email: [email protected]
Website: www.addent.com
P/N 660104 REV D 5/2017 P/N 660104 REV D 5/2017
ISO CERTIFIED ISO CERTIFIED
Figure 3
Removing the used
compule from the
CoMax dispenser
Figure 3
Removing the used
compule from the
CoMax dispenser
Figure 2
Holding the CoMax
to express composite
Figure 2
Holding the CoMax
to express composite
Trigger Trigger
Flange Flange
