ADEMCO AlarmDecoder AD2 User manual

PLEASE READ THIS LICENSE AGREEMENT CAREFULLY
This license governs use of he accompanying firmware. If you use he device, you accep his license. If you do
no accep he license, do no use he device.
The embedded devices firmware ("Sof ware") is licensed, no sold, o you by Nu Tech Sof ware Solu ions, Inc. ("Nu
Tech Sof ware Solu ions") for use only under he erms of his License, and Nu Tech Sof ware Solu ions reserves
any righ s no expressly gran ed o you. You own he device on which he Sof ware is s ored, bu Nu Tech Sof ware
Solu ions, i s licensors and sub-licensors re ain ownership of he Sof ware i self.
1. Defini ions
The erms "reproduce," "reproduc ion" and "dis ribu ion" have he same meaning here as under U.S. copyrigh law.
"You" means he licensee of he sof ware. "Your company" means he company you worked for when you
downloaded he sof ware. "Reference use" means use of he sof ware by you or wi hin your company as a
reference, for he sole purposes of developing your produc , debugging your produc s, main aining your produc s,
or enhancing he in eroperabili y of your produc s wi h he sof ware, and specifically excludes he righ o
dis ribu e he sof ware ou side of your company or o any hird par y.
2. Gran of Righ s
(A) Copyrigh Gran - Subjec o he following erms and condi ions, Nu Tech Sof ware Solu ions gran s o he end
user (“You”) a non-exclusive, non- ransferable, fully paid and royal y-free license, wi hou he righ of sublicense, o
use he Produc solely in he form of he binary firmware image provided, only o he ex en necessary o use he
AD2USB hardware. No wi hs anding he foregoing, his License does no apply o he source code or objec code
of he Produc . This license is no a sale. You may no ren , lease, or lend he Produc . Nu Tech Sof ware Solu ions
may cancel his LICENSE if you do no abide by i s erms and condi ions. This LICENSE applies o upda es or
supplemen s o he original Produc , unless we provide o her erms along wi h he upda e or supplemen .
RESERVATION OF RIGHTS. Nu Tech Sof ware Solu ions reserves all righ s no expressly gr an ed o you in
his LICENSE. Ti le and copyrigh s o he Produc remain wi h Nu Tech Sof ware Solu ions.
3. Limi a ions
(A) No Trademark License- This license does no gran you any righ s o use he Licensor’s name, logo, or
rademarks.
(B) If you begin pa en li iga ion agains he Licensor over pa en s ha you hink may apply o he sof ware
(including a cross-claim or coun erclaim in a lawsui ), your license o he sof ware ends au oma ically.
(C) LIMITATION ON REVERSE ENGINEERING, DECOMPILATION, AND DISASSEMBLY. You may no reverse engineer,
decompile, or disassemble he Produc . You may no copy he Produc or ransfer i o o her devices wi hou he
express prior wri en consen of Nu Tech Sof ware. No wi hs anding any prior agreemen you may have wi h Nu
Tech Sof ware.
(D) The sof ware is licensed "as-is." You bear he risk of using i . In no even will Nu Tech Sof ware Solu ions, i s
paren or subsidiaries or any of he licensors or sub-licensors, direc ors, officers, employees or affilia es of any of
he foregoing be liable o you for any consequen ial, inciden al, indirec or special damages wha soever (including,
wi hou limi a ion, damages for loss of business profi s, business in errup ion, loss of business informa ion and he
like), whe her foreseeable or or unforeseeable, arising ou of he use of or inabili y o use he Sof ware or
accompanying wri en ma erials, regardless of he basis of he claim and even if Nu Tech Sof ware Solu ions or a
Nu Tech Sof ware Solu ions represen a ive has been advised of he possibili y of such damage. Nu Tech Sof ware
Solu ions' liabili y o you for direc damages for any cause wha soever, and regardless of he form of he ac ion,
will be limi ed o replacemen of he Sof ware ha caused he damages. THE LIMITATION WILL NOT APPLY IN
CASE OF PERSONAL INJURY ONLY WHERE AND TO THE EXTENT THAT APPLICABLE LAW REQUIRES SUCH
LIABILITY. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
4. General
(A) This License will be cons rued under he laws of he S a e of Oregon. If any provision of his License shall be
held by a cour of compe en jurisdic ion o be con rary o law, ha provision will be enforced o he maximum
ex en permissible, and he remaining provisions of his License will remain in full force and effec . If you are a
U.S. Governmen user, hen he Sof ware is provided wi h " RESTRICTED RIGHTS" as se for h in subparagraphs (c)
(1) and (2) of he Commercial Compu er Sof ware-Res ric ed Righ s clause a FAR 52.227-19 or subparagraph (c)(1)
(ii) of he Righ s in Technical Da a and Compu er Sof ware clause a DFARS 252.277-7013, as applicable.
Manufac urer: Nu Tech Sof ware Solu ions, 11575 SW Pacific HWY, Sui e 109, Tigard, Oregon 97223
5. Termina ion
(A) This License is effec ive un il ermina ed. This License will ermina e immedia ely wi hou no ice from Nu Tech
Sof ware Solu ions or judicial resolu ion if you fail o comply wi h any provision of his license. Upon such
ermina ion you mus des roy he Sof ware, all accompanying wri en ma erials and all copies hereof, and
Sec ions 3, and 4 will survive any ermina ion.
AlarmDecoder (AD2) Install Guide v2.5
Ademco Vista and DSC Power Series Alarm to Computer interface adapter
Video Install Tutorials are available on our website at
http://www.alarmdecoder.com
Before you start...
Please take a moment and read this manual before you install the AD2 to
your alarm panel. Rushing into the install of devices like this can
result in damage to the device or accidental activation of your alarm and
alerting of your alarm company.
Please use caution when using this device. You should notify your
monitoring company you are testing your alarm prior to installing this
device or when testing with this device.
Introduction
Thanks for purchasing the AlarmDecoder adapter. The AD2 device was
designed to work with a wide range of Ademco Vista as well as the DSC
Power Series alarm panels.
The device has different connection options including RS232 Serial, USB
serial and 5v or 3.3v uP compatible TTL serial. The AD2USB and AD2Pi
serial settings are 115200,n,8,1 and for AD2Serial the baud is 19200. On
some models it is also possible to adjust the baud rate via a jumper
setting.
Drivers (AD2USB Only)
If you are running windows you can get the Virtual COM port drivers
from FTDI http://www.ftdichip.com/Drivers/VCP.htm. In many cases your
computer may already have this driver if you have ever used an FTDI
based USB2Serial device as many of them are based upon FTDI chips. These
drivers are installed for you with our free software keypad installer
available on our website.
If you are running Linux you can use the ftdi_sio driver. This should
automatically load when you connect the device if you are using a
relatively new distribution of Linux. For OSX and many other operating
systems the drivers can be found at http://www.ftdichip.com/FTDrivers.htm
Connecting to the Alarm Panel
The AD2 device requires all four keypad bus wires from the alarm panel
to be connected to operate correctly but only consumes ~30mA. Connect
all 4 of the keypad bus wires from the panel to your AD2 as shown. We
suggest you perform this connection while the alarm panel is powered
down and the battery is disconnected. When power is connected to the AD2
the LED indicator will flash a pattern indicating its state.
When ground isolation is required the AD2USB version offers 20kv ground
isolation between the host controller and the alarm panel.
(p4) (p1)

Connecting the AD2 to your host computer.
Connect the AD2 to a computer. If using the USB version You may see it install
some new hardware or give some indication that a new devices COM port was
attached. You can see this COM port under your device manager on windows or using
the dmesg command under Linux, OSX or other Unix based operating systems. If this
is a TTL Serial or RS232 version your port will be fixed on your host such as
/dev/ttyAMA0 on Raspberry Pi. Read the host documentation for the device path
details.
Once powered on and connected you can communicate with the device directly using
our free Alarmdecoder App for Linux, OSX and Windows and its Debug Log screen. You
can also use Putty, tinyserial: http://brokestream.com/tinyserial.html or the
'screen' command. For our Raspberry Pi Appliance you can also enable Ser2Sock
option and connect directly to the AD2 over a socket connection using telnet or
other terminal program. Connect using 115200,8,N,1#1 and press the = key
#2
to reset
the device and verify you can send data to the AD2 correctly.
Example AD2 Boot message.
!boot....................
!Ademco Keypad Emulator V2.2a.8.6
!Copyright (C) 2008-2015 Nu Tech Software Solutions, Inc.
!Reproduction without permission is prohibited
!By Sean Mathews <[email protected]>
!For support email [email protected]
!www.AlarmDecoder.com
!Reading configuration.
!UART init.
!Ready. Press ! for configuration.
#1 The AD2SERIAL Adapter operates at a different baud rate ( 19200,8,N,1 )
#2 Some terminal programs require sending a ENTER key. Set term to char mode.
Alarm Panel Programming
If you have an older SE based panel or DSC panel then addressing is not used and
it is not necessary to change any panel programming for the AD2 to operate. For SE
set the address to 31 and for DSC set the address to the partition and slot
number by default 11.
With other Ademco panels you will need to configure the alarm panel with the
address of the AD2 as a new keypad device. In Ademco address mode only one device
can be at a given address. See “Configuration your AlarmDecoder” section on how to
change this if you already have a device at the default address 18.
You can 1) call your security monitoring company and ask them to add in a new
keypad - (ask them what address they configured it to); or 2) if you know the
Installer Code, you can program it in yourself. You should reference the
Programming Guide and Installation and Setup Guide for your unit. (find these at
www.aesecurity.com/manuals.html)
Configuring Your AlarmDecoder
You may need to set the AD2 devices mode and address. By default the AD2
device is factory configured for Ademco mode at address 18. If you already have a
device at 18 or need to change to DSC mode you will need to change the AD2
settings.
To do this just press ! in your terminal program to configure the AD2. You can
press ENTER on any configuration options you a don’t want to change and it will
keep the current setting.
If you press * into your terminal program your panel should respond as if you
hit the same key on your alarms keypad. You will see a message from the AD2 such
as this “!Sending.done” if you see “!Sending.....done” and it appears to take a
long time for the send operation this probably means that the alarm panel is not
recognizing the AD2 or a device conflict exists. Confirm that the AD2 address for
Ademco and Partition for DSC is configured on the alarm panel. Also on Ademco make
sure no other devices exist at the same address on as the AD2.
The AD2 should display all messages from the alarm panel regardless of
programming of the panel provided the mode is set to the correct panel
type. If you are not seeing messages after connecting the AD2 to your
panel you either have a wiring issue, the AD2 is in the wrong mode for
your panel type or you have an SE panel and you have not set your AD2 to
address 31.
Example Message from DSC panel in programming mode.
[01111001000000000D--],064,[000200000000000000011000000000],"En er Sec ion --- "
Post installation
Sample code, example programs and our free KeyPad software as well as
the API documentation and more is available in the forums and
Documentation areas of our website: http://www.alarmdecoder.com/
We also now have available to purchase an alarm panel unlocker module
for the software keypad. This program when used with this device will
determine the master installer code and any other codes on the alarm
panel. Other modules are available as well as example code to write your
own module.
For questions and support email [email protected]. We try to
respond to emails in the same day that we get them.
DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC
COMPATIBILITY
We, Nu Tech Software Solutions, of 11575 SW Pacific Hwy #109, Tigard OR
97223, declare under our sole responsibility that the product:
AD2SERIAL,AD2PI,AD2USB to which this declaration relates: Complies with
Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference
that may cause undesired operation.
CE Declaration of Conformity
We, Nu Tech Software Solutions, declare under our sole responsibility
that the AD2SERIAL,AD2PI,AD2USB to which this declaration relates, is in
conformity with General Emissions Standard EN50081-1 and with Generic
Immunity Standard EN50082-1 1992.
(p2) (p3)
TRADEMARKS
Ademco is a registered trademark of Hone well International Inc.
DSC is a trademark of T co Safet Products Canada Ltd.
AlarmDecoder, AD2USB, AD2Serial, and AD2Pi are trademarks of Nu Tech Software Solutions, inc.
All brands or product names are the propert of the respective owners.
