Adexa SC1/1 User manual

Vacuum low temperature soft cooker user manual
1
(1)
Respected users:
Thank you very much for your support. Before installing and using this product, please read the
instruction manual carefully and your valuable suggestions on our products and after-sales service is
welcomed.
1.Method used
1. Remove all packaging and wipe the product body and food rack with a damp cloth；
2. Pack the food with the vacuum packaging machine and put them into the food rack (adjusted according
to the actual situation)；
3. Operate the ,according to the operation instructions (Figure two)；
4.After the food is finished, open the drainage valve on the left and remove the power plug；
2.Scope of application
Applicable to major shopping malls, restaurants and so on.

Vacuum low temperature soft cooker user manual
2
3.Product data list
Model
Voltage
Power
Size
SC1/1
AC 100~120V
700W
62.6X36X30cm
AC 220~240V
SC2/3
AC 100~120V
500W
45X36X30cm
AC 220~240V
4.Electrical schematic
5.Cleaning and maintenance
1.When cleaning and maintenance, the power should be cut off to prevent accidents.
2.After the work is finished every day, use a wet towel with a non-corrosive cleaner diluent to clean the
surface of the device and the power cord. Do not flush the surface directly with water to avoid damaging
the device's performance.
3.When not use for a long time, the machine should be cleaned and stored in a
well-ventilated,non-corrosive atmosphere.

Vacuum low temperature soft cooker user manual
Parameter: AC 220-240V 50Hz/60Hz; (Note: temperature accuracy is 0.1°C), real-time
temperature can not only display 21.0, there must be 0.1, 0.2, 0.3.....temperature
display last "C", like 21.0℃
Switch on：1. The digital screen is on along with the indicator light. The temperature display
shows the current temperature and the temperature of the last power-on setting.
(Real-time temperature display for 5 seconds, jump display setting temperature for 1
second, repeated cycle), 3 seconds later，the relay is pulled up after the clock starts
heating, and the buzzer “bee”a short sound;
2. The time display shows the time of the last setting, starts the countdown and enters
the standby state after the timer is completed, and the buzzer sounds three times;
3. Standby state: The switch light flashes. Both of the temperature screen and the time
screen flash to show the last set temperature and set time. The standby temperature
can be set to adjust the temperature and time.
Function key: switch temperature screen and time screen adjust model test per second , no
operation for 5 s, keep the new setting and start to work, buzzer "bee" a short sound;
Adjustment keys (+/-): Temperature: Click one time to adjust 0.1 ℃,Click for 3s to adjust 1℃,3s
later each time adjust 5 ℃.Temperature range :45.0°C-95.0°C;
Time:0.5h each within adjust 5mins;0.5h-2h per adjust 10mins;2h-10h per adjust0.5h;10h-99h per
adjust 1h;Time range:0-99h,0 is no operation,Click and long press are the same range.
Pump control:It take 5 min to begin working after press the switch.
Temperature
screen
function
(heat/time control)
+
Time screen
-
Switch
indicator light

Vacuum low temperature soft cooker user manual
Product Components ：
