ADJ BOOM BOX FX3 User manual

User Manual
BOOM BOX FX3

©2021 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying
product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection
claimed includes all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this document may be trade-
marks or registered trademarks of their respective companies and are hereby acknowledged. All
non-ADJ Products, LLC brands and product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as
a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and opera-
tion of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment. Please turn o all electrical products when
they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from power
when not in use. Thank you!
2
Date Document
Version
Software
Version DMX Channels Notes
07/24/2017 1.0 1.0 3 / 52 Ch Initial Release.
11/11/2021 1.1 N/C No Change Updated UC IR/Airstream Control.
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of
this document may be available online.
Please check www.adj.com for the latest revision/update of this manual
before beginning installation and/or programming.

TABLE OF CONTENTS
3
General Information 4
General Instructions | Features | Warranty Registration |
Handling Precautions 5
Safety Precautions 6
DMX Setup 7
Installation | Rear Layout 9
CAD Drawing 10
System Menu 11
Offset Menu 14
Operation 15
Primary-Secondary Setup | Power Cord Daisy Chain 16
UC IR/Airstream Control 17
DMX Traits 19
Fuse Replacement | Cleaning | Trouble Shooting 22
Limited Warranty (USA Only) 23
Specifications 24

4
Unpacking: Thank you for purchasing the Boom Box FX3 by ADJ Products, LLC. Every Boom Box
FX3 has been thoroughly tested and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during shipping. If the carton appears to be
damaged, carefully inspect your xture for any damage and be sure all equipment necessary to oper-
ate the unit has arrived intact. In the event that damage has been found or parts are missing, please
contact our toll free customer support number for further instructions. Please do not return this unit to
your dealer without contacting customer support rst.
Introduction: The Boom Box FX3 is a DMX intelligent LED moon-ower, matrix, & color ring/tunnel
eect xture. The Boom Box FX3 has 2 DMX channel modes: a 3 channel mode and 52 channel mode.
The xture can operate in as a stand alone xture or in a Primary/Secondary set up. The Boom Box
FX3 has three operating modes: sound active, show mode, and DMX Control. For best results use fog
or special eects smoke to enhance the beams projections.
Customer Support: Contact ADJ Service for any product related service and support needs. Also visit
forums.adj.com with questions, comments or suggestions.
Parts: To purchase parts online visit:
http://parts.adj.com (US)
http://www.adjparts.eu (EU)
ADJ SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
Voice: 800-322-6337 | Fax: [phone] | [email protected]
ADJ SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
Voice: [phone] | Fax: [phone] | [email protected]
ADJ PRODUCTS LLC USA
6122 S. Eastern Ave. Los Angeles, CA. 90040
323-582-2650 | Fax [phone] | www.adj.com | [e-mail]
ADJ SUPPLY Europe B.V
Junostraat 2 6468 EW Kerkrade, The Netherlands
[phone] | Fax [phone]
www.americandj.eu | [email protected]
ADJ PRODUCTS GROUP Mexico
AV Santa Ana 30 Parque Industrial Lerma, Lerma, Mexico 52000
[phone]
WARNING! TO PREVENT OR REDUCE THE RISK OF ELECTRICAL SHOCK OR FIRE, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION! THIS MAY CAUSE EYE DAMAGE. AVOID LOOKING DIRECTLY INTO THE LIGHT
SOURCE. USE SENSIBLE PRECAUTION.
GENERAL INFORMATION

5
GENERAL INSTRUCTIONS
To optimize the performance of this product, please read these operating instructions carefully to
familiarize yourself with the basic operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please keep this manual with the unit for
future reference.
FEATURES
• 2 DMX Channel Modes: 3 Channel and 52 Channel Modes
• 3 Operating Modes - Sound Active, Show Mode, & DMX Control
• Internal Microphone
• Digital Display for Address and Function Setting
• Power Cord Daisy Chain
• UC IR Compatible (Not Included) & Airstream IR Compatible (Transmitter Included)
WARRANTY REGISTRATION
The Boom Box FX3 carries a 1 Year limited warranty. Please fill out the enclosed warranty card to
validate your purchase and warranty. You may also register your product online at www.adj.com. All
returned service items, whether under warranty or not, must be freight pre-paid and accompanied
by a return authorization (R.A.) number. If the unit is under warranty you must provide a copy of your
proof of purchase invoice. Please contact ADJ customer support for an R.A. number.
HANDLING PRECAUTIONS
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, as
doing so will void your manufacturer’s warranty. In the unlikely event that your unit requires service,
please contact ADJ Products, LLC.
During operation the housing may become extremely hot. Avoid touching the unit with bare hands
while in use.
ADJ Products, LLC will not accept any liability for any resulting damages caused by the non-obser-
vance of this manual or any unauthorized modification to this unit.

6
SAFETY PRECAUTIONS
Safety Issues: This unit may “pop” the fuse if the maximum allotted load of 2 amps is reached.
• To reduce the risk of electrical shock or fire, do not expose this unit to rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to remove or break off the ground prong from the electrical cord. This prong is
used to reduce the risk of electrical shock and fire in case of an internal short. Do not attempt to
operate this unit if the power cord has been frayed or broken.
• Disconnect from main power before making any type of connection.
• Do not remove the cover for any reason. There are no user serviceable parts inside.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
(15cm) between this device and a wall.
• Do not attempt to operate this unit if it has been damaged in any way.
• This unit is intended for indoor use only. Use of this product outdoors voids all warranties.
• During long periods of non-use, disconnect the unit from main power.
• Always mount this unit in a safe and stable matter.
• Power cords should be routed so they are not likely to be walked on, or pinched by items placed
upon or against them.
• Cleaning - The fixture should be cleaned only as recommended by the manufacturer. See the
Cleaning section of this manual for cleaning details.
• Heat - The appliance should be situated away from heat sources such as radiators, heat regis-
ters, stoves, or other appliances (including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen onto, or liquid has been spilled into, the unit.
C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a marked change in performance.

7
DMX SETUP
Power Supply: The ADJ Boom Box FX3 contains an automatic voltage switch, which will automati-
cally sense the voltage when it is plugged into the power source. With this switch there is no need to
worry about the correct power voltage, and this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal protocol used by most lighting and
controller manufacturers as a form of communication between intelligent fixtures and controllers.
A DMX controller sends DMX data instructions from the controller to the fixture. DMX data is sent
as serial data that travels from fixture to fixture via the DATA “IN” and DATA “OUT” XLR terminals
located on all DMX fixtures (most controllers only have a DATA “OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of different manufacturers to be
linked together and operate from a single controller, as long as all fixtures and the controller are DMX
compliant. To ensure proper DMX data transmission, try to use the shortest cable path possible
when linking several DMX fixtures. The order in which fixtures are connected in a DMX line does not
influence the DMX addressing. For example, a fixture assigned a DMX address of 1 may be placed
anywhere in a DMX line: at the beginning, at the end, or anywhere in the middle. When a fixture is
assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that
unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX and Primary/Secondary Operation): The
Boom Box FX3 can be controlled via DMX-512 protocol. The Boom Box FX3 is has 2 DMX channel
modes: a 3 channel mode and a 52 channel mode. The DMX address is set electronically using the
controls on the back panel of the unit. Your unit and your DMX controller require an approved DMX-
512 110 Ohm Data cable for data input and data output (Figure 1). We recommend Accu-Cable DMX
cables. If you are making your own cables, be sure to use standard 110-120 Ohm shielded cable
(This cable may be purchased at almost all professional sound and lighting stores). Your cables
should be made with a male XLR connector on one end and a female XLR connector on the other.
Also remember that DMX cable must be daisy chained and cannot be split.

8
DMX SETUP
Notice: Be sure to follow figures two and three when making your own cables. Do not use the
ground lug on the XLR connector. Do not connect the cable’s shield conductor to the ground lug
or allow the shield conductor to come in contact with the XLR’s outer casing. Grounding the shield
could cause a short circuit and erratic behavior.
Special Note: Line Termination. When longer runs of cable are used, you may need to use a ter-
minator on the last unit to avoid erratic behavior. A terminator is a 110-120 ohm 1/4 watt resistor
which is connected between pins 2 and 3 of a male XLR connector (DATA + and DATA -). This unit is
inserted in the female XLR connector of the last unit in your daisy chain to terminate the line. Using a
cable terminator (ADJ part number Z-DMX/T) will decrease the possibilities of erratic behavior.
5-Pin XLR DMX Connectors. Some manufacturers use 5-pin XLR connectors for DATA transmis-
sion in place of 3-pin. 5-pin XLR fixtures may be implemented in a 3-pin XLR DMX line. When insert-
ing standard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be used. These adaptors
are readily available at most electric stores. The chart below details a proper cable conversion.

9
INSTALLATION
The unit should be mounted using a mounting clamp (not provided) and affixing it to the mounting
bracket that is provided with the unit. Always ensure that the unit is firmly fixed to avoid vibration
and slipping during operation. Always ensure that the structure to which you are attaching the unit is
secure and is able to support at least 10 times the unit’s weight. Also, always use a safety cable that
can hold 12 times the weight of the unit when installing the fixture. The equipment must be installed
by a professional, and it must be installed in a place where it is out of the reach of people’s grasp.
REAR LAYOUT
1. Function Display: Used to show the various menus and selected functions.
BUTTON
MENU To select the programming functions
UP To go forward in the selected functions
DOWN To go backward in the selected functions
ENTER To conrm the selected functions
LED ON
PRI Primary mode
SEC Secondary mode
SOUND
DMX
2. Power On/Off: To turn on/off the fixture.
3. DMX In/Out: For DMX512 links, use 3-pin XLR plug cable to link the units together.
4. Fuse (T2A): Protect the unit from damage due to over current.
5. Power In/Out: Used to connect to power supply or next fixture in the chain.

CAD DRAWING
10

SYSTEM MENU
11

12
SYSTEM MENU
System Menu: When making adjustments, press ENTER to confirm your setup, then press and
hold the MENU button for at least 3 seconds. To exit without making any adjustments, press
the MENU button. The display will lock after 30 seconds, and can be unlocked by pressing and
holding the MENU button for 3 seconds.
ADDR - DMX Address Setting.
1. Press the either the MENU, UP, or DOWN buttons until “ADDR” is displayed, then press ENTER.
2. The current address will now be displayed and flashing. Press the UP or DOWN buttons to find
your desired address. Press ENTER to set your desired DMX address.
CHND - This will let select your desired DMX channel mode.
1. Press the MENU button until “CHND” is displayed, then press ENTER. The current DMX channel
mode will be displayed.
2. Press the UP or DOWN buttons to find your desired DMX channel mode, then press ENTER to
confim and exit.
SECD - This will let you set unit as a primary or secondary in a primary/secondary configura-
tion.
1. Press the MENU button until “SECD” is displayed, then press ENTER. Either “PRI”, “SEC 1”, or
“SEC 2” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is displayed, and press ENTER to con-
firm.
NOTE: In a Primary-Secondary configuration, if one fixture is set to Primary and the next is set to
“SEC 2”, the fixtures will now have contrasting movement to each other.
SHND - Show modes 0-9 (Factory programs).
1. Press the MENU button until “SHND” is displayed, then press ENTER.
2. “Sh X” will now be displayed, “X” representing a number between 0-6. Shows 1-6 are factory
programs, while show “0” is random mode. Use the UP or DOWN buttons to find your desired
show.
3. When you have found your desired show, press ENTER, then press and hold the MENU button
for at least 3 seconds to activate. After you have set your desired show, it can be changed at any
time using the UP or DOWN buttons.
SOUN - Sound Active mode.
1. Press the MENU button until “SOUN” is displayed, then press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or DOWN buttons to select “ON” to
activate sound active mode, or “OFF” to deactivate sound active mode.
3. Press ENTER to confirm.
SENS - In this mode you can adjust the sound sensitivity.
1. Press the MENU button until “SENS” is displayed, then press ENTER.
2. A number between 0-100 will be displayed. Press the UP or DOWN buttons to adjust the sound
sensitivity. 0 is the least sensitive, and 100 is the most sensitive.
3. When you have found your desired setting, press ENTER to confirm.

13
SYSTEM MENU
DNST - This mode defines the behavior of the fixture in the event that DMX signal is lost or
interrupted, or if power is lost.
1. Press the MENU button until “DNST” is displayed, and either “MASL”, “BLND”, or “LAST” will be
displayed beneath.
2. Press ENTER and the bottom choice will begin to flash. Use the UP or DOWN buttons to choose
an operating mode you would like the unit to start up in when power is applied or the DMX signal
is lost.
• LAST - If the DMX signal is lost, the fixture will stay in the last DMX setting. If power is applied
and this mode is set, the unit will automatically go into the last DMX set up.
• PRI (Primary-Secondary) - If the DMX signal is lost or power is applied, the unit will automati-
cally go into Primary-Secondary mode and run a built-in show.
• BLAC (Blackout) - If the DMX signal is lost or interrupted, the unit will automatically go into
stand by mode.
3. Press ENTER to confirm your desired set up.
DISP - This function will reverse the display 180º.
1. Press the MENU button until “DISP” is displayed, and press ENTER.
2. Press ENTER to “flip” the display. Press ENTER to “flip” it again. Press ENTER when you have
made your desired setup.
LED - With this function, the LED display can be set to turn off after 10 seconds.
1. Press the MENU button until “LED” is displayed, then press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or DOWN buttons to select “ON” or
“OFF.” “ON” will keep the LED display on at all times, while “OFF” will turn the LED display off
after 10 seconds of inactivity.
TEST - This function will run a self test program.
1. Press the MENU button until “TEST” is displayed, then press ENTER.
2. The fixture will now run a self test.
FHRS - This function displays the running time of the unit.
1. Press the MENU button until “FHRS” is displayed, then press ENTER.
2. The running time of the fixture will now be displayed. Press MENU to exit.
VER - Use this function to display the Software version of the unit.
1. Press the the MENU button until “VER” is displayed, then press ENTER.
2. The display will show the software version.
RSET - This function will reset the unit.
1. Press the MENU button until “RSET” is displayed. Press the ENTER button and the unit will reset
itself.

14
OFFSET MENU
To enter the home position adjustment menu, press and hold the ENTER button for at least 5 sec-
onds. In this submenu you are able to adjust the original position of the beam and gobo motors and
laser motors.
oPAn - Adjustment of the beam motor.
1. Press and hold the ENTER button for at least 5 seconds, then press the UP or DOWN buttons so
that “oPAn” is displayed. Press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and then press ENTER to confirm.
Press the MENU button for one second to exit.

15
OPERATION
Universal DMX Control: This function allows you to use a universal DMX-512 controller to control
the matrix lights, moonflower rotation, strobing, and the visual ring colors. A DMX controller allows
you to create unique programs tailored to your individual needs.
• The Boom Box FX3 has 2 DMX channel modes: a 3-channel mode, and a 52-channel mode. See
the DMX Traits section of this manual for full details.
• To control your fixture in DMX mode, follow the set-up procedures described in the DMX Setup
section of this manual, as well as the set-up specifications that are included with your DMX con-
troller.
• Follow the instructions in the System Menu section of this manual to select your desired DMX
channel mode and set the DMX address.
• For longer cable runs (more than a 100 feet) use a terminator on the last fixture.
• For help operating in DMX mode consult the manual included with your DMX controller.
Sound Active Mode: This mode allows a single unit or several units linked together to run to the
beat of the music.
1. Press the MENU button until “Soun” is displayed, and press ENTER.
2. Press the UP or DOWN buttons to either activate or deactivate sound active mode, and press
ENTER. The unit will now run to the beat of the music.
3. The sound sensitivity can be adjusted by pressing the MENU button until “Sens” is displayed,
and then press ENTER. Use the UP or DOWN buttons to adjust the sound sensitivity, 0 being the
least sensitive, and 100 being the most sensitive.
Show Mode: This mode allows a single unit or several units linked together to run 1 of 9 built-in
shows.
1. Press the MENU button until “Shnd” is displayed, and press ENTER.
2. Press the UP or DOWN buttons to find your desired show and press ENTER. The unit will now
run your chosen built-in program.

PRIMARY-SECONDARY SET UP
16
This function will allow you to link up to 16 units together and operate without a controller. In a
Primary-Secondary set up, one unit will act as the controlling unit and the others will react to the
controlling unit’s programs. Any unit can act as a Primary or as a Secondary.
1. Using approved DMX data cables, daisy chain your units together via the XLR connectors on the
rear panels of the units. Remember that the Male XLR connector is the input and the Female XLR
connector is the output. The first unit in the chain (primary) will use the female XLR connector
only, and the last unit in the chain will use the male XLR connector only. For longer cable runs we
suggest using a terminator on the last fixture.
2. On the Primary unit, press the MENU button until “SECD” is displayed, and press ENTER. Use
the UP and DOWN buttons to scroll to the “PRI” setting, and press ENTER.
3. After setting the Primary unit, find and set your desired operating mode.
4. On the secondary units, press the MENU button until “SECD” is displayed, and press ENTER.
Choose either “SEC1” or “SEC2” and press ENTER. See the System Menu section of this man-
ual for more information.
5. The secondary units will now follow the primary unit.
POWER CORD DAISY CHAIN
With this feature you can connect the fixtures to one another using the IEC input and output sockets.
The maximum number of units that can be linked in this way is as follows:
• 8 fixtures maximum @ 120V
• 16 fixtures maximum @ 230V
After the maximum amount of fixtures has been reached, a new power outlet will need to be used to
accommodate any additional units. All fixtures must be of the same make and model type. DO NOT
mix fixtures.

17
UC IR/AIRSTREAM CONTROL
WIRELESS SETUP
There are many factors that can affect and/or interrupt a wireless signal, including walls, glass,
metal, objects, and people. Therefore, the following guidelines are recommended in order to maxi-
mize the chances of having a clear path for the wireless signal to reach the device:
• Install the device a minimum of 9.8 ft (3m) above audiences and/or ground level.
• Arrange the wireless antenna in an upright, vertical position.
• Position devices in direct line of sight of the transmitting controller.
Careful planning and testing of the selected installation location is critical to ensure optimum and
reliable wireless operation.
UC IR REMOTE
The unit should respond to commands issued from the UC IR Remote. NOTE: The unit can only
be controlled when it has been set to Primary mode. The unit will NOT respond to commands
when it has been set to Secondary mode.

18
UC IR/AIRSTREAM CONTROL
WIRELESS FUNCTIONS
The UC IR (sold separately) infrared remote gives you control of various functions (See below). To
control the fixture you must aim the remote at the front of the fixture and be no more than 30 feet
away.
The Boom Box FX3 is also compatible with the Airstream IR app. The IR transmitter is available
through any ADJ dealer or through the ADJ parts website. Plug the transmitter into the headphone
jack of your iOS phone or tablet. To control your IR fixture you must raise the volume to the maxi-
mum on your iOS phone or tablet, aim the transmitter at the front of the fixture, and be no more than
15 feet away. After you have purchased the Airstream IR transmitters, the app is a free download
from the app store for your iOS phone or tablet. The app comes with 3 pages of control depending
on the IR fixture you are using. Please see below for IR functions including the corresponding app
page.
Works with App page 1.
STAND BY - Pressing this button will blackout the fixture. Press the button again to return to the ini-
tial state.
FULL ON - Hold this button down to fully light up the unit. When the button is released, the unit will
return to its previous state.
STROBE - No defined function on this unit.
FADE/GOBO - Press this button and the press one of the numeral buttons to select your desired
show.
“DIMMER +” and “DIMMER -” - No defined function on this unit.
COLOR - Press this button and the press one of the numeral buttons to select your desired show.
1-9 - Use buttons 1-9 to select your desired show when show mode is activated.
SOUND ON & OFF - Use the buttons to activate and deactivate sound active mode.
SHOW 0 - Press this button to activate show 0 and show mode. Use buttons 1-9 to select your
desired show.

19
DMX TRAITS
CHANNEL DMX VALUE FUNCTION
3CH 52CH
1 000 - 255 Matrix Red LED 1, 0% to 100%
2 000 - 255 Matrix Green LED 1, 0% to 100%
3 000 - 255 Matrix Blue LED 1, 0% to 100%
4 000 - 255 Matrix Red LED 2, 0% to 100%
5 000 - 255 Matrix Green LED 2, 0% to 100%
6 000 - 255 Matrix Blue LED 2, 0% to 100%
7 000 - 255 Matrix Red LED 3, 0% to 100%
8 000 - 255 Matrix Green LED 3, 0% to 100%
9 000 - 255 Matrix Blue LED 3, 0% to 100%
10 000 - 255 Matrix Red LED 4, 0% to 100%
11 000 - 255 Matrix Green LED 4, 0% to 100%
12 000 - 255 Matrix Blue LED 4, 0% to 100%
13 000 - 255 Matrix Red LED 5, 0% to 100%
14 000 - 255 Matrix Green LED 5, 0% to 100%
15 000 - 255 Matrix Blue LED 5, 0% to 100%
16 000 - 255 Matrix Red LED 6, 0% to 100%
17 000 - 255 Matrix Green LED 6, 0% to 100%
18 000 - 255 Matrix Blue LED 6, 0% to 100%
19 000 - 255 Matrix Red LED 7, 0% to 100%
20 000 - 255 Matrix Green LED 7, 0% to 100%
21 000 - 255 Matrix Blue LED 7, 0% to 100%
22 000 - 255 Matrix Red LED 8, 0% to 100%
23 000 - 255 Matrix Green LED 8, 0% to 100%
24 000 - 255 Matrix Blue LED 8, 0% to 100%
25 000 - 255 Matrix Red LED 9, 0% to 100%
26 000 - 255 Matrix Green LED 9, 0% to 100%
27 000 - 255 Matrix Blue LED 9, 0% to 100%
28
Matrix Strobe
000 - 007 Close
008 - 015 Open
016 - 131 Strobing, slow to fast
132 - 139 Open
140 - 181 Fast Close, Slow Open
182 - 189 Open
190 - 231 Fast Open, Slow Close
CONTINUED ON NEXT PAGE

20
DMX TRAITS
CHANNEL DMX
VALUES FUNCTION
3CH 52CH
28
Matrix Strobe (continued)
232 - 239 Open
240 - 247 Random Strobing
248 - 255 Open
29 000 - 255 Matrix Master Dimmer, 0% to 100%
30 000 - 255 Beamer Red LED
31 000 - 255 Beamer Green LED
32 000 - 255 Beamer Blue LED
33 000 - 255 Beamer White LED
34
Beamer Strobe
000 - 007 Close
008 - 015 Open
016 - 131 Strobing, slow to fast
132 - 139 Open
140 - 181 Fast Close, Slow Open
182 - 189 Open
190 - 231 Fast Open, Slow Close
232 - 239 Open
240 - 247 Random Strobing
248 - 255 Open
35 000 - 255 Beamer Master Dimmer, 0% to 100%
36 000 - 255 Beamer Motor Movement
37 000 - 255 Beamer Motor Speed, slow to fast
38 000 - 255 1st Ring, Red LED, 0% to 100%
39 000 - 255 1st Ring, Green LED, 0% to 100%
40 000 - 255 1st Ring, Blue LED, 0% to 100%
41 000 - 255 2nd Ring, Red LED, 0% to 100%
42 000 - 255 2nd Ring, Green LED, 0% to 100%
43 000 - 255 2nd Ring, Blue LED, 0% to 100%
44 000 - 255 3rd Ring, Red LED, 0% to 100%
45 000 - 255 3rd Ring, Green LED, 0% to 100%
46 000 - 255 3rd Ring, Blue LED, 0% to 100%
47 000 - 255 4th Ring, Red LED, 0% to 100%
48 000 - 255 4th Ring, Green LED, 0% to 100%
49 000 - 255 4th Ring, Blue LED, 0% to 100%
CONTINUED ON NEXT PAGE
